Silvercrest SKR 800 A1 User manual

IAN 110458
KITCHEN RADIO SKR 800 A1
KITCHEN RADIO
Operating instructions
KÜCHENRADIO
Bedienungsanleitung

GB/IE Operating instructions Page 1
DE/AT/CH Bedienungsanleitung Seite 19
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of
the device.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen
Funktionen des Gerätes vertraut.

IAN 110458
KITCHEN RADIO SKR 800 A1
KITCHEN RADIO
Operating instructions
KONYHAI RÁDIÓ
Használati utasítás
RADIO KUCHENNE
Instrukcja obsługi
KUCHYNSKÉ RÁDIO
Návod na obsluhu
KUCHYŇSKÉ RÁDIO
Návod k obsluze
KÜCHENRADIO
Bedienungsanleitung

1SKR 800 A1
GB
IE
Contents
Introduction .................2
Information concerning these operating
instructions........................2
Copyright ........................2
Intended use ......................2
Warning notes. . . . . . . . . . . . . . . . . . . . . 3
Safety......................4
Risk of electrocution ................4
Handling batteries..................4
Basic safety guidelines ..............5
Descriptions of components ....6
Before use...................7
Check the package contents..........7
Disposal of packaging materials.......7
Set-up location requirements ..........7
Installation under a wall cupboard .....8
Dismantling .......................9
Setting up the device................9
Connecting the power supply .........9
Inserting batteries ..................9
FM wire aerial.....................9
Handling and operation ......10
Setting the time, alarm time and alarm
type............................10
To switch the alarm function on or off . .11
Switching off the alarm .............11
Switching radio mode on/off ........11
Adjusting the volume...............12
Adjusting stations manually..........12
Searching for the next station ........12
Automatic station search (AMS function)12
Retrieving saved radio stations .......12
Receiving stations in mono quality ....13
Kitchen timer .....................13
Cleaning ...................14
Cleaning the housing ..............14
Troubleshooting .............15
Fault causes and rectification ........15
Storage/Disposal............16
Storage .........................16
Disposal of the device..............16
Disposing of the batteries ...........16
Appendix ..................16
Notes concerning the EC Declaration
of Conformity ....................16
Technical data....................17
Warranty........................18
Service .........................18
Importer. . . . . . . . . . . . . . . . . . . . . . . . .18

2SKR 800 A1
GB
IE
Introduction
Information concerning these operating instructions
Congratulations on the purchase of your new device.
You have selected a high-quality product. The operating instructions are part of this product.
They contain important information on safety, usage and disposal. Before using the product,
familiarise yourself with all handling and safety guidelines. Use the product only as described
and for the range of applications specified. Keep these operating instructions in a safe
place. Please also pass these operating instructions on to any future owner(s).
Copyright
This documentation is protected by copyright. Any copying or reproduction, including in
the form of extracts, or any reproduction of images (even in a modified state), is permitted
only with the written authorisation of the manufacturer.
Intended use
This device is a consumer electronics device designed for the reception of FM radio pro-
grammes, as a kitchen timer and as an alarm by means of an alarm tone or radio.
It is intended only for indoor use. The device is intended as a free standing unit or for
installation under a wall cupboard. For these purposes the integrated stand or mounting
plate must be used. It is not intended for any other or more extensive use. This device is
not intended for use in commercial or industrial environments. The manufacturer accepts
no responsibility for damage caused by failure to observe these instructions, improper
use or repairs, unauthorised modifications or the use of unapproved replacement parts.
The risk shall be borne solely by the user.

3SKR 800 A1
GB
IE
Warning notes
The following warning notice types are used in these operating instructions:
DANGER
A warning notice at this hazard level indicates an imminently hazardous
situation.
If the hazardous situation is not avoided, it could result in death or serious physical
injury.
► Follow the instructions in this warning notice to avoid the risk of death or serious
injury.
WARNING
A warning notice at this hazard level indicates a potentially hazardous
situation.
Failure to avoid this hazardous situation could result in injury.
► Follow the instructions in this warning notice to prevent injury.
CAUTION
A warning notice at this hazard level indicates a potential for property
damage.
Failure to avoid this situation could result in property damage.
► Follow the instructions in this warning notice to prevent property damage.
NOTE
► A note provides additional information that will assist you in using the device.

