Silvercrest SKHT 1.5 A1 User manual

HOYER Handel GmbH Tasköprüstraße 3 DE-22761 Hamburg DEUTSCHLAND Status of information · Informationernes stand Stand van de informatie · Stand der Informationen:
BODY HAIR TRIMMER SKHT 1.5 A1
KÖRPERHAARTRIMMER Bedienungsanleitung
DE
AT CH
IAN 288903 IAN 288903
12/2017 ID: SKHT 1.5 A1_17_V1.2
DK
NL
DE
GB
IE
NI
BODYTRIMMER Gebruiksaanwijzing
NL
BODY HAIR TRIMMER Operating instructions
GB
IE
NI
KROPSHÅRTRIMMER Betjeningsvejledning
DK
GB
IE NI
DK
NL
B6_288903_Koerperhaartrimmer_U1U4.fm Seite 1 Mittwoch, 13. Dezember 2017 1:10 13

English.................................................... 2
Dansk................................................... 22
Nederlands........................................... 42
Deutsch ................................................ 62
__288903_Koerperhaartrimmer_B6.book Seite 2 Dienstag, 12. Dezember 2017 12:15 12

Overview / Oversigt / Overzicht / Übersicht
9
13
7
6
8
5
1
2
3
4
5
6
7
8
9
10
11
12
A B C
D E F
1
1
1/9 10/11
10/11
__288903_Koerperhaartrimmer_B6.book Seite 3 Dienstag, 12. Dezember 2017 12:15 12

2 GB
Contents
1. Overview ................................................. 3
2. Intended purpose ..................................... 5
3. Safety instructions .................................... 5
4. Items supplied ......................................... 8
5. Inserting/replacing the battery ................. 9
6. Operation .............................................. 10
6.1 Replacing the blade head......................... 10
6.2 Changing attachments for the trimmer
head ......................................................10
6.3 Trimming................................................ 11
6.4 Shaving.................................................. 12
7. Cleaning and maintenance of the device 13
8. Storage .................................................. 15
9. Disposal ................................................. 15
10.Troubleshooting ..................................... 16
11.Technical specifications ........................... 17
12.Warranty of the HOYER Handel|GmbH ... 18
__288903_Koerperhaartrimmer_B6.book Seite 2 Dienstag, 12. Dezember 2017 12:15 12

3
GB
1. Overview
1Blade head: trimmer head
2Lock (for trimmer head/shaver head)
3On/off switch
4Battery compartment lock
5Battery compartment cover
6Shaving foil
7Shaving foil frame
8Release buttons
9Blade head: shaver head
10 3|mm attachment for trimmer head
11 0.5|mm attachment for trimmer head
12 Battery (type LR6, AA, 1.5 V)
13 Cutter block
not shown: Protective cap for the shaver head
Cleaning brush
__288903_Koerperhaartrimmer_B6.book Seite 3 Dienstag, 12. Dezember 2017 12:15 12

4 GB
Thank you for your trust!
Congratulations on your new body hair trimmer.
For a safe handling of the device and in order to get to know the entire
scope of features:
• Thoroughly read these user instructions prior to initial
use.
• Above all, observe the safety instructions!
• The device should only be used as described in these
user instructions.
• Keep these user instructions for reference.
• If you pass the device on to someone else, please in-
clude this copy of the user instructions. The user instruc-
tions are a part of the product.
We hope you enjoy your new body hair trimmer!
Symbols on your appliance
This symbol indicates that the appliance is suitable for use in the
shower or bath. It may be cleaned under running water.
GB_288903_Koerperhaartrimmer_.fm Seite 4 Mittwoch, 13. Dezember 2017 1:19 13

