VULCAN™ Generator
Operations/Service Manual

31061526 Rev. CVULCAN™ Generator Operations/Service Manual
Glossary of Symbols
Non-Sterile Footswitch
Dangerous Voltage:
Danger of electric shock EU: Not for general waste
CAUTION: U.S. Federal law restricts
this device to sale by or on the order
of a physician.
UL Classification
Fragile; handle with care Fuse
This Way Up Amplitude Control
Keep Dry ON
Neutral (Return) Electrode
Connector
(Split Grounding Pad)
OFF
Defibrillator Proof Type
BF Equipment Up and Down Buttons
Equipotentiality Temperature Range
Alternating Current Humidity
Non-ionizing Electromagnetic Radiation European Representative
Protective Earth (ground) Service lifetime in years

41061526 Rev. C VULCAN™ Generator Operations/Service Manual
Preface
This manual provides the information required to operate and maintain the Smith & Nephew VULCAN™ Generator.
It is essential that all the information in this manual and on the generator label is read and understood before
using or maintaining the equipment.
Preface / Table of Contents
Table of Contents
GlossaryofSymbols..................................3
Preface ............................................4
Introduction ........................................5
DeviceDescription...................................5
IndicationsforUse ...................................5
Contraindications....................................5
Warnings.........................................5-6
Precautions.........................................7
Unpacking and General Inspection . . . . . . . . . . . . . . . . . . . . . .7
FrontPanelLayout..................................8–9
RearPanelLayout...................................10
PreoperativeSetup.................................. 11
OperationalModes..................................12
PowerDeliveryModes ...............................12
ControlsandFunctions............................ 13–14
Instructions for Use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14–15
Cleaning and Sterilization. . . . . . . . . . . . . . . . . . . . . . . . . . .15-16
Service and Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . .16-17
ServicePhilosophy................................16
ReplacingFuses..................................16
SoftwareUpgrades ............................... 17
Replacing/Returning Worn or Defective
Equipment or Parts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Preventative Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Calibration of Temperature Measurement Circuit . . . . . . . . 17
Troubleshooting .................................18-24
GeneratorControlUnit.............................18
Alarm and Fault Messages . . . . . . . . . . . . . . . . . . . . . . 18–21
ObservedProblems............................22–24
TechnicalSpecifications..............................25
OrderingInformation ................................26
OutputCharts...................................27-28
Output Voltage vs. Output Control. . . . . . . . . . . . . . . . . . . . 27
Power Output vs. Output Control, Cut Mode. . . . . . . . . . . . 27
Power Output vs. Output Control, Coag Mode . . . . . . . . . .28
Power Output vs. Load Resistance . . . . . . . . . . . . . . . . . . .28
Guidance and Manufacturer’s Declaration . . . . . . . . . . . . 29-31
Electromagnetic Emissions . . . . . . . . . . . . . . . . . . . . . . . . . 29
Guidance for Separation Distances. . . . . . . . . . . . . . . . . . . 29
Electromagnetic Immunity . . . . . . . . . . . . . . . . . . . . . . . 30-31
Warranty ...................................BackCover
Service Replacement Units Warranty . . . . . . . . . . . . .Back Cover
Service Replacement Program . . . . . . . . . . . . . . . . . .Back Cover
Repair Service Program. . . . . . . . . . . . . . . . . . . . . . . .Back Cover
Figures
1 Controlunitfrontpanel................................8
2 Controlunitrearpanel................................10
3 AC receptacle with fuses. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

51061526 Rev. CVULCAN™ Generator Operations/Service Manual
Introduction / Device Description / Indications for Use / Contraindications / Warnings
Introduction
The Smith & Nephew VULCAN™ Generator is designed
to provide finely-controlled radiofrequency (RF) energy
for the coagulation, cutting, ablation, and hemostasis
of soft tissue during a variety of surgical procedures.
The generator control unit is specifically designed for
use with Smith & Nephew temperature-controlled
and power-controlled probes.