4SKR 800 A1
GB
IE
Safety
In this section, you will find important safety instructions for using the device. This device
complies with statutory safety regulations. Improper use may result in personal injury and
property damage.
Risk of electrocution
DANGER
Risk of fatal injury from electrocution!
Contact with live cables or components can result in fatal injury!
Comply with the following safety information in order to avoid the risk of electric shock:
► Do not use the device if the mains power plug or the connection cable are damaged.
► When disconnecting the device from the mains supply, always pull on the plug and
never on the cable.
► Never touch the mains plug or the device with wet hands.
► The device housing must not be opened under any circumstances. There is a risk of
electric shock or fire if live connections are touched and the electrical and mechanical
structure is changed.
► Do not insert any objects into the ventilation slots or other openings on the device.
► The device consumes power in standby mode. To completely disconnect the device
from the mains power, the power plug must be removed from the mains power
socket. The device should be positioned so that you have unrestricted access to
the mains power socket at all times, and can pull out the plug immediately in an
emergency.
Handling batteries
DANGER
Mishandling the batteries can cause fires, explosions, leakages or
other hazards!
► Do not throw the batteries into a fire and do not subject them to high temperatures.
► Do not open, deform or short-circuit batteries, since this can lead to chemical leakage.
► Do not attempt to recharge batteries. Do not charge batteries unless they are explicitly
labelled as "rechargeable". There is a risk of explosion!
► Check the condition of the batteries at regular intervals. Leaking chemicals can
cause permanent damage to the device. Take particular care when handling
damaged or leaking batteries. Risk of acid burns! Wear protective gloves.
► Chemicals which leak from a battery can cause skin irritation. In the event of contact
with the skin, rinse with plenty of water. If the chemicals come into contact with your
eyes, rinse thoroughly with water, do not rub and consult a doctor immediately.

5SKR 800 A1
GB
IE
DANGER
► Keep batteries out of the reach of children.
Children might put batteries into their mouth and swallow them. If a battery has
been swallowed, seek medical assistance IMMEDIATELY.
► Do not mix different types of batteries.
► Always insert the batteries the right way round (observe correct polarity) otherwise
there is a danger that they could explode.
► If you do not intend to use the device for a long time, remove the batteries.
Basic safety guidelines
To ensure safe operation of the device, follow the safety guidelines set out below:
■ This device may be used by children aged 8 years and above and by persons with
limited physical, sensory or mental capabilities or lack of experience and knowledge,
provided that they are under supervision or have been told how to use the device
safely and are aware of the potential risks. Children must not use the device as a
plaything. Cleaning and user maintenance tasks may not be carried out by children
unless they are supervised.
■ Check the device for visible external damage before use. Do not operate a device
that has been damaged or dropped.
■ If the cables or connections are damaged, have them replaced by an authorised
specialist or the Customer Service department.
■ Protect the connection cable from hot surfaces and sharp edges.
■ Ensure that the power cable is not stretched tightly or kinked.
■ Do not allow the cable to dangle over edges (tripwire effect).
■ All repairs must be carried out by authorised specialist companies or by the Customer
Service department. Failure to make proper repairs may put the user at risk. It will
also invalidate any warranty claims.
■ Defective components must always be replaced with original replacement parts.
Compliance with the safety requirements can only be guaranteed by using these
replacement parts.
■ Do not make any unauthorised modifications or alterations to the device.
■ Always place the device on a stable and level surface. It can be damaged if dropped.
■ Do not expose the device to direct sunlight or high temperatures. Otherwise it may
overheat and be irreparably damaged.
■ Be sure to provide sufficient air circulation to avoid a heat build-up. Never cover the
device! Risk of fire!
■ Do not place the product near heat sources such as radiators or other heat-generat-
ing devices.
■ Do not operate the device close to naked flames (e.g. candles).

