Product Overview
SMC-EZ1016DT/SMC-EZ1024DT
EZ Switch 16- and 24-port Fast Ethernet switches
The EZ Switches™ 10/100 SMC-EZ1016DT and SMC-EZ1024DT are 16-/24-port
unmanaged Fast Ethernet switches. All 10BASE-T/100BASE-TX ports deliver
dedicated 10/100 Mbps links to each attached LAN segment – all with conventional
cabling and adapters. Auto-negotiation is used to select the optimal communication
mode for each connection, auto-sensing selects the optimal transmission speed. With
store-and-forward switching and flow control, maximum data integrity is always
maintained, even under heavy loading. Environmentally friendly the switches
consume less power than non-Green Ethernet switches without reducing network
performance. Easy installation and reliability make these plug-and-play switches an
ideal choice for smooth Fast Ethernet integration in home and small office network
environments.
Key Features and Benefits
Auto MDI/MDI-X on each port
No crossover cables required, pure plug and play.
LED indicators
Simple, at-a-glance LEDs to see port status and for
simple troubleshooting..
Green Ethernet
Environmentally friendly with up to 60% power saving
compared to non-Green switches, maximum power
consumption of 6.8W/ 8.5W.
Metal chassis, fan-less design
The compact, rack mountable metal chassis is ideal for
desktop or rack mounting applications. In addition, the
lack of fans ensures silent operation.
Internal power supply
The internal power supply is simple and easy to use. No
fumbling with oversized AC adapters. Plug ‘N’ Play Rackmountable
Power Saving

Features
Optional Accessories
Contact
North America
20 Mason, Irvine,
CA 92618, U.S.A
1-800-SMC-4YOU
24/7 Technical Support
Europe/Africa
Fructuos Gelabert 6-8
08970 Sant Joan Despi
Barcelona, Spain
Check www.smc.com for your local country contact information
©2009 SMC Networks. EZ SwitchTM is a trademark of SMC
Networks. Other trademarks or registered trademarks are the
property of their respective owners. Information is subject to
change without notice. All rights reserved.
PHYSICAL PORTS
SMC-EZ1016DT
16 x 10/100 BASE-TX
SMC-EZ10124DT
24 x 10/100 BASE-TX
NETWORK INTERFACE
10BASE-T (IEEE 802.3), Ethernet
100BASE-TX (IEEE 802.3u), Fast Ethernet
SWITCHING DATABASE
SMC-EZ1016DT: 8K MAC address entries
SMC-EZ1024DT: 8K MAC address entries
BUFFER MEMORY
SMC-EZ1016DT: 160KB/ device
SMC-EZ1024DT: 160KB/ device
SWITCH FABRIC
SMC-EZ1016DT: 3.2 Gbps, non-blocking
SMC-EZ1024DT: 4.8 Gbps, non-blocking
THROUGHPUT
SMC-EZ1016DT: 2.4Mpps
SMC-EZ1024DT: 3.6Mpps
FEATURES
IEEE 802.3x Flow Control
Auto-MID/ MDI-X
Green Ethernet, low power consumption
LED
System: Power
Port: Link/Activity
POWER CONSUMPTION
SMC-EZ1016DT: 6.8W
SMC-EZ1024DT: 8.5W
POWER REQUIREMENTS
Input Voltage: 100-240 VAC @ 50-60Hz
DIMENSIONS
SMC-EZ1016DT: 21.6*13.3*4.2 cm/ 8.5*5.2*1.7 in
SMC-EZ1024DT: 26.7*16.1*4.2 cm/ 10.5*6.3*1.7 in
WEIGHT
SMC-EZ1016DT: 870g/ 1.90lbs
SMC-EZ1024DT: 1376g/ 3.0lbs
ELECTROMAGNETIC COMPATIBILITY
CE Mark
FCC Class A
IMMUNITY
EN55024
IEC61000-4/2/3/4/5/6/8/11
EMISSIONS
FCC Class A, CISPR Class A, EN55022/EN61000-3-2
SAFETY
LVD (EN60950)
TEMPERATURE
Operating: 0~400C, 32~1040F
Humidity: 10% to 90%, non-condensing
WARRANTY
Please check www.smc.com for the warranty terms in
your country.
