Simrad CS90 User manual

Simrad CS90
Fish nding sonar
www.
si
mr
ad
.
com
T
E
C
HN
O
L
OG
Y F
O
R
SUS
TAINABLE FI
S
HERIE
S
Quick Start Guide

445947/A
February2020©KongsbergMaritimeAS
SimradCS90
FishFindingSonar
QuickStartGuide
Thepurposeofthismanualistoprovideanintroductiontosafeand
efcientuseoftheSimradCS90FishFindingSonar.Thismanualis
intendedforallinexperiencedandnewusersoftheSimradCS90.
Caution
YoumustneverstartCS90transmissions(pinging)whentheshipisindry
dock.Thetransducersmaybedamagediftheytransmitinopenair.
Allend-usermanualsprovidedforoperationandinstallationofyour
SimradCS90canbedownloadedfromourwebsite.
•https://www.simrad.com

KongsbergMaritimeAS
www.kongsberg.com
Documentinformation
•Product:SimradCS90
•Document:QuickStartGuide
•Documentpartnumber:445947
•DocumentISBNnumber:N/A
•Revision:A
•Dateofissue:24February2020
Copyright
TheinformationcontainedinthisdocumentremainsthesolepropertyofKongsberg
MaritimeAS.Nopartofthisdocumentmaybecopiedorreproducedinanyformorbyany
means,andtheinformationcontainedwithinitisnottobecommunicatedtoathirdparty,
withoutthepriorwrittenconsentofKongsbergMaritimeAS.
Warning
Theequipmenttowhichthismanualappliesmustonlybeusedforthepurposeforwhich
itwasdesigned.Improperuseormaintenancemaycausedamagetotheequipmentand/or
injurytopersonnel.Youmustbefamiliarwiththecontentsoftheappropriatemanuals
beforeattemptingtooperateorworkontheequipment.
KongsbergMaritimedisclaimsanyresponsibilityfordamageorinjurycausedbyimproper
installation,useormaintenanceoftheequipment.
Disclaimer
KongsbergMaritimeASendeavourstoensurethatallinformationinthisdocumentis
correctandfairlystated,butdoesnotacceptliabilityforanyerrorsoromissions.
Supportinformation
Ifyourequiremaintenanceorrepair,contactyourlocaldealer.Youcanalsocontactus
usingthefollowingaddress:[email protected].Ifyouneedinformationabout
ourotherproducts,visithttps://www.simrad.com.Onthiswebsiteyouwillalsonda
listofourdealersanddistributors.

445947/A3
Tableofcontents
ABOUTTHISMANUAL..................................................................5
SIMRADCS90..............................................................................6
Important.................................................................................................................................6
Systemdescription..................................................................................................................9
Generalsafetyrules...............................................................................................................10
Supportinformation...............................................................................................................11
GETTINGSTARTED....................................................................14
OperatingPaneldescription..................................................................................................15
Startingnormaloperation.....................................................................................................18
TurningontheCS90fornormaluse...........................................................................18
Gettingtoknowtheuserinterface..............................................................................20
Gettingtoknowpresentationmodesandviews..........................................................22
SelectingNormalmodetostart"pinging"...................................................................26
Adjustingtheradiusofthesearcharea.......................................................................28
Adjustingtheechosensitivity.....................................................................................29
Changingtheverticalangleofthesonarbeams..........................................................31
Adjustingthehorizontaldirectionofthesonarbeam.................................................33
TurningofftheCS90...................................................................................................35
Basicoperatingprocedures...................................................................................................36
Selectingthelanguagedisplayedinthemenusanddialogboxes...............................36
Selectingoperatingfrequencyforminimumnoise.....................................................37
Hidingthemenusystemwhenyoudonotneedit......................................................38
Savingsingleorsequentialscreencaptures................................................................39
Savingthecurrentusersettings...................................................................................40
Deningtheping(transmission)modes......................................................................41
MENUSYSTEM...........................................................................43
Aboutthemenusandmenubuttons......................................................................................44
Usingthe“smart”menubuttons...........................................................................................44
Mainmenu............................................................................................................................45
Operationmenu.....................................................................................................................47
Displaymenu........................................................................................................................48
Setupmenu...........................................................................................................................50
Activemenu..........................................................................................................................52
Objectsmenu........................................................................................................................55
QuickStartGuide

4445947/A
VisualObjectsmenu.............................................................................................................59
Cosmeticsmenu....................................................................................................................62
Shortcutmenus.....................................................................................................................64
SimradCS90

