Simrad PI HBU - REV A User manual

Instruction manual
Simrad PI HBU
Hydrophone Booster Unit
TECHNOLOGY FOR SUSTAINABLE FISHERIES
www.simrad.com

SimradPIHBU
HydrophoneBoosterUnit
InstructionManual
ThisdocumentallowsyoutoinstallandputtousethePI
HBU(HydrophoneBoosterUnit).
326153/A
08January2008

Documenthistory
Documentnumber:326153
Rev.A8January2006Firstversion.
Copyright
©2008KongsbergMaritimeAS
TheinformationcontainedinthisdocumentremainsthesolepropertyofKongsbergMaritimeAS.Nopart
ofthisdocumentmaybecopiedorreproducedinanyformorbyanymeans,andtheinformationcontained
withinitisnottobecommunicatedtoathirdparty,withoutthepriorwrittenconsentofKongsberg
MaritimeAS.Thedocument,oranypartofit,maynotbetranslatedtoanyotherlanguagewithoutthe
writtenapprovalfromKongsbergMaritimeAS.
Disclaimer
KongsbergMaritimeASendeavourstoensurethatallinformationinthisdocumentiscorrectandfairly
stated,butdoesnotacceptliabilityforanyerrorsoromissions.
Warning
Theequipmenttowhichthismanualappliesmustonlybeusedforthepurposeforwhichit
wasdesigned.Improperuseormaintenancemaycausedamagetotheequipmentand/orinjury
topersonnel.Theusermustbefamiliarwiththecontentsoftheappropriatemanualsbefore
attemptingtoinstall,operateorworkontheequipment.
KongsbergMaritimeASdisclaimsanyresponsibilityfordamageorinjurycausedbyimproper
installation,useormaintenanceoftheequipment.
Support
IfyourequiremaintenanceonyourSimradproductcontactyourlocaldealer.Y oucanalsocontactususing
thefollowingaddress:s
i m r a d . s u p p o r t @ s i m r a d . c o m .Ifyouneedinformationaboutourotherproducts,
visitww w . s i m r a d . c o m .Onourwebsiteyouwillalsondalistofourdealersanddistributors.
Kongsb e rg M a ritim e A S
S tra n d prom e n a d e n 5 0
P.O.Box 1 11
N- 31 91 H orten , N orwa y
S im r a d
Te le ph one : + 47 3 3 0 3 4 0 0 0
Te le fax: + 47 3 3 0 4 2 9 8 7
co nta ct@s im ra d .com
w w w .s im r a d .c o m

InstructionManual
Tableofcontents
ABOUT..............................................................................5
PIHBU(HYDROPHONEBOOSTERUNIT)...........................6
RECOMMENDEDPARAMETERSETTINGS............................7
SimradPI32..............................................................................................................7
SimradPI44andPI54...............................................................................................7
INSTALLATION.................................................................9
326153/A3

SimradPIHBU
4326153/A

About
ABOUT
ThisdocumentallowsyoutoinstallandputtousethePIHBU
(HydrophoneBoosterUnit).
Figure1PIHBU(HydrophoneBoosterUnit)
Figure2CommercialpowersupplyprovidedwiththePIHBU
326153/A5

SimradPIHBU
PIHBU(HYDROPHONEBOOSTERUNIT)
ThePIHBU(HydrophoneBoosterUnit)isasmallandcompact
unitprovidingamplicationfortheweaksignalsfromthePI
hydrophone.ItisconnectedbetweenthehydrophoneandthePI
cabinet.ThePIHBUispoweredbyaseparatepowersupply.
Prerequisitesforuse
InordertousethePIHBUyourPIreceivermustoperatewith
thefollowingsoftwareversion:
•PI32:Notapplicable
•PI44:DSP(DigitalSignalProcessor)version1.11(orlater)
withMMIversion0.50(orlater).
•PI54:DSP(DigitalSignalProcessor)version1.11(orlater)
withMMIversion0.50(orlater).
WhyusethePIHBU
OnthePI44andPI54systems,softwarerelease1.08providedan
increasedrangecapability.ByusingthePIHBU(Hydrophone
BoosterUnit)aswellthesystemswillofferadditionalrange,
andtheywillbemoretolerantfornoise.OnPI32systems,the
PIHBU(HydrophoneBoosterUnit)willalsoprovideincreased
rangecapability.
Whyn
o t usethePIHBU
ForthemajorityofPIusersexperiencingadequateperformance,
andwithnoneedtoincreasetherangecapability,thePIHBU
(HydrophoneBoosterUnit)willnotberequired.
WhentousethePIHBU
ThePIHBU(HydrophoneBoosterUnit)isrecommendedif
thereceptionofthePIsystemisclutteredwithnoisefrom
interference,orwithnoisefromotheracousticsystemsonthe
vessel,suchassonars,echosoundersorlogs.ThePIHBU
(HydrophoneBoosterUnit)mayalsoproveusefulifyou
experiencenoisefromthevesselpropellers.
6326153/A

