SK SK - 5000 ADVANCE User manual

SK -5000 ADVANCE
User Manual


Advanced features of SK-5000 ADVANCE
Mobile camera
SK-5000ADVANCEwith camera attached!
The phone, which isequipped with a mobile camera rotating in a
360-
degree arc, enables you to take a picture anytime anywhere
and to save the image in order to decorate the Logo or make a
video phonebook.
Exchange of photo Mail
Transmit beautiful photos to a SK -5000 ADVANCE of a friend
of mine!
You can send a picture, which is taken with a mobile camera and
decorated in various frame, to a mobile phone or E-mail together
With a message to the others, and also receive a photo mail
from them.
Large 65000 Color LCD
Large 2”LCD with 65000 color display!
With a wider 2”
LCD and splendor 65000 color, you can enjoy a
satisfactory and vivid LCD screen.
40 chordmelody
More vivid melody!
The phone provides diverse and more vivid music in various
fields with 40-chord melody.
Wizard
Support of diverse WWWsupplementary services!
You can enjoy a hundredfold realistic wireless Internet at
anytime and anywhere by downloading various multimedia
contents to SK -5000 ADVANCE.
New menu structure
More friendly SK -5000ADVANCEmenu structure!
Totally enhanced menu structure! with a menu structure similar
to Windows Systems such as popup menu and icon display of
men
u, you can easily find out a required function enabling the
full utilization of SK -5000 ADVANCE diverse functions.
CDMA2000 1x super high
speed data communication
SK-5000ADVANCEis a mobile phone faster than a modem.
The phone implements the CDMA 2000 1x super high
speed communication function of 153.6Kbps with MSM 5000
equipped, enabling you to navigate the wireless Internet in super
high speed or to swiftly download the multimedia data.
Other features
Still smart and various functions!
IrDA communication, auto answering/recorder,
99 memory location numbers, stopwatch, electronic pocketbook
(Calendar/scheduler, alarm, and calculator), various animations,
my melody, etiquette, music bell, earphone mic, etc.


SK -5000 ADVANCE User’s Manual Table of Contents
The contents of this user’s manual are subject to change without prior notice for enhancement of
product performance.
Introduction
Precautions for usin the mobile phone..........................................................................................................................
Package Contents.................................................................................................................................................................
Part Names and Functions ...............................................................................................................................................10
Display Indicators……………………………………………………………………………………….………12
Multi-Function Keys……………………….…………………………………………………………….……...13
How to activate and select menu....................................................................................................................................14
How to use the linked menu.............................................................................................................................................14
Using the battery..................................................................................................................................................................14
Cautions……………………………………………………………………………………….…………...14
Inserting the battery…………………………………………………………………………….…...…….15
Removing the battery ………………………………………………….…….………..……….…………15
Battery life….…………………………………………………………………………………….…….…..15
Low battery alarm……………………………………………………….……………………….………..16
Charging the battery…………………………………………………….…….………………..…………16
Minimum Battery ChargingTime……………………………………..……………………….…………17
BasicOperation
Switching the phone on......................................................................................................................................................18
Switching the phone off......................................................................................................................................................18
Makingacall..........................................................................................................................................................................18
Redialing calls .......................................................................................................................................................................18
Last number redialing……………………………………………………..……………………………...18
Search call history and redial………………………………………………………………...…………..19
Speed dial ...........................................................................................................................................................................…19
One digit speed dial (Address 1~9) …………………………………………………….……….……...19
Two digit speed dial (Address 10~99) ……………………………………………..…………………...19
Answering calls……………………………………………………………………………………….…………20
Hot menu……………………………………………………………………………………………..………….20
Adjusting the earpiece volume…………………………………………………………………..……….20
Checkreceivedmessages……………………………………………………………………………….21
Mute…………………………………………………………………………………………..…………….21
Etiquette mode......................................................................................................................................................................21
Enabling Etiquette mode at standby mode……………………………………………………………..21
Enabling Etiquette mode during the call..............................................................................................................21