5
GB
2. Intended purpose
The body hair trimmer is intended exclusively for cutting human body hair
(not including the head, neck and face).
The device is designed for private, domestic use. The device must only be
used indoors.
This device must not be used for commercial purposes.
Foreseeable misuse
WARNING! Risk of material damage!
~Do not use the device to cut artificial hair or animal hair.
NOTE: Do not use the device for cutting head hair or beard hair. You will
not achieve a satisfactory result.
3. Safety instructions
Warnings
If necessary, the following warnings will be used in these user instruc-
tions: DANGER! High risk:failure to observe this warning may result
in injury to life and limb.
WARNING! Moderate risk: failure to observe this warning may result in
injury or serious material damage.
CAUTION: low risk: failure to observe this warning may result in minor
injury or material damage.
NOTE: circumstances and specifics that must be observed when han-
dling the device.
__288903_Koerperhaartrimmer_B6.book Seite 5 Dienstag, 12. Dezember 2017 12:15 12

6 GB
Instructions for safe operation
~This device can be used by children from the
age of 8 and people with restricted physical,
sensory or intellectual abilities or people with-
out adequate experience and/or understand-
ing, if they are supervised or instructed on
how to use this device safely and if they are
aware of the resulting hazards. Children must
not play with the device. Cleaning and main-
tenance by the user must not be performed
by children without supervision.
~
This device may be used by children aged
3 years or above with adult supervision.
DANGER for children
~ Children must not play with packing material. Do not allow children to
play with plastic bags. There is a risk of suffocation.
~Keep the device out of the reach of children.
DANGER to and from pets and livestock
~Electrical devices can represent a hazard to pets and livestock. In
addition, animals can also cause damage to the device. For this rea-
son you should keep animals away from electrical devices at all
times.
DANGER from batteries
~Be sure to observe the polarity (+/-) when inserting the batteries.
~Only use the battery type specified in the technical data.
__288903_Koerperhaartrimmer_B6.book Seite 6 Dienstag, 12. Dezember 2017 12:15 12

7
GB
~ The battery included must not be charged or reactivated by other means,
neither must it be dismantled, thrown into a fire or short-circuited.
~Always remove used batteries immediately, as these could leak and
therefore cause damage. Always dispose of the old batteries ac-
cording to regulations.
~Remove the battery if the device is not going to be used for an ex-
tended period of time.
~Do not subject batteries to extreme conditions, e.g. do not place the
device on radiators or in direct sunlight. Otherwise, there is an in-
creased danger of batteries leaking. The ambient temperature
should not be lower than 0 °C or higher than +40 °C.
~If battery acid has leaked, avoid contact with the skin, eyes and mu-
cous membranes. In case of contact with the acid, rinse the affected
area at once with plenty of clean water and seek medical assistance
immediately.
WARNING! Risk of injury
~Never use the trimmer head|1without attachment|10/11.
~Do not use the device if parts are damaged.
~Do not use the device on open wounds, cuts, sunburn or blisters.
WARNING! Risk of material damage
~Do not apply excessive pressure on the shaving foil|6of the shaver
head|9. It is thin and can easily be damaged.
~Only use the cleaning brush for cleaning the cutter block|13. Under
no circumstances should it be used to clean the shaving foil|6. Bris-
tles could get caught in the shaving foil and damage it.
~To avoid any risk, do not make modifications to the device. Repairs
must be carried out by a specialist workshop or the Service Centre.
~Use the original accessories only.
~Never place the device on hot surfaces (e.g. hot plates) or near heat
sources or open fire.
~Do not use any astringent or abrasive cleaning agents.
NOTE on hygiene
• For hygienic reasons the device should only be used by one person.
__288903_Koerperhaartrimmer_B6.book Seite 7 Dienstag, 12. Dezember 2017 12:15 12

8 GB
4. Items supplied
1 body hair trimmer with trimmer head|1
1 shaver head|9
13|mm attachment for trimmer head|10
10.5|mm attachment for trimmer head| 11
1 battery (type LR6, AA, 1.5 V)|12
1 protective cap for the shaver head
1cleaningbrush
1 copy of the user instructions
__288903_Koerperhaartrimmer_B6.book Seite 8 Dienstag, 12. Dezember 2017 12:15 12