Recommendedparametersettings
RECOMMENDEDPARAMETERSETTINGS
WhenthePIHBU(HydrophoneBoosterUnit)isputtouse,the
recommendedparametersettingsarechanged.
SimradPI32
ThefollowingReceiversetupparametersarerecommendedwhen
thePIHBU(HydrophoneBoosterUnit)isputtouse.
•Interferencelter:OFF
–SwitchONifinterferenceisstillaproblem.Asan
alternative,youmaykeepthelterOFF,andincreasethe
Detectionthreshold(DT)settinginstepsof2dBuntilthe
interferencedisappears.
•Interferencelterlevel:9
–IfyouswitchtheinterferencelterON,youmaychange
thelevelto8.
•AGC:OFF
•Manualgain:20dB
•Maxshootingspeed:1kn
–Inordertomaintainbestpossiblereceptionduringthe
shootingyoumayincreasethissettingto5kn.
•Detectionthreshold(DT):8dB
Theothersettingsarenotimportant.
Figure3PI30ReceiverSetup,example
SimradPI44andPI54
WhenthePIHBU(HydrophoneBoosterUnit)isputtouse,the
recommendedparametersettingsarechanged.
326153/A7

SimradPIHBU
•Interferencelter:OFF
–SwitchONifinterferenceisstillaproblem.Asan
alternative,youmaykeepthelterOFF,andincreasethe
Detectionthreshold(DT)settinginstepsof2dBuntilthe
interferencedisappears.
•Interferencelterlevel:8
–IfyouswitchtheinterferencelterON,youmaychange
thelevelto7.
•Sensorlter:LIGHT
•Catch/Bottomsensorlter:LIGHT
•AGC:OFF
•Manualgain:20dB
•Multipathlter:OFF
–IfyouusethePIGeometrysensor,thisltermustbeON.
•Detectionthreshold(DT):8dB
•Maxshootingspeed:1kn
–Inordertomaintainbestpossiblereceptionduringthe
shootingyoumayincreasethissettingto5kn.
Theothersettingsarenotimportant.
Figure4PI44/54ReceiverSetup,example
8326153/A

Installation
INSTALLATION
ObservetheproceduretoinstallthePIHBU(Hydrophone
BoosterUnit).
1UnpackthePIHBU(HydrophoneBoosterUnit)unit.
2Checkthatthepackagecontainstheunitandapowersupply.
3FindasuitablelocationforthePIHBUunit.
TheunitmustbeplacedclosetothePIoperatorunit,and
withinreachofapoweroutlet(115–230V ac).Observethe
lengthofthehydrophonecable,whichlimitsthedistance
betweentheunits.
4MountthePIHBUunit.
5PowerdownyourPIsystem.
6Disconnectthehydrophoneconnectorontherearsideofthe
PIoperatorunit,andconnectittothePIHBUunit(A).
Figure5PIHBU(HydrophoneBoosterUnit)connections
AHydrophonesocket
BCabletohydrophonesocketonPIoperatorunit
C+24Vdcpowersocket(usepowersupplyprovided
withthePIHBU)
7ConnectthecablefromthePIHBUunit(B)tothe
hydrophonesocketontherearsideofthePIoperatorunit.
8ConnectthepowersupplytoACmains,andconnectthe
powercabletothesocket(C)onthePIHBUunit.
9PowerupyourPIsystem.
326153/A9
