Skope FDM Series User manual

FDM Series
SKOPE Food Display Cabinet
Integral models: FDM900i, 1200i, 1500i
Service Manual MAN2056S Rev. 1.1 May 2023
FDM1200i

FDM900i/1200i/1500i
SKOPE Food Display Cabinet
Service Manual
MAN2056S
Rev. 1.1 May 2023
© 2014 SKOPE Industries Limited. All rights reserved.
SKOPE Industries Limited reserves the right to alter specifications without notice.
is a registered trademark of SKOPE Industries Limited.
SKOPE INDUSTRIES LIMITED
Head Office
PO Box 1091, Christchurch
New Zealand
A.B.N. 73 374 418 306
AU: 1800 121 535
NZ: 0800 947 5673
E-mail: [email protected]
Website: www.skope.com
Trademark Infringement
The SKOPE trademark on this product is infringed if the owner, for the time being, does any of the
following:
• Applies the trade mark to the product after its state, condition, get-up or packaging has been
altered in any manner
• Alters, removes (including part removal) or obliterates (including part obliteration) the trade
mark on the product
• Applies any other trade mark to the product
• Adds to the product any written material that is likely to damage the reputation of the trade
mark
Notice of the above contractual obligations passes to:
• Successors or assignees of the buyer
• Future owners of the product

SKOPE Food Display Cabinet
Service Manual iii
Contents
1 Specifications
Servicing Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
2 Controller
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Variations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
CAREL ir33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Faceplate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Temperature Setpoint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Controller Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Hardware Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
ir33 Controller Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
ir33 Controller Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
SKOPE CAREL S4 EVO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Faceplate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Messages and Alarms. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Controller Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Running the Cabinet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Operating Modes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Compressor and Fans. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Temperature Probes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Defrost Cycle. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Lighting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Cold Climate Protection (CCP) . . . . . . . . . . . . . . . . . . . . . . . . .14
3 Wiring
FDM Series – Integral . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
4 Spare Parts
Cabinet Assembly – FDM900i . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Cabinet Assembly – FDM1200i . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Cabinet Assembly – FDM1500i . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Sliding Door Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Tier Shelf Light Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Top Light Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Control Box Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Controller Box Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Refrigeration Cartridge Assembly – FDM900i . . . . . . . . . . . . . . . . . .29
Refrigeration Cartridge Assembly – FDM1200i . . . . . . . . . . . . . . . . .30
Refrigeration Cartridge Assembly – FDM1500i . . . . . . . . . . . . . . . . .31
5 Replacement Procedures
Refrigeration System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Refrigeration System Assembly . . . . . . . . . . . . . . . . . . . . . . . . . .34
Gaining Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
Control Box Assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Condenser Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Evaporator Fans . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Compressor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
Compressor Electrics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
Glass Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

SKOPE Food Display Cabinet
Service Manual
iv
Cabinet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Lighting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Controller Box. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Sliding Doors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Gasket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Wheels and Track. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
6 Maintenance
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Cabinet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Condenser Coil. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