445947/A5
Aboutthismanual
Thepurposeofthismanualistoprovideanintroductiontosafeandefcientuseofthe
SimradCS90FishFindingSonar.Themanualdoesnotcontaindetailedinformationabout
functions,dialogboxesandoperatingparameters.
Targetaudience
ThismanualisintendedforallinexperiencedandnewusersoftheSimradCS90.We
assumethatyouarefamiliarwiththebasicacousticprinciplesofsoundinwater.Wealso
expectthatyouhavesomeexperiencewithsonaroperation.
Registeredtrademarks
Observetheregisteredtrademarksthatapply.
Simrad®,SIMRAD®andtheSimrad®logoareeitherregisteredtrademarks,ortrademarks
ofKongsbergMaritimeASinNorwayandothercountries.
Windows®isaregisteredtrademarkofMicrosoftCorporationintheUnitedStatesand
othercountries.
Wewantyourfeedback
WewanttoimproveCS90continuously.Wealsowantourend-userdocumentationto
becomprehensiveandrelevant.Youcanhelp.Pleaseprovidecomments,suggestionsor
constructivecriticismtoanyofoursupportofces.
Onlineinformation
Allend-usermanualsprovidedforoperationandinstallationofyourSimradCS90canbe
downloadedfromourwebsite.OurwebsitealsoprovidesinformationaboutotherSimrad
products.
•https://www.simrad.com/cs90
Aboutthismanual

6445947/A
SimradCS90
Topics
Important,page6
Systemdescription,page9
Generalsafetyrules,page10
Supportinformation,page11
Important
TheCS90isanadvancedproduct.Itisusedwithotheradvancedproducts.Thereis
importantinformationthatyouneedtoknow.
BeforeyouturnontheCS90
BeforeyouturnontheCS90,makesurethatyouhavesufcientwaterdepthtolower
thetransducer!
Caution
YoumustneverturnontheCS90whentheshipisindrydock.Thetransducermaybe
damagedifittransmitsinopenair.
SimradCS90QuickStartGuide

445947/A7
WhentheCS90isnotused
WhenyoudonotusetheCS90,turnofftheentiresystem.
Note
YoumustneverturnofftheCS90bymeansoftheon/offswitchontheProcessorUnit.
YoumustALWAYSusetheOperatingPanel.
Whenyouaredockingyourvessel
YoumustneversettheCS90tonormaloperationwhentheshipisindrydock.The
transducermaybedamagedifittransmitsinopenair.Topreventinadvertentuseofthe
CS90,pulloutthemainsplugontheProcessorUnitwheneveryourvesselisindrydock.
Additionalprecautionarymeasurersshouldbeconsidered.
Ifsomethingbreaksdown
Ifyoubelievethatsomethinghasbrokendown,contactyourlocaldealer.Alistofallour
dealersisprovidedonourwebsite.
•https://www.simrad.com
Ifyouareunabletocontactadealer,observethesupportinformationinthispublication.
WhenyouwanttoturnofftheCS90
YoumustneverturnofftheCS90bymeansoftheon/offswitchontheProcessorUnit.
WhenyoudonotusetheCS90,turnitoffwiththePowerbuttonontheOperatingPanel.
IfthetransducerisloweredwhenyouturnofftheCS90,itisautomaticallyretractedto
itsupperposition.
Note
IfyouturnofftheCS90bymeansoftheon/offswitchontheProcessorUnityoumaydamage
thesoftwareandtheinterfacesettingsusedtocommunicatewithexternaldevices.
Manualoperationofthehullunit
Intheeventofimproperoperation,thepowerfulelectricmotoronthehullunitmaycause
seriousdamagetotheequipmentand/orinjurytopersonnel.Therefore,beforeyoustart
manualoperation,readcarefullythroughtherelevantoperatingprocedures.
Note
Youmustfamiliarizeyourselfwiththecorrecthandlingmethodsandtherelevantsafety
requirements.
SimradCS90

8445947/A
Rulesfortransducerhandling
Atransducermustalwaysbehandledasadelicateinstrument.Incorrectactionsmaydamage
thetransducerbeyondrepair.Aphysicalblowtothetransducerfacemayeasilydamageone
ormoreelements.Observethesetransducerhandlingrules:
•Donotactivatethetransducerwhenitisoutofthewater.
•Donothandlethetransducerroughlyandavoidimpacts.
•Donotexposethetransducertodirectsunlightorexcessiveheat.
•Donotdamagetheouterprotectiveskinofthetransducer.
•Donotusehigh-pressurewater,sandblasting,metaltoolsorstrongsolventstoclean
thetransducer.
•Donotsteponthetransducercables.
•Donotdamagethetransducercables,andavoidexposuretosharpobjects.
SimradCS90QuickStartGuide

