Sloan TRUFLUSH TRF1036-N User manual

Code No. 08160127
Rev. 0 (01/23)
INSTALLATION INSTRUCTIONS FOR
TRUFLUSH MANUAL DUAL FLUSH VALVE
SLOAN®INDIA PRIVATE LIMITED — LIMITED WARRANTY SUMMARY
Sloan India Private Limited (“Sloan”), warrants its products against defects in materials and workmanship, excluding damage caused by matters beyond Sloan’s reasonable
control. Instructions for filing claims can be found in the Limited Warranty which can be obtained at https://www.sloan.com/company/international/sloanindia or by requesting a
free copy by telephone to Sloan India toll free number 1 800 123 3080 or via Mobile: [phone] or via Landline : [phone]. Sloan will repair or replace your
defective product, or provide a refund, as your exclusive remedy.
This is only a general summary of Sloan’s Limited Warranty so it is important to note that the specific terms, conditions, limitations and exclusions, including the duration of
warranty coverage for your particular Sloan product, are contained in the actual Sloan Limited Warranty. The Limited Warranty is subject to applicable laws in your country, state,
province or other jurisdiction—and disputes arising under the Limited Warranty are to be resolved by binding arbitration unless you provide Sloan with an opt-out notice no later
than 30 days after your purchase date. In case of a conflict with this summary, the terms and conditions set forth in the complete Limited Warranty will prevail.
Manual Dual Flush Models:
TRF1036-N-Man Dual Flush
6/3 LPF Valve
TRF1024-N High Efficiency
4-4.5/2-2.5 LPF Valve
This valve is designed for new construction or where there is easily accessed
plumbing for the fixture and the valve. This valve is designed for minimum six
inch (153 mm) wall space depth. Distance from center of the valve (inlet or
outlet pipe) to the finished surface of the wall can vary from 2”-3” (51-76 mm).
Wall plate opening must be minimum of 4” x 4” (102 x 102 mm) to
maximum of 4.5” x 4.5” (114 mm x 114 mm). Mud plate is provided and
must accompany valve for proper installation. Mud plate is removed after
wall is finished.
PRIOR TO INSTALLATION
TOOLS REQUIRED FOR INSTALLATION
• Phillips screwdriver • Adjusting tool (supplied)
ITEMS INCLUDED WITH THE PRODUCT
1. Valve assembly
2. Mud Guard
3. (2) #10-32 x 2-1/2 screws to secure mud guard
4. (2) 1/4”-20 x 2” screws to remove activation assembly
5. Adjusingt tool
6. Installation instructions
1
2. Mud Guard1. Valve Assembly 4. Activation Assembly
Screws
3. Mud Guard Screws
5. Adjusting Tool
VALVE BOX
6. Instructions

2
ROUGH-IN
WITH THE EXCEPTION OF INLET, DO NOT USE
PIPE THREAD SEALANT. DO NOT USE PLUMBING
GREASE ON VALVE COMPONENTS OR COUPLINGS!
!!! IMPORTANT !!!
1. CONNECT FLUSHOMETER
1.
SLOAN’S FLUSHOMETERS ARE DESIGNED TO OPERATE WITH 20 TO
80 PSI (138 TO 552 KPA) OF WATER PRESSURE. THE MINIMUM
PRESSURE REQUIRED TO THE VALVE IS DETERMINED BY THE
TYPE OF FIXTURE SELECTED. CONSULT FIXTURE MANUFACTURER
FOR MINIMUM PRESSURE REQUIREMENTS. MOST HIGH EFFICIENCY
WATER CLOSETS REQUIRE A MINIMUM FLOWING PRESSURE OF 25 PSI
(172 KPA). MANY BUILDING CODES AND THE ASME A112.19.2 FIXTURE
STANDARD LIST MAXIMUM STATIC WATER PRESSURE AS 80 PSI (552 KPA).
!!! IMPORTANT !!!
Remove the mud guard and save for
later use - DO NOT DISCARD.
2. Connect inlet pipe to top (“IN”) and fixture flush
connection to bottom (“OUT”) of flushometer,
tighten securely.
3. Reinstall mud guard to valve. Use the
mud guard screws (supplied).
NOTE: Flush Connections shown in
dotted lines not included.
4” (102 mm) MINIMUM
4.5” (114 mm) MAXIMUM
4” (102 mm) MINIMUM
4.5” (114 mm) MAXIMUM
Finished Wall Finished Floor
1 1/4” BSP
INLET
1 1/2”
OUTLET
NPSM
2” (51 mm) MINIMUM
3” (76 mm) MAXIMUM
C.L. TO FINISHED WALL
24”
(610 mm) 40”
(1016 mm)
NOTE: MTA/FTA not
included; must be
purchased separately.