5
SKOPE Food Display Cabinet
Specifications
Service Manual
1 Specifications
Servicing Tools Tools required for servicing may consist of the following:
• Screwdriver with TORX T-10 and T-15 bit
• Screwdriver with Pozidriv PZ1 and PZ2 bit
• Small slotted screwdriver (for electrical connectors)
Table 1: Cabinet
Construction FDM900i FDM1200i FDM1500i
Insulation 50 mm polyurethane foam
Dimensions External Internal External Internal External Internal
Height 1305 mm 800 mm 1305 mm 800 mm 1305 mm 800 mm
Width 900 mm 600 mm 1200 mm 900 mm 1500 mm 1200 mm
Depth 662 mm 600 mm 662 mm 600 mm 662 mm 600 mm
Floor area 0.6 m20.8 m21.0 m2
Cabinet internal volume 288 litres 432 litres 576 litres
Doors 2 double-glazed sliding doors
with internal mirror finish
2 double-glazed sliding doors
with internal mirror finish
2 double-glazed sliding doors
with internal mirror finish
Internal door opening size 2 rear door openings: 275 mm
wide × 630 mm high
2 rear door openings: 390 mm
wide × 630 mm high
2 rear door openings: 540 mm
wide × 630 mm high
Shelves 3 shelves (2 adjustable angle):
630 mm wide × 440 mm deep
3 shelves (2 adjustable angle):
930 mm wide × 440 mm deep
3 shelves (2 adjustable angle):
1230 mm wide × 440 mm deep
Cabinet temperature range 1°C to +7°C in 32°C ambient, +10°C to +23°C in elevated mode
Total weight 160 kg 190 kg 225 kg
Table 2: Refrigeration cartridge
FDM900i FDM1200i FDM1500i
Refrigeration system Integral Food Display Refrigeration Cartridge
Electronic controller SKOPE customised CAREL ir33
Cartridge model
UB70AAD-420ZX or
UB70ABD-420ZX or
UB70ALD-420ZE
UB71AAD-420ZX or
UB71ABD-420ZX or UB71ALD-
420ZE
UB72AAD-420ZC or
UB72ABD-420ZC
Drainage No plumbing required
Compressor Electrolux GLY90RA or
Embraco NEK6187Z
Electrolux GLY90RA or
Embraco NEK6187Z Danfoss SC12G
Nominal capacity 450 watts 540 watts 620 watts
Refrigerant R134a
Charge 480 g 480 g 950 g
Table 3: Electrical
FDM900i FDM1200i FDM1500i
Supply 220-240 volts a.c. 50 Hz, single phase supply
Lighting 3 × 14 W/830 T5 fluorescent
tube (Ø16 mm × 550 mm)
3 × 21 W/830 T5 fluorescent
tube (Ø16 mm × 850 mm)
3 × 28 W/830 T5 fluorescent
tube (Ø16 mm × 1150 mm)
Total run amps 2.0 amps 2.4 amps 3.4 amps

6Controller
Service Manual
SKOPE Food Display Cabinet
2 Controller
Overview
Introduction The SKOPE electronic controller controls and displays the cabinet temperature. The preset
temperature setting controls the internal air temperature for chilled food between 1°C and 7°C,
and room temperature food between 10°C and 23°C. The electronic controller also signals
temperature alarms, and the CAREL ir33 records the minimum and maximum value reached
at the time of the alarm.
The electronic controller is visible on the rear panel of the cabinet and is connected to the
refrigeration cartridge junction box. The cabinet is fitted with either a SKOPE customised
CAREL ir33 controller (ELZ3333) or a CAREL S4 EVO controller. Check the label on top of the
controller to verify the controller type.
Customised SKOPE controllers cannot be replaced with standard CAREL controllers.
Variations Note: All SKOPE cabinets manufactured from January 2023 will use the CAREL S4 EVO
controller. All necessary replacement components are supplied in a replacement kit when
ordered as a spare part. See:
• Table 13, “Parts – FDM900i cabinet”, on page 17
• Table 14, “Parts – FDM1200i cabinet”, on page 19
• Table 15, “Parts – FDM1500i cabinet”, on page 21
See "Control Box Assembly" on page 36 for replacement procedures.
While the controllers are similar, there are some visual and functional differences between
them. This manual covers both.
CAREL ir33
Faceplate
910
11
12
43
15
14
1312
8
7
6
5

