SmarTrike 820 User manual

20010020820
820/840
USA: 1-855-SMTRKUS
(1-855-768-7587)
LOOK US UP ON YOUTUBE:
www.youtube.com/user/SmartTrikeOcial
UK: 0845 5046410
9:30am – 5:00pm Monday to Friday
Not Bank Holidays or weekends.
You can also email us: [email protected]
for assistance and advice.
If you have any assembly issues or are
missing a part, please call us for
assistance. Our smarTrike® assembly
experts will assist you.
DO NOT RETURN TO THE STORE
If you are experiencing problems with this
product, please call our HELP LINE.
20010004620 20010006680
C
20010003820
D F
G H I J
N
20010001820
20010007680
E
B
LK M2M1
A
1
2
20010008680 20010004820 20010005820 20010006820
20010014680 20010007820 20010001840
20010016680
www.smarTrike.com
-1-

Step 1 Parts needed to complete this section
B
A
1a
Insert part A into part B
until you hear a "click".
CLICK!
-2-

Insert part E all the way
through, until the ball
meets the retaining head.
Insert part D into part C
all the way through the
hole (as shown)
Step 2 Parts needed to complete this section
E
- a - b
DC
2a 2b
-3-

CLICK!
CLICK!
Push the apple firmly down to
insert, slightly turn until you
hear a "click". Make sure white
connector is not visible.
Step 3 Parts needed to complete this section
- a - b 3a 3b
Insert the wheel all the way
through the body of the trike until
the bolt meets the retaining head.
-4-

N
- a - b
F
4a 4b
1
2
-5-
By using the "Allen"
key (N), remove
screw by turning
counter clockwise.
Take the reclining seat (F), lift bottom seat cover
and push the screws through the seat's bottom
holes. Screw tip into the most rear facing hole
and firmly tighten with the Allen key (N).
Step 4 Parts needed to complete this section

CLICK!
G
- a 5a
-6-
Suitable for 10 Months
WARNING: It may be dangerous to
leave your child unattended. Use a
safety belt as soon as your child can sit
unaided. This seat is not suitable for
children under 10 months. Any load
attached to the handle aects the stability
of the product. This product is not suitable
for running or skating.
With a little force, push part G's protrusions
into reclining seat slots (located on both
sides of the seat) until you hear a "click".
Step 5 Parts needed to complete this section

6a
H
-7-
CLICK!
Canopy's (H) narrow arch needs to face
towards the rear of the trike. Attach both
sides of canopy into grooved holder by
sliding downward until secured.
Step 6 Parts needed to complete this section

Step 7 Parts needed to complete this section
N
I
7a 7b
7c
CLICK!
CLICK!
1
2
Attach basket firmly to vertical
frame (as shown), use removed
screw and turn clockwise until
secured.
Use the Phillips screwdriver (N)
to remove the screw by turning
counter clockwise.
Push basket (I) firmly onto
rear axle until it "clicks" into
position (see 1 & 2).
-8-

8a
Step 8 Parts needed to complete this section
K
J
Align part J in to the designated
holes in the center of the handlebar
and push down firmly until it "clicks".
CLICK!
8b
CLICK!
-9-
Align part K in to the designated
holes in the center of the handlebar
and push down firmly until it "clicks".

Step 9 Parts needed to complete this section
L-
9a
-
WARNING: This product
should be used on safe
ground, it should not be used
near steps, slopes, roadways,
public highways or wet areas.
Push the button on the parent
handlebar as shown, and fully
extend length.
9b
2
1
Unlock securing pin and remove
it from the hole.
9c
Insert the parent handle (L) into
the retaining hole at the rear of
the trike.
-10-

L
-
9d
1
2
-11-
WARNING: Make sure
safety pin is inserted
correctly and secured.
Insert the securing pin through the
parent handle, and secure with lock.
Step 9b-10 Parts needed to complete this section
10a 10b
For the 10+ month stage, open
the footrest by pulling it down.
Pull down both sides of the
footrest.

M1
1
2
Attach the handle of the bag
to the parent handle hook.
Pull the plastic hooks of the bag
(M1) around the rim of the basket.
Parts needed to complete this section
10a 10b
10c
Max. load of basket
2.2 lb / 1 kg.
-12-
Wrap hook and loop straps
around the parent handle.
Recliner InfinityTM 840

1
2
3
M2
10a 10b
10c
-13-
Max. load of basket
2.2 lb / 1 kg.
Wrap hook and loop strap and buckle
strap around the parent handle.
Attach handles of the bag (M2) to
parent handle hook.
Pull the elastic bands of the bag
around the sides of the basket.
Parts needed to complete this section
ExplorerTM 820

Parent control
When the clutch is pulled away from the
wheel, there is no pedal control and the
wheel is in a free mode position.
1
10M+
2b2b
-14-

Child control
-15-
3a 3b
1
1
2
1
180
3
1
2
4
2b
2a
For the 24+ months stage,
fold up left and right footrest.
Push release button to place it
back into frame.
1
1
2
2

2
2
1
1
1
2
7
8
5 6
When the clutch is aligned with
the front wheel, child has pedal
control. In this mode the
footrest should be folded.
82028014603
-16-