Search call history (list)......................................................................................................................................................22
My Information.......................................................................................................................................................................22
Timers.......................................................................................................................................................................................23
PIM PhoneBook
Adding an entry.....................................................................................................................................................................24
Electronic dialing using Pause…………………………………….…………………………………………..24
Speed Search……………………………………………………………………………………….…………..25
Search by name....................................................................................................................................................................25
Search by number................................................................................................................................................................25
Add phonebook.....................................................................................................................................................................26
Add a phone number to the new name……………………………………………….………………...26
Add a photo………………………………………………………………………………….……………..26
E-mail address add/edit……………………………………………………………….………………….26
Adding an Entry in Logo……………………………………………………………………………….……….27
Add a number to the new Name…………………………………………………………………………27
Add a number to the exsting Name…………………………………….……………………………….27
EditPhonebook………………………………………………………..…………………………………..28
Anniversary………………………………………………………………………………………………...28
Phonebook memo.……………………………………………………………………………………..…28
Delete names………………………………………………………………………………………….…..29
Edit Speeddial……………………………………………………………………………………………..…...29
Add new speed dial…….…………………………………………………………………..…………..…29
Change the existing speed dial………………………………………………………………………….29
Delete the exisring speed dial..………………………………………………………..……….……..…30
Editgroup................................................................................................................................................................................30
Add new group………………………………………………………………………………………….…30
Change group…………………………….……………………………………………………….……….31
Delete group……………………………………………………………………………………………….31
Camerafunction
Getting started.......................................................................................................................................................................32
Takinggoodpictures……………………………………………………………………………………...32
Precautions……………………………….…………………………………………………..………..…. 32
How to manage………………………….…………………………………………………..……..…….. 32
Batterylifetimeatcameraoperation….………………………………………………………..……... .32
Taking pictures ......................................................................................................................................................................33
Photo Mail…………………………………………………………………………………………….…………33
New Photo Mail…………………………………………………………………………...……………….33


Edit the Existing Photo Mail……………………………………………………………….……………..35
Received Photo Mail……………………………………………………………..……………………….35
My photo album ......................................................................................................................………………………….35
Designate photo……………………………………………………………….…………………………..35
Change file name…………………………………………………………….……………………………35
User’sfileinformation……………………………………………………….…………………………….36
Delete all photos…………………………………………………………..…….………………………...36
Photo Lock……………………………………………………………………...………………………….36
PIM/Entertainment
Calendar................................................................................................................................................................................37
Retrieve calendar…………………………………………………………...………………………….... 37
Scheduler................................................................................................................................................................................37
Add new schedule………………………..…….……………………………………………………….. .37
Set my holiday…………………………………………………………...……………...………….……..37
Checkschedule………………………………………………………..……………………………….....38
Delete partial schedule…………………………………………………………………...…………..…. 38
Alarm........................................................................................................................................................................................38
Set new alarm……………………………………………………..……………………………………….38
Set alarm ringer……………………………………………………...…………………………………….39
Calculator................................................................................................................................................................................39
Stopwatch...............................................................................................................................................................................39
World time...............................................................................................................................................................................40
My memo................................................................................................................................................................................40
New memo…...…………………………………………………………….……………………….……..40
Check/Edit memo…………………………………………………………..……………………………..40
Game........................................................................................................................................................................................41
Convenient features
Auto answering…………………………………………………………………………………………..……..43
Set auto answering………………………………………………………………….…………………….43
Auto answering operation………………………………………………………………………………...43
Check Message…………………………………………………………………………………….. ……43
Release Auto answering……………………………………………………………..…………………...43
Voice Recorder......................................................................................................................................................................44
Record…………………………………………………….…………….………………………………... .44
Play……………………………………………………………………….………………………………...44
Delete the Reading………………………………………………………..………………………………45
Earphone Mic (accessory)................................................................................................................................................45


Message Function
Text Message.........................................................................................................................................................................46
Voice Message......................................................................................................................................................................46
CreateNewMessage…………………………………………………………………………………….…….47
Save Phrase………………………………………………………………………………………….…...47
Retireve Sentence……………………………………………………………………………………..….47
Search Phonebook………………………………………………………………………………………..47
Search by Incoming call history…………………………………...……………………………………..48
Save message…………………………………………………………………………………………..…48
DeleteseletNumber………………………………………………………………………………………48
All phone Number…………………………………………………………………………………………48
Outbox ………………………………………………………………………………………….….…………..49
Editoldmessage……………………………………………………………………………………….….49
Delete All Old Messages………………………………………………………………………………….49
Sent Message........................................................................................................................................................................49
Phrase......................................................................................................................................................................................49
Delete All Messages ...........................................................................................................................................................50
SMS Alert................................................................................................................................................................................50
Data Communication Service Function
WWW Menu……………………………………………….…………………………………………………….52
Connect WWW…………………………………………………………………………….………………52
Wizard Box………………………………………………………………………………….…….………..52
Multimedia……………………………………………………………………………….……….………...52
Ringtones……………………………………………………………………………….………………….53
Animations…………………………………………………………………………..……………………..53
Voice Portal…………………………………………………………………...……………………………53
What`s New…………………………………………………………………………..……………………54
SMS Info…………………………………………………………………………..………………………..54
IrDA Communication...........................................................................................................................................................54
Communication with SK-5000ADVANCE……………....………………………………………………54
Communication with PC…………………………………………………………………………………..55
Set the Function of IrDA Communication at PC……………….……………………………………….55
SetMenu
Set Call Alert..........................................................................................................................................................................57
Select Ringer/Vibrate……………………………………………………………………………………..57
Group Ring…………………………………………………………………………………………………57


