Silvercrest SHLF 2000 D1 User manual

143 mm 138 mm
IAN 323104_1901
FAN HEATER SHLF 2000 D1
FAN HEATER
Operation and safety notes
This product is only suitable for well insulated
spaces or occasional use.
VÄRMEFLÄKT
Bruksanvisning och säkerhetsanvisningar
Denna produkt är endast avsedd för väl isolerade
utrymmen eller för enstaka bruk.
TERMOWENTYLATOR
Wskazówki dotyczące obsługi i bezpieczeństwa
Ten produkt nadaje się tylko do dobrze izolowa-
nych pomieszczeń lub do sporadycznego użytku.
ŠILDYTUVAS
Naudojimo ir saugos pastabos
Šis produktas skirtas tik gerai izoliuotoms
patalpoms arba nenuolatiniam naudojimui.
HEIZLÜFTER
Bedienungs- und Sicherheitshinweise
Dieses Produkt ist nur für gut isolierte Räume oder
für den gelegentlichen Gebrauch geeignet.

138 mm
GB Operation and safety notes Page 5
SE Bruksanvisning och säkerhetsanvisningar Sidan 19
PL Wskazówki dotyczące obsługi i bezpieczeństwa Strona 33
LT Naudojimo ir saugos pastabos Psl 47
DE/AT/CH Bedienungs- und Sicherheitshinweise Seite 61

143 mm138 mm
A
11
B
1 2 543 87
10
13
9
16
15
17
18
14
12
19
6

138 mm
D
C
21
20
25
26
23
22
24

5GB
Warnings and symbols used ............................................. Page 6
Introduction ................................................................ Page 6
Intended use.................................................................. Page 6
Scope of delivery.............................................................. Page 7
Description of parts ............................................................ Page 7
Technical data ................................................................ Page 7
Safety instructions......................................................... Page 7
Safety instructions for batteries / rechargeable batteries........... Page 12
Before first use ............................................................. Page 13
Operation................................................................... Page 13
Turning on the product .......................................................... Page 13
Turning off the product .......................................................... Page 13
Control panel ................................................................. Page 13
Selecting an operating mode..................................................... Page 14
Setting the desired temperature ................................................... Page 14
Swivel function ................................................................ Page 14
Timer ....................................................................... Page 14
Replacing the battery........................................................... Page 15
Transport ................................................................... Page 15
Cleaning and care ......................................................... Page 15
Storage ..................................................................... Page 15
Disposal..................................................................... Page 15
Warranty ................................................................... Page 16
Information requirements for electric local space heaters........... Page 17

6 GB
Warnings and symbols used
The following warnings are used in this user manual and on the packaging:
DANGER! This symbol in combination
with the signal word “Danger” marks a
high-risk hazard that if not prevented could
result in death or serious injury.
Voltage (alternating current)
Hertz (supply frequency)
Watt
WARNING! This symbol in combination
with the signal word “Warning” marks a
medium-risk hazard that if not prevented
could result in death or serious injury.
Danger – risk of electric shock!
NOTE: This symbol in combination
with “Note” provides additional useful
information.
CAUTION! This symbol in combination
with the signal word “Caution” marks a
low-risk hazard that if not prevented could
result in minor or moderate injury.
Symbol for a Protection Class II product.
WARNING! Do not cover the product to
prevent it from overheating.
CAUTION.
Hot surface!
The frost protection function prevents the
room temperature from dropping below
freezing.
FAN HEATER
Introduction
We congratulate you on the purchase of your new
product. You have chosen a high quality product.
The instructions for use are part of the product. They
contain important information concerning safety,
use and disposal. Before using the product, please
familiarise yourself with all of the safety information
and instructions for use. Only use the product as
described and for the specified applications. If you
pass the product on to anyone else, please ensure
that you also pass on all the documentation with it.
Intended use
The product can be used for short-term heating of
rooms. It can also be used as a fan with the heating
function turned off.
The product is designed for household use; it is not
suitable for commercial use.
The manufacturer accepts no liability for damages
caused by improper use.