Device Description
The generator control unit is a line-voltage powered,
radiofrequency generator capable of delivering up
to 200 watts of power. The generator control unit
includes a neutral electrode monitor (NEM) to monitor
split grounding pad contact quality. It is designed to
be used only with Smith & Nephew temperature-
controlled, cutting, and ablation probes and includes
the following features:
• Two RF output modes: Temperature Control
Mode, where the output power is software-
controlled to maintain a specified tissue
temperature; and Power Control Mode, used for
cutting, ablation, and hemostasis.
• Numerical displays for impedance, set power,
delivered power, set temperature, actual
temperature, set cut, set coagulation, and preset
selections.
• Message display for text messages.
• Indicators for electrode type (monopolar or
bipolar), mode (Temperature Control or Power
Control), stand-by, RF power on, RF output type
(cut or coagulation), fault, and split grounding pad
monitoring. NEM monitors the split grounding
pad connection during surgery, discontinuing
RF delivery if a fault in the NEM monitor circuit is
detected.
• A probe recognition system: the generator control
unit automatically selects the appropriate mode
and preset settings for the probe type.
The Smith & Nephew VULCAN Generator software
can be upgraded at the customer’s location
with a Smith & Nephew supplied PCMCIA card.
For information regarding software upgrades,
please contact your authorized Smith & Nephew
representative.
Indications for Use
The Smith & Nephew VULCAN Generator is
indicated for general surgical purposes, including
orthopedic and arthroscopic applications, for
coagulation, ablation, and hemostasis of soft tissues
in combination with Smith & Nephew temperature-
controlled, cutting, and ablation probes.
Contraindications
There are no known absolute contraindications to the
use of electrosurgery.
The use of the Smith & Nephew VULCAN Generator
and accessories is contraindicated, when, in the
judgment of the physician, an electrosurgical
procedure would be contrary to the best interest of
the patient.
Warnings
• It is the surgeon’s responsibility to be familiar
with the appropriate surgical techniques prior
to use of this device.
• Read these instructions completely prior to
use.
• DANGER: Risk of explosion if used in the
presence of flammable anesthetics, skin
preparation agents, or biointestinal gases.
• Hazardous electrical output. This equipment
should be used only by qualified medical
personnel trained in the use of electrosurgery
devices.
• This device has been tested and verified to
comply with the IEC 60601-2-2. This exceeds
the requirements specified by FCC part 18
for ISM equipment. This device is intended
for operation in a medical facility only. Usage
in a residential environment will likely cause
unacceptable RF interference for which the
user is held responsible.
• The generator control unit must be powered
from a properly grounded 120–240 VAC,
single-phase supply. Excessive risk (leakage
current) may result if this equipment is
connected to other than the manufacturer’s
recommended power distribution system.
• Risk of burns or fire. Do not use near
conductive materials such as metal bed parts,
inner-spring mattresses, etc.

61061526 Rev. C VULCAN™ Generator Operations/Service Manual
Warnings (continued)
• Check that the electrical equipment is properly
grounded (i.e. plugs contain a ground prong).
The generator control unit must be plugged
into a hospital-grade AC outlet.
• Safe use of monopolar electrosurgery demands
proper grounding of the patient and proper
insulation between the patient and any metal
surfaces. A split pad with a surface area of at
least 20 square inches (130 cm2) is required.
Valleylab… REM… pads (REF 7209687)
meet this dimensional requirement and are
recommended by Smith & Nephew for use with
the VULCAN™ Generator. Pads with a surface
area of less than 20 square inches may have a
lower dispersive effect. It is the responsibility
of the user to qualify any alternate ground
pad.
• Use of an inadequate ground pad or incorrect
placement of the ground pad may result in a
burn injury to the patient.
• Improper probe usage may result in patient
burns at the return pad. To avoid this, follow
the manufacturer’s Instructions for Use.
• Do not exceed the RF duty cycle for the probe.
• Do not withdraw the probe while energy
delivery is activated; this may result in
an unintended patient burn or ignition of
flammable materials.