Manage My Ringer………………………………………………………………………………………..57
Set volume…………………………………………………………………………………………………58
Set alert…………………………………………………………………………………………………….58
Set Screen..............................................................................................................................................................................59
Set Logo……………………………………………………………………………………………………59
Set Picture………………………………………………………………………………………………….59
Manage My Picture.……………………………………………………………………………………….60
Manage My Photo…………………………………………………………………………………………61
Adjust Screen Contrast…………………………………………………………………………………...61
Set Backlight……………………………………………………………………………………………….61
Set Screen Background…………………………………………………………………………………..62
Auto Answering.....................................................................................................................................................................62
Setting auto answering function…………….……………………………………………………….…..62
Record/Play
Announcement……………………………...………………………………………………63
Set Environment...................................................................................................................................................................63
Auto Function……………………………………………………….……………………………………..63
Set Options………………………………………………………….……………………………………..64
Lock Function…………………………………………………………..………………………………….64
Change Password………………………………………………………………………………….……..65
Initialize Phonebook…………….…………………………….…………………………………….…….65
Initialize System……………………………………………….…………………………………….…….65
Data service…………………………………………….…….……….………..………………….………65
Select System……………………………………………….……………………………………..………66
Check S/W version………………………………………….……………………………………….……67
WWW Font Config………………………………………………………………………………..……….67
Appendix
Menu Construction...............................................................................................................................................................68
Options.....................................................................................................................................................................................70
Q&A For Phone………………………………………………………………………………………………....71
Prevent Illegal Handling of ESN......................................................................................................................................71
Specification and Features…………………………………………………………………………………….72
Mobile Phone Data ……………………………………………..………………………………………………72


Before Use
Precautions for using the mobile phone
Read these precautions carefully to use this unit with full performance.
Fully charge the battery before you use the unit for the first time or when the mobile phone has
been left unused for a long time.
The unit may not be repaired when flooded. Avoid hot and damp area.
Note that the unit disassembled or remodeled by other than qualified service personnel cannot be
covered by warranty.
Avoid severe impact and keep the unit in a safe place.
Since the unit in your hippocket may be out of order due to excessive forces, make sure not
to cause damages to your unit.
Do not grip or touch the antenna during the call to keep the clean voice quality.
Clean the unit with soft clothes or towel and do not use chemical cleaners including thinner or
solvent.
Since this unit is sensitive to electric wave, any antenna or accessories not approved by SK
Teleteh may deteriorate the performance. Also keep the unit away from steel desk, computer or
microwave oven, which may cause electromagnetic interference.
* Keep theringer volume low not to disturb others.
* If you use or keep the cellular phone in extremely cold or hot areas, the unit performance may be
deteriorated and lifespan shortened.
Safety information
1. Using a cellular phone during driving may not only increase the risk of traffic accident but also affect
the electronic devices in a car. Give full attention to driving. If you must use a phone, please use
hands free for your safe driving.
2. Since hospitals or health care facilities may be using equipment that could be sensitive to external
RF energy, turn your phone off in those facilities.
3. Since using a phone while in the air may affect the electronic flight devices, please turn it off in the
airplane.
4. Turn your phone off in any places where posted notices so require.


Package Contents


Part Names and Functions
Part Name
.
Message / function key:
Press the key when using
charactermessages.
Select the lower left
item on LCD screens
excluding the Logo.
Send key :
Press the key to make
a call or to redial
the last number called
Inner LCD
screen :
Displaying the mobile
phone status.
Function key :
Select lower right item
on LCD screens excluding
the Logo.
Record/Play
key :
Press and hold the
key to start/finish
playing the record.
Numberic
Mic(Sender)Mic(Sender)
Earpiece(Receive)
Multi-functionkey :
Select various
functions with five
multi-function keys.
Folder
Open the folder
to answer the call,
and close it to
end the call..
End key :
Switches the phone
on/off, ends a call, and
backs out to main menu.
Lock Key:
Press it long in standby
mode and the phone is
locked (unlock the phone
with password).
Etiquette mode Key :
Press and hold the key during
the standby mode to activate
vibration and silent keypad,
during a call to activate silent
keypad and whisper mode.
Delete/Cancel Key :
Press the key to delete
the letter entered or to
cancel a function.


