Silvercrest SNAW 1000 C1 User manual

IAN 270053
NUTRITION SCALE SNAW 1000 C1
NUTRITION SCALE
Operating instructions
NÆRINGSVÆRDI-ANALYSEVÆGT
Betjeningsvejledning
DIETVÅG
Bruksanvisning
DIEETTIVAAKA
Käyttöohje
NÄHRWERT-ANALYSE-WAAGE
Bedienungsanleitung

GB/IE Operating instructions Page 1
FI Käyttöohje Sivu 37
SE Bruksanvisning Sidan 73
DK Betjeningsvejledning Side 107
DE/AT/CH Bedienungsanleitung Seite 141
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of
the device.
Käännä ennen lukemista kuvallinen sivu esiin ja tutustu seuraavaksi laitteen kaikkiin toimintoihin.
Vik ut bildsidan och ha den till hands när du läser igenom anvisningarna och gör dig bekant med
apparatens/maskinens funktioner.
Før du læser, vend siden med billeder frem og bliv bekendt med alle apparatets funktioner.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen
Funktionen des Gerätes vertraut.

2
3
4
5
6
7
8
9
1

1
GB
IE
SNAW 1000 C1
Index
Introduction...................................................2
Copyright............................................................... 2
Limited liability ........................................................... 2
Intended use ..................................................2
Items supplied / Transport inspection..............................3
Disposal of the packaging.................................................. 3
Operating Elements ............................................4
Technical data .................................................5
Warnings .....................................................5
Safety ................................................................. 5
Basic Safety Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Interaction with batteries ................................................... 7
Initial use .....................................................8
Setup.................................................................. 8
Operation ....................................................8
Weighing items .......................................................... 8
Weighing additional items (tare)............................................. 9
Display nutrient and energy values ........................................... 9
Switching the scale off....................................................10
Saving a measurement ...................................................10
Display added measurement values ......................................... 11
Delete saved measurement values...........................................11
Saving own codes ....................................................... 11
Replacing the battery..........................................13
Cleaning and Care ............................................13
Troubleshooting ..............................................14
Disposal .....................................................15
Warranty and Service .........................................15
Importer.....................................................16
Food codes...................................................17

2
GB
IE
SNAW 1000 C1
Introduction
Congratulations on the purchase of your new appliance.
You have clearly decided in favour of a quality product. These operating instruc-
tions are a part of this product. They contain important information in regard to
safety, use and disposal. Before using the product, familiarise yourself with all of
these operating and safety instructions. Use the product only as described and
only for the specified areas of application. In addition, pass these documents on,
together with the product, to any future owner.
Copyright
This documentation is copyright protected.
All rights including those of photographic reproduction, duplication and distribution
by means of particular methods (for example data processing, data carriers and
data networks), wholly or partially as well as substantive and technical changes are
reserved.
Limited liability
All technical information, data and directions for operation contained in these
operating instructions correspond to the latest status at the time of printing and,
to the best of our knowledge, also take into account all of our previous experi-
ences and awarenesses.
No claims can be derived from the details, illustrations and descriptions in these
instructions.
The manufacturer assumes no responsibility for damage caused by failure to
observe the instructions, improper use, inappropriate repairs, making unauthor-
ized changes or for using unapproved replacement parts.
Intended use
This appliance is intended only for the weighing of food and nutrition monitoring.
It is intended for domestic use only.
Do not use this appliance commercially!
This appliance is not intended for any other use or for uses beyond those mentioned.

3
GB
IE
SNAW 1000 C1
WARNING
Risks from unintended use!
Risks can be presented by the appliance if used for unintended purposes and/
or other types of use.
► Use the appliance exclusively for its intended purposes.
► Observe the procedures described in these operating instructions.
Claims of any kind for damage resulting from unintended use will not be accepted.
The operator alone bears liability.
Items supplied / Transport inspection
WARNING
Risk of suffocation!
► Packaging material should not be used as a play thing.
There is a risk of suffocation!
The appliance is delivered with the following components as standard:
▯ Nutrition Scale
▯ 1 x Button battery, 3V, CR2032
▯ Operating instructions
NOTICE
► Check the contents to make sure everything is there and for visible damage.
► If the contents are not complete or are damaged due to defective pack-
aging or transportation, contact the Service Hotline.
Disposal of the packaging
The packaging protects the appliance from transport damage. The packaging
materials are selected from the point of view of their environmental friendliness
and disposal technology and are therefore recyclable.
The return of packaging to the material circulation saves raw materials and
reduces waste volumes. Dispose of packaging material that is no longer needed
according to the regionally established regulations.
NOTICE
► If possible preserve the appliance's original packaging during the war-
ranty period so that in the case of a warranty claim you can package the
appliance properly for return.

