Simrad SP60 - REV D User manual

Simrad SP60
Low frequency fishery sonar
Installation manual
A L W A Y S A T T H E F O R E F R O N T O F T E C H N O L O G Y
www.simrad.com

Simrad SP60
Low frequency fishery sonar
WARNING
The sonar must never be powered up when the ship is
in dry dock. The transducer will be damaged if it
transmits in open air. To prevent inadvertent use of the
sonar, pull out the mains plug on the Sonar Processor
Unit whenever the vessel is in dry dock.
851--164574 / Rev.C

Note
Simrad AS makes every effort to ensure that the information contained within this
document is correct. However, our equipment is continuously being improved and
updated, so we cannot assume liability for any errors which may occur.
Warning
The equipment to which this manual applies must only be used for the purpose for which
it was designed. Improper use or maintenance may cause damage to the equipment or
injury to personnel. The user must be familiar with the contents of the appropriate manuals
before attempting to operate or work on the equipment.
Simrad AS disclaims any responsibility for damage or injury caused by improper
installation, use or maintenance of the equipment.
Copyright
E2003 Simrad AS
ISBN 82-8066-006-2
The information contained within this document remains the sole property of Simrad AS.
No part of this document may be copied or reproduced in any form or by any means, and
the information contained within is not to be communicated to a third party, without the
prior written consent of Simrad AS.
Support
For support on your Simrad equipment, consult your local dealer, visit www.simrad.com,
or contact us directly at [email protected].
Simrad AS
Strandpromenaden 50
Box 111
N-3191 Horten
Telephone: [phone]
Facsimile: [phone]
A L W A Y S A T T H E F O R E F R O N T O F T E C H N O L O G Y

Installation manual
I
851-164574 / C
Sections
This document is the Installation manual for the Simrad SP60 sonar system. It provides the
information and technical specifications necessary to install the various system
components.
1Introduction(Page 1)
2 Installation planning (Page 22)
3 Installation of the Sonar Trunk (Page 29)
4 Installation of the Hull Unit (Page 34)
5 Installation of the Transceiver Unit (Page 42)
6 Installation of Wheelhouse Units (Page 46)
7 Cable layout (Page 55)
8 Connecting Auxiliary equipment (Page 75)
9 Start-up procedures (Page 87)
10 Testing the auxiliary equipment (Page 124)
11 Final testing and measurements (Page 138)
12 Technical specifications (Page 150)
13 Drawing file (Page 171)
14 Installation remarks and signature (Page 196)

Simrad SP60
II 851-164574 / C
Remarks
References
Further information about the SP60 system may be found in the following manuals:
•SP60 Operator manual
The reader
This Installation manual is intended for the design and installation engineers at the shipyard
performing the installation. The information is supplied as the basis for the shipyard’s own
installation drawings applicable to the vessel. On completion of the installation, this
manual must be kept on the vessel for reference purposes during system maintenance.
Additional copies
Additional copies of this manual may be ordered from Simrad AS quoting the book’s order
number 851-164574. It can also we ordered in major bookstore quoting the ISBN number
82-8066-006-2.
An electronic version in PDF format may be obtained from Simrad AS or any of our
distributors.

Installation manual
III
851-164574 / C
Table of contents
1 INTRODUCTION 1.........................................
1.1 Purpose and description 1....................................
Introduction 1.............................................
Installation procedures 1....................................
1.2 System diagram 2...........................................
1.3 Scope of supply 4...........................................
Main units 4..............................................
General 4................................................
Options 4................................................
1.4 Peripheral equipment 6......................................
Required inputs 6..........................................
Additional inputs 6.........................................
1.5 Supply conditions 8.........................................
Purpose 8................................................
Equipment responsibility 8..................................
Receipt, unpacking and storage 8..............................
1.6 General safety rules 9........................................
1.7 Installation requirements 10....................................
Responsibility and approval 10................................
Supply power 10...........................................
Environmental requirements 10................................
Compass deviation 10.......................................
Noise sources 10...........................................
Dry docking 11.............................................
Wiring 11.................................................
1.8 Equipment handling 12.......................................
Introduction 12.............................................
Transportation 12...........................................
Initial preservation 13.......................................
Inspection and unpacking 15..................................
1.9 Storage 17.................................................
Pre-installation storage 17....................................
After use storage 17.........................................
Re-packing 19.............................................
ESD precautions 20.........................................
Temperature protection 21....................................