7
SKOPE Food Display Cabinet
Controller
Service Manual
Temperature
Setpoint The temperature setpoint is set at the factory depending on the cabinet or program type. If
necessary the standard setting for chilled food can be adjusted between 1.0°C and 5.0°C, and
the standard setting for room temperature food can be adjusted between 10°C and 20°C.
SKOPE does not recommend changing the setpoint unless it is absolutely necessary, and then
only by small increments at a time.
Controller
Reset To delete program modifications and reset the controller to SKOPE default program, or when
a replacement controller is being fitted, a Controller Reset must be performed. The electronic
controller must never be left in program mode bn0, as failure will occur.
Table 4: ir33 controller faceplate
Item Icon Function
1Mute/program: Button. Mutes the audible alarm (buzzer) and deactivates the alarm
relay. To initiate program sets, press for 5 seconds.
2 Up: Button. To scroll settings up (in program mode).
3Set point: Button. If pressed for more than 2 seconds displays and / or enables changing
the temperature setpoint (see page 7).
4Manual defrost / down: Button. Press for more than 5 seconds to initiate manual defrost.
To scroll settings down (in program mode).
5Compressor: Indicator. ON when the compressor and condenser fan starts. Flashes
when activation of the compressor is temporarily delayed.
6 Fan: Indicator. Shows when the fan is operational.
7Defrost: Indicator. ON when the defrost is activated. Flashes when the activation of the
defrost is temporarily delayed due to procedures in progress.
8 Aux: Indicator. n.a.
9 Alarm: Indicator. Flashes in the event of some alarms (see page 10).
10 Clock: Indicator. n.a.
11 Light: Indicator. n.a.
12 Service: Indicator. Flashes in the event of malfunctions (see page 10).
13 DISPLAY: Indicator. Shows the cabinet temperature. Flashes when the door is open.
14 HACCP: Indicator. n.a.
15 CONTINUOUS CYCLE: Indicator. n.a.
Procedure 1: To view and adjust the temperature setpoint on an ir33 controller
1. To view the setpoint: press and hold the button for 2 seconds, until the setpoint value flashes
2. To adjust the setpoint: press the or buttons to display the required setpoint value.
3. Press the button again to assign the new setpoint value. If you do not do this within
60 seconds, changes will be lost and you will need to repeat the procedure.

8Controller
Service Manual
SKOPE Food Display Cabinet
Hardware
Setup Refer to the wiring diagrams on page 15. The controller has five separate inputs, three of which
are used for temperature probes.
Programming “Cold Key”
A controller may be field-programmed via a CAREL Cold Key. The SKOPE factory
pre-programmed cold key has the capability of instantly changing program configurations. A
cold key may also be used to introduce a customised program to meet a specific customer
requirement.
Field-adjustable Programming
Within each program are field-adjustable (Type C) parameters. Non-useful parameters are
hidden. Changes to SKOPE factory default programs are not recommended.
Procedure 2: To reset the ir33 controller
1. Disconnect the cabinet from the power supply.
2. Press and hold the button while plugging the cabinet into the power supply (this may require
two people). After a few seconds the controller is reset and program mode bn0 is displayed. You
must not leave the controller in program mode bn0 as failure will occur.
3. Press the or buttons to select the appropriate bn program mode.
4. Immediately press the button to confirm the preferred program. If not confirmed within
60 seconds the controller will remain in program mode bn0 (and cause failure). If this occurs,
repeat the procedure.
CAUTION
The electronic controller must never be left in program mode bn0,
as failure will occur.
Table 5: ir33 inputs
Input Used for Description and location
1Control probe
Determines cabinet temperature, temperature display and cabinet
temperature alarms.
Located in the return airflow on the bracket in front of the evaporator
face.
2Evaporator probe
(red sleeve)
Determines defrost termination and evaporator fan activation.
Located inside the evaporator coil between fins at the bottom of the coil.
3
Condenser probe
(grey or blue
sleeve)
Determine refrigeration shut down due to overheating of condensing
temperature.
Located and insulated on the outside middle tube of the condenser.
4Unused
5Unused
Table 6: ir33 relays
Relay Used for
1Compressor
2Aux1 – Alarm
3Unused
4Unused