7GB
Scope of delivery
After unpacking the product, make sure that the
product is in orderly condition. Remove all packaging
materials before use.
1x Fan heater
1x Remote control with battery (type CR2025)
1x Instruction manual
Description of parts
Before reading, unfold the page containing the
illustrations and familiarise yourself with all the
functions of the product.
1Control panel
2Air outlet safety guard
3button
4button
5button
6Display (LCD)
7button
8button
9button
10
Infrared receiver
11
Control lamp
12
Base
13
Anti-tip switch (bottom of product)
14
Handle
15
Storage compartment for remote control
16
Air inlet safety guard
17
Temperature sensor
18
On/off switch
19
Power cord with power plug
20
Remote control
21
Battery compartment
22
indicator (swivel function)
23
Operating mode indicator
24
/ Timer indicator
25
Room temperature display
26
Desired target temperature display
Technical data
Input: 220–240 V~, 50 Hz
Protection class: II/
Power consumption
Level : 1000 W
Level : 2000 W
Remote control
Battery: 1x 3 V, CR2025
TÜV SÜD / GS-certified
Safety instructions
BEFORE USING THE PRODUCT,
PLEASE FAMILIARISE
YOURSELF WITH ALL OF THE
SAFETY INFORMATION AND
INSTRUCTIONS FOR USE! WHEN
PASSING THIS PRODUCT ON TO
OTHERS, PLEASE ALSO INCLUDE
ALL THE DOCUMENTS!
In the case of damage resulting
from non-compliance with these
operating instructions the warranty
claim becomes invalid! No liability is
accepted for consequential damage!
In the case of material damage or
personal injury caused by incorrect
handling or non-compliance with
the safety instructions, no liability is
accepted!

8 GB
Children and persons with
limitations
mWARNING! DANGER
OF DEATH AND ACCI-
DENTS FOR TODDLERS
AND CHILDREN!
Never leave children unsupervised
with the packaging material. The
packaging material represents a
danger of suffocation. Children
frequently underestimate the
dangers.
Children of less than 3 years
should be kept away unless
continuously supervised.
Children aged from 3 years and
less than 8 years shall only switch
on/off the product provided that
it has been placed or installed
in its intended normal operating
position and they have been
given supervision or instruction
concerning use of the product in
a safe way and understand the
hazards involved.
Children aged from 3 years and
less than 8 years shall not plug in,
regulate and clean the product or
perform user maintenance.
This product can be used by
children aged from 8 years and
above and persons with reduced
physical, sensory or mental
capabilities or lack of experience
and knowledge if they have been
given supervision or instruction
concerning use of the product in
a safe way and understand the
hazards involved.
Children shall not play with the
product.
Cleaning and user maintenance
shall not be made by children
without supervision.
m DANGER! Risk of electric
shock! Never attempt to repair
the product yourself. In case of
malfunction, repairs are to be
conducted by qualified personnel
only.
m WARNING! Risk of electric
shock! Do not immerse the
product’s electrical components in
water or other liquids. Never hold
the product under running water.

9GB
m CAUTION! Risk of electric
shock! Do not use the product if
it is damaged. Disconnect it from
the power supply and contact
your retailer in the event of
damage.
m WARNING! Risk of injury!
Turn off the product and
disconnect it from the power
supply before cleaning and when
the product is not in use.
m WARNING! Improper use may
result in personal injury. Use the
product only as described in the
user manual. Never attempt to
alter the product in any way.
Setup instructions
The product must not be located
immediately below a socket-
outlet.
Do not use this product in the
immediate surroundings of a
bath, a shower or a swimming
pool.
Always operate the product on
an even, stable, clean, heat-
resistant and dry surface.
Use the product in dry indoor
rooms only.
Fire/burn hazard and heat
m CAUTION! Some parts of
this product can become very
hot and cause burns. Particular
attention has to be given where
children and vulnerable people
are present.
WARNING! In order
to avoid overheating,
do not cover the
product.
m CAUTION! Fire hazard!
Do not cover the product’s air
vents. Make sure the product has
sufficient ventilation. Do not place
the product in a cabinet.
Do not operate the product
near flammable materials such
as curtains, furniture or other
flammable materials.
Keep the product at least
100 cm away from other objects
(curtains, walls, etc.).
Regularly remove dust and filth
with a soft, dry cloth.