445947/A9
Systemdescription
TheSimradCS90isanomnidirectionalhighfrequencyshndingsonar.
ADisplay(Theseconddisplayis
optional.)
BProcessorUnit
COperatingPanel
DTransceiverUnit
EHullUnit
FHoistmotor
GMotorControlUnit
HTransducer
Achoiceofhullunitsisavailableforthe
CS90FishFindingSonar.Thehullunits
offerdifferentloweringdepthsandcable
lengths.Thesametransducerisusedon
allhullunittypes.Thesameinstallation
trunkisusedonallhullunittypes.
TheCS90isdesignedforshing
vesselsofallsizes,bothpurseseiners
andtrawlers.Thecentreoperational
frequencyis86kHz,butyoucanselect
anyoperationalfrequencyfrom70to90
kHzinstepsof1kHz.Thecylindrical
multi-elementtransducerallowsthe
omnidirectionalsonarbeamstobetilted
electronicallyfrom-10to+84degrees.
Thisallowsyoutoautomaticallytrackschoolsofsh,andtoobservethewholewater
volumearoundthevessel.Astabilizingsystemisincludedforelectronicpitchandroll
compensation.
SimradCS90

10445947/A
Generalsafetyrules
Safetyisimportant.Thesafetyprecautionsmustbefollowedatalltimesduringinstallation
andmaintenancework.
WARNING
TheCS90operateson115VACand/or230VACat50/60Hz.Thisvoltageislethal!
Youmustneverworkaloneonhigh-voltageequipment!
Thehullunitispoweredbya3-phasehighvoltage.
Thisequipmentmustbeservicedonlybyqualiedpersonnelfamiliarwiththe
constructionandoperationoftheCS90,aswellasthepotentialhazardsinvolved.
Failuretoobservethisprecautioncouldresultinbodilyinjury.
1Youmustalwaysswitchoffallpowerbeforeinstallationormaintenanceworkon
theCS90system.
Usethemaincircuitbreaker,andlabelthebreakerwithawarningsignthatinforms
othersthatmaintenanceorinstallationworkisinprogressonthesystem.
2Forsafetyreasons,twopersonsmustalwaysbepresentduringtroubleshootingwith
powerON.
3Readandunderstandtheapplicablerstaidinstructionsrelatedtoelectricshock.
4Whenevermaintenanceisinprogress,itisessentialthatarstaidkitisavailable,and
thatallpersonnelarefamiliarwiththerstaidinstructionsforelectricalshock.
5Thevariouspartsofthesystemmaybeheavy.
Makesurethattheappropriatetoolsandcertiedliftingequipmentareavailable.The
personnelmustbetrainedinrelevantinstallationandmaintenancework.
SimradCS90QuickStartGuide

445947/A11
Supportinformation
IfyouneedtechnicalsupportforyourSimradCS90youmustcontactyourlocaldealer,or
oneofoursupportdepartments.Alistofallourofcesanddealersisprovidedonour
website.Y oucanalsocontactourmainsupportofceinNorway.
Norway(mainofce)
•Companyname:KongsbergMaritimeAS/Simrad
•Address:Strandpromenaden50,N-3190Horten,Norway
•Telephone:[phone]
•Telefax:[phone]
•Website:https://www.simrad.no
•E-mailaddress:[email protected]
Spain
•Companyname:SimradSpainS.L.U
•Address:PartidaAtalayes20,03570Villajoyosa,Spain
•Telephone:[phone]
•Telefax:[phone]
•Website:http://www.simrad.es
•E-mailaddress:[email protected]
France
•Companyname:SimradFrance
•Address:5ruedeMenMeur,29730Guilvinec,France
•Telephone:[phone]
•Telefax:[phone]
•Website:http://www.simrad.fr
•E-mailaddress:[email protected]
SimradCS90

