Slinex ML-20HR User manual

ML-20HR video door panel
User manual
Thank you for
choosing our equipment { Design. Uniqueness. Innovations }
SERIES
ACCESSORIES

12
Rev. 2.0
Safety instructions
Read and keep that manual.
The device installation process should be carried out by the qulied specialists.
Use the device from the –40 ˚C to +65 ˚C, always keep it within that
temperature range.
Installation surface should be free from vibration and impact inuence.
Keep this device far from open sources of heat, such as radiators, heaters, and
ovens.
The device can be installed near other electronic equipment in case if the
temperature of the environment does not exceed previously mentioned
range.
The device should be protected from the direct inuence of the natural
phenomena, such as direct sunlight, rain or snow.
Don’t use aggressive or abradant detergent for the device surface cleaning.
Use soft wet cloth or tissue to remove strong dirt.
Attention!
As a result of continuous upgrades and functionality
improvements, technical characteristics of this device can
be changed without any preliminary declaration.
This manual can contain some inaccuracy or misprint.
The owner reserves the right to make corrections to the information described
in that user manual and device package.
The last revision of this manual is available on www.slinex.com
Nature protection
Don’t throw away the device with other industrial or
nutritive trash if you see that symbol. Some regions have
separation and recycling systems for the electronic
equipment.
Connect with local authorities to receive information about recycling of
electronic equipment for your region.
Rights and limitation of liability
All rights reserved. Any part of that document can not be published in any
form, translated into other languages or reproduced in any way including
electronic or mechanical.
Document recording and copying is strictly denied without owner permission.
!
{ Design. Uniqueness. Innovations } SERIES
ACCESSORIES

34
Table of contents
1. Package ..................................................................................................................................4
2. Specication ......................................................................................................................... 4
3. Description............................................................................................................................6
4. Schematic diagram ............................................................................................................7
5. Installation............................................................................................................................. 8
6. Video camera mode setting CVBS →AHD →CVI ..................................................9
7. Limited Warranty.............................................................................................................. 10
1. Package
ML-20HR door panel − 1 pc.
Wall mounting bracket − 1 pc.
Angle bracket − 1 pc.
Rainshield − 1 pc.
Flush mounting box − 1 pc. (optional)
Mounting screws and anchors − 1 pkg.
User manual − 1 pc.
2. Specication
Sensor type
Resolution
View angle
Night backlight
Voltage
Lock relay continuous current
Power consumption
Installation type
Dimensions
Working temperature
1/4” CMOS
960 ТV-lines
120˚
Infrared LED’s. 1,5 m distance
+12 V
1A
3 W in working mode
Surface or ush mount
45×130×24 mm
–40 ... +65 ˚C
{ Design. Uniqueness. Innovations } SERIES
ACCESSORIES

56
1
2
3
4
5
6
130 mm
45 mm 24 mm
Red
Black
Yellow
White
Brown
Blue
Red & white
ML-20HR wire colors
Power, +12 V
Ground (GND)
Video
Audio
COM relay contact
NO relay contact
Video camera power, +12 V
3. Description
5
4
3
2
1
5
6
Microphone
Video camera
Night infrared backlight
Call button
Speaker
Rainshield mounting hole
{ Design. Uniqueness. Innovations } SERIES
ACCESSORIES

78
4. Schematic diagram
Power (Red)
Audio (White)
GND (Black)
Video (Yellow)
COM (Brown)
NO (Blue)
Lock
ML-20HR
SL-07M (Master)
Lock power
supply
Camera power
(Red & White)
Door 1
Door 2
CCTV 1
CCTV 2
Input
Output
PowerTV out
Camera
power
suppply
(Optional for using cameara as
a source of video for DVR)
1) Take the angle bracket from the kit and place it 150-160 cm from the oor
line;
2) Mark and drill two halls inside the wall;
3) Take two anchors from the kit and hammer them into the drilled halls;
4) Fix angle bracket on the wall by two screws from the kit;
5) Fix wall mounting bracket on the angle bracket by two screws from the kit;
6) Connect all communication wires and x the door panel on the wall
mounting bracket by the screw from the down side.
5. Installation
{ Design. Uniqueness. Innovations } SERIES
ACCESSORIES

910
7. Limited warranty
Manufacturer guarantees product normal functioning during the warranty
period if the user keeps all safety instructions described in that manual.
Warranty period is 12 months from the moment of the product purchasing
(warranty period could be extended up to 24 months or more, depending on
the local regulations).
Warranty period allows user to make guarantee repair in cases when normal
functioning of the product was violated by the fault of manufacturer and the
user haven’t oend transporting, installation and working conditions.
This limited warranty does not cover any damage to the product that results
from improper installation, accident, abuse, misuse, natural disaster,
insucient or excessive electrical supply, abnormal mechanical or
environmental conditions, or any unauthorized disassembly, repair or
modication.
Warranty void in such cases:
• the product was damaged by the fault of the customer;
• the product wasn’t properly installed according reccomendations from
the manual;
• the sticker on the backside of the product was broken;
• the product was not used for its intended function.
This limited warranty covers only repair, replacement, refund or credit for
defective products, as provided above. Manufacturer is not liable for, and does
{ Design. Uniqueness. Innovations } SERIES
ACCESSORIES
6. Video camera mode setting CVBS →AHD →CVI
Door panel video camera can work in three basic modes: analog (CVBS), AHD
and CVI (CVBS mode activated by default). As AHD and СVI are high resolution
modes, so they have better quality then analog СVBS mode. While using high
resolutioon modes, monitor must maintain that kind of signal (AHD or CVI),
otherwise there will be no image on the monitor screen after switching to AHD
or CVI.
To switch into AHD or CVI mode you should remove resin cap on the back
cover and press the camera mode button under it by screwdriver during 8
seconds to switch video camera to the next mode in a such sequence:
CVBS → 8 seconds button holding → AHD →8 seconds button holding → CVI
→8 seconds button holding → CVBS
Camera mode button
under resin cap
Speaker volume
potentiometer
under resin cap

11 12
not cover under warranty, any damages or losses of any kind whatsoever
resulting from loss of, damage to, or corruption of, content or data or any costs
associated with determining the source of system problems or removing,
servicing or installing products. This warranty excludes third party software,
connected equipment or stored data. Manufacturer is therefore not liable for
any losses or damage attributable to third party software, connected
equipment or stored data.
In the event a product has been discontinued, manufacturer shall either repair
the product, oer to replace it with a comparable product or provide a refund
at the lesser of the purchase price or the product’s current value.
Repaired or replacement products will continue to be covered by this limited
warranty for the remainder of the original warranty term.
