Silvercrest SHBS 3.7 B1 User manual

HAIR & BEARD TRIMMER SHBS 3.7 B1
HAIR & BEARD TRIMMER
Operating instructions
TONDEUSE BARBE ET CHEVEUX
Mode d’emploi
ΚΟΥΡΕΥΤΙΚΗ ΜΗΧΑΝΗ ΓΙΑ
ΜΑΛΛΙΑ ΚΑΙ ΓΕΝΙΑ
Οδηγία χρήσης
HÅR- OG SKÆGTRIMMER
Betjeningsvejledning
HAAR- EN BAARDTRIMMER
Gebruiksaanwijzing
HAAR- UND BARTSCHNEIDER
Bedienungsanleitung
IAN 281952
CPE281952_Haartrimmer_LB6.indd 2 14.10.16 14:25

English.................................................... 2
Dansk................................................... 26
Français................................................ 48
Nederlands........................................... 76
ƧnjnjLjǎNJNjƽ ............................................ 102
Deutsch............................................... 128
ID: SHBS 3.7 B1_16_V1.3
__NAS281952_Haar_und_Bartschneider_5in1_B6.book Seite 1 Dienstag, 11. Oktober 2016 4:10 16

Overview / Oversigt / Aperçu de l'appareil /
Overzicht /
ƧǑNJǔNjǝǑLjǔLj / Übersicht
1
C
B
A
12
3
4
5
6
7
8
11
10
12
14
13
9
__NAS281952_Haar_und_Bartschneider_5in1_B6.book Seite 2 Dienstag, 11. Oktober 2016 4:10 16

2 GB
Contents
1. Overview ......................................................3
2. Intended purpose ...........................................5
3. Safety information ..........................................5
4. Items supplied .............................................10
5. Charging ....................................................11
6. Operation ...................................................12
6.1 Transport safety lock........................... 12
6.2 Changing the cutting attachments......... 12
6.3 Changing the comb attachments .......... 13
6.4 Cutting hair ....................................... 14
6.5 Trimming a beard............................... 15
6.6 Cutting a hairline................................ 16
6.7 Shaving............................................. 16
6.8 Trimming nose and ear hair................. 16
7. Cleaning and care .......................................17
8. Storage ......................................................19
9. Reordering parts ..........................................19
10. Disposal .....................................................20
11. Troubleshooting ...........................................21
12. Technical specifications ................................22
13. Warranty of HOYER Handel|GmbH ...............22
__NAS281952_Haar_und_Bartschneider_5in1_B6.book Seite 2 Dienstag, 11. Oktober 2016 4:10 16

3
GB
1. Overview
1Adjustable (3, 4, 5, 6 mm) comb attachment for the
beard trimmer attachment
2Comb attachments for the hair trimmer attachment 3,
6, 9, 12 mm
3Shaving attachment
4Precision trimmer attachment
5Hair and beard trimmer with connection for plug-in
power unit cable/battery charger
6Switch for cutting length fine tuning 1: 0.8 mm /
2:1.3mm/3:1.8mm
7On/off switch
8Battery symbol
is lit blue: device in operation
flashing blue during charging: battery is fully charged
flashes green 3 times: transport safety lock activated
9Plug symbol
Flashing red: battery almost empty
is lit red during charging: the battery is being charged
10 Power unit
11 Battery charger with charge contact
12 Nose/ear hair trimmer attachment
13 Hair trimmer attachment
14 Beard trimmer attachment
__NAS281952_Haar_und_Bartschneider_5in1_B6.book Seite 3 Dienstag, 11. Oktober 2016 4:10 16

4 GB
not shown:
15 Scissors
16 Blade oil
17 Cleaning brush
18 Comb
19 Storage bag (for the hair and beard trimmer and its
accessories)
Thank you for your trust!
Congratulations on your new 5in1 hair and beard trimmer.
For a safe handling of the device and in order to get to
know the entire scope of features:
• Thoroughly read these operating instructions
prior to initial commissioning.
• Above all, observe the safety instructions!
• The device should only be used as described
in these operating instructions.
• Keep these operating instructions for refer-
ence.
• If you pass the device on to someone else,
please include these operating instructions.
We hope you enjoy your new 5in1 hair and beard trimmer!
__NAS281952_Haar_und_Bartschneider_5in1_B6.book Seite 4 Dienstag, 11. Oktober 2016 4:10 16