• When using RF surgical equipment, keep the
working part of the RF probe’s active electrode
in the field of view to avoid accidental RF
burns. Avoid contact of the probe with metal
parts of the scope and other conductive
accessories by ensuring, before activation of
the RF probe, that the active electrode is at
sufficient distance from the tip of the scope.
• Failure of the radiofrequency surgical
equipment could result in unintended increase
of output power.
• Burns to the surgeon’s hands may be possible
if a probe comes into contact with a metal
instrument or surface.
• Use of electrosurgery in patients with
internal or external pacemakers, implantable
defibrillators or monitoring equipment
may require special considerations. The
attending cardiologist and/or the pacemaker
manufacturer should be consulted prior to
surgery.
• The operating table should be grounded.
• During monopolar electrosurgery the patient
should not come into contact with any metal
parts which are grounded or which have
appreciable capacitance to earth (operating
tables, supports, etc.). The use of anti-static
sheeting is recommended for this purpose.
• During monopolar electrosurgery skin-to-skin
contact (i.e., between the arms and body of
the patient) should be avoided. Insertion of dry
gauze or its equivalent is recommended.
• The probe cables and extension cable should
be positioned in such a way that contact with
the patient or other leads is avoided. Probes
not in use should be stored isolated from the
patient.
• Incorrect actual temperature readings may
result in improper treatment. Verify that the
TEMPERATURE display reads the expected
value (room temperature or body temperature)
prior to treatment. If the TEMPERATURE
reading is not accurate, check the device
and connectors for damage, moisture, or
contamination. Clean or replace as needed.
• If desired tissue effect is not being achieved,
do not increase power beyond the normal
range without first inspecting the integrity of
the probe and neutral (return) electrode.
• To prevent electric shock, unplug the
control unit from the electrical outlet before
attempting to replace the fuses.
• To avoid fire hazard, use only fuses of the
correct type, voltage rating, and current rating.
• To prevent electric shock, do not remove
the control unit cover. There are no user-
serviceable components inside. Dismantling
the equipment will void the warranty. Refer
servicing to qualified Smith & Nephew
personnel.

71061526 Rev. CVULCAN™ Generator Operations/Service Manual
Precautions / Unpacking and General Inspection
Precautions
U.S. Federal law restricts this device to sale by or
on the order of a physician.
• Prior to each use, inspect the device to ensure it is
functioning properly and not damaged. Do not use
a damaged device.
• The Smith & Nephew VULCAN™ Generator is
designed specifically for use only with Smith &
Nephew arthroscopic radiofrequency probes. Do
not use other devices with the generator control
unit.
• Check the probe and extension cable connections
for the presence of liquid before use or whenever
a probe is connected or disconnected during
a procedure. Liquid may enter the connection
during a procedure. ANY liquid can cause the
connections to short, resulting in erroneous probe
recognition or damage to the probe, cable, or
generator control unit.
• Check the generator control unit’s LCD message
display to ensure that the proper probe
identification and settings are displayed prior to
beginning any procedure.
• Use the lowest RF power setting necessary to
achieve the desired tissue effect.
• This equipment is designed and tested to
minimize interference with other electrical
equipment. However, if interference occurs with
other equipment it may be corrected by one or
more of the following measures:
– Reorient or relocate this equipment, the other
equipment, or both.
– Increase the separation between the pieces of
equipment.
– Connect the pieces of equipment into different
outlets or circuits.
– Consult a biomedical engineer.
• This equipment contains electronic printed circuit
assemblies. At the end of the useful life of the
equipment it should be disposed of in accordance
with any applicable national or institutional related
policy relating to obsolete electronic equipment.
• Inspect all components, including extension
cables and power cord, regularly for wear. Pay
particular attention to extension cable insulation.
Replace if evidence of deterioration is noted.
• Apparent low output or failure of the generator
control unit to function properly at normal
operating settings may indicate faulty application
of the split grounding pad.
