RANGEHOOD INSTALLATION INSTRUCTIONS
Congratulations on your purchase!
Thank you for choosing a Sirius product.
SM927 520 EAN #9351116000356
SM927 850 EAN #9351116000370
www.siriusbrand.com

2
BEFORE YOU INSTALL
LINE DRAWINGS
DUCTING AND CLEARANCES
INSTALLING THE RANGEHOODS
USING THE RANGEHOOD / MAINTENANCE
REPLACING THE LED LIGHT
WIRING DIAGRAM
WARRANTY INFORMATION
3
4
5
6
8
9
10
11

3
The symbol on the product or on its packaging indicates that this product
may not be treated as house-hold waste. Instead it shall be handed
over to the applicable collection point for the recycling of electrical and
electronic equipment. By ensuring this product is disposed of correctly,
you will help prevent potential negative consequences for the environment
and human health, which could otherwise be caused by inappropriate
waste handling of this product. For more detailed information about
recycling of this product, please contact your local city office, your
household waste disposal service or the shop where you purchased the
product. This appliance is marked according to the European directive
2002/96/EC on waste electrical and electronic equipment (WEEE).
Sirius warranty covers only Sirius product. If you choose to install a non-Sirius branded accessory
such as flexible ducting, Sirius will only warrant the rangehood and motor. If installation is found to be
the cause of failure or issue then charges will apply for service and parts.
Flexible ducting is not permitted under any circumstances. Flexible ducting has been found to
increase noise levels, increase vibration and reduce airflow. Sirius Semi-rigid or solid ducting can be
used in lieu. There is a range available to suit any application.
Ducting available at www.siriusbrand.com
6 Year Warranty when Sirius Ducting is used. Full replacement warranty on parts and labour.
See website for terms & conditions.
A reduction in the duct diameter from stated ducting size will void warranty.
If you are in doubt about the ducting, please contact Sirius on 1300 762 219 prior to installation
WARNING
The appliance must be installed and
connected to the power supply only by a
qualified technician.
• There should be adequate ventilation of the room when the rangehood is used at the same time as
appliances burning gas or other fuels (not applicable to appliances that only discharge the air back into the
room)
• The details concerning the method and frequency of cleaning
• There is a fire risk if cleaning is not carried out in accordance with the instructions;
• Do not flambé under the range hood;
• CAUTION: Accessible parts may become hot when used with cooking appliances.
BEFORE YOU INSTALL - DUCTING INFORMATION

4
LINE DRAWINGS
SM 927

5
Min. 600mm - Max. 700mm for induction cooktops.
Min. 650mm - Max. 750mm gas cooktops.
If the rangehood is positioned above the max height
recommended, warranty may be compromised
as performance of the rangehood will be affected.
Measurement is taken from the top of the trivets to
the underside of the hood. (Fig.1)
• The air being drawn can’t be conveyed through
or into a duct used to let out fumes from
appliances fed by energy other than electric
power (eg. centralized heating, radiators, water
heaters, etc.).
• Attention: remove any possible PVC film from the
stainless steel, including the filters.
• To externally vent, please comply with the
pertaining rules given by competent authorities.
• Provide the room with an adequate ventilation
when a rangehood and appliances fed by energy
other than electric power (gas, oil, or coal stoves,
etc.) are used simultaneously. The rangehood,
when evacuating the air, could generate a
negative pressure in the room which can’t exceed
the limit of 0.04 mbar, in order to avoid the
suck of exhausts deriving from the heat source.
Therefore the room should be provided with air
intakes to allow a constant flow of fresh air.
If the rating label in the rangehood shows the symbol
, the appliance is built in class II° and it does not
need any earth connection.
If the rating label in the rangehood does not show
the symbol , the appliance is built in class I° and it
needs the earth connection.
When performing the electrical connections on the
appliance, please make sure that the current-tap
is provided with earth connection and that voltage
values correspond to those indicated on the label
placed inside the appliance itself.
Before carrying out any cleaning or maintaining
When ducting rangehood, options are as follows:
Roof vent - EASYROOF 150T/M
*Kit includes roof flashing
Download installation guide
Eave vent - EASYEAVE 150
Download installation guide
Wall vent - EASYWALL 150
Download installation guide
operations, the appliance needs to be switched off.
If the appliance is not provided with a non-separable
flexible cable and plug, or with another device
ensuring omnipolar disconnections from the grid,
with an opening distance between the contacts of at
least 3mm, then such disconnecting devices must be
supplied within the fixed installation.
If the fixed appliance is endowed with a supply cord
and a plug, the appliance has to be put in a place
where the plug can be reached easily.
The use of materials which can burst into flames
should be avoided in close proximity of the appliance.
When frying, please pay particular attention to fire
risk due to oil grease. Being highly flammable, fried
oil is especially dangerous. Do not use uncovered
electric grills. In order to avoid possible fire risk, all
instructions for grease-filter cleaning and for removing
eventual grease deposits should be strictly followed.
WARNING
600 - 700mm (induction)
600 - 750mm (gas)
600 - 700mm (induction)
600 - 750mm (gas)
(Fig. 1)
(Fig. 2a)
(Fig. 2b)
(Fig. 2c)
SIDE VIEW FRONT VIEW
DUCTING AND CLEARANCES