6SKR 800 A1
GB
IE
■ The device is not designed for use in rooms with high temperatures or humidity
(e.g. bathrooms) or where there is excessive dust.
■ Protect the device from drips or splashes of water. Never immerse the device in water
and do not set up the device in the close vicinity of water and do not place objects
filled with liquids (e.g. vases) onto the device.
■ If you notice a burning smell or smoke, pull out the plug immediately and remove the
batteries.
■ In the case of a malfunction occurring or a thunderstorm, disconnect the plug from
the mains power socket.
■ DANGER! Do not allow children to play with the packaging material! Keep all
packaging materials out of the reach of children. Risk of suffocation!
Descriptions of components
(see fold-out page)
TIMER switch
2button
3button
4Mounting plate
5Display
6button
7button
8VOLUME/DISPLAY/ dial
9Stand (folding)
10 Loudspeaker
11 Power cable
12 Battery compartment
13 Cable antenna for FM reception
14 Spacer (for under-cabinet installation)
15 Mounting screw (long)
16 Mounting screw (short)
17 Operating instructions

7SKR 800 A1
GB
IE
Before use
Check the package contents
♦ Remove all parts of the device and the operating instructions from the box.
♦ Remove all packaging material.
The package contents include the following components:
▯ Kitchen Radio SKR 800 A1
▯ Mounting plate 4(pre-assembled)
▯ 4 x spacers 14
▯ 4 mounting screws (long) 15
▯ 4 mounting screws (short) 16
▯ These operating instructions 17
NOTE
► Check the package for completeness and for signs of visible damage.
► If any items are missing or damaged as a result of defective packaging or insufficient
care during transportation, contact the Service hotline (see the section Service).
Disposal of packaging materials
The packaging protects the device from damage during carriage. The packaging materials
have been selected for their environmental friendliness and ease of disposal, and are
therefore recyclable.
Returning the packaging to the material cycle conserves raw materials and
reduces the amount of waste which is generated. Dispose of packaging materials
that are no longer needed in accordance with applicable local regulations.
NOTE
► If possible, keep the device's original packaging for the warranty period so that the
device can be packed properly for return shipment in the event of a warranty claim.
Set-up location requirements
For safe and trouble-free operation of the device, the set-up location must fulfil the following
requirements:
■ When setting it up, place the device on a firm, flat and horizontal surface. Use the
fold-out stand.
■ The surfaces of some items of furniture might contain components that can corrode
and soften the rubber feet of the device. If necessary, place a cover under the
device's rubber feet.
■ Set up or mount the device in such a way that the ventilation openings and the
speaker are not covered.

8SKR 800 A1
GB
IE
■ Do not place the device in a hot, wet or extremely damp environment or in the vicinity
of flammable materials.
■ The mounting location must be selected so that the device is not exposed to steam.
Do not install the device directly over a hotplate.
■ The mains power socket must be easily accessible so that the power cable can be
easily disconnected in an emergency.
Installation under a wall cupboard
3,1 cm
6,3 cm
You can install the device under a wall cupboard using the supplied mounting plate 4.
Proceed as follows to mount the device:
♦ Slide the mounting plate to the rear and remove it from the device.
♦ Find a suitable installation location for the device (see also the section Set-up
location requirements).
♦ Hold the mounting plate under the installation location. Ensure that the front edge
of the mounting plate is approx. 3.1cm behind the front of the cupboard so that the
device is flush with the cupboard after installation. The side edges of the mounting
plate must be around 6.3cm from any adjacent cabinets or walls.
♦ Mark the 4 mounting points with a pencil.
♦ Using a spike or nail, make a small depression at the respective marking points.
♦ If required, place the supplied spacers 14 between the cupboard and the mounting
plate. If using the spacers, you will need the long mounting screws 15 .
♦ Screw the mounting plate tight using the mounting screws (15 or 16 ) provided.
♦ Push the device with its top against the mounting plate 4until it clicks audibly into
place.
♦ Check to ensure that the device is securely seated.