10 GB
Before use, always check the
air filter for debris and dust. An
unclean air filter prevents air from
flowing through. This may result in
the product overheating.
Remove from the product’s
heating area all firm, liquid and
gaseous materials that might
ignite.
Never insert any fingers or
foreign objects into the product’s
openings.
NEVER touch the heating
elements with your hands.
If you notice any smoke or
unusual noises, immediately
disconnect the product from the
power supply. Have the product
checked by a specialist before
continued use.
In the event of a fire, first pull
the plug from the power outlet
or disconnect the product from
the power supply before taking
appropriate firefighting measures.
Never leave the product
unattended while it is in use.
m CAUTION! Fire hazard!
This product is not intended to
be operated by means of an
external timer or separate remote-
control system. The product may
be switched on, for example even
when it is covered.
Do not move the product while it
is in operation or cooling down.
Do not use the product anymore
if it has been dropped.
Electrical safety
The product complies
with protection class II.
It has reinforced
insulation and therefore does not
require protective grounding.
The product may not remain
unattended as long as it is
connected to the power supply.
Make sure that the nominal
voltage on the rating plate
complies with the supply voltage.
The product has increased energy
consumption. Do not connect any
other devices (e.g. heaters, air
conditioners, etc.) to the same
circuit.

11GB
The use of extension cords is not
recommended. If the use of an
extension cord is necessary, it
must be designed for a current
flow of at least 10 A.
Shield the product, power cord
and plug from dust, direct sunlight
and dripping and splashing
water.
Protect the product from heat. Do
not place the product in direct
proximity to open flames or heat
sources such as heaters, ovens or
stoves.
Protect the power cord from
damage. Do not allow it to hang
over sharp corners; do not crush
or bend it. Keep the power cord
away from any hot surfaces and
open flames. Make sure that no
one may accidentally pull on it or
trip over it.
Regularly check power plug and
power cord for damages.
Do not operate the product if the
power cord or power plug are
damaged, if the product does not
work or is damaged in any way.
If the supply cord is damaged,
it must be replaced by the
manufacturer, its service agent
or similarly qualified persons in
order to avoid a hazard.
Do not operate the product with
wet hands or while standing on a
wet floor. Do not touch the power
plug with wet hands.
Always turn off the product
before disconnecting it from the
power supply.
Do not unplug the product by
pulling on the power cord. Do not
wrap the power cord around the
product.
Cleaning and storage
Disconnect the product from the
wall outlet during periods of
disuse and before cleaning.

12 GB
Instructions on cleaning the
product: see “Cleaning and
care”.
Store the product in a cool, dry
place protected from sunlight and
out of the reach of children.
Safety instructions
for batteries /
rechargeable batteries
DANGER TO LIFE! Keep
batteries / rechargeable batteries
out of reach of children. If
accidentally swallowed seek
immediate medical attention.
DANGER OF
EXPLOSION! Never
recharge non-rechargeable
batteries. Do not short-circuit
batteries / rechargeable
batteries and / or open them.
Overheating, fire or bursting
can be the result.
Never throw batteries /
rechargeable batteries into fire or
water.
Do not exert mechanical loads
to batteries / rechargeable
batteries.
Risk of leakage of batteries /
rechargeable batteries
Avoid extreme environmental
conditions and temperatures,
which could affect batteries /
rechargeable batteries, e.g.
radiators / direct sunlight.
If batteries / rechargeable
batteries have leaked, avoid
contact with skin, eyes and
mucous membranes with the
chemicals! Flush immediately the
affected areas with fresh water
and seek medical attention!
WEAR PROTECTIVE
GLOVES! Leaked or
damaged batteries /
rechargeable batteries can
cause burns on contact
with the skin. Wear suitable
protective gloves at all times if
such an event occurs.
In the event of a leakage
of batteries / rechargeable
batteries, immediately remove
them from the product to prevent
damage.
Remove batteries / rechargeable
batteries if the product will not be
used for a longer period.