• When the generator control unit is used
simultaneously with physiological monitoring
equipment on the same patient, any monitoring
electrodes should be placed as far from the
surgical electrodes as possible. Needle monitoring
electrodes are not recommended. Monitoring
systems using high frequency current-limiting
devices are recommended.
• Use only the power cord and connector specified
for this unit.
• Electrical safety testing should be performed by a
biomedical engineer or other qualified person.
• Do not immerse the footswitch cable.
Unpacking and General
Inspection
Carefully unpack and inspect all of the components
shipped with the Smith & Nephew VULCAN
Generator. The following should have been received:
Quantity Description
1 Smith & Nephew VULCAN
Generator (REF 7210812)
1 Smith & Nephew VULCAN
Footswitch (REF 7209692)
1 Hospital-grade power cord,
country-specific
1 Smith & Nephew VULCAN
Generator Operations/Service
Manual (REF 1061526)
The Smith & Nephew VULCAN Extension Cable
(REF 7209693) is available as an accessory for use
with probes that do not include an integrated cable.
If any parts are missing or damaged, please
contact your authorized Smith & Nephew sales
representative. Save the carton and packing materials
in the event that a component needs to be returned
for repair.

81061526 Rev. C VULCAN™ Generator Operations/Service Manual
Front Panel Layout
IMPEDANCE Display
IMPEDANCE displays the impedance in ohms,
measured at the tip of the probe. Active in both
Temperature Control and Power Control Modes.
SET POWER Display with Up/Down Arrows
SET POWER displays the maximum probe power
output in watts, increased or decreased using
the SET POWER up/down arrows. Active only in
Temperature Control Mode.
SET TEMP Display and Up/Down Arrows
SET TEMP displays the target tissue temperature
in degrees Celsius (° C), increased or decreased
using the SET TEMP up/down arrows. Active only in
Temperature Control Mode.
SET CUT Display with Up/Down Arrows
SET CUT displays the maximum probe power output
in watts, increased or decreased using the SET CUT
up/down arrows. Active only in Power Control Mode
and the probe supports adjustment of SET CUT.
PRESET Display with Up/Down Arrows
PRESET displays the preset temperature and/or
power combination chosen and is adjustable using
the PRESET up/down arrows. Settings are displayed
as 1, 2, 3, etc. Active in Temperature Control and
Power Control Modes when the probe supports
adjustment of PRESET.
ACTUAL PWR Display
ACTUAL PWR displays the actual power in watts
delivered to the probe. Active only in Temperature
Control Mode.
TEMPERATURE Display
TEMPERATURE displays the actual temperature in
degrees Celsius (° C), measured at the tip of the
probe. Active only in Temperature Control Mode.
SET COAG Display with Up/Down Arrows
SET COAG displays the maximum probe power
output in watts, increased or decreased using the
SET COAG up/down arrows. Active only in Power
Control Mode and the probe supports adjustment
of SET COAG.
SET BLEND Display with Up/Down Arrows
The SET BLEND mode is inactive for all probes.
FAULT Indicator (Red Light)
FAULT illuminates when a fault condition is detected.
NEM Indicator (Green or Red Lights)
NEM illuminates with a green light when the NEM
circuit is correctly connected and with a red light
when the NEM circuit is incorrectly connected. NEM
will only illuminate when a monopolar probe is being
used.
Front Panel Layout
Figure 1. Control unit front panel

91061526 Rev. CVULCAN™ Generator Operations/Service Manual
Front Panel Layout (continued)
BI / MONOPOLAR Button
The BI / MONOPOLAR button selects the appropriate
RF energy mode (monopolar or bipolar). The generator
selects the appropriate mode automatically based on
the probe type.
BI / MONOPOLAR Indicator
Either MONO (monopolar) or BIPOLAR is illuminated
to identify the appropriate probe type.
MODE Button
The MODE button selects the appropriate RF energy
delivery mode (Temperature Control or Power
Control).
MODE Indicator
Either TEMPERATURE (Temperature Control Mode)
or POWER (Power Control Mode) is illuminated to
identify the appropriate generator mode.
