Silvercrest KH 2170 User manual

3B
KOMPERNASS GMBH · BURGSTRASSE 21 ·
D-44867 BOCHUM
www.kompernass.com
ID-Nr.: KH2170-04/08-V2
Bathroom Radio
Operating instructions
Ραδιόφωνο µπάνιου
Οδηγίες χρήσης
Radio
Bruksanvisning
BATHROOMRADIO
KH 2170
CV_KH2170_AR3543_LB3B 18.04.2008 14:02 Uhr Seite 1

KH 2170
 





+
–
––
+
+
CV_KH2170_AR3543_LB3B 18.04.2008 14:02 Uhr Seite 4

- 1 -
IINNDDEEXXPPAAGGEE
Read these operating instructions carefully before using the appliance for the first time
and preserve this booklet for later reference. Pass this booklet on to whoever might
acquire the appliance at a later date.
Intended use 2
Items supplied 2
Technical Data 3
Description of the appliance 3
Safety instructions 4
Inserting the batteries 5
Placement 5
Reception mode 6
Cleaning and storage 6
Maintenance 6
Disposal 7
Importer 7
Warranty and Service 8
IB_KH2170_AR3543_LB3B.qxp 21.04.2008 9:22 Uhr Seite 1

- 2 -
BBAATTHHRROOOOMMRRAADDIIOOKKHH22117700
Intended use
This appliance is spraywater protected (IPX4) – thus, it can be utilised in
areas where it may be subject to being sprayed/splashed with water, e.g.
bath and washrooms, in domestic households.
This appliance is not watertight – it is therefore not intended for utilisation
in areas with high humidity or where it could come into direct contact with
water e.g. in the very close vicinity of a shower or bath, for use outdoors
and in commercial or industrial applications.
Items supplied
1 x Appliance
2 x Suction discs
1 x Operating instruction
• Check to ensure that the appliance is undamaged, all component
parts are present and that packaging remnants are removed from it.
IB_KH2170_AR3543_LB3B.qxp 21.04.2008 9:22 Uhr Seite 2

- 3 -
Technical Data
Reception range FM: 87.5 - 108 MHz
Reception range AM: 530 – 1600 KHz
Output level: ca. 280 mW
Batteries: 3 x 1.5 V Type AAA/Micro
Dimensions (LxWxH): 120 x 85 x 40 mm
Weight : 100 g
Spray water protected: IPX4
CE Conformity
This device has been tested and approved regarding conformance with
the fundamental requirements and other relevent regulations of the EMV
directive 2004/108/EC.
Description of the appliance
Tuning regulator
On/Off switch, volume regulator
Suspension eyelet
Suction disc
Mounting holes for suction discs
Selector switch “AM” / “FM”
Battery compartment
Battery compartment closure
IB_KH2170_AR3543_LB3B.qxp 21.04.2008 9:22 Uhr Seite 3

- 4 -
Safety instructions
• If you do not intend to use the appliance for an extended period, remove
the batteries – batteries can discharge themselves and then leak.
• Should the batteries leak: Clean the battery compartment with a dry cloth
whilst wearing protective gloves. Use ONLY the type of battery detailed in
the Technical Data as replacements for discharged batteries.
• Always exchange all batteries at the same time. Always use batteries of
the same type as replacements.
• Keep batteries and cells away from small children. Should a battery be
swallowed, seek medical attention IMMEDIATELY, as life is at risk.
• Check to ensure that the appliance is in a serviceable condition before
taking it into use. Should there be visible damage to the appliance, do
not take it into use.
• Do not attempt to recharge batteries. Risk of explosion!
• Ensure that sources of direct heat (e.g. heating, sunlight) cannot have an
effect on the appliance.
• Do not allow liquids to permeate into the appliance, do not submerse it in
water. Avoid also a possible penetration by foreign objects.
IB_KH2170_AR3543_LB3B.qxp 21.04.2008 9:22 Uhr Seite 4