4
GB
IE
SNAW 1000 C1
Operating Elements
Weighing plate
Battery compartment
Display
Button M+
Input confirmation to save the measured values
Button MR
To display the added measured values
Comma-sign for the self-saved nutritional values
Button MC
C
To delete the saved data or the previously entered food code
Number buttons
To enter the nutritional values of the food codes
Function buttons:
Switch on and off / Tara function (Nil setting)
Bread units
shows the carbohydrate content in grammes (g)
shows the fat content in grammes (g)
shows the protein content in grammes (g)
shows the cholesterol content in milligrammes (mg)
de shows the weight in grams (g)/kilogramme (kg) or ounces (oz)/pound (lb)
to save ones own foodstuffs
Switch between the units kcal and kJ
Unit switch
For setting the desired units of weight (g/kg or oz/lb)

5
GB
IE
SNAW 1000 C1
Technical data
Power supply
1x Button battery CR2032
1 x 3 V
Lithium batteries
max. Loading 5 kg
11 lb : 0.4 oz
min. Loading 2 g
0.1 oz
Indicator in 1 g - / 0.05 oz - steps
Warnings
In the existing operation instructions the following warnings are used:
WARNING
A warning of this danger level signifies a possible dangerous
situation.
If the dangerous situation is not avoided it can lead to injuries.
► The directives in this warning are there to avoid personal injuries.
IMPORTANT
A warning of this danger level signifies possible property
damage.
If the situation is not avoided it can lead to property damage.
► The directives in this warning are there to avoid property damage.
NOTICE
► A notice signifies additional information that assists in the handling of the
appliance.
Safety
In this chapter you receive important safety information regarding handling of the
appliance.
This appliance complies with the statutory safety regulations. Incorrect usage
can, however, lead to personal injury and property damage.

6
GB
IE
SNAW 1000 C1
WARNING
NEVER take medications (e.g. the dispensing of insulin) solely
on the basis of nutritional values given by this nutrition analy-
sis scale!
Reinforce your knowledge of the values given by, for example, referring to
literature on the subject. In this way, possible aberrances of the food nutritional
values can be avoided with the reference values saved in the appliance.
► Otherwise, it may lead to incorrect dosages of medications! If in any
doubt, seek medical advice!
Basic Safety Instructions
For safe handling of the appliance observe the following safety infor-
mation:
WARNING - RISK OF INJURY!
■ Before use check the appliance for visible external damage. Do not
take into use an appliance that is damaged or has fallen down.
■ This device may be used by children aged 8 over and by persons with
reduced physical, sensory or mental capabilities or lack of experience
and knowledge, provided that they are under supervision or have
been told how to use the device safely and are aware of the poten-
tial risks. Children must not play with the device. Cleaning and user
maintenance tasks must not be carried out by children unless they are
supervised.
■ Repairs should only be carried out by authorized specialist companies
or by the customer service department. Incorrect repairs can result in
significant dangers for the user. In addition warranty claims become void.
WARNING - PROPERTY DAMAGE
■ Defective components may only be replaced with original replacement
parts. Only by using original replacement parts can you guarantee
that the safety requirements are complied with.

7
GB
IE
SNAW 1000 C1
■ Protect the appliance from moisture and liquid penetration.
■ Do not place anything on the scale if it is not in use.
■ Protect the scales from impacts, moisture, dust, chemicals, extremes of
temperature and being too close to sources of heat (ovens, radiators).
■ Do not press on the buttons with excessive force or sharp objects.
■ Do not expose the appliance to high temperatures or strong electro-
magnetic fields (eg mobile phones).
NOTICE
► A repair to the appliance during the warranty period may only be
carried out by a cutomer service department authorized by the
manufacturer otherwise no additional warranty claims can be con-
sidered for subsequent damages.
Interaction with batteries
WARNING
Danger from improper use!
For safe handling of batteries observe the following safety instructions:
► Do not throw the batteries into a fire.
► Do not short circuit the batteries.
► Do not attempt to recharge the batteries.
► Regularly check the condition of the batteries. Leaking battery acid
can cause permanent damage to the appliance. When handling
a damaged or leaking battery special care should be taken.
Danger from acid burns! Wear protective gloves.
► Store batteries in a place inaccessible to children. If one is swal-
lowed seek immediate medical attention.
► If you do not intend to use the appliance for a long time, remove the
batteries.