9
SKOPE Food Display Cabinet
Controller
Service Manual
ir33 Controller
Parameters Factory default configuration of the controller is set by SKOPE for a specific SKOPE product.
The factory default cannot be altered in the field. A label on the controller box indicates the
default parameter program (P420 bn1, bn2, bn3, or bn4).
Parameter programs
Within each program are field adjustable (Type C) parameters. To help with navigation, the
parameters can be displayed in groups listed in the table below. Non-useful parameters are
hidden.
Changes to SKOPE factory default programs are not recommended.
Table 7: ir33 parameter programs
Models Parameter program
FDM900i/1200i/1500i (standard mode) P-420 bn1
FDM900i/1200i/1500i (manual mode) P-420 bn2
FDM900i/1200i/1500i (auto mode) P-420 bn3
FDM900i/1200i/1500i (elevated mode) P-420 bn4
Table 8: ir33 parameter groups
Display Group Display Group
Pro Probe Fan Fan
Ctl Temperature CnF General
CMP Compressor HcP HACCP
dEF Defrost rtc Real time clock
ALM Alarm
Procedure 3: To access ir33 Type C parameters
1. Press the and buttons together for more than 5 seconds. The display will show either 00
or -1, representing the password prompt.
2. Press the or buttons until displaying the password number 66.
3. Confirm by pressing the button. The display will show the code of the first modifiable Type C
parameter.
Procedure 4: To modify CAREL ir33 Type C parameters
1. Access the relevant category using one of the two methods:
• Press the or keys until you reach the parameter you want. When scrolling, an icon
appears on the display representing the category the parameter belongs to.
• Press the key to display a menu that is used to quickly access the group of parameters to
be modified (see Table 9, “ir33 controller alarms”, on page 10), then scroll through the menu
with the or keys. The display shows the codes of the various categories of
parameters.
2. When you have reached the desired category, press the key to move directly to the first
parameter in the category.
3. At this stage, continue to scroll through the parameters or press the key to return to the
categories.
4. Press the key to display the value associated with the parameter.

10 Controller
Service Manual
SKOPE Food Display Cabinet
ir33 Controller Alarms
5. Increase or decrease the value using the or keys respectively.
6. Press the key to temporarily save the new value and return to the display of the parameter
code.
7. Repeat step 1 on the previous page.
8. If the parameter has sub-parameters, press the key to display the first sub-parameter.
9. Press the or keys to scroll through all the sub-parameters.
10. Press the key to display an associated value.
11. Increase or decrease the value using the or keys respectively.
12. Press the key to temporarily save the new value and return to the display of the sub-
parameter code.
13. Press the key to return to the display of the parent parameter.
14. Press the key for more than five seconds to store the new values of the modified parameters.
Procedure 4: To modify CAREL ir33 Type C parameters (continued)
Table 9: ir33 controller alarms
Code Display LCD Buzzer Alarm description Initial action Final action
Flashing On
Product HIGH
temperature alarm
(auto reset)
1. Check the cabinet product loading to ensure
ventilation slots are not blocked and that product
does not overhang the shelves.
2. Ensure the cabinet is installed with good
refrigeration cartridge ventilation.
3. Check and clean the condenser coil.
4. Unplug cabinet from the power supply for 1
minute, then reconnect to power supply.
If the alarm
persists, contact
SKOPE (see
page 2).
Flashing On
Product LOW
temperature alarm
(auto reset)
Flashing Off
Refrigeration system
high temperature
pre-warning
(auto reset)
1. Clean the condenser coil.
2. Check refrigeration ventilation. Ensure clear
airpath at the top and front of the cabinet (to
extract hot air). A minimum of 200 mm clear
space is required above and in front of the
refrigeration cartridge.
3. Ensure the cabinet is installed in a suitable
environment.
4. Unplug cabinet from the power supply for
1 minute, then reconnect to the power supply.
Flashing On
Refrigeration system
high temperature
shutdown
(manual reset)
Flashing Off Ambient probe fault
(also flashes ‘rE’)
Unplug cabinet from the power supply for 1 minute,
then reconnect to power supply.
Flashing Off Evaporator probe
fault
Flashing Off Condenser probe
fault
None Off Defrost over-time
limit
Flashing Off Controller E prom
error
Flashing Off Controller E prom
error