9SKR 800 A1
GB
IE
Dismantling
♦ Pull the device forwards off the mounting plate.
♦ Unscrew the screws (15 or 16 ) on the mounting plate and remove the mounting plate
from the wall cupboard.
Setting up the device
As an alternative you can stand the device on a level surface. To prevent the ventilation slots
and speaker 10 on the bottom of the device from being covered, the device's stand 9
must be folded outwards:
♦ Reach into the recess on the side of the stand and pull it out as far as it will go.
♦ Select a suitable location for the device (see also the section Set-up location
requirements).
Connecting the power supply
CAUTION
► Before connecting the device compare the connection data (voltage and frequency)
on the rating plate with that of your electric supply. These data must agree so that
no damage is sustained by the device.
♦ Insert the power plug into a mains wall socket. The time ( ) flashes on the display 5.
Inserting batteries
By inserting 2 x 1.5V batteries (type AA/Mignon/LR6) you can prevent the programmed
time or saved stations from being lost in the event of a power failure. The batteries make
sure that the internal clock continues to run even during a power outage. When power is
restored, the correct time automatically appears on the display.
NOTE
► The device can also be operated without a battery. The display, radio and alarm
do not function in emergency mode.
♦ Open the cover of the battery compartment 12 on the bottom of the device.
♦ Insert 2 x 1.5V batteries (type AA/Mignon/LR6) (not supplied) into the battery
compartment. Insert the batteries as shown on the polarity diagram in the battery
compartment.
♦ Then close the battery compartment by replacing the cover and snapping it into place.
FM wire aerial
♦ Completely unwind the wire aerial 13 for FM radio reception.

10 SKR 800 A1
GB
IE
Handling and operation
Setting the time, alarm time and alarm type
Requirement: The device is in clock/standby mode.
NOTE
► Make the settings quickly. If you do not press a button for 7 seconds, the entry is
cancelled. All settings made up to this point are saved automatically.
♦ Press the button 2for about 2 seconds. The display 5flashes, showing
the indicator for 24-hour mode ( ).
♦ Press the button 6or button 7to switch between 24-hour ( ) and 12-hour
mode ( ).
NOTE
► If the 12-hour mode is set, AM appears in the upper left of the display until 12
noon. From 12 noon, this changes to PM.
♦ Press the button to accept the setting. The hours will flash in the display and
the clock icon appears.
♦ Press or hold down the button or the button to set the hour.
♦ Press the button to accept the setting. The minutes will flash in the display.
♦ Press or hold down the button or the button to set the minutes.
♦ Press the button to accept the time. The hour digits for the alarm will flash in
the display and the icon for the activated alarm function appears.
♦ Press or hold down the button or the button to set the hour.
♦ Press the button to accept the setting. The minute digits for the alarm flash on
the display.
♦ Press or hold down the button or the button to set the minutes.
♦ Press the button to accept the setting. The alarm type appears in the display:
(buzzer) or (radio).
♦ Press the or button to set the required alarm type.
♦ If you have selected the (radio) alarm type, press the button again.
appears on the display.
♦ Use the button 6or the button 7to set the desired volume ( ) for
the radio alarm.
♦ Press the button 2to accept the setting. The time reappears on the display 5
together with the icons.