8
GB
IE
SNAW 1000 C1
Initial use
■ Remove all packaging materials from the appliance. Remove the protective
foil from the display . The transport restraint that prevents the weighing
plate from being pushed down must be removed from under the weigh-
ing plate .
■ Open the battery compartment on the underside of the scales and remove
the small plastic strips which are clamped between the batteries and the
contacts. Close the battery compartment afterwards, such that the battery
compartment cover audibly engages.
■ The scale can display weights in g (grams) / kg (kilograms) or oz (ounces)/
lb (pounds). You can set the unit on the rear of the appliance. Press the
unit switch on the rear of the device to change units. In these operating
instructions, g (grams) is always the unit shown as an example.
Setup
Place the scales on a level and heat-resistent surface. A firm standing is the
prerequisite for correct measurement.
NOTICE
► This appliance is equipped with non-slip rubber feet. As furniture surfaces
may be made of a variety of materials and are treated with many different
types of cleaning agents, it cannot be completely ruled out that some
substances contain ingredients which may corrode the rubber rests and
soften them. If possible place an anti-slip material under the feet of the
appliance.
Operation
Weighing items
1) Press the button ON/OFF/TARE to switch the scales on.
The start display appears briefly, then “0 g” appears automatically.
IMPORTANT
Overloading or improper loading lead to irreparable damage
to the appliance.
► NEVER place more than 5000 g (11 lb) on the weighing plate .
► Do not place objects or foodstuffs on the display or on the buttons.

9
GB
IE
SNAW 1000 C1
2) If you wish to weigh without the bowl/container, lay the item to be weighed
on the weighing plate . The weight will be indicated.
If you wish to weigh the item in a bowl / in a container, first place the empty
bowl / the empty container onto the weighing plate . Press the button
ON/OFF/TARE . The display shows “0 g” and “T” appears on the
display . Place the items to be weighed in the bowl/container. The weight
of the items is shown.
Weighing additional items (tare)
To weigh in further amounts (e.g. flour and water for dough), you can set the
scales back at “0 g”.
■ If you wish to return the scales back to “0 g” after the first measurement so
as to measure the next ingredient, press the button ON/OFF/TARE .
The display once again indicates “0 g” and “T” appears in the display .
Display nutrient and energy values
1) Place the items to be weighed on the scales.
2) Find the appropriate code for the food to be weighed from the food list.
3) Enter in the 3-figure code with the number buttons , e.g. 024. The display 
then indicates the code and the weight.
NOTICE
► If you make an error when putting in the codes, briefly press the button MC
C .
The code will be deleted. Enter the code in once again.
4) To recall the nutritive and energy values, press the desired function button .
The required detail appears in the display .
If no further buttons are pressed, after approx. 8 seconds the display changes
back to the weighing mode and the weight is indicated. If you wish toswitch
straight into the weighing mode, press the button de The appliance indicates
the weight.
NOTICE
► Should you press a function button (except , de ), although a
code has not yet been entered, "Code" blinks in the display 3 times.
In this case, enter in the desired code.
NOTICE
► Due to natural fluctuations in the energy and nutritional values, only
approximate are possible.

10
GB
IE
SNAW 1000 C1
Switching the scale off
To switch the scales off, press the button ON/OFF/TARE for about 3 sec-
onds. The scales switches itself off
or
wait for about 60 seconds after the last usage. The scales switches itself off
automatically.
Saving a measurement
You can save all indicated values of a foodstuff. The scales automatically adds
together the values each saved measurement. Thus, for example, you can save
your entire food values eaten in one day and recall them at the end of the day.
The saved values are retained, even when you switch the scales off or change the
batteries.
You have previously made a measurement and entered the code.
1) Press the save button M+ to save the measurement. In the display 
appears “M”, the save location (e.g. 01) and the weight. M01 (or the last oc-
cupied space) is shown permanently on the display .
NOTICE
► If you press the save button M+ without having previously entered in
a code, "Code" blinks 3 times in the display . Then enter in the required
code.
2) When you want to carry out and save the next measurement, press the save
button M+ once again. In the display the next save position (e.g. M02)
appears.
3) To make further measurements, repeat the previously described steps.
NOTICE
► You can save up to 99 measurements (M99). When the memory is full,
it no longer permits measurements to be saved. In this case, delete the
saved data: press the button MC
C continuously until the indication
M99 (or the number of the last occupied memory space) extinguishes.
► If the nutritive value upper limit is reached with a memory input, "M" blinks
in the display and no further measurements can be added.