13GB
Risk of damage of the
product
Only use the specified type of
battery / rechargeable battery!
Insert batteries / rechargeable
batteries according to polarity
marks (+) and (–) on the
battery / rechargeable battery
and the product.
Clean the contacts on the
battery / rechargeable battery
and in the battery compartment
before inserting!
Remove exhausted batteries /
rechargeable batteries from the
product immediately.
Before first use
Remove the packing materials.
Check the product for any damages.
Pull the insulating strip from the battery
compartment
21
.
NOTE: The product may give off some vapours
or odours during first use. These are production
or transport residue that will quickly subside.
There may also be quiet noises such as clicking
or crackling. These will also quickly subside
once the plastic parts have finally adjusted to the
operating conditions.
Operation
NOTES:
The product is equipped with a tilt protection
switch
13
at the bottom of the product. The
product shuts down automatically if it falls over or
if it is lying on its side.
The product cannot be turned on if it is not
standing securely and the tilt protection switch
13
is not pressed.
Turning on the product
Connect the power plug
19
to a suitable power
outlet.
Activating the standby mode: Set the on/off
switch
18
to I. A short beep sounds. The display
6shows the room temperature 25
. 0:00
flashes.
Turning on the product: Press 8. The product
switches to fan mode.
NOTE: When the product is in operation, the
control lamp
11
is lit.
Turning off the product
Switching to standby mode: Press 8.
NOTE: The fan continues to run for about
another 2 seconds. Afterwards, the product turns
off and the control lamp
11
goes out.
Turning off the product fully: Set the on/off switch
18
to 0.
Control panel
Press the buttons on the control panel 1or use
the remote control
20
to make settings:
NOTE: In standby mode, no settings can be
made. First, switch on the product by pressing
8.
Button Setting
3Timer
4Swivel function
5Operating mode
7Increase value
8Standby/operation
9Decrease value

14 GB
Selecting an operating mode
Switching the mode: Press 5. The
corresponding operating mode indicator
23
is
shown in the display 6:
Display Operating mode
Fan
In fan mode, no heating level is
activated.
Half heating level
50 % heating power
Full heating level
100 % heating power
Automatic heating level
The product automatically adjusts
the heating level to the ambient
temperature.
Frost protection
At room temperature under +6 °C,
the product turns on automatically.
The product heats the room until the
temperature exceeds +12 °C.
At a temperature of +12 °C, the
product turns off automatically.
NOTE: Whether heating level or is the
appropriate selection, depends on the room size.
We recommend first operating the product on
heating level .. Switch to heating level if the
heat output on heating level is not sufficient.
Setting the desired temperature
NOTES:
The temperature values are displayed in Celsius
(°C).
The target temperature
26
and the room
temperature
25
are shown in the display 6.
Select a heating operating mode ( , or )
with 5.
Set the desired temperature
26
with 7and
9.
As soon as the room temperature
25
reaches the
set target temperature
26
, the product switches
off automatically.
The product automatically switches back on
again as soon as the room temperature
25
falls
below the set target temperature
26
. In active
heating operation, the control lamp
11
is lit.
Swivel function
The built-in swivel function allows the product to
swivel to the left and right. The air flow is thereby
evenly distributed in the room.
Turning the swivel function on/off: Press 4.
When the swivel function is active,
22
is
shown in the display 6.
Timer
The timer turns off the product automatically after a
preset time elapses.
Setting the timer: During operation, press 3.
The hour display starts flashing.
Set the hours with 7and 9.
Press 3to confirm.
The minute display starts flashing.
Set the minutes with 7and 9.
Press 3to confirm or wait for 5 seconds.
When the timer is set, and the remaining time
24
are shown in the display 6.
After the set time runs down, the product turns off
automatically.
NOTE: When the product has been turned off
by the timer, End is shown in the display 6.
If no button is pressed within 5 seconds after
3was pressed, the timer setting will be aborted.

