Skope ReFlex User manual

ReFlex Salad and Pizza
Preparation Fridge
User Guide
Thank you for purchasing a SKOPE refrigeration product.
Safety
Always observe safety precautions when using any electrical appliance. Read these instructions carefully and retain them
for future reference.
• Do not use this appliance for other than its intended use.
• Do not probe any opening.
• Only use this appliance with the voltage specified on the cabinet rating label.
• Ensure the appliance has adequate ventilation as this is essential to economical, high performance.
• Be careful not to touch internal moving parts and hot surfaces.
• For your own safety and that of others, ensure that all electrical work is done by authorised personnel.
• If the power supply flexible cord becomes damaged, it must be replaced by an authorised service agent or similarly qualified
person in order to avoid a hazard.
• Ensure all necessary safety precautions are observed during installation or removal of the refrigeration unit.
• The appliance is not designed to be stable while in motion. Use extreme caution when moving or transporting it.
• Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance.
• Do not exceed a maximum load of 20kg per shelf.
• If the cabinet is to be scrapped, ensure the cabinet is unplugged from the power supply and cut off the mains flex close to the
back of the cabinet. Be mindful of the risk of animals or children becoming trapped in the appliance - either remove or secure
doors if necessary.
WARNING
• Ensure the appliance is disconnected from the power supply before performing any cleaning or maintenance.
• Do not cover the grilles or block the entry or exhaust of airflow by placing objects up against the refrigeration unit.
• Should manual defrosting be necessary, turn off the refrigeration system and allow the ice to melt by air
circulation. Collect ice and water during defrost to prevent a slip hazard. Do not use mechanical methods to
remove ice, as this may damage the refrigeration circuit.
• Do not use any electrical devices or appliances inside the food storage compartment.
This cabinet is designed to operate within a specific climatic class environment.
See the cabinet rating label inside the cabinet for climate class number.
The cabinet includes relevant hazard symbols that may be associated with the
cooler. Refer to the information below for symbol description.
Climate class Ambient temperature Relative humidity WARNING
The refrigeration system contains flammable R290 refrigerant.
Do not tamper with it.
The refrigeration system must only be serviced by qualified
personnel.
325°C 60%
430°C 55%
540°C 40%
7 (tropical) 35°C 75%

Installation Guidelines
Ensure the installation guidelines below are considered and met .
Ventilation and Clearance Requirements
This cabinet must have the following ventilation clearances at all times:
* When operated in recommended conditions.
Cleaning Before First Use
The cabinet interior and food contact surfaces such as the worktop must be thoroughly cleaned and sanitised before first
use. Ensure the cabinet is unplugged from the power supply before cleaning, and use only standard stainless steel cleaners
suitable for food preparation areas. If required, the cabinet exterior can be cleaned as instructed on the back page of this
user guide.
Ventilation
Ensure all ventilation
requirements below are
met.
Door Opening
Allow adequate space for
the door/s to open and
close properly.
Sunlight
Do not install the cabinet
in direct sunlight.
Uneven Surface
Do not install the cabinet
on an uneven surface.
Surface
The installation surface
must be capable of
supporting the loaded
cabinet.
Power Supply
Do not overload the power
supply.
Blocking Ventilation
Do not store boxes or items in
front or on top of the cabinet.
Climate Class
The cabinet must be
installed in an environment
within its climate class.
The climate class is stated
on the cabinet rating label
inside the fridge, and
explained on the front page
of this user guide.
No side
clearance
required
No behind
clearance
required
No below clearance required
190mm (salad) and 420mm (pizza) above clearance required (for cover opening)
Keep area in front
of grille and doors clear **
190mm 420mm
No behind
clearance
required *
ReFlex Salad and Pizza
Preparation Fridge

Power Cord
Before final positioning of the cabinet, pull the power cord out and connect to the
power supply.
Shelves
Each shelf is held in place with four shelf clips, which clip into the shelf support strips.
The shelf clips may be positioned at different heights to suit various product.
Food Preparation Pans and Cover
The cabinet is supplied with GN 1/3 -100mm deep food preparation pans and pan dividers. The pans and pan dividers fit
into openings on top of the cabinet. The cabinet is also fitted with a hinged cover that closes over the pan area.
IMPORTANT: For correct operation of the cabinet:
• Pans must be in place to assist with air circulation. Use the pan dividers to ensure there are no gaps between the pans.
• Hinged cover must stay closed to cover the food preparation containers when not in use. Leaving the covers raised
for more than 4 hours at the recommended operating temperature will compromise the performance of the chiller.
• The maximum operating ambient temperature for Salad and Pizza cabinets is 40°C.
Loading product
Let the cabinet cool down to the desired storage temperature before loading it with product. When loading the cabinet:
Door Lock/s
The cabinet is fitted with key locks, which can be unlocked with the supplied key.
Electronic Controller
The electronic controller regulates the cabinet internal temperature, signals alarms and captures
operational information. The internal temperature is factory set for storage of perishable product.
To customise the settings to your requirements and view historical data, download the
SKOPE-connect app from the Google Play Store or Apple App Store, and connect via
Bluetooth
®
wireless
technology.
Lights
The interior lights switch on and off automatically depending on usage.
Shelf Loading
Do not overload the
shelves
Shelf Flexing
Remove product if the
shelf is flexing
Shelf Overhang
Do not let product
overhang the shelves
Front
Top
Back
MAX
20kg
per shelf
Internal Airflow
Leave 25mm space
between product and
the back of cabinet
interior
Cabinet Floor
Do not load product
on the cabinet floor.
Use the shelves.
Load Limit
Do not load product
above the load limit
indicators
LOAD LIMIT
ReFlex Salad and Pizza
Preparation Fridge

Routine Cleaning
Ensure the cabinet is unplugged from the power supply before cleaning.
IMPORTANT: Do NOT use abrasive, corrosive or solvent based cleaners, as this could damage the protective coating on
the door exterior.
Wipe the outside of the cabinet with a damp cloth, and the inside of the cabinet with standard stainless steel cleaners
suitable for food preparation areas. Take care to keep moisture away from electrical parts.
The food preparation pans and air diffuser panels can be easily lifted from the cabinet for cleaning.
The condenser coil must be kept clean. SKOPE strongly recommends monthly cleaning of the condenser coil and air filter.
Do
NOT use hard or sharp tools to clean the coil as these may cause damage.
Service & Support
We know you will get years of satisfaction from your new SKOPE product when you follow a few simple
preventative maintenance guidelines.
Helpful information is available on the SKOPE website
www.skope.com/serviceandsupport
Clean filter
1. Unplug the cabinet from the power
supply.
2. The filter is located behind the unit
bottom grille, and attached using
magnets. Remove the filter from the
cabinet.
3. Clean the filter with a vacuum
cleaner, wash with cold water and
shake off any excess water before
refitting. Do NOT apply hot water,
blow-dry or place in dishwasher. If
necessary, discard and refit new
filter.
Clean Coil
1. With the cabinet unplugged from the
power supply and the filter removed
(see steps above), brush the
condenser coil with a soft brush to
remove any dust and fluff.
2. Refit the filter, close the bottom grille
and reconnect to the power supply.
Filter
Unit bottom
grille
Coil
PRN80252 Rev. 1.0 Jul. 2020
