SmartLock VISION User manual

VISION TECHNICAL MANUAL
Default codes (change default codes)
Setup (Master) 5-0-5-0-5-0-5-0
Service not installed
Manager 1-2-3-4-5-6
Users (1-9) not installed
Open the lock
•Enter the code and open within 4 seconds.
•If time delay is set wait for counting: an acoustic signal indicates open window.
•Enter the code and open within 4 seconds.
Open the lock with time delay override
•Enter override user (9) code.
•Enter second code and open within 4 seconds.
If lock is already counting time delay enter override user (9) code to immediately open.
Change code (door open)
•Press and hold 0 until double beep: enter old code.
•Enter and confirm new code.
Install a user
•Press and hold 1 until double beep: enter Manager code.
•Enter user ID (1-9).
•Enter and confirm new user code.
To install Manager enter the function with Service code.
Users management
•Press and hold 2 until double beep: enter Manager code.
•Press P to scroll users list and check their status.
•Press 1 to install a user: enter and confirm user code.
•Press 2 to disable/enable a user.
•Press 3 to delete a user.
•Press OK to confirm and exit.
Delete a user
•Press and hold 3 until double beep: enter Manager code.
•Enter user ID (1-9).
To delete Manager enter the function with Service code.
Test function
•Press and hold 5 until double beep.
•Enter the sequence: 1-2-3-4-5-6-7-8-9-0.
•Double beep: key properly working. Long beep: key malfunction.
If lock and keypad don’t communicate display shows the message: NO ANSWER.

of 1 2
OPEN
LOCK
CODE
o o o o o o
INSTALL
o o o o o o
CHANGE
o o o o o o

ID= 1
ID= 2
ID = 3
DELETE
o o o o o o
TEST

Change Setup code (Master)
•Press and hold 8 until double beep, enter Setup code and select function 0.
•Enter and confirm new Setup code.
Install Service
•Press and hold 8 until double beep, enter Setup code and select function 1.
•Press OK to confirm the operation.
•Enter and confirm new Service code.
Delete Service
•Press and hold 8 until double beep, enter Setup code and select function 3.
•Press OK to confirm the operation.
Reset lock
•Press and hold 8 until double beep, enter Setup code and select function 5.
•Display shows the message RESET.
•Press OK to confirm the operation.
•Enter a valid code.
•Lock is in pre-setup mode.
Pre-setup mode
•To open press 1.
•Setup code (Master) 5-5-5-5-5-5-5-5.
Lock setup
•Press and hold 8 until double beep. Enter the Setup code 5-5-5-5-5-5-5-5.
•Display shows the following options (press P to scroll):
•CHANGE: change Setup code to exit pre-setup mode.
•SETUP: check (OK) or change (P) lock configuration (bold = default settings)
•DELAY DOWN - DELAY UP: time delay counting up or down.
•DUAL NO - DUAL YES: dual mode active - dual mode not active.
•DIGITS 6 - DIGITS 7 - DIGITS 8: opening codes length.
Time delay
•Press and hold 9 until double beep and enter Manager code (or Service code) or
access Setup menu and press 9.
•Display shows current time delay values: press OK to confirm or enter new values
(00-99min) and press OK.
•Display shows current open window values: press OK to confirm or enter new values
(01-19min) and press OK.
Time delay can be increased at any moment, decreased only during open window.
Change language
•Press and hold OK until double beep: display shows the current language.
•Press OK until the desired language will be selected.
Check firmware version
•Press and hold OK until double beep: display shows the current language.
•Press P: display shows serial number and firmware version.

of 2 2
ENGLISH
ITALIAN?
42C1AH90
VER. 01.01
DELAY
o o o o o o
FUNCTION
01 3 5 6 7 9
FUNCTION
0 13 5 6 7 9
FUNCTION
0 1 3 56 7 9
FUNCTION
0 1 35 6 7 9
RESET
WINDOW
02min?
DELAY
05min?