15GB
Replacing the battery
Replace the remote control battery as soon as the
signal reception weakens.
Follow the illustration on the back of the remote
control
20
.
Slightly press in the tab of the battery
compartment
21
to pull it out (Fig. C).
Remove the old battery.
Insert a new battery (type CR2025) with correct
polarity.
Push the battery compartment
21
shut.
Transport
mWARNING! Do not move the product while it is
in operation or cooling down.
Carry the product by the provided handle
14
only.
Cleaning and care
mDANGER! Risk of electric shock! Always
disconnect the power plug
19
from the wall outlet
before cleaning the product.
mWARNING! Never immerse the product in
water or other liquids. Never hold the product
under running water.
Wipe down the product with a slightly damp
cloth.
Do not let any water or other liquids enter the
product interior.
Do not use any abrasive, aggressive cleaners or
hard brushes to clean the product.
Let all parts dry completely after cleaning.
Use a vacuum cleaner to clean the air outlet
safety guard 2and the air inlet safety guard
16
when they have become dirty.
Storage
When not in use, store the product in its original
packaging.
Store the product in a dry, secure location away
from children.
Disposal
The packaging is made entirely of recyclable
materials, which you may dispose of at local
recycling facilities.
Observe the marking of the packaging
materials for waste separation, which
are marked with abbreviations (a) and
numbers (b) with following meaning: 1 – 7:
plastics / 20 – 22: paper and fibreboard /
80 – 98: composite materials
The product and packaging materials are
recyclable, dispose of it separately for
better waste treatment.
The Triman logo is valid in France only.
Contact your local refuse disposal authority
for more details of how to dispose of your
worn-out product.
To help protect the environment, please
dispose of the product properly when it
has reached the end of its useful life and
not in the household waste. Information on
collection points and their opening hours
can be obtained from your local authority.
Faulty or used batteries / rechargeable batteries must
be recycled in accordance with Directive 2006/66/
EC and its amendments. Please return the batteries /
rechargeable batteries and / or the product to the
available collection points.

16 GB
Environmental damage through
incorrect disposal of the batteries /
rechargeable batteries!
Batteries / rechargeable batteries may not be
disposed of with the usual domestic waste. They
may contain toxic heavy metals and are subject to
hazardous waste treatment rules and regulations. The
chemical symbols for heavy metals are as follows:
Cd = cadmium, Hg = mercury, Pb = lead. That is why
you should dispose of used batteries / rechargeable
batteries at a local collection point.
Warranty
The product has been manufactured to strict quality
guidelines and meticulously examined before delivery.
In the event of product defects you have legal rights
against the retailer of this product. Your legal rights
are not limited in any way by our warranty detailed
below.
The warranty for this product is 3 years from the
date of purchase. Should this product show any fault
in materials or manufacture within 3 years from the
date of purchase, we will repair or replace it – at our
choice – free of charge to you.
The warranty period begins on the date of purchase.
Please keep the original sales receipt in a safe
location. This document is required as your proof
of purchase. This warranty becomes void if the
product has been damaged, or used or maintained
improperly.
The warranty applies to defects in material or
manufacture. This warranty does not cover product
parts subject to normal wear, thus possibly considered
consumables (e. g. batteries) or for damage to fragile
parts, e. g. switches, rechargeable batteries or glass
parts.
Warranty claim procedure
To ensure quick processing of your case, please
observe the following instructions:
Please have the till receipt and the item number
(e.g. IAN 123456_7890) available as proof of
purchase.
You will find the item number on the type plate,
an engraving on the front page of the instructions
(bottom left), or as a sticker on the rear or bottom of
the appliance.
If functional or other defects occur, please contact the
service department listed either by telephone or by
e-mail.
You can return a defective product to us free of
charge to the service address that will be provided
to you. Ensure that you enclose the proof of purchase
(till receipt) and information about what the defect is
and when it occurred.
Service
Service Great Britain
Tel.: [phone]
E-Mail: [e-mail]

17GB
(1/2)
Information requirements for electric local space heaters
Model identifier(s): Fan heater, SHLF 2000 D1, HG05381
Item Symbol Value Unit Item Unit
Heat output Type of heat input (select one)
Nominal heat output Pnom 2.0 kW Manual heat charge control, with
integrated thermostat
[yes/
no]
Minimum heat output
(indicative) Pmin 1.0 kW Manual heat charge control with room
and/or outdoor temperature feedback
[yes/
no]
Maximum continuous heat
output Pmax, c 2.0 kW Electronic heat charge control with room
and/or outdoor temperature feedback
[yes/
no]
Auxiliary current consumption Fan assisted heat output [yes/
no]
At nominal heat output elmax 2.0 kW Type of heat output/room temperature
control (select one)
At minimum heat output elmin 1.0 kW Single stage heat output and no room
temperature control
[yes/
no]
In standby mode elSB
0.00044 kW Two or more manual stages, no room
temperature control
[yes/
no]
With mechanic thermostat room
temperature control
[yes/
no]
With electronic room temperature
control
[yes/
no]
Electronic room temperature control plus
day timer
[yes/
no]
Electronic room temperature control plus
week timer
[yes/
no]