11SKR 800 A1
GB
IE
To switch the alarm function on or off
Requirement: The device is in clock/standby mode.
♦ Press the button briefly. The icon for the activated alarm function appears
on the display.
♦ Press the button again briefly. The icon for the activated alarm function is
switched off.
NOTE
► The alarm time can only be changed if the menu "Set clock" is executed (see section
Setting the time, alarm time and alarm type).
Switching off the alarm
♦ While the alarm is sounding, press the button 3to switch off the alarm for
24 hours.
If the alarm is not manually deactivated, the device will switch off the alarm automatically
after 1 hour.
Switching radio mode on/off
NOTE
► The technical features of this device enable an adjustable reception capability that
exceeds the permitted FM frequency range of 87.5–108MHz. In some countries,
different national regulations may apply to the assigned radio frequency ranges.
Please note that information received outside of the assigned radio frequency ranges
may not be exploited, passed on to third parties or otherwise misused.
♦ Press the button to switch the radio on.
♦ Press the button again to switch the radio off and thus put the device into clock/
standby mode.
NOTE
► The display illumination is switched off between 11 pm and 5 am in the clock/
standby mode. This switch-off time is permanently programmed and cannot be
changed.
♦ Press the or button to switch on the display illumination for a short time.

12 SKR 800 A1
GB
IE
Adjusting the volume
♦ Turn the VOLUME/DISPLAY/ 8dial to the right to increase the volume.
♦ Turn the VOLUME/DISPLAY/ dial to the left to decrease the volume.
The set volume will be shown on the display 5as a value between (mute) and .
Adjusting stations manually
♦ Press the button 6briefly to increase the frequency.
♦ Press the button 7briefly to reduce the frequency.
The station frequency is shown on the display and the speaker 10 is switched off during the
station search. If a station broadcasting in stereo is being received, the stereo icon
appears on the display.
Searching for the next station
The device can automatically search for the nearest station.
♦ Press the button for about 2seconds. The device searches for the station with the
next higher frequency.
♦ Press the button for about 2seconds. The device searches for the station with
the next lower frequency.
Automatic station search (AMS function)
The device uses the AMS function to automatically search for stations and saves them in
the device’s 20 preset slots.
♦ Press the button 2for about 2 seconds. The device begins the station search
and allocates the stations found to the preset slots to . Every time a station is
saved, the frequency remains briefly on the display. Once all the station presets are
filled, the search is terminated and the station saved in the first preset is played.
Retrieving saved radio stations
♦ Press the button briefly. The current station preset is shown on the display,
e.g. .
♦ Press or hold down the button or the button to set the required station preset.
♦ Press the button to confirm the selection or wait around 4seconds until the
frequency changes automatically to that of the selected preset.

13SKR 800 A1
GB
IE
Receiving stations in mono quality
♦ If you would like to receive a station in mono, press and hold the button 3
for about 2seconds until the stereo icon disappears from the display 5.
♦ If you would like to switch back to stereo reception, press and hold the button
for about 2seconds until the stereo icon appears on the display.
Kitchen timer
The device has a convenient kitchen timer with which you can monitor cooking and baking
times. There are 4 preset times and also an adjustable time range between 1 minute and
3 hours. The two timer types (preset times and adjustable time range) can also be used
in parallel.
Using preset times
♦ Use the TIMER dial to select one of the 4 settings 3, 5, 10 or 15minutes.
The countdown starts immediately and is briefly shown on the display.
♦ After the countdown has elapsed, you will hear an alarm tone. Press any button on
the device or turn the TIMER dial to the OFF position to switch off the alarm.
NOTE
► Press the VOLUME/DISPLAY/ 8dial briefly to show the remaining time for the
kitchen timer on the display.
► Set the TIMER dial to the OFF position if you want to turn the kitchen timer off
before it has finished.
Setting a variable timer time
NOTE
► Make the settings quickly. If you do not press a button for 4 seconds, the entry is
cancelled.
♦ Press and hold the VOLUME/DISPLAY/ dial for about 5seconds until the kitchen
timer icon appears on the display and the time display flashes.
♦ Turn the VOLUME/DISPLAY/ dial to the right to set the desired time to anywhere
between 1 minute and 3 hours.
♦ Turn the VOLUME/DISPLAY/ to the left to decrease the time.
The countdown starts immediately and is briefly shown on the display. The icon for the
kitchen timer also appears on the display.

