Smarteh LPC-2.ID1 User manual

USER MANUAL
Longo programmable controller
LPC-2.ID1
RFID Card reader
Version 7
SMARTEH d.o.o. / Poljubinj 114 / 5220 Tolmin / Slovenia / Tel.: [phone] / e-mail: i[email protected] / www.smarteh.si

Longo programmable controller LPC-2.ID1
Written by SMAR EH d.o.o.
Copyright © 2012, SMAR EH d.o.o.
User Manual
Document Version: 007
July 1, 2012
i

Longo programmable controller LPC-2.ID1
S ANDARDS AND PROVISIONS: Standards, recommendations,
regulations and provisions of the country in which the devices will
operate, must be considered while planning and setting up electrical
devices. Work on 100 .. 240 V AC network is allowed for authorized
personnel only.
DANGER WARNINGS: Devices or modules must be protected from
moisture, dirt and damage during transport, storing and operation.
WARRAN Y CONDI IONS: For all modules LONGO LPC-2 – if no
modifications are performed upon and are correctly connected by
authorized personnel – in consideration of maximum allowed
connecting power, warranty of 24 months is valid from the date of
sale to the end buyer, but not more than 36 months after delivery
from Smarteh. In case of claims within warranty time, which are based
on material malfunctions the producer offers free replacement. he
method of return of malfunctioned module, together with description,
can be arranged with our authorized representative. Warranty does
not include damage due to transport or because of unconsidered
corresponding regulations of the country, where the module is
installed.
his device must be connected properly by the provided connection
scheme in this manual. Misconnections may result in device damage,
fire or personal injury.
Hazardous voltage in the device can cause electric shock and may
result in personal injury or death.
NEVER SERVICE HIS PRODUC YOURSELF!
his device must not be installed in the systems critical for life (e.g.
medical devices, aircrafts, etc.).
If the device is used in a manner not specified by the manufacturer,
the degree of protection provided by the equipment may be impaired.
Waste electrical and electronic equipment (WEEE) must be collected
separately!
LONGO LPC-2 complies to the following standards:
•EMC: EN 61000-6-3:2007 + A1:2011, EN 61000-6-1:2007, EN 61000-
3-2:2006 + A1:2009 + A2: 2009, EN 61000-3-3:2013
•LVD: IEC 61010-1:2010 (3rd Ed.), IEC 61010-2-201:2013 (1st Ed.)
Smarteh d.o.o. operates a policy of continuous development.
herefore we reserve the right to make changes and improvements to
any of the products described in this manual without any prior notice.
MANUFAC URER:
SMAR EH d.o.o.
Poljubinj 114
5220 olmin
Slovenia
ii

Longo programmable controller LPC-2.ID1
Longo programmable controller LPC-2.I 1
1 DESCRIP ION...................................................................................1
2 FEA URES.......................................................................................2
3 INS ALLA ION..................................................................................3
3.1 Connection scheme....................................................................3
3.2 Mounting instructions.................................................................5
3.3 Module labeling........................................................................7
4 ECHNICAL SPECIFICA IONS.................................................................8
5 PROGRAMMERS GUIDE........................................................................9
6 CHANGES .....................................................................................11
7 NO ES..........................................................................................12
iii

Longo programmable controller LPC-2.ID1
1 ESCRIPTION
LPC-2.ID1 card reader (RFID identification) special module is used for a room door unlock.
On room entrance the identification card (ID card) must be approached to the identification module.
In case that ID card is read correctly (correct RFID key standard) the green LED switches on and a
short whistle appears. If ID card for correspondent room is valid (valid ID card number), the green
LED switches on again and a short whistle appears. After few moments the electric lock will be
opened (use LPC Manager for function logics). If the ID card number is wrong, the red LED switches
on and a longer whistle appears (refer to the able 5).
LPC-2.ID1 module is also used to present messages “OCCUPIED”, “DO NO DIS URB”, “ROOM
SERVICE” and “SOS” - use LPC Manager for function logics - (refer to the able 5).
LPC-2.ID1 is connected to the main module RS485 port using interconnection cable (e.g. SIC4-7)
which must be ordered together with LPC-2.ID1 reader. When more special modules (e.g. LPC-2.ID1,
LPC-2.ID2, LPC-2.P01) are connected to one main module, splitter (e.g. SPL-2) is also required (refer
to the Figure 2).
In case that other (magnet or contact – chip) card system is used for door unlock, LPC-2.ID1 module
can be used to show messages.
NO E: For proper system configuration and data allocation please refer to LPC Composer software
help menu.
LPC-2.ID1 module can be modified on customer request (front label changed, push buttons added,
LEDs added). Please contact manufacturer for more information.
1

