Warnings and symbols used
The following warnings are used in this user manual and on the packaging:
DANGER! This symbol in combination
with the signal word “Danger” marks
a high-risk hazard that if not prevented
could result in death or serious injury.
NOTE: This symbol in combination
with “Note” provides additional useful
information.
WARNING! This symbol in combination
with the signal word “Warning” marks a
medium-risk hazard that if not prevented
could result in death or serious injury.
Danger – Risk of electric shock!
CAUTION! This symbol in combination
with the signal word “Caution” marks a
low-risk hazard that if not prevented could
result in minor or moderate injury.
Only use the product in dry indoor rooms.
Do not put fingers through the grille.
CE mark indicates conformity with
relevant EU directives applicable for this
product.
UKCA mark indicates conformity with
relevant Great Britain regulations
applicable for this product (The UKCA
mark logo is valid in Great Britain only).
PEDESTAL FAN
Introduction
We congratulate you on the purchase of your new
product. You have chosen a high quality product.
The instructions for use are part of the product. They
contain important information concerning safety,
use and disposal. Before using the product, please
familiarise yourself with all of the safety information
and instructions for use. Only use the product as
described and for the specified applications. If you
pass the product on to anyone else, please ensure
that you also pass on all the documentation with it.
Intended use
This product is intended to produce a cooling airflow.
Any other use not mentioned in these instructions may
cause a damage to the product or create a serious
risk of injury.
This product is only intended for private household
use, not for commercial purposes.
The manufacturer accepts no liability for damages
caused by improper use.

7GB/IE/NI
Scope of delivery
Unpack the product. Remove the transport locks,
if any.
After unpacking the product, check if all parts
are complete and in good condition. Remove
all packing materials (including protective foils)
before use.
1 Motor unit (with speed buttons, grille lock nut
and lock screw)
2 Cross base (with screws)
1 Blade lock nut
1 Extension pole and lower pole (with height
adjustment lock and pole cover)
1 Front grille (with lock nut and lock screw)
1 Rear grille
1Blade
NOTE: Various removable components are
delivered pre-assembled (see “Description of
parts”).
Description of parts
Before reading, unfold the page containing the
illustrations and familiarise yourself with all the
functions of the product.
Fig. A
[1] Front grille
[2] Blade lock nut
[3] Blade
[4] Grille lock nut
[5] Rear grille
[6] Motor unit
[] Motor shaft
[7] Oscillation control knob
[8] Speed button panel (0, 1, 2, 3)
[9] Lock screw
[] Extension pole
[] Height adjustment lock
[] Lower pole
[] Pole cover
[] Cross base
[] *Screw for cross base (M6x14mm) (x4)
[] *Lock screw and lock nut
[] Power cord with power plug
*pre-assembled
Technical data
Input voltage: 220–240 V~~, 50–60 Hz
Power consumption: 45 W
Description Symbol Value Unit
Maximum fan
flow rate F 62.03 m3/min
Fan power input P 38.9 W
Service value SV 1.59 (m3/min)/W
Standby power
consumption PSB 0.0 W
Fan sound power
level LWA 53.75 dB(A)
Maximum air
velocity C2.7 meters/sec
Measurement
standard for
service value
IEC 60879:1986 (corr. 1992)
Contact details
for obtaining
more information
OWIM GmbH & Co. KG
Stiftsbergstraße 1
74167 Neckarsulm
GERMANY
www.owim.com

8 GB/IE/NI
Safety instructions
BEFORE USING THE PRODUCT,
PLEASE FAMILIARISE
YOURSELF WITH ALL OF THE
SAFETY INFORMATION AND
INSTRUCTIONS FOR USE! WHEN
PASSING THIS PRODUCT ON TO
OTHERS, PLEASE ALSO INCLUDE
ALL THE DOCUMENTS!
In the case of damage resulting
from non-compliance with these
operating instructions the warranty
claim becomes invalid! No liability is
accepted for consequential damage!
In the case of material damage or
personal injury caused by incorrect
handling or non-compliance with
the safety instructions, no liability is
accepted!
Children and persons with
disabilities
mDANGER! Risk of
suffocation! Never leave
children unsupervised with the
packaging material.
The packaging material
represents a danger of
suffocation. Children frequently
underestimate the dangers.
Always keep children away from
the packaging material.
This product can be used by
children aged from 8 years and
above and persons with reduced
physical, sensory or mental
capabilities, or lack of experience
and knowledge if they have been
given supervision or instruction
concerning use of the product in
a safe way and understand the
hazards involved.
Cleaning and user maintenance
shall not be made by children
without supervision.
Children shall not play with the
product.
Electrical safety
mWARNING! Risk of injury!
Switch the product off and
disconnect it from the power
supply before cleaning work and
when not in use.

9GB/IE/NI
mWARNING! Risk of electric
shock! Ensure the rated voltage
shown on the rating label
corresponds with the voltage of
the power supply.
mWARNING! Risk of electric
shock! If the supply cord is
damaged, it must be replaced by
the manufacturer, its service agent
or similarly qualified persons in
order to avoid a hazard.
Operation
Only use the product in dry
indoor rooms.
Protect the product, its power
cord and power plug against
dust, direct sunlight, dripping and
splashing water.
mCAUTION! Risk of injury!
Ensure that the fan is switched
off from the supply mains before
removing the guard.
mCAUTION! Risk of injury!
Never use the product without the
safety grille or with a damaged
safety grille.
mCAUTION! Risk of injury!
During use, keep hands, hair,
clothing and utensils away from
the safety grille to avoid injuries
and damage of the product.