5
GB
2. Intended purpose
The 5in1 hair and beard trimmer is intended exclusively for
trimming human hair. Only use the device for dry hair.
The device is designed for private home use and must not
be used for commercial purposes. The device must only be
used indoors.
Foreseeable misuse
WARNING! Risk of material damage!
Do not use the device to cut artificial hair or animal hair.
3. Safety information
Warnings
If necessary, the following warnings will be used in these
operating instructions:
DANGER! High risk: failure to observe this warn-
ing may result in injury to life and limb.
WARNING! Moderate risk: failure to observe this warn-
ing may result in injury or serious material damage.
CAUTION: low risk: failure to observe this warning may
result in minor injury or material damage.
NOTE: circumstances and specifics that must be observed
when handling the device.
__NAS281952_Haar_und_Bartschneider_5in1_B6.book Seite 5 Dienstag, 11. Oktober 2016 4:10 16

6 GB
Instructions for safe operation
~ This device can be used by children from
the age of 8 and people with restricted
physical, sensory or intellectual abilities or
people without adequate experience and/
or understanding, if they are supervised or
instructed on how to use this device safely
and if they are aware of the resulting dan-
ger. Children must not play with the de-
vice. Cleaning and maintenance by the
user must not be performed by children
without supervision.
~ Keep children under the age of 8 away
from the device and the power cable.
~ Only use the included original power
adaptor for mains operation.
~WARNING! Keep the device dry.
DANGER for children
~Packing materials are not children's toys. Children
should not be allowed to play with the plastic bags:
There is a risk of suffocation!
~Keep the device out of the reach of children.
DANGER to and from pets and
livestock
~Electrical devices can represent a hazard to pets and
livestock. In addition, animals can also cause damage
__NAS281952_Haar_und_Bartschneider_5in1_B6.book Seite 6 Dienstag, 11. Oktober 2016 4:10 16

7
GB
to the device. For this reason you should keep animals
away from electrical devices at all times.
DANGER! Risk of electric shock due to
moisture
~Protect the device from moisture, water drops and wa-
ter splashes.
~Never touch the device with wet hands.
~The device, the battery charger and the power unit
must not fall into water or other liquids and must not be
rinsed under running water.
~If the device has fallen into water, pull out the power
unit immediately, and only then remove the device
from the water. Do not use the device again, but have
this checked by a specialist.
~Should liquid enter the device, have it checked before
starting the device up again.
~If the device is used in a bathroom, the power unit must
be pulled out after use, as the proximity of water repre-
sents a hazard, even when the device is switched off.
~Installation of a residual current device (FI/RCD) with a
rated residual operating current of no more than
30|mA is recommended to provide additional protec-
tion. Ask your electrician for advice. The installation
should only be carried out by a qualified electrician.
DANGER! Risk of electric shock
~Never put the device into operation if there are visible
damages to the device, the battery charger or the ca-
ble or if the device has been dropped before.
~Connect the cable to the device/battery charger be-
fore plugging the power unit into a wall socket.
__NAS281952_Haar_und_Bartschneider_5in1_B6.book Seite 7 Dienstag, 11. Oktober 2016 4:10 16