12445947/A
USA
•Companyname:KongsbergUnderwaterTechnologyInc/SimradFisheries
•Address:1921033rdAveW,SuiteA,Lynnwood,W A98036,USA
•Telephone:[phone]
•Telefax:[phone]
•Website:https://www.simrad.com
•E-mailaddress:[email protected]
Canada
•Companyname:KongsbergMesotechLtd.
•Address:1598KebetWay,PortCoquitlam,BC,V3C5M5,Canada
•Telephone:[phone]
•Telefax:[phone]
•Website:https://www.simrad.com
•E-mailaddress:[email protected]
Malaysia
•Companyname:KongsbergMaritimeMalaysiaSdn.Bhd
•Address:Unit27-5SignatureOfces,TheBoulevard,MidV alleyCity,LingkaranSyed
Putra,59200KualaLumpur,Malaysia
•Telephone:[phone]
•Telefax:[phone]
•Website:https://www.simrad.com
•E-mailaddress:[email protected]
Korea
•Companyname:KongsbergMaritimeKoreaLtd
•Address:#1101-HarborTower,113-1,Nampodong6-Ga,Jung-Gu,Busan600-046,Korea
•Telephone:[phone]
•Telefax:[phone]
•Website:https://www.simrad.com
•E-mailaddress:[email protected]
SimradCS90QuickStartGuide

445947/A13
China
•Companyname:KongsbergMaritimeChinaLtd
•Address:555ChuanqiaoRoad,China(Shanghai)PilotFreeTradeZone,201206,China
•Telephone:[phone]
•Telefax:[phone]
•Website:https://www.simrad.com
•E-mailaddress:[email protected]
SimradCS90

14445947/A
Gettingstarted
Topics
OperatingPaneldescription,page15
Startingnormaloperation,page18
Basicoperatingprocedures,page36
SimradCS90QuickStartGuide

445947/A15
OperatingPaneldescription
TheCS90OperatingPanelisthemostimportantdeviceforfastandefcientuser
interface.TheOperatingPaneloffersallnecessarycontrolfunctionsfornormaloperationof
theCS90.
ThecontrolsprovidedbytheOperatingPanelarearrangedinlogicalfunctionalgroups.This
offersyouclearandeasyoperationwithfastaccesstokeyfunctionality.Themajorityofthe
CS90functionscanbeaccessedusingthetrackballontheOperatingPanelandthemenu
systemshownintheCS90presentation.TheOperatingPanelallowsyoutoassigncertain
functionstodedicatedbuttonsandswitches.
Tip
AUSBsocketisprovidedinthetopleftcorneroftheOperatingPanel.Usethissocketto
connectacomputerkeyboard,amouseoraUSBashdrive.
APower:PressthisbuttontoturntheCS90onandoff.
•BeforeyouturnontheCS90,makesurethatyouhavesufcientwaterdepthto
lowerthetransducer!
•YoumustneverturnontheCS90whentheshipisindrydock.Thetransducermay
bedamagedifittransmitsinopenair.
•YoumustneverturnofftheCS90bymeansoftheon/offswitchontheProcessor
Unit.YoumustALWAYSusetheOperatingPanel.
BSonarSelect:SincetheOperatingPanelusesEthernettocommunicatewiththe
ProcessorUnit,youcanuseonesinglepaneltocontrolmorethanonesonarsystem.To
changewhichsonartocontrol,pressSonarSelectontheOperatingPanel.Ifyouuse
Gettingstarted