11
SKOPE Food Display Cabinet
Controller
Service Manual
Condenser Over-temperature Two Stage Alarm
To prevent damage to the refrigeration system, during periods of excess condensing
temperature, the electronic controller will completely shut down the cabinet (and can only be
reset by replugging the cabinet into the power supply).
This is a two stage alarm. Stage One is simply a warning code of cht, which ideally the
customer should respond to. Cleaning the condenser may possibly fix the problem. If the
condenser fan fails, the controller will quickly move to Stage Two alarm CHT and completely
shut down the cabinet.
• Parameter “Ac” (SKOPE default) = 60 (Shutdown = 60°C)
• Parameter “AE” (SKOPE default) = 10 (Warning Initiation = Ac minus AE/2 = 55°C.
Warning Reset = Ac minus AE = 50°C).
Note
In low ambient conditions the alarm may not activate due to a blocked condenser. In
applications with a continuously low ambient, it may be worthwhile lowering the alarm
threshold if condenser blockage notification is wanted.

12 Controller
Service Manual
SKOPE Food Display Cabinet
SKOPE CAREL S4 EVO
Faceplate
Messages and Alarms
Controller
Display
The following tables explain the messages and alarms that the electronic controller displays.
ES
12
3
4
5
68
7
Table 10: CAREL S4 EVO controller faceplate
No. Item Description
1
Digital display of cabinet temperature or messages.
The temperature is what the sensor inside the chiller detects, and not necessarily
the product temperature. However, they may be very close depending on how the
controller is set to sense temperature.
2Up: Button. Used for programming.
3Set (mute): Press to mute the alarm. Press and hold to access parameters. Also
used for programming.
4Light (down): Press to switch the cabinet light on and off. Also used for
programming.
5Defrost: ON when the defrost is activated. Flashes when the activation of the
defrost is temporarily delayed due to other procedures in progress.
6Compressor: ON when the compressor and condenser fan starts. Flashes when
activation of the compressor is temporarily delayed.
7Fan: ON when the internal cabinet fans are activated. Flashes when activation of
the fans is temporarily delayed.
8Alarm: ON when alarm is signalled.
ES

13
SKOPE Food Display Cabinet
Controller
Service Manual
Alarms signal unexpected operational changes in the cabinet and can be muted by pressing
the Set (mute) button on the electronic controller faceplate (see page 12).
Running the Cabinet
Operating
Modes
The electronic controller runs the cabinet in constant “Normal” mode. There is no energy
saving/night mode (or similar).
Note: Normal mode is suitable for perishable product (all shelves maintain temperature below
5°C).
During some conditions or refrigeration system alarms, the electronic controller may run the
cabinet in cold climate protection mode (CCP), or may shut down the lights and/or refrigeration
system. Refer to "Cold Climate Protection (CCP)" on page 14, or "Messages and Alarms" on
page 12 for more information.
Compressor
and Fans
The compressor and condenser fan will start shortly after the cabinet is turned on. The
compressor stops when the setpoint (parameter St) is reached.
Table 11: CAREL S4 EVO messages
Display Description
The cabinet is in Normal mode and the electronic controller displays the temperature.
The cabinet’s internal temperature is above 13°C.
The cabinet is in Cold Climate Protection (CCP) mode. The cabinet enters CCP mode if
the control probe detects the interior temperature below parameter St - CCt temperature
for more than CCd time. The lights remain on and cannot be switched off (see below for
more information).
Table 12: CAREL S4 EVO alarms
Display Description
Control probe error.
Condenser probe error.
Evaporator probe error.
Low temperature alarm. An alarm sounds. The temperature inside the cabinet is too
cold. The controller will automatically reset the alarm once the temperature inside the
cabinet rises.
High temperature alarm. An alarm sounds. The temperature inside the cabinet is too
warm. The controller will automatically reset the alarm once the temperature inside the
cabinet drops.
Refrigeration system high
temperature.
Pre-warning (auto reset).
1. Check refrigeration ventilation and ensure the
cabinet is installed in a suitable location.
2. To reset the “CHt” alarm unplug the cabinet
from the power supply for 1 minute, then
reconnect to the power supply.
Refrigeration system high
temperature.
Shutdown (manual reset).
Low voltage alarm. An alarm sounds. The mains voltage is low. The controller switches
off the compressor. The controller will automatically reset the alarm once the mains
voltage rises.
High voltage alarm. An alarm sounds. The mains voltage is high. The controller switches
off the compressor. The controller will automatically reset the alarm once the mains
voltage drops.
Electronic controller fault.