8 GB
~Only connect the power unit to a properly installed,
easily accessible wall socket, the voltage of which cor-
responds to the specifications on the rating plate. The
wall socket must continue to be easily accessible after
the device is plugged in.
~Ensure that the cable cannot be damaged by sharp
edges or hot surfaces.
~Ensure that the cable is not trapped or crushed.
~When removing the power unit from the wall socket,
always pull the power unit and never the cable.
~Pull the power unit out of the wall socket, …
… after every use,
… after each charging process,
… if there is a fault,
… before connecting the device to the cable,
… before you clean the device and
… during thunderstorms.
~To avoid any risk, do not make modifications to the de-
vice. Repairs must be carried out by a specialist work-
shop or the Service Centre.
DANGER from batteries
~Protect the battery against mechanical damages. Fire
hazard!
~Do not expose the device to direct sunshine or heat.
The ambient temperature should not be lower than
-10 °C and higher than +40 °C.
~The charge contacts on the device must not be connect-
ed by metallic objects.
~The
battery may only be charged with the original ac-
cessory (power unit).
__NAS281952_Haar_und_Bartschneider_5in1_B6.book Seite 8 Dienstag, 11. Oktober 2016 4:10 16

9
GB
WARNING! Risk of injury from cutting
~The points of the comb attachments, the hair trimmer
attachment, the beard trimmer attachment and the pre-
cision trimmer attachment are sharp. Handle with care.
~Do not use the device if the attachment shows damag-
es.
~Switch off the device before pinning up or changing
the attachments and each time before cleaning.
WARNING! Risk of injury
~Place the cable in such a way that no one trips over it
or steps on it.
~Do not push the nose/ear hair trimmer attachment too
deep into the nostril or the ear canal.
~Do not use the device on open wounds, cuts, sunburn
or blisters.
WARNING! Risk of material damage
~ The battery charger is fitted with non-slip silicon feet. As
furniture is coated with a variety of different varnishes
and acrylics and treated with different cleaning agents,
we cannot rule out that some of these substances could
damage and soften the rubber feet. If necessary, place a
non-slip mat under the battery charger.
~Use the original accessories only.
~Never place the device on hot surfaces (e.g. hob
plates) or near heat sources or open fire.
~Do not cover the power unit to prevent overheating.
~Do not exert too much pressure on the shaving foil of
the shaving attachment, to avoid damaging the shav-
ing foil.
~Do not detach the shaving foil from the shaving foil
frame, and do not clean it using the brush.
~Do not use any astringent or abrasive cleaning agents.
__NAS281952_Haar_und_Bartschneider_5in1_B6.book Seite 9 Dienstag, 11. Oktober 2016 4:10 16

10 GB
4. Items supplied
15in1 hair and beard trimmer|5
1Powerunit|10
1Battery charger|11
5Interchangeable cutting attachments:
hair trimmer attachment|13
beard trimmer attachment|14
precision trimmer attachment|4
nose/ear hair trimmer attachment|12
shaving attachment|3
4Comb attachments|2for the hair trimmer attachment 3,
6, 9, 12 mm
1Adjustable (3, 4, 5, 6 mm) comb attachment|1for the
beard trimmer attachment|14
1Comb|18
1Scissors|15
1Cleaning brush|17
1Blade oil|16
1Storage bag (for the hair and beard trimmer and its ac-
cessories)|19
1Operating Instructions
__NAS281952_Haar_und_Bartschneider_5in1_B6.book Seite 10 Dienstag, 11. Oktober 2016 4:10 16

11
GB
5. Charging
NOTES:
• Before first use (without cable), and for every charging
procedure afterwards, charge the hair and beard trim-
mer|5for approx. 90 minutes.
• When the batteries are almost empty, the plug sym-
bol|9flashes in red. The device can then only be used
for a short time without being connected to the electric-
ity supply.
1. Place the battery charger|11 on a level surface.
2. Connect the power unit|10 to the battery charger|11.
3. Switch off the device with the on/off switch|7if neces-
sary.
4. Insert the power unit|10 into a readily accessible wall
socket whose voltage matches the voltage stated on
the rating plate.
5. Put the hair and beard trimmer|5into the battery
charger|11.
6. The plug symbol|9is lit red and the battery is
charged. When the battery is fully charged, the bat-
tery symbol|8flashes in blue. When the battery is ful-
ly charged, the device can be used for approximately
60 minutes without being connected to the power sup-
ply.
__NAS281952_Haar_und_Bartschneider_5in1_B6.book Seite 11 Dienstag, 11. Oktober 2016 4:10 16