9
GB
5. Inserting/replacing the battery
DANGER from batteries!
~Be sure to observe the polarity (+/–) when inserting the batteries.
~Only use the battery type specified in the technical data.
~Always remove used batteries immediately, as these could leak and
therefore cause damage. Always dispose of the old batteries ac-
cording to regulations.
~Remove the battery if the device is not going to be used for an ex-
tended period of time.
NOTE: When the motor of the device becomes slower and the cutting
performance deteriorates, replace the battery.
1. Switch off the device with the on/off switch|3if necessary.
2. Figure B: rotate the battery compartment cover|5so that the arrow
of the battery compartment lock|4points to the open lock symbol .
3. Remove the battery compartment cover|5.
4. Remove the empty battery|12, if appropriate, and dispose of it in
an environmentally friendly manner.
5. Insert the new battery (type LR6, AA, 1.5 V)|12 into the battery
compartment with the (+)-pole first, corresponding to the marking on
the battery compartment.
6. Replace the battery compartment cover|5so that the arrow of the
battery compartment lock|4points to the open lock symbol .
7. Applying light pressure, rotate the battery compartment cover|5so
that the arrow points to the closed lock symbol .
__288903_Koerperhaartrimmer_B6.book Seite 9 Dienstag, 12. Dezember 2017 12:15 12

10 GB
6. Operation
6.1 Replacing the blade head
The device is supplied with two different blade heads:
• The trimmer head|1is used with two different attachments for trim-
ming body hair to 3|mm (using the 3|mm attachment|10) or 0.5|mm
(using the 0.5|mm attachment|11).
• The shaver head|9is used for smooth shaving of body hair.
1. Switch off the device with the on/off switch|3if necessary.
2. Figure A: rotate the trimmer head|1/ shaver head|9so that the ar-
row of the lock|2points to the open lock symbol .
3. Remove the trimmer head|1/ shaver head|9.
4. Place the desired blade head (trimmer head|1or shaver head|9) so
that the arrow points to the open lock symbol .
5. Rotate the blade head (1/9) so that the arrow points to the closed
lock symbol .
6.2 Changing attachments for the trimmer
head
WARNING! Risk of injury!
~Never use the trimmer head|1without attachment|10/11.
~Do not use the device if parts are damaged.
•Usethe3|mm attachment|10 to trim hair to a length of 3|mm, or as
a preparation for longer hair (longer than 20mm).
•Usingthe0.5|mm attachment|11, you achieve a hair length of ap-
prox. 0.5|mm.
1. Figure C: remove any attachment|10/11 currently in place by
gripping it from the sides and carefully pulling it off the trimmer
head|1.
__288903_Koerperhaartrimmer_B6.book Seite 10 Dienstag, 12. Dezember 2017 12:15 12

11
GB
2. Figure D: place the desired attachment|10/11 onto the trimmer
head|1in such a way that the two arrows on the attachment|10/
11 and trimmer head|1point at one another, and carefully press
the attachment|10/11 down until it clicks into place.
6.3 Trimming
WARNING! Risk of injury!
~Do not use the device if parts are damaged.
~Do not use the device on open wounds, cuts, sunburn or blisters.
NOTES:
• The device can be used on either dry or wet skin. You will achieve
the best results if the hair is dry when trimmed.
• Stretch sensitive areas of skin during trimming.
• Do not apply strong pressure.
1. Place the trimmer head|1onto the device.
2. Switch on the device with the on/off switch|3.
3. Figure E: move the trimmer head|1with the attachment|10/11 flat
against the skin, always holding the device at a 45° angle. Move
the device slowly against the direction of hair growth. You can move
the device in both directions (forwards and backwards).
4. Press the on/off switch|3again to switch the device off again.
__288903_Koerperhaartrimmer_B6.book Seite 11 Dienstag, 12. Dezember 2017 12:15 12

