60C3D 12 VDC Power Supply
Installation Guide for PN 701507-60C3D – NEC Class 2 Output
NOTE: Ensure adequate ventilation. Power supply operating ambient temperature is -40º to 60º C. Power supply must be mounted in an enclosure
(i.e., transformer can/raceway). Power supply spacing to thermoplastic, wood, ber, or other combustible type enclosure materials shall be 1"(25
mm) Two or more adjacent power supplies shall not be mounted closer than 1"(25 mm) end to end or 4" (102 mm) side to side. If mounted inside
a sign cabinet, UL requires that cabinet is made from an enclosure rated material. Ensure power supplies are not overloaded by verifying output
current is less than 5 DC Amps. It is recommended to use photocells or light sensors to prolong life of power supply and to keep unit at maximum
operating efciency.
5. Connect Primary:
CAUTION: Have a licensed
electrician connect primary.
ATTENTION: Avoir un permis
électricien connecter primaire.
1. Tools required: Wire strippers,
drill, and screwdriver.
2. Supplies required: Conduit and
electrical enclosure for power supply
(if not placed in a sign made from
enclosure rated material), #8 pan
head screws, UL Listed PLTC cable,
UL Listed electrical wire connectors
(e.g., wirenuts), silicone.
Europe: Electrical enclosure
for power supply, M4 pan head
screws, PLTC cable, silicone, 3M™
Scotchlok™connectors.
3. Power Supply: Identify primary
wires, secondary wires, and
location of mounting tabs.
4. Mount Power Supplies:
Use mounting tab in corner to
secure power supply.
Mounting Tabs
Primary Wires (Brown & Blue)
12 VDC Output: Red (V+) & Black (V-)
Dimming: Violet (Dimming+) & Pink (Dimming-)

60C3D 12 VDC Power Supply
Installation Guide for PN 701507-60C3D – NEC Class 2 Output
PAGE 2 OF 2
SloanLED Headquarters
5725 Olivas Park Drive, Ventura, CA, USA
888.747.4LED (888.747.4533) • [e-mail]
SloanLED.com
SloanLED Europe b.v.
Argonstraat 110, 2718 SN Zoetermeer, NL
[phone] • [e-mail]
P/N 402715 Rev B 2021-06-22
Customer service and technical support
SloanLED products carry a limited warranty.
For complete details refer to the warranty policy found at SloanLED.com
TROUBLESHOOTING
If sign is not functioning properly, check the following:
• Primary voltage is between 120-277 VAC
• Secondary voltage is 12 VDC
• Output current is 5 Amps or less
• Power supply is not overloaded (see power supply capacity chart in product installation guide or SloanLED.com)
• There are no shorts in secondary wiring
• All secondary connections are RED-TO-RED and BLACK-TO-BLACK
Some or all of the products shown are covered by U.S. and foreign patents pending and covered by one of more of the following U.S. patents issued:
6776504, 6969179, 7192157, 6932495, 7241031
E215393
E336107
LED curr ent (%)
1.2
1
0.8
0.6
0.4
0.2
0
2 4 6 8 10 12
Dimming voltage (V)
Dimming by voltage
LED curr ent (%)
1.2
1
0.8
0.6
0.4
0.2
0
6K 10K 20K 30K 40K 50K 60K 70K 80K 90K 10 0K
Resi stance (oh m)
Dimming by resistor
LED curr ent (%)
1.2
1
0.8
0.6
0.4
0.2
0
0.2 0.4 0.6 0.8 11.2
Dimming PWM
Dimming by PWM