- 5 -
Inserting the batteries
• Turn the battery compartment closure to the position “OPEN” and
open the battery compartment .
• Insert the batteries, 3 x 1.5V Type AAA/Micro, into the battery compart-
ment . Ensure the polarities are correct, as shown in the illustration.
Close the battery compartment. The appliance is now ready for use.
• When the batteries are exhausted, always replace all of them at the same
time. For replacements, use ONLY the type of battery detailed in the
Technical Data. In this regard, also take note of the notices contained in
the section “Disposal”.
Placement
• You can place the appliance on a hook or suspend it with a cord –
for this, the suspension eyelet  is available for use.
• With the two supplied suction discs  you can also attach the appliance
to smooth surfaces such as tiles or mirrors. To do this, insert the two suction
discs  into the mounting holes  at the rear of the appliance and then
slide them outwards, resp. to the sides. Then press the appliance with the
suction discs against the smooth surface. Select a location where, should
the suction discs loosen themselves, the appliance will not fall into water
and also where it will not be seriously damaged by the fall.
IB_KH2170_AR3543_LB3B.qxp 21.04.2008 9:22 Uhr Seite 5

Reception mode
a) Switching the appliance on/off, sound volume
• To switch the appliance on, turn the volume regulator  from the position
“OFF” to the right. With this you can also regulate the sound volume.
• To switch the appliance off, turn the volume regulator  all the way to the
left until it is again in the position “OFF” (Click).
b) Adjusting the reception
• Select the reception range AM or FM by placing the selector switch 
into the appropriate position.
• Then search for the desired radio station by slowly turning the tuning re-
gulator until you have clear reception. From the lettering above the
tuning regulator  you can read off the currently tuned frequency –
for “FM” in the unit “MHz” (Megahertz) and, for “AM” in the unit “kHz”
(Kilohertz), this is then be multiplied by 10.
Cleaning and storage
• Clean the appliance with a dry or lightly moistened cloth only. To avoid
potential damage to the surfaces, do not use any detergents or abrasive
cleaning agents.
• If you do not intend to use the appliance for longer than a year, remove
the batteries. Store the appliance in a dry location.
Maintenance
• NEVER open any of the coverings on the appliance. Arrange for the ap-
pliance to be repaired by specialists only. The appliance is maintenance-
free. In the event of malfunction or apparent damage, make contact with
Customer Services.
- 6 -
IB_KH2170_AR3543_LB3B.qxp 21.04.2008 9:22 Uhr Seite 6

Disposal
Disposing of the appliance
Do not, under any circumstances, dispose of the appliance with house-
hold waste. Dispose of the appliance through an approved disposal
centre or at your community waste facility. This appliance is subject to
the European Guidelines 2002/96/EC. Observe the currently appli-
cable regulations. In case of doubt, please contact your waste dispo-
sal centre.
Disposal of batteries/accumulators
Used batteries/rechargeable batteries may not be disposed of in household
waste. Every consumer is legally obliged to dispose of batteries at a collec-
tion site of his community/city district or at a retail store. The purpose of this
obligation is to ensure that batteries are disposed of in a non-polluting manner.
Only dispose of batteries when they are fully discharged.
Disposal of packaging
Dispose of all packaging materials in an environmentally friendly
manner.
Importer
KOMPERNASS GMBH
BURGSTRASSE 21
D-44867 BOCHUM
www.kompernass.com
- 7 -
IB_KH2170_AR3543_LB3B.qxp 21.04.2008 9:22 Uhr Seite 7

Warranty and Service
The warranty for this appliance is for 3 years from the date of purchase.
Should you have grounds for complaint, despite our high quality standards,
please contact our Service Hotline.
In the event that the processing of your complaint is not possible by
telephone, you will receive
• a processing number (RMA number) as well as
• an address to which you can send your product for warranty processing.
In the event of a mail despatch, please enclose a copy of the purchase
receipt (sales slip). The appliance must be securely packed and the RMA
number clearly visible. Products sent in without an RMA number cannot be
processed.
Note:
The warranty provisions cover only material or factory defects.
The warranty is not valid;
• worn out parts
• for damages to breakable parts such as switches and batteries.
The appliance is intended for domestic use only, NOT for commercial purposes.
If this product has been subjected to improper or inappropriate handling,
abuse, or modifications not carried out by one of our authorised sales and
service outlets, the warranty will be considered void.
Your statutory warranty claims are not restricted by this warranty.
- 8 -