6
To install the appliance please respect the follow
instructions:
• The appliance must be installed by qualified
technicians, or where possible use a Sirius
recommended installer. See siriusbrand.com.
In order to avoid damage to the electronic parts
of the appliance, please do not use additional
screws.
• Essential precautions to respect before installing
the appliance are the following:
To have made a cutout on the bottom of the
cabinet which is suitable to hold the appliance in
position (fig. 2):
SM923 520 - (W) 502 x (D) 265mm
SM923 850 - (W) 835 x (D) 265mm
SM927 INSTALLATION
Before installing the appliance, make sure that
none of the parts are damaged in any way. In
case of damaged parts, contact your retailer
and do not proceed with installation. Read all
of the following instructions with care before
installing the appliance.
• Use ducting within the min/max specifications
• Limit the number of ducting bends.
• Do not make any changes in ducting diameter
(recommended constant diameter: Ø 150 mm
or equal surface area).
Before installing the appliance - in order not to
damage the appliance itself - the metal grease filter
should be removed. These filters could be removed
by pushing the handles towards the back side of the
rangehood and pulling it downwards to unfasten it
from its slot. (Fig.1).
NOTE
(Fig.1)
(Fig.2)
1. Prepare the power supply - 240 volts.
2. Prepare a hole for the exhaust - 160mm diameter.
• Do not use screws to fix the ducting to the
rangehoods as they will prevent the movement of
non-return valves.
• Limit the number of elbows in the ducting, since
each elbow reduces the duct efficiency by 1
metre. (i.e. if you use two 90° elbows, the length
of ducting must not exceed 5 metres.)
• Avoid abrupt direction changes.
• Use 150mm constant diameter ducting for the
whole length.
• The use of Sirius ducting will increase the
warranty of the unit to 6 years.
WARNING: Failure to install the screws or fixing
device in accordance with these instructions
may result in electrical hazards.

7
(Fig.3)
NOTE
WARNING
The rangehood is quite heavy, so two people
will be needed for installation.
1. To install the appliance, adjust the position of the
adjustable side-springs using the supplied screws
(fig.4), according to the thickness of the board, in
which the appliance will be fixed.
2. Insert the rangehood into the cutout in the
cabinet until the stop click of the side-springs is
heard and the rangehood is supported (Fig 5).
3. Insert the 25mm screws provided into the front
and rear holes inside the rangehood (Fig.5A) to fix
it to cabinetry.
4. Insert the grease filter (Fig.1)
(Fig.4)
• To make it easier to install the rangehood inside
the cabinet, it is recommended to remove the
glass. Unscrewing the four M3x10 screws as
shown in Fig. 3.
(Fig.5)
(Fig.5A)

8
• Accurate maintenance guarantees good
functioning and long-lasting performance.
• Particular care is due to the grease filter panel. It
can be removed by pushing its handle toward the
back side of the rangehood and pulling the filter
downwards so to unfasten it from its slot (Fig.1).
To insert the filter just perform the opposite
operation.
• The grease filter needs cleaning by regular
handwashing or in dishwashers every two
months or 30 continuous hours, depending on its
use. Button lights will flash when filter needs to
be cleaned. To reset, press and hold the the 01
button for 2 seconds when the motor is off.
Filters may require cleaning sooner if
frequent heavy frying is done.
• To clean the appliance itself, water and detergent
are recommended, while abrasive products
should be avoided. For steel appliances
specialized detergents are recommended (please
follow the instructions indicated on the product
itself to obtain the desired results).
To remove the rangehood from the cabinet,
remove the fixing screws (fig. 5A) using a
screwdriver, and remove the grease filters
(fig.1).
• Push down on the small handle of the springs,
which are inside the rangehood, with the
necessary strength to unhook the hood from the
cabinet.
If the supply cord is damaged, it must be
replaced by the manufacturer or its service
agent or a similarly qualified person in order to
avoid a hazard.
MAINTENANCE
WARNING
NOTE
SM927 (fig. 6)
A: Motor switch on speed 1/off - (low/simmer)
B: Motor switch on speed 2 - (general cooking)
C: Motor switch on speed 3 - (high power)
D: Motor switch on speed 4 - (booster)
E: Light on/off switch
USING THE RANGEHOOD
(Fig.6)

9
REPLACING THE LED STRIP ON THE
SM927
1. Before replacing the LED light, switch off the
rangehood, then - by using appropriate tools -
remove the LED light from its slot. (Fig 7a - b)
• Note: light is easier to remove from the centre
of LED strip. Use a small, flathead screwdriver,
pallette knife or blunt butter knife.
(Fig.7a) (Fig.7c)
(Fig.7b) (Fig.7d)
2. Take out the LED light from its connector and
replace. (Fig 7c - d)
• To find the correct LED light, please contact Sirius
directly on our toll-free number: 1300 762 216.

10
WIRING DIAGRAM