COAG Indicator (Blue Light)
COAG illuminates when the generator control unit is
delivering RF power and when the blue COAG (right)
footswitch is pressed.
CUT Indicator (Yellow Light)
CUT illuminates when the generator control unit is
delivering RF power and when the yellow CUT (left)
footswitch is pressed.
RF POWER ON Indicator (Green Light)
RF POWER ON illuminates when the generator control
unit is delivering RF power.
STAND-BY Indicator (Green Light)
STAND-BY illuminates when the generator control
unit is in Stand-By Mode.
Neutral (Return) Electrode Connector
Accepts a dual–pin connector specifically designed
for neutral electrode monitoring (NEM).
Message Display
Displays modes, probe type, alarms, warnings, or
fault messages.
Probe Connector
Accepts 8-pin Smith & Nephew temperature-
controlled, cutting, ablation, and hemostasis probes.
The Smith & Nephew VULCAN™ Extension Cable
(REF 7209693) may be used with the generator
control unit.

10 1061526 Rev. C VULCAN™ Generator Operations/Service Manual
Rear Panel Layout
Footswitch Connector
Accommodates the generator footswitch cable
supplied with the Smith & Nephew VULCAN™
Generator.
Volume Control
This knob adjusts the volume of the energy
delivery tone.
Fan Outlet
Carrying Handle
Equipotential Compensator Terminal
This terminal can be used to bring other equipment
to the same case potential as the generator control
unit.
Power Cord Connector
The power cord connector is part of the power input
module, and accommodates the hospital-grade
power cord supplied with the Smith & Nephew
VULCAN Generator.
Fuse Access Door
The fuse access door is part of the power input
module. See the “Replacing Fuses” section for
instructions on fuse replacement. To avoid hazards,
use appropriate fuses as specified in the “Technical
Specifications” section.
On/Off Switch
Rocker-type main power switch.
100–240V~
81013076 Rev. C 01/2008
7210812
VULCAN™
Generator ∑ Generator ∑ Generador ∑ Générateur ∑ Generatore ∑
Generator ∑ Generator ∑ Gerador ∑ Generator ∑ Generator ∑ ෧ແૺ
50/60Hz, 800VA
OUTPUT POWER
200 W Max. (100–250 U)
460 kHz ZL
Rear Panel Layout
Figure 2. Control unit rear panel

111061526 Rev. CVULCAN™ Generator Operations/Service Manual
Preoperative Setup
Preoperative Setup
WARNINGS:
• DANGER: Risk of explosion if used in the
presence of flammable anesthetics, skin
preparation agents, or biointestinal gases.
• Hazardous electrical output. This equipment
should be used only by qualified medical
personnel trained in the use of electrosurgery
devices.
• This device has been tested and verified to
comply with the IEC 60601-2-2. This exceeds
the requirements specified by FCC part 18
for ISM equipment. This device is intended
for operation in a medical facility only. Usage
in a residential environment will likely cause
unacceptable RF interference for which the
user is held responsible.
• The generator control unit must be powered
from a properly grounded 120–240 VAC,
single-phase supply. Excessive risk (leakage
current) may result if this equipment is
connected to other than the manufacturer’s
recommended power distribution system.
• Risk of burns or fire. Do not use near
conductive materials such as metal bed parts,
inner-spring mattresses, etc.
1. Plug the power cord into the rear panel power
cord connector and a grounded AC power source.
WARNING: Check that the electrical
equipment is properly grounded (i.e., plugs
contain a ground prong). The generator control
unit must be plugged into a hospital-grade AC
outlet.
2. Inspect the footswitch for any obvious defects.
Connect the footswitch cable to the appropriate
connector on the rear of the generator control unit.
3. Prepare the patient using standard technique for
electrosurgical procedures. The patient’s entire
body, including extremities, must be insulated
against contact with grounded metal parts, and
sufficient layers of electrically insulating sheets
should be placed underneath the patient. A
waterproof cover should be placed over the
insulating sheets, with absorbent sheets placed
between the patient and the waterproof cover to
absorb any moisture.