12 GB
6. Operation
Regardless of the charging state of the battery, the 5in1 hair
and beard trimmer can always be mains-operated.
1. For mains operation, ensure that the hair and beard
trimmer|5is switched off.
2. Connect the power unit|10 to the connector of the
hair and beard trimmer|5.
3. Insert the power unit|10 into a readily accessible wall
socket whose voltage matches the voltage stated on
the rating plate.
4. Switch on the device with the on/off switch|7.
6.1 Transport safety lock
When the transport safety lock is activated, the battery sym-
bol|8flashes green 3 times.
• Press and hold the on/off switch|7for approx. 3 sec-
onds to activate/deactivate the transport safety lock.
• By connecting the power unit|10, the transport safety
lock is deactivated, and also cannot be activated while
plugged in to the power supply.
6.2 Changing the cutting attachments
WARNING! Risk of injury!
Switch off the hair and beard trimmer|5 , before you attach
or remove the attachments.
•Figure A: to remove the attachments|13,|3,|4,|12,
14 use your thumbs to press the attachment towards
the rear of the hair and beard trimmer|5.
__NAS281952_Haar_und_Bartschneider_5in1_B6.book Seite 12 Dienstag, 11. Oktober 2016 4:10 16

13
GB
•Figure B: to attach the attachments, put the lower flap
of the attachment|13,|3,|4,|12,|14 into the slot in the
hair and beard trimmer|5and press the upper part of
the attachment against the hair and beard trimmer until
it audibly locks into place and sits firmly in position.
6.3 Changing the comb attachments
Pushing on
• To attach the comb attachments|2+|1carefully slide
the appropriate comb attachment over the hair or
beard trimmer attachment|13 /|14. Press the lower
part of the comb attachments|2firmly until they lock
into place.
Removing
• To remove the comb attachments|2loosen the comb at-
tachment at its lower end and pull it off the hair and
beard trimmer|5.
• Slide the comb attachment|1for the beard trimmer at-
tachment|14 upwards from the hair and beard trim-
mer|5.
__NAS281952_Haar_und_Bartschneider_5in1_B6.book Seite 13 Dienstag, 11. Oktober 2016 4:10 16

14 GB
6.4 Cutting hair
Hair trimmer attachment| 13
NOTES:
• The hair to be dressed must be dry.
• The cutting length may deviate depending on the cut-
ting angle.
• Place a sheet or cape around throat and neck to pre-
vent cut-off hair from dropping into the collar.
• Comb the hair well.
• First, start with a comb attachment|2with a longer cut-
ting length and then, in the course of the cutting pro-
cess, use shorter cutting lengths step by step.
• Start by cutting the hair in the neck or on the sides and
cut towards the centre of the head. Then, cut the front
section of the hair towards the centre of the head.
• Hold the hair and beard trimmer|5in such a way that
the comb attachment|2lies as flat as possible on the
head. Move the device evenly through the hair.
• If possible, cut against direction of hair growth.
• In order to catch all the hair, move the hair and beard
trimmer|5several times through each section of the
hair.
• Comb the hair repeatedly and well.
• In order to achieve a straight cutting line for cutting
lengths over 12 mm, the hair and beard trimmer|5
should be passed through the hair several times from
different directions.
__NAS281952_Haar_und_Bartschneider_5in1_B6.book Seite 14 Dienstag, 11. Oktober 2016 4:10 16

15
GB
6.5 Trimming a beard
Beard trimmer attachment| 14
NOTE: please note that the cutting lengths will only be
achieved if the switch for cutting length fine tuning|6is at
position 1and the hair and beard trimmer|5is held at a
right angle to the skin surface.
• Comb the beard in the direction that it grows.
• Trim the beard downwards from ear to chin. First trim
one side, then the other.
•Comb attachment|1
Figure C: adjust the cutting length with the slider ac-
cording to the desired hair length and read off the cut-
ting length using the marking on the side of the comb
attachment|1(3, 4, 5, 6 mm). Now, shorten your
beard step-by-step.
• Use the beard trimmer attachment|14 without a comb
attachment|1, to cut the beard very short or to cut a
moustache and hairline.
• Using the switch for cutting length fine tuning| 6 the cut-
ting length can be slightly varied with three levels
(
1 : 0.8 mm / 2 : 1.3 mm / 3 : 1.8 mm).
• To trim your moustache, first comb it straight down-
wards. Then use either the beard trimmer attach-
ment|14 or the precision trimmer attachment|4. Start
at the centre above the mouth and trim first one side,
then the other.
__NAS281952_Haar_und_Bartschneider_5in1_B6.book Seite 15 Dienstag, 11. Oktober 2016 4:10 16