10 GB/IE/NI
Before use
Unpacking
Remove the packaging. Check if the product is
damaged.
Assembly
Accessory needed: Cross head screwdriver
Number of persons needed for assembly: 1 adult
Fig. Step
B
1. Remove the 4lock screws[] from the
cross base[].
2. Place both parts of the cross base[] on
the floor so they resemble the shape of a
cross.
C
1. Remove the pole cover[] from the lower
pole[].
2. Loosen the height adjustment lock[] on
the extension pole[].
3. Pull out the extension pole[].
D
1. Place the lower pole[] on the cross
base[].
2. Tighten with the 4lock screws[].
E
1. Insert the pole cover[] into the lower
pole[] until it hits the bottom.
2. Tighten the height adjustment lock[] at
the desired height.
F
1. Remove the grille lock nut[4] from the
motor unit[6].
2. Attach the rear grille[5] to the motor
unit[6].
3. Tighten with the grille lock nut[4].
G1. Place the blade[3] on the motor shaft[].
2. Tighten with the blade lock nut[2].
Fig. Step
H
1. Open the 4grille clips on the front
grille[1].
2. Remove the lock screw and the lock
nut[] from the front grille[1].
3. Hang the hanger of the front grille[1] on
the rear grille[5].
4. Insert the lock screw[]. Fasten the lock
nut[]. Close the 4grille clips at the grille
frame.
NOTE: The 4grille clips must fit over the
frame of the rear grille[5].
I
1. Place the motor unit [6] with speed button
panel[8] on the extension pole[].
2. Align the hole on the back side.
3. Tighten with the lock screw[9].
Height adjustment
Loosen the height adjustment lock [] (positioned
on the extension pole []) in a counter-clockwise
direction.
Adjust the length of the extension pole [].
Tighten the height adjustment lock [] in a
clockwise direction.
Tilt adjustment
Adjust the tilt angle manually.
Do not perform the tilt adjustment when the
product is in operation.
NOTE: Do not remove the lock screw[9] when
adjusting the tilt angle.

11GB/IE/NI
Operation
Place the product on a flat, stable ground.
Connect the power plug [] to a suitable
socket-outlet.
Fan speed
Press the speed button panel [8] to turn the
product on/off and to select the fan speed
setting:
Position Function
0Off
1Low fan speed
2Medium fan speed
3Maximum fan speed
Oscillation
Adjust the oscillation control knob [7]:
Knob position Oscillation during
operation
Pulled out Off
Pushed in On
Cleaning and care
Before cleaning: Press 0on the speed button
panel [8]. Disconnect the power plug [] from
the socket-outlet.
Clean the product with a slightly moistened cloth.
Do not allow any water or other liquids to enter
the motor unit [6].
Do not remove the front grille[1] nor the rear
grille[5] under any circumstances.
Clean the front grille[1] and the rear grille[5]
with a vacuum cleaner and a slightly moistened
cloth only.
mWARNING! Do not immerse the electrical parts
of the product in water or other liquids. Never
hold the product under running water.
Storage
When not in use, store the product in its original
packaging.
Store the product in a dry, secure location away
from children.
Disposal
The packaging is made entirely of recyclable
materials, which you may dispose of at local
recycling facilities.
Observe the marking of the packaging
materials for waste separation, which
are marked with abbreviations (a) and
numbers (b) with following meaning: 1–7:
plastics / 20–22: paper and fibreboard /
80–98: composite materials.
The product and packaging materials are
recyclable, dispose of it separately for
better waste treatment.
The Triman logo is valid in France only.
Contact your local refuse disposal
authority for more details of how to
dispose of your worn-out product.
To help protect the environment, please
dispose of the product properly when it
has reached the end of its useful life and
not in the household waste. Information on
collection points and their opening hours
can be obtained from your local authority.

12 GB/IE/NI
Warranty
The product has been manufactured to strict quality
guidelines and meticulously examined before
delivery. In the event of product defects you have
legal rights against the retailer of this product.
Your legal rights are not limited in any way by our
warranty detailed below.
The warranty for this product is 3 years from the date
of purchase. The warranty period begins on the date
of purchase. Please keep the original sales receipt
in a safe location. This document is required as your
proof of purchase.
Should this product show any fault in materials
or manufacture within 3 years from the date of
purchase, we will repair or replace it – at our
choice – free of charge to you. This warranty
becomes void if the product has been damaged, or
used or maintained improperly.
The warranty applies to defects in material
or manufacture. This warranty does not cover
product parts subject to normal wear, thus possibly
considered consumables (e.g. batteries) or for
damage to fragile parts, e.g. switches, rechargeable
batteries or glass parts.
Warranty claim procedure
To ensure quick processing of your case, please
observe the following instructions:
Please have the till receipt and the item number
(IAN 393751_2107) available as proof of
purchase.
You will find the item number on the rating plate, an
engraving, on the front page of the instructions for
use (bottom left), or as a sticker on the rear or bottom
of the product.
If functional or other defects occur, please contact
the service department listed either by telephone or
by e-mail.
You can return a defective product to us free of
charge to the service address that will be provided
to you. Ensure that you enclose the proof of purchase
(till receipt) and information about what the defect is
and when it occurred.
Service
Service Great Britain
Tel.: [phone]
E-Mail: [email protected]
Service Ireland
Tel.: [phone]
Service Northern Ireland
Tel.: [phone]
E-Mail: [email protected]

IAN 393751_2107
OWIM GmbH &Co. KG
Stiftsbergstraße 1
74167 Neckarsulm
GERMANY
Model No.: HG07988-BS
Version: 02/2022