11
GB
IE
SNAW 1000 C1
Display added measurement values
You can retrieve the added measurement values at any time, for example, daily.
1) Press the button MR .
In the display appears the sum sign, the number of occupied save locations
and the added-up measurement values.
2) Using the function buttons (except ON/OFF/TARE ) switch between
the nutrient and energy value.
NOTICE
► When the sum of the saved energy values exceeds 199999 kJ, or another
nutritive or energy value is exceeded, the display indicates “E- - - - “.
After about 8 seconds, if no other buttons are pressed, the scales switches back
to the weighing mode.
NOTICE
► If you press the button MR although no measured values have been
saved, the indicator "NULL" appears in the display .
Delete saved measurement values
When you wish to delete the saved measurement values, press the button MC
C 
continuously until the number of the last occupied memory space extinguishes.
Saving own codes
On up to 200 memory slots you can save your own foods and their nutritional
values, and give them a code number (codes 800 - 999). The values you input
will each refer to 100 grams of food.
You can find the nutritional values of foods on their individual packaging or in
specialist literature.
For this proceed as follows:
1) Press the button ON/OFF/TARE to switch the scales on. The start display
appears briefly, then “0 g“ is indicated automatically.
2) Press the button de for about 3 seconds until “Code 0“ blinks in the display .
3) Enter the desired code number, between 800 - 999, and then confirm it with
the button M+ .

12
GB
IE
SNAW 1000 C1
4) Now enter the nutritional value of the food:
NOTICE
► The following maximum values can be entered:
Kilocalories 0 - 65534
Kj Kilojoules 0 - 65534
Cholesterol 0.0 - 6553.4
Bread units 0.0 - 655.34
Carbohydrates 0.0 - 6553.4
Fats 0.0 - 6553.4
Protein 0.0 - 6553.4
► Use the button MR to add a decimal point when entering values.
► Use the button MC
C to delete the entered values.
–First, the display blinks: enter the kilocalories and confirm the entry
with the button M+ .
–the display Kj blinks: enter the kilojoules and confirm the entry with
the button M+ .
–the display blinks: enter the cholesterol content in milligrams and
confirm the entry with the button M+ .
–the display blinks: enter the bread units and confirm the entry with
the button M+ .
The bread units can be calculated from the carbohydrate value: Divide
the carbohydrate value by “12“.
–the display blinks: enter the carbohydrate content in grams and
confirm the entry with the button M+ .
–the display blinks: enter the fat content in grams and confirm the
entry with the button M+ .
–the display blinks: enter the the protein content in grams and con-
firm the entry with the button M+ .
The display indicates “done” and the food is now saved under the selected code
number with all of its nutritional values.

13
GB
IE
SNAW 1000 C1
5) Repeat steps 3) - 4) if you want to enter more codes. Press the button de
when you want to finish the save process.
6) Enter the food in the appropriate field in the food tables of these operating
instructions.
NOTICE
► You can also overwrite one of your previously saved codes, in that you simply
reassign the code number and save the new nutritional values under this code.
Replacing the battery
1) Open the battery compartment , remove the old battery and dispose of it
in an environmentally correct way.
2) Insert a new button cell battery of type CR2032 3 V in accordance with the
polarity specified in the battery compartment.
3) Close the battery compartment . The battery compartment cover must
engage audibly.
Cleaning and Care
IMPORTANT
Ensure that no fluids can enter the scale!
This could irreparably damage the appliance.
Do not use abrasive or solvent cleaners.
These could damage the surfaces.
■ Wipe the scale with a soft cloth moistened with mild soap suds.
■ Clean the display only with a lightly moistened cloth and then wipe it dry
with a lint-free towel.
■ To clean the weighing plate carefully remove it, in that you pull it straight
up. Clean the weighing plate in a mild soapy solution . Dry the weighing
plate well before putting it back on the scale and firmly pressing it down.

14
GB
IE
SNAW 1000 C1
Troubleshooting
In this chapter you will receive important information for malfunction localization
and remedies. Observe the instructions in order to avoid danger and damage.
WARNING
Observe the following safety information to avoid danger and property damage:
► Repairs to electronic appliances may only be carried out by specialists
who have been trained by the manufacturer. Considerable danger to the
consumer and damage to the appliance can occur as a result of incorrect
repairs.
The following table will help with localizing and remedying minor malfunctions:
Display Possible cause Solution
In the display 
"L0" is indicated and
the battery symbol
appears
The battery is very weak. Replace the battery.
No indicators in the
display .
The battery is dis-
charged.
The plastic strip in the
battery compartment 
has not been removed.
Replace the battery.
Remove the plastic strip from the
battery compartment .
In the display 
"0 - Ld" appears
The permitted maximum
weight of 5 kg/ 11 lb is
being exceeded.
Remove some weight from the scales.
In the display 
"NULL" appears
when one tries to
retrieve the saved
values.
No values have been
saved. The memory is
empty.
First save some measured values.
NOTICE
► If you cannot resolve the problem with the above steps, please contact
Customer Support.