Longo programmable controller LPC-2.ID1
2 FEATURES
Figure 1: LPC-2.ID1 special module.
Table 1: Technical data
RFID identification
4 LEDs for “OCCUPIED”, “DO NO DIS URB”, “ROOM SERVICE” and “SOS” status
OK “ √ ” LED
FAUL “ X ” LED
Power LED
Internal fault LED
Digital input
Relay output
2

Longo programmable controller LPC-2.ID1
3 INSTALLATION
3.1 Connection scheme
Figure 2: Connection scheme
3

Longo programmable controller LPC-2.ID1
Table 2: K1
K1.1 GND Ground
K1.2 9 V DC Power supply input
K1.3 Standard RS-485 A Data receive/send line A
K1.4 Standard RS-485 B Data receive/send line B
Table 3: K2
K2.1 SPS relay contact Make contact (NO)
K2.2 SPS relay contact Make contact (NO)
Table 4: K3
K3.1 9 V DC Power supply output
K3.2 Digital input, 0 .. 9 V DC 9 V DC digital input
Table 5: LE s & Buttons
Power LED (on the upper side of
the module)
Green LED: indicates
power supply status
On: power supply OK
Off: power supply missing or
power off
Internal fault LED (on the upper
side of the module)
Red LED: indicates
LPC-2.ID1
communication state
On: RS-485 communication fault
Off: RS-485 communication OK
OCCUPIED, DO NO DIS URB,
ROOM SERVICE, SOS
Green LED: indicates
correspondent signal
presence
On: signal present
Off: signal not present
OK “ √ ” LED
Green LED: indicates
RFID key standard and
number
On: RFID key standard OK and ID
card number valid
FAUL “ X ” LED
Red LED: indicates
RFID key standard and
number
On: RFID key standard NOK and ID
card number wrong
4

Longo programmable controller LPC-2.ID1
3.2 Mounting instructions
Figure 3: Housing dimensions
Dimensions in milimeters.
All connections, module attachments and assembling must be done
while module is not connected to the main power supply.
he LPC-2.ID1 module should be positioned on the wall outside the
room. It is advised to avoid direct sunlight or position near
heating/cooling source object. Round flush-mounting box (e.g. Gewiss
GW 24232), Φ60 mm is recommended for installation. A box must be
installed with screw holes in the horizontal position!
Mounting instructions:
1. Mount LPC-2.ID1 module back plate to the provided leveled place on the wall.
2. Fasten 2 screws (DIN 7981 or similar, Φ3 mm, max. head height 3 mm) to fix LPC-2.ID1
module to its place.
3. Connect interconnection cable to the interconnection connector K1. Max. allowed tractive
force is 30 N.
4. Power (PWR) green LED should switch on according to the able 5.
5. Mount LPC-2.ID1 module front plate to the back plate.
IMPOR AN : Front plate must be placed in order that switch S1 (according to the Figure 2) is
pressed (normally is released).
6. Fasten the screw in the bottom carefully (not too strong), to fix the front plate to the back
plate.
5
26

Longo programmable controller LPC-2.ID1
NO E:
LPC-2.MC3 main control module should be powered separately from other electrical appliance
connected to LPC-2 system. Signal wires must be installed separately from power and high voltage
wires in accordance with general industry electrical installation standard.
Several RFID panels should not be mounted close to each other. Minimum distance to next panel is
at least 30 cm. his restrict also applies in case of mounting panels on both sides of the same wall.
Adequate shielding material and provisions should be used to avoid interference between panels.
Signal wires must be installed separately from power and high voltage wires in accordance
with general industry electrical installation standard.
6

