OVERVIEW
The SMC8511WG Outdoor Multi-Radio Wireless Access Point with integrated DOCSIS cable modem offers
cable operators a quick and easy method to extend the reach of their existing DOCSIS networks and to
increase service offerings within their current infrastructure without a cable drop. In addition to plant
extension applications, the SMC8511WG can also serve as an Access Point allowing multiple PCs to connect
from a public hotspot. The ruggedized, industrial design of the SMC8511WG can withstand harsh outdoor
environments, and the dual external antennas provide extended wireless coverage.
www.smc.com
v.1
SMC8511WG
IEEE 802.11a/b/g Outdoor Multi-Radio Wireless Access Point
with Integrated Cable Modem
JD:/,((N>
)/')%((^
Xek\eeXj
-'$0'M:fXo
:f]]\\J_fg
fi fi
F]]`Z\ Jki`gDXcc
APPLICATION DIAGRAM
KEY FEATURES
Rugged, Outdoor Enclosure Dynamic WAN Interface Features
Certified IP68 sturdy water-tight housing to withstand harsh
outdoor environments
Built-in automatic thermal sensor and regulator module to
facilitate deployment in cold regions
2 durable-N-type external antennae connectors for ultimate flexibility
Flexible wireless network distribution system
Bandwidth aggregation by logically combining multiple RF links to
achieve super trunk mode for high bandwidth deployments
Smart traffic load balancing across multiple RF links
Advanced Business Class Features Full Featured Operational Support
Static IP support via RIP/v1/v2 or Static Routes
VPN access to corporate LANs via pass through of L2TP, PPTP,
and IPSec
DHCP server supports management of Static IP block
User friendly and powerful CLI supports quick configuration and
troubleshooting
Remote management and provisioning via GUI and CLI-Point to
Point, Point to Multipoint, Access Point
SWITCHES VDSL WIRELESS VOIP STORAGE BROADBAND ADAPTERS
10G FIBER
10/100
PoE
COAX
DSL
WIRELESS
SMC DIAGRAM LEGEND

802.11 a/b/g WIRELESS
• Standard Support
Wireless: IEEE 802.11a, IEEE802.11b/g
INTERFACE
• Wireless : Antenna Connector: 2 x
Reversed Female N-type
CABLE MODEM FEATURES
• DOCSIS 2.0 certified
• 64/256QAM auto detection
• Support maximum DOCSIS transfer
rates
• Independent resets for downstream and
upstream blocks
• Quality of Service (QoS)
• Support 16 Service Identifiers (SIDs)
• Support 64/128/256 bit RC4
authentication and encryption
NETWORKING
• IEEE 802.1d compliant bridging
• DHCP Client and DHCP Server
• SNMP/DDNS/DMZ/Telnet/SSH/Radius/
TACACS/TACACS+/ UPnP
SECURITY
• SSID: Support Enable/Disable
Broadcast/ Support Multi-ESSID
• WEP:
• 64/128/152-bit Data Encryption
• Authentication type Open system/
Shared Key
• 802.1x : 802.1x Client and Server
• Radius: Support Radius Client
• WPA: Wi-Fi Protected Access ( EAP/TKIP)
• WPA 2: AES/802.11i
• MAC: MAC Address Filtering
ENCRYPTION
• 56-bit/128-bit DES
• 64-bit/128/256-bit WEP
ENVIROMENTAL
• Operating Temp: -30 to +65 C
-40 to +60C
• Operating Humidity: 5%~95% non-
condensing
• Storage Temp: -30 to +70C
REGULATION AND COMPLIANCE
• FCC Part 15 Class B & C & A
• Safety: UL1950,CB,CCIB
COMPLIANCE
• DOSCIS 1,0,1.1, 2.0 CableLabs® Certified™
DIMENSIONS (without brackets)
• 12.6 x 8.5 x 5.1 in (L x W x H)
• 32 x 21.5 x 13cm ((L x W x H)
SYSTEM SETTING
Standard: AP/AP Client/Bridge/ Router
RF INTERFACE APPLICATION
• Support Dynamic WAN Interface
assignments
FREQUENCY RANGE
• USA: 2.4-2.483GHz, 5.15-5.35GHz,
5.725-5.825GH
CHANNEL SUPPORT
• 802.11b/g
• US/Canada: 11 (1~11)
• 802.11a
• US/Canada: 12 non-overlapping
channels (5.15 ~5.35GHZ, 5.47~5.725 GHz)
WIRELESS TRANSMISSION RATE
• 802.11b/g: 11,5.5,2,1Mbps, auto-fallback,
up to 54Mpbs
• 802.11a: 54,48,36,24,18,12,9,6Mbps,
auto-fallback
TRANSMITTED POWER
• 802.11b: 18dBm
• 802.11g: 18dBm @6Mbps
: 15dBm@54Mbps
• 802.11a: 17dBm @6Mbps
: 13dBm@54Mbps
WIRELESS OTHER SETTING
• Enable/Disable Broadcast ESSID
• 802.11b/g compliant
• Bandwidth Control of Wireless Client
• WPA-PSK / WPA-EAP with TKIP/ CCMP
WPA Encryption Type support
• 802.1x EAP-TLS / MD5 WEP Key support
• 64/128/152 bits Dynamic WEP keys
• MAC Filtering
• Trunk: Trunking, Smart Traffic Load
Balance, One Way Transmit, Failover
• 802.11h : DFS and TPC
• Software Alignment/Deployment Tools
• Dual Image (backup)
POWER
• CATV Power AC 36~90V, < 15W
DATA CABLE MODEM
• Operation Frequency
• Downstream: 91~ 857MHz
• Upstream: 5~42MHz
FREQUENCY SELECTION
• Downstream: Auto Scanning; Controlled
by TFTP/SNMP
• Upstream: Controlled by UCC/UCD/
TFTP/SNMP
BANDWIDTH
• Downstream: 6MHz
• Upstream: 200kHz, 400kHz, 800kHz,
1.6kHz, 3.2kHz
DEMODULATION
• Downstream: 64QAM, 256QAM
• Upstream: QPSK, 16QAM
PHYSICAL SPEED
• Downstream: 38 Mbps (64QAM),
42Mbps (256QAM)
• Upstream: 320...5120 Kbps (QPSK)
640...10240 Kbps (16QAM)
RF INPUT/OUTPUT POWER
• Downstream: ITU-T J.83 Annex B
• Upstream: DOSCIS Upstream FEC with
scalable interleaving
NETWORK PROTOCOL
• Ipv4/ARP/ICMP/UDP/IGMPv2/DHCP/
TFTP/SNMPv1/v2c/v3/RIP v1/2
ELECTRICAL SPECIFICATION
• Input Power: 100 ~240 V AC, 50/60 Hz
WEIGHT
• 8.4lb
• 3.8kg
WARRANTY
• Limited Lifetime
Contact
North America
20 Mason
Irvine, CA 92618
1-800-SMC-4YOU
24/7 Technical Support
Europe/Africa
Fructuos Gelabert 6-8
08970 Sant Joan Despí
Barcelona, Spain
Check www.smc.com for your local
country contact information
©2008, SMC Networks. All rights reserved.
www.smc.com
v.1
TECH SPECS - SMC8511WG
SWITCHES VDSL WIRELESS VOIP STORAGE BROADBAND ADAPTERS
Interface 1 Interface 2
Access Point (AP) Access Point (AP)
Access Point (AP) Wireless Station
(Client)
Wireless Station
(Client)
Wireless Station
(Client)