14 Controller
Service Manual
SKOPE Food Display Cabinet
The evaporator fan starts approximately 3 seconds (parameter F0) after the compressor and
condenser fan. To verify, check that the FAN light (item 7 in Table 10 on page 12) is lit on the
electronic controller faceplate.
Temperature
Probes
Three temperature probes feed data to the electronic controller: the control probe, the
evaporator probe, and the condenser probe.
The control probe monitors and controls the cabinet’s temperature, provides the temperature
for the electronic controller to display, and notifies the electronic controller of any erratic or
abnormal temperatures that could identify a problem within the refrigeration system. It is
located in the return airflow on the bracket in front of the evaporator face.
The evaporator probe starts and stops the defrost cycle. It is located inside the evaporator coil,
between the fins at the bottom of the coil.
The condenser probe monitors the refrigeration system condenser temperature, and notifies
the electronic controller of any abnormally high temperatures that could identify a problem
within the refrigeration system. It is located and insulated on the outside middle tube of the
condenser.
To see the probe readings, go to parameters d/1 and d/2.
Defrost Cycle Defrosting is achieved via off-cycle defrosting. It is activated on elapse time (dl) and terminates
on temperature (dt).
Lighting Press the Light button on the electronic controller faceplate to manually switch the lights on
and off.
Cold Climate
Protection
(CCP)
The cabinet will enter CCP mode if the ambient temperature becomes too cold. This happens
if the control probe (at the evaporator air out) detects the interior temperature below 0°C
(parameter St - CCt) for more than 30 minutes (parameter CCd). The lights will stay on and
cannot be switched off while the cabinet is in CCP mode. The cabinet will return to Normal
operation mode once the control probe reading rises to 2°C (parameter St) temperature.