Longo programmable controller LPC-2.ID1
3.3 Module labeling
Figure 5: Labels on housing
Label 1(MC3 sample): Label 2 (MC3 sample):
Label 1 description:
1. LPC-2.MC3 is the full product name.
2. P/N:225MC3040001001 is the part number.
•225 – general code for product family,
•MC3 – short product name,
•04001 – sequence code,
•04 – year of code opening,
•001 – derivation code,
•001 – version code (reserved for future HW and/or SW firmware upgrades).
3. /C:16/05 is the date code.
•16 – week and
•05 – year of production.
Label 2 description:
1. S/N:MC3-S9-0500000190 is the serial number.
•MC3 – short product name,
•S9 – user code (test procedure, e.g. Smarteh person xxx),
•0500000190 – year and current stack code,
•05 – year (last two cyphers),
•00000190 – current stack number; previous module would have the stack number
00000189 and the next one 00000191.
7

Longo programmable controller LPC-2.ID1
4 TECHNICAL SPECIFICATIONS
Table 5: Technical specifications
Power supply from main module (LPC-2.MC7)
Interconnection connector type Berg M
Power consumption 0.5 W
RFID type Manchester 64, read only
Max. reading distance 8 cm
K2
output:
Number of outputs 1 SPS – NO relay output
Nominal switching capacity 2 A 30 V DC
Max. switching power 60 W
Max. switching voltage 220 V DC
Max. switching current 2 A
Min. switching capacity 10 uA, 10 mV DC
Insulation Basic, do not connect mains voltage
Dimensions (L x W x H) 80 x 110 x 26 mm
Weight 80 g
Ambient temperature 0 to 50 °C
Ambient humidity max. 95 %, no condensation
Maximum altitude 2000 m
Mounting position vertical
ransport and storage temperature -20 to 60 °C
Pollution degree 2
Protection class IP 30
8

Longo programmable controller LPC-2.ID1
5 PROGRAMMERS GUI E
Variables
here are 22 bytes available for reading and writing from/to ID1 module. While whole frame of 26
bytes is transferred at a time, LPC Manager variables described in the table below are accessed
separately.
VBOOL8 (#N)
variable range
Comm. status
0..1
New ID received
BI 2
BI 3
BI 4
BI 5
Remove switch status
Door switch status
VBOOL8 (#N+1)*
variable range
BI 0
0..1
BI 1
BI 2
BI 3
BI 4
BI 5
BI 6
BI 7
* Pushbuttons and LEDs can be added on the customer request.
9

Longo programmable controller LPC-2.ID1
VBOOL8 (#N+2)
variable range
Relay output command
0..1
BI 1
BI 2
BI 3
Received ID OK command
Received ID Fault command
BI 6
BI 7
VBOOL8 (#N+3)*
variable range
OCCUPIED LED
0..1
DO NO DIS URB LED
ROOM SERVICE LED
SOS LED
BI 4
BI 5
Reserved
Reserved
* Pushbuttons and LEDs can be added on the customer request.
VWOR 16 (#N+4)
variable range
Received ID WORD1
0..1
Received ID WORD2
Received ID WORD3
WORD4
WORD5
WORD6
WORD7
WORD8
WORD9
WORD10
10

Longo programmable controller LPC-2.ID1
6 CHANGES
he following table describes all the changes to the document.
ate V. escription
1.7.2012 007 CGP General update.
2.8.2007 006 - updated K2 output specs
- updated description about connecting to main module
26.4.2007 005 - updated connection scheme
- updated power supply source
15.3.2006 004 - Added output isolation description
- Added output protection type description
- Pollution degree changed to 2
27.3.2005 003 he initial version, issued as LPC-2.ID1 module User Manual.
11

Longo programmable controller LPC-2.ID1
7 NOTES
12