15
GB
IE
SNAW 1000 C1
Disposal
Disposal of the appliance
Do not dispose of the appliance in your normal domestic waste.
This product is subject to the European directive 2012/19/EU.
Dispose of the appliance through an approved disposal centre or at your com-
munity waste facility. Observe the currently applicable regulations. In case of
doubt, pleasecontact your waste disposal centre.
Disposing of the batteries/cells
Used batteries/cells may not be disposed of in household waste. Every consumer
is legally obliged to dispose of batteries at a collection site in his community/city
district or at a retail store. The purpose of this obligation is to ensure that batteries/
cells are disposed of in a non-polluting manner. Only dispose of batteries/cells
when they are fully discharged.
Warranty and Service
The warranty for this appliance is for 3 years from the date of purchase. The appli-
ance has been manufactured with care and meticulously examined before delivery.
Please retain your receipt as proof of purchase. In the case of a warranty claim,
please make contact by telephone with our Customer Service Department. Only
in this way can a post-free despatch for your goods be assured.
NOTICE
► The warranty is valid only for material or manufacturing faults, not for
damage sustained during transport, parts subject to wear and tear or
damage to fragile parts, e.g. the weighing plate.
This product is for domestic use only and is not intended for commercial use. The
warranty is void in the case of abusive and improper handling, use of force and
internal tampering not carried out by our authorised service branch.
Your statutory rights are not restricted in any way by this warranty. The warranty
period is not extended by repairs made under the warranty. This applies also to
replaced and repaired parts.
Damages and defects extant at the time of purchase must be reported immedi-
ately after unpacking, resp. no later than two days after the date of purchase.
Repairs made after the lapse of the warranty period are subject to charge.

16
GB
IE
SNAW 1000 C1
Service Great Britain
Tel.: [phone] (£ 0.10/Min.)
E-Mail: [email protected]
IAN 270053
Service Ireland
Tel.: [phone]
(0,08 EUR/Min., (peak))
(0,06 EUR/Min., (off peak))
E-Mail: [email protected]
IAN 270053
Hotline availability: Monday to Friday 08:00 - 20:00 (CET)
Importer
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
GERMANY
www.kompernass.com

17
GB
IE
SNAW 1000 C1
Milk
000 Buffalo milk*
001 Donkey milk*
002 Human milk Mothers milk
003 Pre-transitory
human milk*
2.-3.days
post-partum
004 Transitory human
milk
Transitional
milk 6 - 10 days
post-partum
005 Camel milk*
006 Cow milk Full milk (raw milk,
attested milk)
007 Cow milk Consumption
milk
at least 3.5% Fat
008 Cow milk low ft at least
1.5%, maximum
1.8% Fat
009 Cow milk Skimmed milk
(skim milk)
010 Cow milk UHT
011 Cow milk Sterilised milk
012 Sheeps milk*
013 Mares milk*
014 Goats milk
Milk products
015 Condensed milk at least 7.5 % Fat
016 Condensed milk at least. 10 % Fat
017 Condensed milk sweetened
018 Condensed
skimmed milk
sweetened
019 Dried whole milk Whole milk
powder
020 Dried skimmed
milk
Skimmed milk
powder
021 Cream Coffee cream,
coffee cream
at least 10% fat
022 Cream Whipping cream,
whipping cream
at least 30% fat
023 Cream, sour Sour cream
024 Butter Milk
025 Dried buttermilk Buttermilk
powder
026 Whey Sweet
027 Dried whey Whey powder
028 Yoghurt at least 3.5 % fat
029 Yoghurt low ft at least
1.5%, maximum
1.8% Fat
030 Yoghurt skimmed maxi-
mum. 0.3% Fat
031 Fruit yoghurt full fat
032 Fruit yoghurt low fat
033 Fruit yoghurt skimmed
034 Kefir
Food codes
NOTICE
► Due to insufficient study results and deviating compositions of foods containing animal fats
from different manufacturers, the cholesterol levels in some meat products are not stored in
the balance and are thus displayed with „- -“. These foods are marked with a *.
In this case then please use the cholesterol levels given by the manufacturers.