WARNING: The operating table should be
grounded.
4. For monopolar procedures, affix the split
grounding pad to the patient according to the
instructions found in the pad packaging. Select
a well-vascularized application site in close
proximity to the surgical site. Avoid bony or
hairy prominences. Shave, clean, and dry the
application site as needed. Apply the pad firmly,
assuring full adhesion and contact with the
patient’s skin. After the pad is properly applied to
the patient, connect the pad to the NEM connector
on the control unit front panel.
Note: It is important that the split grounding pad
be connected to the generator control unit after
the pad is properly placed on the patient. This
allows the generator control unit to determine an
accurate baseline split grounding pad contact quality
measurement for a particular patient and will allow
the system the greatest resolution in determining if a
loss of split grounding pad contact occurs during the
procedure.
WARNINGS:
• Safe use of monopolar electrosurgery demands
proper grounding of the patient and proper
insulation between the patient and any metal
surfaces. A split pad with a surface area of at
least 20 square inches (130 cm2) is required.
Valleylab… REM… pads (REF: 7209687)
meet this dimensional requirement and are
recommended by Smith & Nephew for use with
the VULCAN™ Generator. Pads with a surface
area of less than 20 square inches may have a
lower dispersive effect. It is the responsibility
of the user to qualify any alternate ground
pad.
• Use of an inadequate ground pad or incorrect
placement of the ground pad may result in a
burn injury to the patient.
• Improper probe usage may result in patient
burns at the return pad. To avoid this, follow
the manufacturer’s Instructions for Use.

12 1061526 Rev. C VULCAN™ Generator Operations/Service Manual
Operational Modes / Power Delivery Modes
Operational Modes
Power Up
When the AC power to the generator control unit is
turned on using the power switch on the rear panel,
the generator performs a series of system self-tests
to determine if it is performing properly. The self-tests
include:
ROM checksum
RAM test
Temperature measurement calibration test
RF system test
Display segments and indicators test
If any of the system self-tests fail, the FAULT indicator
on the front panel is illuminated and a continuous
tone sounds. Contact Smith & Nephew if any system
self-test fails.
WARNING: Failure of the radiofrequency
surgical equipment could result in
unintended increase of output power.
Stand-By Mode
Immediately after performing the self-test, the
generator will default to Stand-By Mode. All of the
displays on the front panel will be blanked, and the
generator control unit will not be able to deliver RF
power while it is in Stand-By Mode.
Fault Mode
If a fault is detected at any time during the generator
control unit’s operation, the FAULT indicator light will
illuminate, an alarm will sound, an error code and text
message will be displayed in the message display,
and the generator will enter the Fault Mode. RF
energy cannot be delivered and the control unit must
be powered down then powered up again to exit from
Fault Mode.
Power Delivery Modes
Temperature Control Mode
If the MODE button is pressed once while the
generator is in Stand-By Mode or if a temperature
controlled probe is connected to the generator, the
generator will enter the Temperature Control Mode.
In Temperature Control Mode, the Smith & Nephew
VULCAN™ Generator software automatically adjusts
energy delivery to maintain the tissue temperature
indicated in the SET TEMP display. Only monopolar
temperature-controlled probes may be used in
Temperature Control Mode.
All Smith & Nephew probes are equipped with a
sensor that enables the generator control unit to
detect the type of probe connected. When a probe is
connected, the Smith & Nephew VULCAN Generator
software will read the sensor and automatically adjust
power output and temperature parameters to the
preprogrammed settings for the probe type.
If a probe is not detected, the generator control
unit will default to PRESET “1”, and the SET POWER
and SET TEMP displays will show the power and
temperature values corresponding to this setting.
Power Control Mode
The generator enters Power Control Mode if the
MODE button is pressed once while the unit is
in Temperature Control Mode, or twice while in
Stand-By Mode, or if a cutting or ablation probe is
connected to the control unit.