18 GB
(2/2)
Information requirements for electric local space heaters
Model identifier(s): Fan heater, SHLF 2000 D1, HG05381
Item Symbol Value Unit Item Unit
Other control options
(multiple selections possible)
Room temperature control, with presence
detection
[yes/
no]
Room temperature control, with open
window detection
[yes/
no]
with distance control option [yes/
no]
With adaptive start control [yes/
no]
With working time limitation [yes/
no]
With black bulb sensor [yes/
no]
Contact details
OWIM GmbH & Co. KG
Stiftsbergstraße 1
DE-74167 Neckarsulm
GERMANY

19SE
Varningar och symboler som används ............................... Sidan 20
Inledning.................................................................. Sidan 20
Avsedd användning .......................................................... Sidan 20
Leverans ................................................................... Sidan 21
Beskrivning av de olika delarna................................................. Sidan 21
Tekniska data ............................................................... Sidan 21
Säkerhetsanvisningar................................................... Sidan 21
Säkerhetsanvisningar för batterier/laddningsbara batterier..... Sidan 26
Före den första användningen......................................... Sidan 27
Hantering ................................................................. Sidan 27
Inkoppling ................................................................. Sidan 27
Avstängning ................................................................ Sidan 27
Kontrollpanel ............................................................... Sidan 27
Välja driftsläge.............................................................. Sidan 28
Ställa in börtemperatur ....................................................... Sidan 28
Svängfunktion............................................................... Sidan 28
Timer ..................................................................... Sidan 28
Byte av batteri .............................................................. Sidan 29
Transport ................................................................. Sidan 29
Rengöring och skötsel .................................................. Sidan 29
Förvaring .................................................................. Sidan 29
Avfallshantering ......................................................... Sidan 29
Garanti.................................................................... Sidan 30
Informationskrav för elektriska rumsvämare....................... Sidan 31

20 SE
Varningar och symboler som används
I denna bruksanvisning och på förpackningen används följande varningsanvisningar:
FARA! Denna symbol med signalordet
”Fara” betecknar en riskkälla med en hög
grad av risk som om den inte undviks kan
leda till svåra skador eller döden.
Spänning (växelström)
Hertz (nätfrekvens)
Watt
VARNING! Denna symbol med
signalordet ”Varning” betecknar en
riskkälla med en måttligt hög grad av risk
som om den inte undviks kan leda till svåra
skador eller dödsfall.
Fara- risk för elchock!
HÄNVISNING: Denna symbol med
signalordet ”Hänvisning” innehåller
ytterligare nyttig information.
VAR FÖRSIKTIG! Denna symbol med
signalordet ”Var försiktig” betecknar en
riskkälla med en låg grad av risk som om
den inte undviks kan leda till ringa eller
måttligt svåra skador.
Symbol för en produkt av skyddsklass II.
VARNING! För att förhindra att
produkten överhettas, får den inte
övertäckas.
VAR FÖRSIKTIG.
Heta ytor! Frostskyddsfunktionen förhindrar att
rumstemperaturen faller under fryspunkten.
VÄRMEFLÄKT
Inledning
Grattis till köpet av din nya produkt. Du har köpt
en högklassig produkt. Bruksanvisningen hör till
produkten. Den innehåller viktiga anvisningar för
säkerhet, användning och avfallshantering. Läs
säkerhetsanvisningarna och monteringsanvisningen
innan du använder produkten. Använd produkten
endast enligt beskrivningen och endast för de
angivna ändamålen. Se till att bruksanvisningen alltid
finns tillgänglig även vid vidare användning av tredje
man.
Avsedd användning
Denna produkt tjänar till kortvarig uppvärmning av
utrymmen. Dessutom kan den användas som fläkt
utan uppvärmningsfunktion.
Denna produkt avses endast för användning i hushåll,
inte för yrkesanvändning.
Tillverkaren tar inte ansvar för skador som uppstår på
grund av felaktig användning.