16 GB
6.6 Cutting a hairline
Precision trimmer attachment| 4
• Use the precision trimmer attachment|4to shorten and
shape moustaches, whiskers, sideburns or eyebrows.
• Put the edge of the attachment at the desired hairline
height and move the hair and beard trimmer|5down-
wards.
6.7 Shaving
Shaving attachment| 3
NOTE: your skin must be clean and dry.
• Hold the hair and beard trimmer|5at a right angle to
the skin surface and gently guide it over your face.
• Shave against the direction of your beard growth.
• Stretch your skin in complicated areas, such as the
chin, to achieve better results.
6.8 Trimming nose and ear hair
Nose/ear hair trimmer attachment| 12
• Insert only the metal tip slowly into a nostril or an ear.
• Slowly move the hair and beard trimmer|5with a cir-
cular motion to trim the hair.
__NAS281952_Haar_und_Bartschneider_5in1_B6.book Seite 16 Dienstag, 11. Oktober 2016 4:10 16

17
GB
7. Cleaning and care
DANGER! Risk of electric shock!
Unplug the power unit|10 from the wall socket before
cleaning the hair and beard trimmer|5and the battery
charger|11.
WARNING! Risk of injury!
Always switch the hair and beard trimmer|5off before
cleaning.
WARNING! Risk of material damage!
Do not use any astringent or abrasive cleaning agents.
NOTE: clean and oil the device after every use.
Hair and beard trimmer| 5 and battery
charger|
11
• Wipe the casing of the hair and beard trimmer and the
battery charger with a damp cloth.
Comb attachments| 2 ,| 1
• Remove the comb attachment. Rinse the comb attach-
ment with water and let it dry before using it again.
Hair trimmer, beard trimmer and precision
trimmer attachments|
13 ,| 14 ,| 4
1. Figure A: remove the attachment from the hair and
beard trimmer|5by pressing it with the thumb towards
the rear.
2. Remove the hair remnants from the attachment using
the cleaning brush|17 included in the delivery.
__NAS281952_Haar_und_Bartschneider_5in1_B6.book Seite 17 Dienstag, 11. Oktober 2016 4:10 16

18 GB
3. Apply a few drops of blade oil|16 to the cutting edge
of the attachment. Using a soft cloth, wipe off the sur-
plus oil, if necessary. Only use acid-free oil, such as
e.g. sewing machine oil.
Nose/ear hair trimmer attachment| 12
• Remove the nose/ear hair trimmer attachment|12.
Rinse it with water and let it dry completely before us-
ing it again.
Shaving attachment| 3
WARNING!
Do not detach the shaving foil from the shaving foil frame,
and do not clean it using the cleaning brush|17.
NOTE: from time to time, oil the cutting blade with a few
drops of acid-free oil (e.g. sewing machine oil). Attach the
shaving attachmentto the hairand beard trimmer|5and let
it run for a few seconds without using it. Using a soft cloth,
wipe off the surplus oil, if necessary.
1. Remove the shaving attachment|3.
2. Press the button on the side of the shaving attachment
and remove the shaving foil frame. While removing
the shaving foil frame, only hold it at the side and do
not press against the shaving foil.
3. Clean the cutting blade using the included cleaning
brush|17.
4. Clean the shaving foil in the shaving foil frame under
running water and allow it to dry completely before
putting it back on the shaving attachment|3.
__NAS281952_Haar_und_Bartschneider_5in1_B6.book Seite 18 Dienstag, 11. Oktober 2016 4:10 16