The user may change the type and amount of
power delivered by adjusting SET CUT (inactive for
ELECTROBLADE™ Resector) or SET COAG (inactive for
GLIDER Articular Cartilage Probe).
All Smith & Nephew probes are equipped with a
sensor that enables the generator control unit to
detect the type of probe connected. When a probe is
connected, the Smith & Nephew VULCAN Generator
software will read the sensor and automatically adjust
parameters to the preprogrammed settings for the
probe type.
If a probe is not detected, the generator control unit
will default to PRESET “10”, and the SET CUT and
SET COAG displays will show the SET CUT and SET
COAG values corresponding to this setting.

131061526 Rev. CVULCAN™ Generator Operations/Service Manual
Controls and Functions
Controls and Functions
SET POWER
SET POWER may be changed by pressing the up/
down arrows located next to the SET POWER display.
Power may be adjusted from 1–50 watts. Pressing the
appropriate button repeatedly will adjust the power
in increments of 1 watt; holding the button down will
scroll through the power settings automatically.
SET TEMP
SET TEMP may be changed by pressing the up/
down arrows located next to the SET TEMP display.
Temperature may be set from 15–99° C. Pressing
the appropriate button repeatedly will adjust the
temperature in increments of 1° C; holding the button
down will scroll through the temperature settings
automatically.
SET CUT
SET CUT (inactive for ELECTROBLADE™ Resector) may
be adjusted by pressing the up/down arrows located
next to the SET CUT display. Power may be adjusted
from 1–200 watts or up to the preprogrammed limit
for the probe type used. Pressing the appropriate
button repeatedly will adjust the power in increments
of 5 watts; holding the button down will scroll through
the power settings automatically.
PRESET (Temperature Control Mode)
Commonly used temperature and power
combinations are preprogrammed into the Smith &
Nephew VULCAN™ Generator software to allow the
operator to quickly configure the generator control
unit in Temperature Control Mode. Use the PRESET
up/down arrows on the control unit front panel to
select the desired setting. The selected setting will
be displayed in the front panel PRESET display, and
the corresponding temperature and power settings
will be displayed in the SET TEMP and SET POWER
displays.
PRESET (Power Control Mode)
Commonly used SET CUT and SET COAG power
combinations are preprogrammed into the generator
software to allow the operator to quickly configure the
control unit in Power Control Mode. Use the PRESET
up/down arrows on the control unit front panel to
select the desired setting. The selected setting
will be displayed in the PRESET display and the
corresponding power settings will be displayed in the
SET CUT and SET COAG displays. PRESET is inactive
for ELECTROBLADE Resector and GLIDER Articular
Cartilage Probes.
SET COAG
SET COAG (inactive for GLIDER Articular Cartilage
Probes) may be adjusted by pressing the up/down
arrows located next to the SET COAG display. Power
may be adjusted from 1–200 watts or up to the
preprogrammed limit for the probe type used.
Pressing the appropriate button repeatedly will
adjust the power in increments of 5 watts; holding
the button down will scroll through the power
settings automatically.
Auto Probe Recognition
The Smith & Nephew VULCAN™ Generator software
recognizes which type of Smith & Nephew probe is
connected to the control unit by reading a sensor
in the probe. When a probe is connected to the
control unit, the software automatically switches to
the appropriate control MODE and PRESET setting (if
supported) for that specific probe.
The SET TEMP, SET POWER, SET CUT, and SET COAG
settings may be changed from their preset values
using the up/down arrows next to the respective
displays (if supported by the probe).
The Smith & Nephew VULCAN Generator software
also contains temperature and power limits for each
probe type. The SET TEMP, SET POWER, SET CUT,
and SET COAG settings cannot be set to values
outside the range programmed in the software. This
feature ensures that each probe type is used within
its safe limits of operation.

14 1061526 Rev. C VULCAN™ Generator Operations/Service Manual
Controls and Functions / Instructions for Use
Energy Delivery Tone
A tone sounds whenever RF energy is delivered.