Part Function
Antenna :
Extendthe antenna
where the signal
is weak.
Mobile Camera/
Earphone Mic Jack :
Connect a MobileCamera
orearphonemic.
IrDA Communication Port :
Used for IrDA
Battery
(Refer to page 14~17)
In-car Connector :
Connecting adapter.
* Always put rubber plug in this part to prevent contact
from metal which causes power off. Whenthe power
is off, remove the battery and insert it again and
switch the power on.
Insert cellular phone hand strap :
Pass the cellular phone hand strap through the hole
near the antenna from the bottom and insert it to the ring at
the other end.
Antenna :
Extend the antenna vertically for best call quality.
Sub LCD Screen
Auto Answering Key:
Press and hold the key to
Activate /deactivate auto
answering


Display Indicators
1. Signal strength of the service area
Indicators
Signal strength level Good Poor Out of service
area
Indicators in the service area of other provider
Indicators
Signal strength level Good Poor Out of service
area
2. Appears in standby mode.
Appears when you make a call or during a call.
3. Appears when auto answering answering is set.
4. Appear when ringer is Set.
5. Appears when alarm is set.
6.. Text message received
Indicators Description
This icon will flick when new text message arrives and disappear after
Checking the message.
7. The remained battery power
Indicators
Meaning Ringer Vibration Ringerafter
Vibration Simultaneous
Ringerand
Vibration
Etiquette
mode
Indicators
Availablebattery
power High Medium Low Needs charging


Multi-function keys
Select Menu
Select outgoing call history
Select incoming call history
Select phonebook
Select Camera
<On active screen>
Select the lower Right item on the LCD screen
Select the lower Left item on the LCD screen
Move to the left
Move to the upward
Move to the downward
Move to the Right
Setting/Cancel OK


How to activate and select menu
Ex) Enter a phonebook: James, friend, Home number 123-4567, and memo.
1. Press (Right)[Book] and (4)[New Entry].
2. Press (OK)[Sel].
3. Enter Name, and press (OK)[Done].
-Press (OK)[Done] to automatically move to the next item.
4. Press (OK)[Sel] and (Up/down).
-After moving to the required group, press (OK)[Sel].
6. Press (OK)[Sel] and (Up/down).
-The cursor is moved automatically to the next item.
-After moving tothe required icon, press (OK)[Sel].
7. Press (OK)[Sel], enter the number and press (OK).
-The cursor is moved automatically to the next item.
8. Press (OK)[Sel].
-After moving tothe required icon, press (OK)[Sel].
9. Press (OK)[Sel], enter the memo and press (OK)[Done].
10. Press (SMS)[Save].
How to use the linked menu
If Menu is displayed on the low screen, you can open the linked menu.
-Press (Left)[Menu] to display executable functions on the screen.
Ex: In case of selecting the connect menu of calendar/scheduler
1. Press (Left)[Menu], (1)[Info. Manager] and (1)[Scheduler]
2. Press (www)[Menu].
Using the battery
Cautions
Always use the authorized, dedicated charger and batteries.
-Unauthorized productmay damage or explode the battery.
Keep the charger and battery clean.
-Dust or dirt on the metal part of the connector terminal may obstruct battery charging.
Do not disassemble the battery and charger, and keep them away from fire.
-Batterymayexplode.


Do not drop the battery or give a severe shock.
-This may cause battery fault or short battery life.
Keep the battery in room temperature (5 -35 C).
-If you place the battery in too cold or too hot places,battery capacity and life may be reduced.
-Remove thebattery from the phone when unused for a long time.
Replace the old battery with a new one when batterycapacity has reduced by half.
-As a consuming item, repeated charging/discharging may reduce the battery capacity.
Dispose the used batteries separately.
-Recyclable metal is used for the battery.
Inserting the battery
The tabs of the batte ry should
line up with the groove of the phone.
Removing the battery
Battery life
<By mode>
Type of battery Mode Standardbattery
Call About 169minutes
Standby About 85–176 hours*
* Maximum value measured in the SK Teletech`s laboratory (in slot mode 2).

Push the battery until you hear
Push the button upward and pull the battery out.