16445947/A
yourOperatingPaneltocontrolmorethantwosonars,pressSonarSelectrepeatedly
toselect.
CUserSettings:PressoneoftheUserSettingsbuttonstoapplyapredenedusersetting.
TochoosewhichfunctiontoapplyopentheOperatingPanelpage.UnderUserSetting
Buttons,assignonepredenedsettingtoeachbuttonontheOperatingPanel.The
OperatingPanelpageislocatedintheInstallationdialogbox.
DF1F2F3:PressoneoftheFxbuttonstoapplyapredenedfunction.Tochoosewhich
functiontoapplyopentheOperatingPanelpage.UnderButtonOptions,assignone
functiontoeachFxbuttonontheOperatingPanel.
ScreenCapture:PressthisbuttontomakeacopyofthecurrentCS90presentation.You
canchooseeitherasinglescreencaptureorasequencewithmultiplescreencaptures.
OpentheScreenCapturesdialogboxtoselectscreencapturemode.
EJoystick:Pressthejoystickforwardtoincreasethetiltangleintheactiveview.Turn
thebuttononthetopofthejoysticktochangethebearingintheactiveview.
FMousebuttons:Thesebuttonscorrespondtothetwomostcommonbuttonsona
standardcomputermouse.Whenaninstructiontellsyouto"select"or"left-click",press
theleftbutton.Whenaninstructiontellsyouto"right-click",presstherightbutton.
GUsethesebuttonstolowerandhoistthetransducer.Whilethetransducerismovingthe
indicatorlampashes,andanaudiblesignalissounded.Whentherequestedposition
hasbeenreached,theindicatorlampislit,andtheaudiblesignalstops.
•Up:PressUptohoistthetransducertoitsupperposition.
•Middle:PressMiddletoplacethetransducerinapredenedmiddleposition.
•Down:PressDowntolowerthetransducertoitsbottomposition.
HRotaryswitches:Turnarotaryswitchtoapplyapredenedfunction.Tochoosewhich
functiontoapplyopentheOperatingPanelpage.UnderRotarySwitchOptions,assign
onefunctiontoeachrotaryswitchontheOperatingPanel.
IUsethesebuttonstoplacemarkersinthecurrentactiveview.
•Marker:PressMarkertoplaceagenericmarkerintheactiveview.Oneormore
markerscanbeplacedintheviewtoidentifyspecicechoes.Eachmarkerisshown
asasmalltrianglewithorwithoutashortidentifyinglabel.Itispositionedbasedon
thetwoknownaxesintheviewaswellasthetiltandbearingofthecurrentping.
•CircleMarker:PressCircleMarkertoplaceacircularmarkerintheactiveview.The
circleisdrawnwiththesamediameterasyourpurse.Bymeansofthecircleyou
canseethesizeoftheschoolrelativetoyourpurse.
•Gear:PressGeartoplaceagearsymbolintheactiveview.Thegearsymbolis
providedasatooltohelpyouplanandshootthepurseseine.Thesymbolisintended
tobeusedinastructuredsequencethatstartswhenyouplantoshootthepurseseine.
JPressthesebuttonstostartpositionortargettracking.
SimradCS90QuickStartGuide

445947/A17
•PositionTrack:UsethetrackballtocontrolthecursorintheCS90userinterface.A
positiontrackpermitstheCS90toautomaticallycontrolthetiltandbearingbased
onthemovementsofyourvessel.Itlocksonapositiondenedbyitslatitude,
longitudeanddepth.Thebearingandtiltsettingsareautomaticallyadjustedto
compensateforthemovementsofyourvessel.
•TargetTrack:AtargettrackpermitstheCS90toautomaticallycontrolthetiltand
bearingbasedonthemovementsofthechosentarget.Itlocksonthetargetdened
byitsposition,headingandspeed.Thebearingandtiltsettingsareautomatically
adjustedtofollowthemovementsofthetrackedtarget.
Anewtrackedobjectisautomaticallygivenprioritystatus.Relevantinformationabout
thepriorityobjectcanbefoundinthelowerleftcorneroftheview.Ifyouchangethe
tiltorbearingsettingsmanuallytheprioritystatusislost.
KTrackball:UsethetrackballtocontrolthecursorintheCS90userinterface.
Note
TheCS90supportstwodifferentoperatingpanels.Thesearereferredtoas"Mk1"and
"Mk2".Inthispublicationalldescriptionsandreferencesarerelatedto"Mk2".
Beforeyoucanchangethesettingsrelatedtoaview,youmustclickinsidetheviewto
activateit.Thechangesyoumakearebydefaultonlyvalidfortheactiveview.Severalof
thefunctionsofferApplytoAll.IfyouselectApplytoAllyoursettingisappliedtoall
theviewsinthecurrentpresentationmode.
Gettingstarted

18445947/A
Startingnormaloperation
Topics
TurningontheCS90fornormaluse,page18
Gettingtoknowtheuserinterface,page20
Gettingtoknowpresentationmodesandviews,page22
SelectingNormalmodetostart"pinging",page26
Adjustingtheradiusofthesearcharea,page28
Adjustingtheechosensitivity,page29
Changingtheverticalangleofthesonarbeams,page31
Adjustingthehorizontaldirectionofthesonarbeam,page33
TurningofftheCS90,page35
TurningontheCS90fornormaluse
InordertousetheCS90,youmustrstturniton.ToturnontheCS90usethePower
buttonontheOperatingPanel.TheCS90programstartsautomaticallywhentheProcessor
Unitisturnedon.
Caution
YoumustneverstartCS90transmissions(pinging)whentheshipisindrydock.The
transducermaybedamagedifittransmitsinopenair.
Procedure
1Makesurethatyouhavesufcientwaterdepthbelowthekeelbeforeyoulowerthe
transducer.
2Turnonthedisplay(s).
Ifrequired,refertotheinstructionsprovidedbythedisplaymanufacturer.
3OntheOperatingPanel,pressPower,andkeepitdepressedforafewseconds.
SimradCS90QuickStartGuide