15
SKOPE Food Display Cabinet
Wiring
Service Manual
3 Wiring
FDM Series – Integral
BN BN
BN RS
RD
WH RS
BU
BU
BN
BS
B
N
BU
BU RS
GNYE
GNYE
S1-1 P1-1
BN BK
P1-N S1-N
BU
BK
BK BK
BK BK
S2-1 P2-1
BK
P2-N S2-N
BK
BN BU
RD
BK BK
OG
WH
WH
Cabinet Light
OG
WH
WH
BU
BU
BN
Cabinet Light
OG
OG
WH
WH
S3-3 P3-3
S3-N P3-N
S3-2 P3-2
S3-1 P3-1
WH
OG
OG
S4-1 P4-1
S4-2 P4-2
S4-N P4-N
S4-3 P4-3
OG
WH
OG
S5-N P5-N
S5-2 P5-2
S5-1 P5-1
Cabinet Light
WH
OG
BN
RD
BU
WH
WH
BU
RD
BN
BN
RD
BU
WH
BN
BN
TwinBallast
L
N
15
14
16
12
11
13
10
WH
T3-4T3-3
T3-1
Sweat WireElement
Evaporator
Fans T3-2
T1-4
T1-3
Control
Probe
Condenser
Probe
Evaporator
Probe
Unit
Isolation
T1-6
Up Glass
Fan
T1-5
To heater elements
– if connected
Fuse
Lights
On/O
T1-1
BN
T4-4
T4-3
T4-2
T4-1
T5-1
T5-2
T5-3
T5-4
T6-4
T6-3
T6-2
T6-1
P
N
T1-7
E
Evaporator
Fan #4
Evaporator
Fan #3
Cubigel Compressor
GLY90RA
BN
BU
BU
BK
BN
Condenser
Fan
Condenser
Fan Capacitor
BU
Singl e Ballast
L
N
16
15
14
13
Danfoss
Compressor
RS
C
L
N
Start
Relay
Compressor
Overload
Alternative
compressors may
be used
Embraco Compressor
C
S
St art Cap acit or
Relay
Overlo ad Compressor
L
N21
R
6 7
4 5
2
Fan
3
1
Lights
8
9
10
11
Carel S4
EVO
Comp.
BN
BN
RD
Relay
BU
BN BN
BN RS
RD
WH RS
BU
BU
BN
BS
RS
BN
BU
BU RS
GNYE
GNYE
S1-1 P1-1
BN BK
P1-N S1-N
BU
BK
BK BK
BK BK
S2-1 P2-1
BK
P2-N S2-N
BK
BN BU
RD
BK BK
OG
OG
WH
WH
Cabinet Light
OG
WH
WH
BU
BU
BN
Cabinet Light
OG
OG
WH
WH
S3-3 P3-3
S3-N P3-N
S3-2 P3-2
S3-1 P3-1
WH
WH
OG
OG
S4-1 P4-1
S4-2 P4-2
S4-N P4-N
S4-3 P4-3
OG
WH OG
OG
S5-3 P5-3
S5-N P5-N
S5-2 P5-2
S5-1 P5-1
WH
Cabinet Light
WH
OG
OG
BN
RD
BU
WH
WH
BU
RD
BN
BN
RD
BU
WH
BN
BN
BU
BU
BN
BN
TwinBallast
L
N
15
14
16
12
11
13
10
WH
T3-4T3-3
T3-1
Sweat WireElement
Evaporator
Fans T3-2
T1-4
T1-3
Control
Probe
Condenser
Probe
Evaporator
Probe
Unit
Isolation
T1-6
Up Glass
Fan
T1-5
To heater elements
– if connected
Fuse
Lights
On/O
T1-1
BN
T4-4
T4-3
T4-2
T4-1
T5-1
T5-2
T5-3
T5-4
T6-4
T6-3
T6-2
T6-1
P
N
T1-7
E
Evaporator
Fan #4
Evaporator
Fan #3
Cubigel Compressor
GLY90RA
BN
BU
BU
BK
BN
Condenser
Fan
Condenser
Fan Capacitor
BU
Singl e Ballast
L
N
16
15
14
13
Danfoss
Compressor
RS
C
L
N
Start
Relay
Compressor
Overload
Alternative
compressors may
be used
Embraco Compressor
C
S
St art Cap acit or
Relay
Overlo ad Compressor
L
N21
R
6 7
4 5
2
Fan
3
1
Lights
8
9
10
11
CAREL S4
EVO
Comp.
BN
BN
BN
RD
Relay
BU
NOTE:
Evaporator fans #3 and #4
not present in 900 wide
cabinet.
Evaporator fan #4 not
present in 1200 wide
cabinet.
Wire colours
BK Black
BN Brown
RD Red
OG Orange
GN Green
BU Blue
GY Grey
WH White
GNYE Green-Yellow
Based upon IEC 757 Standard
Legend
BS Blue sleeve T2 Light ballast supply terminal block
RS Red sleeve T3 Cartridge evaporator fans terminal block
P1/S1 Evaporator fan ENSTO plug and socket T4 Cabinet light 1 terminal block
P2/S2 Up glass fan ENSTO plug and socket T5 Cabinet light 2 terminal block
P3/S3 Cabinet light 1 ENSTO plug and socket T6 Cabinet light 3 terminal block
P4/S4 Cabinet light 2 ENSTO plug and socket
P5/S5 Cabinet light 3 ENSTO plug and socket O Electrical connection/terminal
T1 Junction box main terminal block >> Plug and socket

16 Spare Parts
Service Manual
SKOPE Food Display Cabinet
4 Spare Parts
Cabinet Assembly – FDM900i
1
2
14
3
4
4
5
6
7
8
9
10
11
11
12
13
14
3
15
16
17
18
19
20
21
22
24
23
25
26
27
31
25
28
29
30