12 GB
6.4 Shaving
WARNING! Risk of injury!
~Do not use the device if parts are damaged.
~Do not use the device on open wounds, cuts, sunburn or blisters.
WARNING! Risk of material damage!
~Do not apply excessive pressure on the shaving foil|6of the shaver
head|9. It is thin and can easily be damaged.
NOTES:
• The device is suitable for both dry and wet shaving. You will achieve
the best results with dry hair.
• For wet shaving, never use additional products such as shaving
foam or soap lather, shaving gel or shaving cream. You will impair
the result, and may clog the shaver head|9.
• Stretch sensitive areas of skin during shaving.
• Initial use may cause temporary irritation or redness of the skin, as
the skin has to adjust to shaving. This is normal and usually lasts be-
tween 2 to 4 weeks.
1. Place the shaver head|9onto the device.
2. Switch on the device with the on/off switch|3.
3. Hold the shaver head|9at a right angle to the skin surface and
guide it over your skin without pressure. Move the device slowly
against the direction of hair growth. You can move the device in
both directions (forwards and backwards).
4. Press the on/off switch|3again to switch the device off again.
__288903_Koerperhaartrimmer_B6.book Seite 12 Dienstag, 12. Dezember 2017 12:15 12

13
GB
7. Cleaning and maintenance of the
device
WARNING! Risk of material damage!
~Do not use any astringent or abrasive cleaning agents.
NOTE: To ensure good cutting performance and prevent pinching, the
device must be cleaned and maintained regularly.
Cleaning the trimmer head
1. Switch off the device with the on/off switch|3if necessary.
2. Remove any attachment|10/11 currently in place.
3. Clean the trimmer head|1and the attachments|10/11 using the
cleaning brush supplied.
4. Rinse the trimmer head|1and the attachments|10/11 under clean
running water.
5. Allow all parts to dry completely before reassembling them and put-
ting them away.
Oiling the trimmer head
Oil the trimmer head|1...
… if you feel pinching during trimming, or if the trimming performance
deteriorates.
… depending on the intensity of use, but generally after 6 months at
the latest.
1. Switch off the device with the on/off switch|3if necessary.
2. Remove any attachment|10/11 currently in place.
3. Apply a drop of sewing machine oil to the cleaned blades of the
trimmer head|1.
4. Switch on the device with the on/off switch|3in order to spread the
oil around.
__288903_Koerperhaartrimmer_B6.book Seite 13 Dienstag, 12. Dezember 2017 12:15 12

14 GB
Cleaning the shaver head
WARNING! Risk of material damage!
~Do not apply excessive pressure on the shaving foil|6of the shaver
head|9. It is thin and can easily be damaged.
~Only use the cleaning brush for cleaning the cutter block. Under no
circumstances should it be used to clean the shaving foil|6. Bristles
could get caught in the shaving foil and damage it.
1. Switch off the device with the on/off switch|3if necessary.
2. Figure F: press both release buttons|8and carefully take off the
shaving foil frame|7.
3. Tap the shaving foil frame|7carefully.
4. Clean the cutter block|13 using the cleaning brush supplied.
5. Rinse the cutter block|13 and the shaving foil frame|7under clean
running water.
6. Allow all parts to dry completely before reassembling them and put-
ting them away.
NOTE: It is not necessary to oil the shaver head|9.
__288903_Koerperhaartrimmer_B6.book Seite 14 Dienstag, 12. Dezember 2017 12:15 12