2. FINISH WALL
3
1. Finish the wall. Use marks on mud guard to make sure finished
wall is in between 2” (51 mm) and 3” (76mm) from centerline of
inlet pipe.
2. Remove mud guard and discard.
3. PURGE PLUMBING SYSTEM
1. Ensure the activation assembly is turned
fully clockwise. If not, use the adjustment
tool (supplied) to turn it fully closed.
2. Push the plunger screw in the
center to relieve pressure inside the
flushometer.
3. Push the activation assembly until fully
seated.
4. Squeeze and then pull the safety ring
out. Do not discard safety ring.
5. Use activation assembly screws
(supplied) to pull the activation assembly
out with the piston and conical spring.
6. Keep the piston and conical spring
aside. DO NOT DISCARD and reinstall
activation assembly and the safety ring.
7. Using the activation tool, turn the activation assembly anti-
clockwise slowly to open the water flow to flush the supply
lines clean of air and debris - careful not to overflow the fixture.
After the supply lines are cleared, turn the activation assembly
clockwise to completely shut off the flow of water.
8.
9.
Remove the activation assembly using the activation assembly
screws Repeat steps 2, 3, 4, and 5.
If the valve was flushed before any of the above steps were
followed, then wash the Piston thoroughly using clean water prior
to installation.
Ensure TruFlush valves are in the closed position prior to opening water main valve to supply and pressurize plumbing system.

4
SLOAN INDIA PRIVATE LIMITED • 344, PHASE-II UDYOG VIHAR, GURUGRAM 122015 INDIA
Phone: [phone] • Toll Free: 1800.123.3080 • [email protected] • www.sloan.in
© 2023 SLOAN Code No. 08160127
Rev. 0 (01/23)
3. PURGE PLUMBING SYSTEM, CONTINUED
10. Insert the clean piston and conical spring, then reinstall the
activation assembly and safety ring.
11. Use the activation tool to turn the activation assembly anti-
clockwise slowly to open the flow of water.
Push the plunger to activate flush and adjust the flow as needed
by rotating the activation assembly (clockwise to reduce flow and
anti-clockwise to increase the flow).
NOTE: Make sure there are no leakages after assembly.
12.
THE ACTIVATION ASSEMBLY SHOULD NEVER BE OPENED TO
THE POINT WHERE THE FLOW FROM THE VALVE EXCEEDS THE
FLOW CAPABILITY OF THE FIXTURE. IN THE EVENT OF A VALVE
FAILURE, THE FIXTURE MUST BE ABLE TO ACCOMMODATE A
CONTINUOUS FLOW FROM THE VALVE.
!!! IMPORTANT !!!
THE FLUSHOMETER IS ENGINEERED FOR QUIET
OPERATION. EXCESSIVE WATER FLOW CREATES NOISE,
WHILE TOO LITTLE WATER FLOW MAY NOT SATISFY
THE NEEDS OF THE FIXTURE. PROPER ADJUSTMENT IS
MADE WHEN PLUMBING FIXTURE IS CLEANSED AFTER
EACH FLUSH WITHOUT SPLASHING WATER OUT FROM
THE LIP AND A QUIET FLUSHING CYCLE IS ACHIEVED.
!!! IMPORTANT !!!
4. INSTALL BUTTON / BRACKET ASSEMBLY
Refer to the Wall Plate Installation Manual (08160128), available on www.sloan.in.
For complete listing of items available for repair, please consult
the Maintenance and Repair Guide.
Wall Plate
sold separately
Maximum of two (2) free of charge service technician visits are applicable, one each for pre and
post installation guidance of the product, any further technician visits will incur additional charges.
Please contact your local Sloan representative for more information.
NOTE
The information contained in this document is subject to change without notice.