<By function>
Type of battery Function Standardbattery
Camera operation and use About 222 minutes
*The game current consumption is an average value of Apache, Baby raccoon, Mars Scouter, and
Puzzle.
* The backlighting is on when the folder is open.
-When you are on the move by car or on foot, your mobile phone sends/receives signals with the
base stations adjacent to maintain the optimum call status. In this case, more power consumes, and
the battery life may be reduced.
-Usinga motion picture [animation] of “Set Picture”in Logo may consume more power than not using
it. Therefore, battery life can be reduced by 20-30% than those described in this manual.
Low battery alarm
Appears with alarm when battery requires charging. The phone would be switched off with a
message“The phone is switched off due to low power”if you fail to charge the battery.
Charging the battery
Connect the power plug of battery charger to the outlet.(110V or 220V)
-To charge the battery with handset or to charge the battery only.
(The charging front lamp turns red when the charging starts)
-The lamp turns green when charging is completed.
-Push the battery into the charger fitting in correctly to the guide hop.
* When you fast-charge the standard battery fully discharged , its temperature may be increased a
Little. However, this does not affect the battery performance.
* Dust or dirt on the connecting terminal of the battery charger may cause malfunction.
Keep the battery charger out of reach of the children or animals.
Battery charging
Lamp


Minimum Battery
* Fully charging the battery. Battery is not charged when you purchase the product.
* Charging in too cold or too hot place may take longer charging time.
* When you charge the battery with the handset on, the battery may not, be fully charged even
though the charging completion lamp (green color) is on.
Type of battery Standardbattery
Minimum battery charging About 180 minutes


Basic Operation
Switching the phone on
1.Press and hold the (End) key.
* When vibration or Etiquette mode is selected, the vibration indicator
(etiquetteindicator ) is displayed and the phone vibrates.
* Various animations can be displayed.
* The start screen varies by the setting.
Switching the phone off
1. Press and hold (End) key.
-Animation is displayed forseveral seconds before power is off.
Making a call
1. Press local area code and phone number,and then press (SEND).
-If you make a mistake while entering a phone number, just press (CLR) to delete the last digit.
2. Start talking with the other side.
-To adjust the volume during a call, press (Up/Down)[Vol].
3. To finish the call, close the folder or press (END).
* Camera does not work during the call.
* To make the call in the Phonebook, see Personal Information Manager Phonebook.
* Set automatic local area code of the features to make a call by dialing a phone number without local
area code.
Redialing calls
You can redial the last number called without dialing the digits separately.
Last number redialing
You can redial the last number called.
1. Press (SEND).


Search call history and redial
Up to30 recently called/answered numbers are displayed. Press (SEND) to redial.
<For incoming calls>
1. Press (Down)[Call ID List].
-Press (UP/Down) to find the required number.
-The number entered in phonebook displays name and icon of the other side.
2. Press (OK)[Sel].
-You can verify the time received and phone number.
3. Press (Send).
<For outgoing calls>
1. Press (Up)[Calling List].
-Press (Up/Down) to find the required number.
-The number entered in phonebook displays name and icon of the other side.
2. Press (OK)[Sel].
3. Press (Send)
* If (UP)[Calling List]is selected, you cannot call the last called number with pressing (Send).
* For an incoming call, the received call number is displayed when Calling Line Identification
Presentation service is subscribed.
* For the consecutive incoming/outgoing of the same number, the number is displayed on the call
history screen only once. At this time, the last received/sent time is displayed. To verify how many
times the number is received/sent, press (www)[Menu]and (6)[Called/Calling Time].
Speed dial
You can make a call by justpressing one or two digits speed dial address.
One digit speed dial (Address 1~9)
1. Press and hold the address.
-Or enter the address thenpress (SEND).
-Call is made to the phone number in the address.
Two digit speed dial (Address 10~99)
1. Enter the first digit of the address then Press and hold the second digit.


-Or enter the address then press (SEND).
-Call is made to the phone number in the address.
* Refer to Speed dial to save a new number or to edit the existing number (Refer to page 29).
Answering calls
1. Open the folder when the phone rings or vibrates.
-Press any key if the folder has already opened.
2. Close the folder or press (END) to finish the call.
-Call time blinks on the screen before it returns to standby mode.
* Answer options are divided into <Folder Open>, <Open & Press Key>, <Open & Send Key>.
* If answer options with hands free or earphone is set as on and the phone is connected to them, the
phone automatically answers after ten seconds ofrings.
* If you cannot answer a call and the auto-answering function is set, you can record the received
message according to the announcement.
* When subscribing calling line identification presentation service, the phone number of the third
party will appear on the Sub LCD screen. If the number has already saved in phonebook, the
name of the other party will appear.
Hot menu
The most frequently used functions during the call are collected in hot menu so that user can activate
the functions with multi-function keys.
Adjusting the earpiece volume
You can adjust call volume in5 steps during the call and during the standby mode.
During the call
1. Make or receive a call.
2. Press (Up/Down)[Vol].
-Adjust the earpiece volume using (Up/Down)[Vol] keys during the call.
Check received messages
You can check the text message during the call.
