Silicon Solar Isol-4x User manual

Isol‐4x
(SolarCellPhoneChargerw/Light)

①LED1
②LED2
③LED3
④LED4
⑤Micro‐USB(INPUT)
⑥SolarPanel
⑦USB‐A(OUTPUT)
⑧Button
⑨Hook
⑩LightPanel
ElectricalCharacteristics:
1. Solarpanel:0.44W
2. Li‐ionbattery:3.7WH
3. USBchargingcable:5.0V500mA
4. DCOutput:5.0V±5%500mA
5. Chargingtimeformobilephone:1‐1.5hours
6. ChargingmodeforinternalLithiumbatterybyUSBport:
advancedchargemanagementfeaturesinternalcircuitryforLi‐ionbatteryconstant
voltagesafety.

ProductFeatures:
Youcanchargefromsunlightviathesolarpaneloruseoursuppliedcabletochargethe
internalLi‐ionbatterybycomputer
AdaptorsformajorbrandphonessuchasNokia,Sony‐Ericsson,Samsung,Siemensand
Motorolaareprovided.Ifadaptorsdon’tmatchyourphone,pleasepurchasethemfrom
yourlocalmarket.
ThisappliancecanalsoprovidepowertootherdigitaldevicessuchasDigitalCameras,
PDAandPortableDVDplayers.
With4LEDstoshowchargingconditionorremainingpower
Canworksasportablecampinglightorwalllamp,justpushbutton2~3secondstoturn
on/offthelight.
Efficiency:>80%
OperatingInstructions
1. ChargingviaSolarpanel:
Ensurethesolarpanelisfacingthesun(LED1willbe 
red,whichconfirmstheinternalbatteryischarging).
2. ChargingbyusingtheUSBcable:
ConnectthechargerandPCbytheUSBchargingcable,theLED1,LED2,LED3,LED4will
turnonblueonebyoneduringthecharging.Whenall4LEDsarelighting,itmeansthe 
deviceisfullycharged.
3. Chargingyourdigitaldevices:
Selectacorrectconnectorforyourdevice,andconnectthechargeranddevicebyoutput
cableforcharging.Whenitisfullychargedthedevice,pleasepulloutthecablefromthe 
charger,LED1willturnoff.

4. Remainingpower:
PressthecentreButtonquickly:
A. OnlyLED1turnsonblue=10%‐25%power
available.
B. LED1andLED2turnonblue=26%‐50%power
available.
C. LED1andLED2andLED3turnonblue=51%‐
75%poweravailable.
D. AllLEDSturnonblue=76%‐100%poweravailable.
LEDSwillturnoffafterfewseconds.
Warning:
1. Keepthedeviceawayfromfire,waterandmoistplacesinordertoavoidexplosion,
leakage,moisture;
2. Anysevereshocktothechargerisnotrecommended;
3. Nooneexceptprofessionaltechniciansshouldattempttodisassemblethechargerin
ordertoavoiddamagingthecharger;
SpecialNote:
Pleasefullychargedevicebeforefirstuse;
Pleaseperformfullchargeanddischargeofthechargeratleastonceamonth;
Ifsunlightconditionsarenotidealchargingtimewilltakelongerthantheadvertised
time,thisisnormalforsolardevices.

Componentsincluded:
ChargingCable
OutputCable
Connectors