17
SKOPE Food Display Cabinet
Spare Parts
Service Manual
Table 13: Parts – FDM900i cabinet
Item Description SKOPE Part No. Customer Part No.
1Shelf Support F0900/J22
2Capping Strip Middle F0901/024
3Front Vertical Strip F0901/025
4Horizontal Trim F0901/025A
5Corner Cap – Left Hand F0901/026L
6Corner Cap – Right Hand F0901/026R
7Side Tray – Left Hand F0901/585L
8Side Tray – Right Hand F0901/585R
Bottom Shelf Support Bracket F0900/353
9Air Guide – Left Hand F0901/F88L
10 Air Guide – Right Hand F0901/F88R
11 Wire Shelf F0901/J77
12 Rear Cover F0901/N85
13 Shelf Bracket – Left Hand SSY2234
14 Shelf Bracket – Right Hand SSY2235
15 Wire Upstand – Side STW2978
16 Door Track – 605 mm F0900/N15
17 Door Guide Extrusion F0901/533
18 Front Panel F0901/A18
19 Plinth Side – Left Hand F0901/B87L
20 Plinth Side – Right Hand F0901/B87R
21 Upper Front Panel F0901/C61
22 Evaporator Deflector UB70AB/C93
23 Sliding Door – Left Hand Back F0901/N30LB
24 Sliding Door – Right Hand Front F0901/N30RF
25 Tier Shelf Light Assembly F0901/L83
26 Top Light Assembly F0900/L53
27 CAREL S4 EVO Replacement Kit ELZ11478-SP8
28 Manifold Fan Assembly F0901/U25A
29 Front Manifold Cover F0901/U28
30 Manifold Fan Inspection Cover F0901/U30
31 Refrigeration Cartridge Assembly – Integral UB70ALD-420ZE

18 Spare Parts
Service Manual
SKOPE Food Display Cabinet
Cabinet Assembly – FDM1200i
1
2
15
3
4
4
5
6
7
8
10
12
11
12
14
15
3
16
18
19
20
21
26
25
27
28
29
33
1
9
17
16
22
23
24
27
14
13
32
31 30

19
SKOPE Food Display Cabinet
Spare Parts
Service Manual
Table 14: Parts – FDM1200i cabinet
Item Description SKOPE Part No. Customer Part No.
1Shelf Support F1200/J22
2Capping Strip Middle F1201/024
3Front Vertical Strip F0901/025
4Horizontal Trim F0901/025A
5Corner Cap – Left Hand F0901/026L
6Corner Cap – Right Hand F0901/026R
7Side Tray – Left Hand F0901/585L
8Side Tray – Right Hand F0901/585R
9Tray – Middle F1200/585M
Bottom Shelf Support Bracket F1201/354
10 Air Guide – Left Hand F0901/F88L
11 Air Guide – Right Hand F0901/F88R
12 Wire Shelf F0901/J77
13 Rear Cover F1201/N85
14 Shelf Bracket – Left Hand SSY2234
15 Shelf Bracket – Right Hand SSY2235
16 Wire Upstand – Side STW2978
17 Wire Upstand – Middle STW2979
18 Door Track – 905 mm F1200/N15
19 Door Guide Extrusion F1201/533
20 Front Panel F1201/A18
21 Plinth Side – Left Hand F0901/B87L
22 Plinth Side – Right Hand F0901/B87R
23 Upper Front Panel F1201/C61
24 Evaporator Deflector UB71AB/C93
25 Sliding Door – Left Hand Back F1201/N30LB
26 Sliding Door – Right Hand Front F1201/N30RF
27 Tier Shelf Light Assembly F1201/L83
28 Top Light Assembly F1200/L53
29 CAREL S4 EVO Replacement Kit ELZ11478-SP8
30 Manifold Fan Assembly F1201/U25A
31 Front Manifold Cover F1201/U28
32 Manifold Fan Inspection Cover F0901/U30
33 Refrigeration Cartridge Assembly – Integral UB71ALD-420ZE

20 Spare Parts
Service Manual
SKOPE Food Display Cabinet
Cabinet Assembly – FDM1500i
1
2
15
3
4
5
7
8
10
12
11
12
14
15
3
16
18
19
20
26
25
29
33
1
9
17
16
22
23
24
27
14
4
6
9
13
21
27
28
