SmartCell SC-41-0200-0001-99 User manual

OUTPUT 2OUTPUT 1
INPUT 1 INPUT 2
EXPAN1 EXPAN2
A
B
+3V
SET
RST
N/O
COM
N/C
N/O
COM
N/C
+3V
SET
RST
A
B
FAULT
ACTIVE
RLY 1 RLY 2
3 Prepare the back box
1 Pre installation 2 Components
DO NOT
use the
shaded
area
The unshaded
area is
available for
cable entry
4 Fix back box
All four corner fixing
positions must be used to
ensure a firm fixing
Use suitable fasteners and
fixings.
Fixing position
location within
cavity
118.5 mm
Dual Input / Output Device
Installation Guide
Part number Product description
SC-41-0200-0001-99 Dual Input / Output Device
!Installation must conform to applicable local installation codes and
should only be installed by a fully trained competent person.
This device contains electronics that may be susceptible to damage
from Electrostatic Discharge (ESD). Take appropriate precautions
when handling electronic boards.
STATUS
DUAL INPUT/OUTPUT DEVICE
LOG ON POINT
The use of a non-metallic spacer should be considered if mounting
the device on to a metal surface.
Unscrew the four lid fixing
screws and remove the lid.
Drill cable entry points where
necessary the in UNSHADED
area.
Cable glands should be used.
The status light pipe should also
now be fitted, as shown below.
6 Configuration
ER14500AA
ER14500AA
+
-
+
-
ER14500AA+
-
Refer to the programming manual (TSD155) for full programming
details.
The device must now be added (programmed) to the control panel.
Device powering
Method 1
Magnet application
Method 2
Via computer
Method 3
5 Fit batteries
OBSERVE BATTERY
POLARITY!
!
Carefully unclip the battery cover.
When fitting / replacing batteries, observe correct polarity, using only specified
batteries.
Re-fit the battery cover once all batteries are correctly in place.
STATUS
OUTPUT 2 OUTPUT 1
INPUT 1 INPUT 2
EXPAN1 EXPAN2
FAU LT
ACTIVE
*When batteries are not included, only fit specified batteries.
† The gasket can be fitted to the lid for additional protection.
4x lid screws Lid
12Back box
3
4
Resistor pack
6Gasket †
Batteries ( not included in some regions * )
75
Status light pipe ( supplied in resistor pack)
21 4 5 63 7
Two resistor monitored inputs are available. If both inputs enter an
alarm condition, only the first activated input will be shown at the
control panel.
To ensure correct operation, products must be used within the
specified environmental operating conditions.
www.acornfiresecurity.com
www.acornfiresecurity.com

OUTPUT 2OUTPUT 1
INPUT 1 INPUT 2
EXPAN 1 EXPAN 2
A
B
+3V
SET
RST
N/O
COM
N/C
N/O
COM
N/C
+3V
SET
RST
A
B
FAULT
ACTIVE
RLY 1 RLY 2
7 Input wiring
8 Output wiring
Operating temperature -10 to +55 °C
Storage temperature
With batteries -10 to +30 °C
Without batteries -10 to +55 °C
Humidity 0 to 95% noncondensing
Location Type A: for indoor use
Supply 3 x ER14505M 3.6 V lithium thionyl chloride
batteries (Fanso or Titus)
CAUTION!
Operating voltage 2.7 to 3.65 VDC
Operating frequency 868 MHz
Output transmitter power 14 dBm / 25 mW
Signalling protocol X5
Dimensions (W x H x D) 150 x 200 x 55mm
Manufacturer EMS Ltd. Technology House, Herne Bay, Kent, CT6 8JZ.
United Kingdom
Year of manufacture See devices serial number label
Certification
Certification body
CPR certificate DoP 0359-CPR-00269
Approved to EN54-13:2005. Fire detection and fire alarm systems.
Part 13: compatibility assessment of system
components.
EN54-18:2005. Fire detection and fire alarm systems.
Part 18: input/output devices.
EN54-25:2008. Incorporating corrigenda september
2010 and march 2012. Fire detection and fire alarm
systems. Part 25: components using radio links.
European Union
EMS declares that the radio equipment type SmartCell
directives Dual Input / Output Device is in compliance with
Directive 2014/53/EU. The full text of the EU
declaration of conformity is available at the following
internet address: www.mysmartcell.co.uk
2012/19/EC (WEEE directive): Products marked with
this symbol cannot be disposed of as unsorted
municipal waste in the European Union. For proper
recycling, return this product to your local supplier
upon purchase of equivalent new equipment, or
dispose of it at designated collection points. For more
information see www.recyclethis.info
Dispose of your batteries in an environmentally
friendly manner according to your local regulations.
19
Two resistor monitored inputs are
available.
Both inputs monitor; normal,
alarm, open circuit and closed
circuit conditions.
Each input is factory fitted with an
end of line 20 kΩ resistor.
To connect inputs to external
devices, wire as shown, using the
resistors provided.
Minimum input detection time is 2
seconds.
If an input is not being used, leave
the 20 kΩ resistor as factory fitted.
Two outputs are available.
Both outputs are voltage free,
with a maximum switching
capacity of 30 V at 1 A.
This product contains relays which when subjected to severe mechanical shock
may cause momentary transitions from the currently active state. The
transitions will be less than 1 second and any equipment connected must not
respond to such momentary changes of the relay. This product should be fixed
to a stable and secure structure that is not subject to severe mechanical shock.
0359
OUTPUT 1 OUTPUT 2
N/O
COM
N/C
N/O
COM
N/C
20k 4k7
CN/O
EOL resistor
configuration
Remote monitored device
A
B
INPUT 1
A
B
INPUT 2
Note: max cable
length of 10 m
20kΩ
!
9 LED operation 10 Completing the installation
Output 1
LED
Output 2
LED
Input 2
LEDs
Input 1
LEDs
The front lid must now be re fitted to the device and all four fixing screws
tightened to fully reassemble the unit.
The device has six indication LEDs. They operate as follows:
Input fault: YELLOW LED ON
Input active: RED LED ON
Output active: RED LED ON
Application label
This can be utilised to
identify connected
circuits as per the
above example
Status LED location
This status LED is
multi functional. See
programming manual
(TSD155) for full
details of operation
WARNING. DO NOT CONNECT TO MAINS.
Specification Regulatory information
STATUS
DUAL INPUT/OUTPUT DEVICE
LOG ON POINT
Input 1: BEAM DETECTION
Input 2: GAS DETECTION
Output 1: FAN SHUT OFF
Output 2: GAS SHUT OFF
©2020 EMS Ltd. All rights reserved. Page 1 of 2 TSD089-0001-99 (Issue 1) 12/05/2020 AJM
This is a life safety product. Only use manufacturer approved battery types.
Failure to do so may result in damage to the product.
DO NOT mix batteries of different type or age.
When replacing batteries; remove all old batteries before fitting replacements.