15
GB
8. Storage
DANGER!
~Keep the device out of the reach of children.
• If you are not going to use the device for an extended period, re-
move the battery|12.
• Store the device in a location protected against dust and extreme
conditions, e.g. without direct sunlight, in an ambient temperature
between 0 °C and +40 °C.
9. Disposal
This product is subject to the provisions of European Di-
rective 2012/19/EC. The symbol showing a wheelie
bin crossed through indicates that the product requires
separate refuse collection in the European Union. This
applies to the product and all accessories marked with
this symbol. Products identified with this symbol may not
be discarded with normal household waste, but must be taken to a col-
lection point for recycling electric and electronic appliances. Recycling
helps to reduce the consumption of raw materials and protect the environ-
ment.
Batteries must not be discarded with your household
waste. Spent batteries must be disposed of properly.
Special containers are available for this purpose in
shops selling batteries and at municipal collection
points.
(Rechargeable) batteries marked with the following let-
ters contain harmful substances such as: Cd (cadmium), Hg (mercury),
Pb|(lead).
__288903_Koerperhaartrimmer_B6.book Seite 15 Dienstag, 12. Dezember 2017 12:15 12

16 GB
Packaging
When disposing of the packaging, make sure you comply with the envi-
ronmental regulations applicable in your country.
10. Troubleshooting
If your device fails to function as required, please try this checklist first.
Perhaps there is only a minor problem, and you can solve it yourself.
WARNING! Risk of material damage!
~Do not attempt to repair the device yourself under any circumstanc-
es.
Fault Possible causes / Action
No function • Is the battery|12 empty?
The device is louder
than usual, vibrates
more strongly or
becomes hot.
• Do the blade head|1/9 and attach-
ment|10/11 need to be cleaned?
• Is a part defective? In this case, do not use
the device.
Cutting performance is
deteriorating.
• Do the blade head|1/9 and attach-
ment|10/11 need to be cleaned?
• Is the attachment|10/11 mounted correct-
ly?
• Is the battery|12 almost empty?
• Does the trimmer head|1need to be
oiled?
• Is the skin damp? You will achieve better
cutting performance with dry skin.
__288903_Koerperhaartrimmer_B6.book Seite 16 Dienstag, 12. Dezember 2017 12:15 12

17
GB
11. Technical specifications
Technical Symbols
Subject to technical modifications.
Model: SKHT 1.5 A1
Protection type: IPX7
(protected against the effects of tem-
porary immersion)
Battery:
1x 1.5 V (type LR6, AA)
Ambient conditions: only approved for indoor use
Operation and storage tempera-
ture: 0 °C to +40 °C
With the CE marking, HOYER Handel GmbH declares the
conformity with EU guidelines.
This symbol reminds you to dispose of the packaging in an
environmentally friendly manner.
Recyclable materials: cardboard (except corrugated card-
board)
__288903_Koerperhaartrimmer_B6.book Seite 17 Dienstag, 12. Dezember 2017 12:15 12

18 GB
12.Warranty of the
HOYER Handel|GmbH
Dear Customer,
your device is provided with a 3 year warranty starting with the purchase
date. In the event of product defects, you are entitled to statutory rights
against the vendor. These statutory rights are not restricted by our war-
ranty presented in the following.
Warranty conditions
The warranty period starts with the purchase date. Please keep the origi-
nal purchase receipt in a safe place. This document is required to verify
the purchase.
If within three years from the purchase date of this product a material or
factory defect occurs, the product will be repaired or replaced by us – at
our discretion – free of charge to you. This warranty implies that within
the period of three years the defective device and the purchase receipt
are presented, including a brief written description of the defect and the
time it occurred.
If the defect is covered by our warranty, the repaired or a new product
will be returned to you. No new warranty period starts with a repair or
replacement of the product.
Warranty period and statutory claims for defects
The warranty period is not extended when the warranty has been
claimed. This also applies to replaced and repaired parts. Any damages
and defects already existing at the time of purchase must be reported im-
mediately upon unpacking. Repairs arising after the expiration of the
warranty period are subject to a charge.
Warranty coverage
The device was produced carefully according to strict quality guidelines
and tested diligently prior to delivery.
The warranty applies to material or factory defects.
Excluded from the warranty are wear parts subject to nor-
mal wear and damages to fragile parts, e.g. switches, bat-
teries, lamps or other parts manufactured from glass.
__288903_Koerperhaartrimmer_B6.book Seite 18 Dienstag, 12. Dezember 2017 12:15 12