14 SKR 800 A1
GB
IE
NOTE
► Press the VOLUME/DISPLAY/ 8dial twice briefly to show the remaining time
for the kitchen timer on the display 5.
► If you want to cancel the variable kitchen timer prematurely, press and hold the
VOLUME/DISPLAY/ dial for about 5seconds until the remaining time of the
variable kitchen timer flashes on the display.
► While the remaining time is flashing on the display, press the button 7to
switch off the kitchen timer. As soon as the time display or the frequency display
appears, the icon for the kitchen timer disappears.
Cleaning
DANGER
Risk of fatal injury from electrocution!
► Remove the plug from the mains power socket before starting to clean the device.
CAUTION
Damage to the device!
► To avoid irreparable damage to the device, ensure that no moisture gets into it
during cleaning.
Cleaning the housing
♦ Clean the surfaces of the device with a soft, dry cloth.
♦ Use a lightly moistened cloth and a mild detergent to remove stubborn dirt residues.

15SKR 800 A1
GB
IE
Troubleshooting
This section contains important information about fault identification and rectification.
Follow the instructions to avoid hazards and damage.
Fault causes and rectification
The following table will help you to identify and rectify minor malfunctions:
Malfunction Possible cause Remedy
The display 5
indicates nothing.
The plug is not connected. Put the power plug into the socket.
The mains power socket is
not supplying power. Check the house mains fuse.
No sound.
The volume is set to minimum. Increase the volume with the
VOLUME/DISPLAY/ 8dial.
The device is in clock/
standby mode.
Switch the device on using the
button 3.
Interference with
the radio recep-
tion.
The station is not properly
tuned in.
Tune the station correctly using the
button 6or the button 7.
The reception is weak.
Try to improve reception by realigning
the wire aerial 13 .
Press and hold the button 2for
about 2seconds to receive the station
in mono.
The time and
station presets are
lost after a power
failure.
No batteries in the battery
compartment 12 or batteries
are dead.
Check that the batteries have sufficient
voltage and replace them if necessary.
The time and station presets will need
to be reprogrammed.
NOTE
► If you are unable to resolve the problem by taking any of the aforementioned steps,
please contact the Customer Service department.

16 SKR 800 A1
GB
IE
Storage/Disposal
Storage
If you do not intend to use the device for an extended period of time disconnect it from
the power supply, remove the batteries and store it in a clean, dry location that is not
subjected to direct sunlight.
Disposal of the device
Never dispose of the device in the normal domestic waste.
This product is subject to the provisions of the European WEEE
(Waste Electrical and Electronic Equipment) Directive 2012/19/EU.
Dispose of the device via an approved waste disposal company or your municipal waste
disposal facility. Please observe applicable regulations. Please contact your waste disposal
facility if you are in any doubt.
Disposing of the batteries
Do not dispose of the batteries in the domestic waste. Consumers are legally obliged to
dispose of used batteries at a collection point in their town/district or at a retail store.
This obligation is intended to ensure that batteries are disposed of in an environmentally
responsible manner. Dispose of batteries only when they are fully discharged.
Appendix
Notes concerning the EC Declaration of Conformity
This device complies with the essential requirements and other relevant
provisions of the European Electromagnetic Compatibility Directive
2004/108/EC, the Low Voltage Directive 2006/95/EC and the
RoHS Directive 2011/65/EU.
The complete Declaration of Compliance, in its original form,
is available from the importer.

17SKR 800 A1
GB
IE
Technical data
Input voltage 220–240 V ~, 50Hz
Protection class II /
Batteries for data retention 2 x 1.5 V type AA/Mignon/LR6
(not supplied)
Power consumption (in operation) approx. 5 W
Power consumption (standby) > 0.8 W
Loudspeaker power output approx. 2 x 0.4 W
(at 10% harmonic distortion)
Frequency range of radio (FM) 87.5–108 MHz
Station presets 20
Operating temperature +5 to +40°C
Humidity (no condensation) 5–70%
Dimensions (W x H x D)
(without stand) approx. 26 x 5 x 15.7 cm
Weight approx. 775 g
