Read these operating instructions carefully before using the
device for the rst time and preserve this booklet for later refer-
ence. Pass this booklet on to whoever might acquire the device
at a future date.
Index Page
Intended Use 2
Items supplied 2
Technical data 2
Please read the safety instructions 3
The operating elements 7
Taking the device into use 7
Switching the device on and off 8
Headphone operation 9
Cleaning and care 9
Disposal 9
CE Conformity 10
Importer 10
Important Warranty Notices 11

- 2 -
Intended Use
This portable radio device is intended exclusively for the recep-
tion of radio transmissions. The device is not intended for use in
commercial or industrial environments. No warranty claims will
be granted for damage resulting from improper use!
Items supplied
1 Portable radio device
1 Mains adapter
1 Operating instruction booklet
Technical data
Mains adapter:
Model number: D41V0600800
Input: 230 V ~50Hz, 55mA
Output : 6 V , 800mA
Protection class: II/
Power supply: via the supplied mains adapter or
from 4 x 1.5 V Batteries (Type C/
Baby/LR14, not supplied)
Frequency ranges: VHF, MW, SW, LW
Max. output voltage at the
headphone socket: 20-40mV
Dimensions (W x H x D): 21.7 x 13 x 7.7 cm
Weight : 480 g approx.
Operating temperature: + 5° ~35°C
Storage temperature : — 20° ~60°C
Humidity: 5 ~90 %, no condensation

- 3 -
Please read the safety instructions
Do not permit children to handle electrical devices without •
supervision, they cannot correctly assess the possible risks
of injury.
Check the device and all parts for visible damages. Should
•
the device become damaged, immediately remove the plug
from the wall socket. Then arrange for the device to be
checked by Customer Services.
Risk of electric shock
Connect the device only to power sockets supplying a mains •
voltage of 230 V ~/50 Hz when using the supplied mains
adapter.
Do not operate the device if the mains adapter, the adapt-
•
er's power cable or the device itself is damaged. Arrange
for a defective mains adapter to be repaired or replaced as
soon as possible by Customer Services.
NEVER open the device. There are no user-servicable ele-
•
ments inside. Should you do so, the safety of the device may
be compromised and the warranty becomes void.
NEVER submerse the device in water. Wipe it only with a
•
slightly damp cloth.
Protect the product from moisture. Use it only in dry rooms,
•
do not use it outdoors or close to liquids.
Ensure that neither the device nor the mains adapter could
•
become wet or damp or sustain any other damage during
use.
Notice regarding power disconnection
•
To completely separate the device from mains power, the
mains adapter must be unplugged from the wall socket.

- 4 -
For this reason, the device should be placed at a location
where unobstructed access to the power socket is assured
at all times, so that you are able to immediately remove the
plug in the event of an emergency. To eliminate the risk of
re, prevent unintended activation and save energy costs,
the mains adapter should be unplugged from the wall socket
when the device is not in use. The mains adapter consumes
power even when the radio is switched o.
Always grasp the mains adapter directly when you wish to
•
unplug it. Do not pull on the cable and never touch the mains
adapter with wet hands, this could result in a short circuit or
you receiving an electric shock. Do not place furniture or other
objects on the cable of the mains adapter, and ensure that it
cannot become trapped. Never tie knots in the power cable,
and do not join it to other cables. Lay the mains adapter cable,
and also the headphone cable, so that no one can step on
or trip over it. A damaged mains adapter can cause a re
or electric shock. Check the mains adapter from time to time.
Should it become damaged, contact your nearest authorised
customer service centre or your dealer to have it replaced.
When a storm and/or thunderstorm with the risk of lightning
•
threatens, please disconnect the mains adapter from the
power socket.
 Riskofre!
Do not use the device near hot surfaces.•
Do not operate or store the device in hot locations and do not •
subject the applianice to direct sunlight or strong articial light
sources. Otherwise, it may overheat and become irreparably
damaged.

- 5 -
Do not place open re sources, such as candles, on the •
device.
Do not leave the device unattended at any time when it is
•
in use.
To avoid overheating, do not use the device under coverings.
•
 Riskofpersonalinjury!
Listening to music with head or earphones for long periods •
and at high volume levels can lead to hearing damage! For
your own protection, we recommend that you do not adjust
the sound level too high.
Keep batteries well away from children. Children can put
•
batteries into their mouths and swallow them. If a battery is
swallowed medical assistance must be sought IMMEDIATELY.
The device can also be operated with batteries. When
•
interacting with batteries, please observe the following:
Riskofexplosion!
Do not throw batteries into a re.•
Do not recharge batteries. •
Never open batteries, never solder or weld batteries. •
The risk of explosions and injuries exists!
Regularly check the condition of the batteries. Leaking
•
batteries can cause damage to the device.
If you do not intend to use the device for an extended
•
period, remove the batteries.
In the event of the batteries leaking acids, wear protective
•
gloves when removing the batteries. Then clean the battery
compartment and the battery contacts with a dry cloth.

- 6 -
 Accidenthazard!
Do not operate the device if it has sustained a fall or is da-•
maged in any way. Arrange for the device to be checked
and/or repaired by qualied technicians.
This device is not intended for use by individuals (including
•
children) with restricted physical, physiological or intellectual
abilities or deciencies in experience and/or knowledge
unless they are supervised by a person responsible for their
safety or receive from this person instruction in how the device
is to be used. Children should be supervised to ensure that
they do not play with the device.
Riskofsuocation!
Do not leave packaging material lying unattended. Plastic •
foils and bags and pieces of styropor etc. are not toys, they
can be dangerous for small children.

- 7 -
The operating elements
qTelescopic aerial
w Carrying handle
e TUNING - transmitter calibration
r Station dial
t Loudspeaker
y DC 6V - Connection for the mains adapter
u Headphone output
i OFF/VOLUME - On/O switch, sound volume
regulator
o FM - Frequency selector button - VHF
aMW - Frequency selector button - MW
sLW - Frequency selector button - LW
d SW - Frequency selector button - KW
fMains adapter
gBattery compartment cover
Taking the device into use
First take all device components from the packaging and >
remove all packing foil and tape.
Connecting the mains adapter
Insert the plug of the mains adapter
>finto the connection
for the power supply voltage yon the device.
Then insert the plug of the mains adapter
>finto a correctly
installed mains power wall socket supplying 230 V ~/50 Hz.
Battery operation
As an alternative to operation with the mains adapter f, the
device can also be operated with batteries (batteries not sup-
plied).

- 8 -
Open the battery compartment >gon the rear of the device.
Insert 4 x 1.5V batteries of the type "C/Baby/LR14" as per
>
the insertion markings shown in the battery compartment g.
Pay heed to the correct poling of the batteries, otherwise the
>
device will not function and could even be damaged.
Close and secure the battery compartment
>g.
Leaking batteries can cause damage to the radio. If you do
>
not intend to use the device for an extended period, remove
the batteries.
Switching the device on and o
To switch the device on, turn the >On/O switch - sound
volume regulator i clockwise over a small resistance.
Press the respective button
>
FM = Very high frequency >o,
MW = Medium wave >a,
LW = Long wave >s, or
SW = Short wave >d,
to select the desired
> frequency range .
For VHF reception, extend the telescope aerial
>qto its full
length and then determine its best positioning.
For reception of the remaining frequency ranges, the radio is
>
tted with a built-in aerial. To improve reception, if necessary
turn the radio until it is in the most favourable position.
Turn the transmitter calibration TUNING
>eto receive the
desired radio station. Use the station dial for orientation.
Select the desired sound volume using the
> sound volume
regulator i.

- 9 -
To switch the radio o, turn the > On/O switch, sound volume
regulator i anti-clockwise, and over a small resistance, until
it comes to a stop.
Headphone operation
You can connect headphones with a 3.5 mm jackplug to the
headphone socket ( , u). In this case, the built-in loudspeaker tis
switched o.
Important! Listening to music with head or earphones
for long periods and at high volume levels can lead to
hearing damage!
Cleaning and care
NEVER submerse the device or its components in water or •
other uids!
Do not allow any liquids to penetrate the housing.
•
Cleaning the housing:
Clean the housing surface with a slightly damp cloth Never
use petrol, solvents or detergents that can damage plastics!
Disposal
Do not dispose of the device in your normal
domestic waste. This device is subject to the pro-
visions of European Guidelines 2002/96/EC.
Radio device
Arrange for the product, or parts of it, to be disposed of by a
•
professional disposal company or by your communal waste
facility.

- 10 -
Observe the currently applicable regulations. In case of•
doubt, please contact your waste disposal centre.
Batteries/rechargeable batteries
Used batteries/rechargeable batteries may not be disposed
•
of in household waste.
Batteries/rechargeable batteries can contain toxic substances,
•
which may damage the environment. Therefore, dispose of
the batteries/rechargeable batteries in accordance with
statutory regulations.
Every consumer is legally obligated to surrender batteries/
•
rechargeable batteries to a community collection centre in
their district or to a dealer. The purpose of this obligation is
to ensure that batteries are disposed of in a non-polluting
manner.
Only dispose of batteries when they are fully discharged.
•
Dispose of packaging materials in an environmentally
responsible manner.
CE Conformity
This device has been both examined and approved in regard
to conformity with the fundamental requirements and other re-
levant regulations of the EMC Directive 2004/108/EC and the
low voltage directive LVD 2006/95/EC.
Importer
KOMPERNASS GMBH
BURGSTRASSE 21
44867 BOCHUM, GERMANY
www.kompernass.com

- 11 -
Important Warranty Notices
You receive a 3-year warranty for this device as of the purchase
date. Should you, in spite of our high quality standards, have
grounds for complaint, please contact our Service Hotline. In
the event that the processing of your complaint is not possible
by telephone, you will receive
a processing number (RMA number) as well as •
an address to which you can send your device for repair •
under warranty.
In the case of a mail-in shipment please enclose a copy of
the purchase receipt (sales slip). The device must be securely
packed and the RMA number clearly visible. Products sent in
without the RMA number cannot be processed.
Note: The warranty provisions cover only material or
factory defects.
The warranty is not valid;
for parts subject to wear
•
for damage to breakable parts such as switches or con-•
sumables such as rechargeable batteries.
This product is for private use only and is not intended for com-
mercial applications. The warranty is void in the case of abusive
and improper handling, use of force and internal tampering not
carried out by our authorized service branch. Your statutory
warranty claims are not restricted by this warranty.

- 12 -

- 13 -
RETRO RADIO
KH 2351
Warranty
In order to guarantee a cost free
repair procedure please get in
touch with the service hotline.
Make sure you have your sales
slip handy.
Sender, please write clearly:
Last name:
First name:
Street:
Postcode/Place:
Country:
Telephone:
Date/Signature:
Description of fault:
Completely fill our this section and enclose with the appliance!
DES Ltd
Tel.: [phone]
Fax: [phone]
e-mail: [e-mail]
Irish Connection
Tel: 00353 (0) 87 99 62 077
Fax: [phone]
e-mail: [e-mail]
www.mysilvercrest.de
GB

- 14 -

- 15 -

- 16 -