Volume is adjustable using the volume control knob
on the control unit rear panel.
In Power Control Mode the tone is a steady sound
while RF energy is delivered.
In Temperature Control Mode the tone sounds
slowly while probe temperature is increasing. The
tone sounds more rapidly as the set temperature
is approached. The tone is rapid and steady when
the set temperature is reached and while it is held.
Any variation in tone speed signals the user that the
probe temperature is not at the target temperature.
Fault Tone
The fault tone sounds briefly during generator control
unit startup, and in the event of a warning or fault
condition. The volume of the fault tone cannot be
adjusted by the user.
Footswitch Connector
A dual, electrically-activated footswitch is provided
to control RF energy delivery. The blue COAG (right)
pedal is used with temperature-controlled probes
and with SET COAG in Power Control Mode. The
yellow CUT (left) pedal is used with cutting/ablation
probes in Power Control Mode.
Temperature Control Mode
Yellow CUT pedal – inactive
Blue COAG pedal – enables coagulation output with
temperature control
Power Control Mode
Yellow CUT pedal – enables cut output
Blue COAG pedal – enables coagulation output
Instructions for Use
1. Turn the control unit on using the on/off switch
on the rear panel. The generator will perform a
series of system self-tests to determine if it is
performing properly. If any of these tests fail, the
FAULT indicator will illuminate and a continuous
tone will sound. Contact Smith & Nephew
Customer Service if any system self-test fails.
Inspect the front panel displays for any system
indicator warnings or messages.
After completing the self-tests, the generator will
default to Stand-By Mode. All the displays on the
front panel will be blank and the generator will not
be able to deliver RF power.
2. Connect the selected Smith & Nephew probe
to the probe connector on the control unit front
panel. If the probe includes an integrated cable,
insert the cable connector with the thumb groove
up.
For probes without an integrated cable, connect
the probe to the extension cable. A “click” may be
heard. Tug gently on the extension cable to ensure
proper connection. Connect the other end of the
probe cable into the probe connector.
Note: ELECTROBLADE Resectors with a
two-prong Valleylab plug end can be plugged
into the ELECTROBLADE Adaptor for use with
the VULCAN™ Generator.
3. Verify that the selected probe’s name is
presented on the message display. The generator
software will recognize the probe type by reading
a sensor in the probe and will automatically
switch to the appropriate power output, MODE,
and setting for that specific probe.
WARNING: Burns to the surgeon’s hands
may be possible if a probe comes into
contact with a metal instrument or surface.
CAUTION: Check the probe and extension cable
connections for the presence of liquid before use
or whenever a probe is connected or disconnected
during a procedure. Liquid may enter the connection
during a procedure. ANY liquid can cause the
connections to short, resulting in erroneous probe
recognition or damage to the probe, cable, or
generator control unit.
CAUTION: Check the generator control unit’s LCD
message display to ensure that the proper probe
identification and settings are displayed prior to
beginning any procedure.

151061526 Rev. CVULCAN™ Generator Operations/Service Manual
Instructions for Use / Cleaning and Sterilization
4. Confirm that the NEM light is illuminated green. If
illuminated red, check the split grounding pad to
assure full adhesion and contact with the patient’s
skin.
5. If using a temperature-controlled probe, proceed
to step 6. If using a power-controlled probe, skip
steps 6–8 and proceed directly to step 9.
6. For temperature-controlled probes, check the
temperature display to confirm expected values.
WARNING: Incorrect actual temperature
readings may result in improper treatment.
Verify that the TEMPERATURE display reads the
expected value (room temperature or body
temperature) prior to treatment. If the
TEMPERATURE reading is not accurate, check the
device and connectors for damage, moisture, or
contamination. Clean or replace as needed.
CAUTION: Use the lowest RF power settings
necessary to achieve the desired tissue effect.
7. To begin RF energy delivery, depress and hold the
blue COAG footswitch for the type of power to be
delivered, according to the probe’s Instructions for
Use. The green RF POWER ON and blue COAG
indicator lights will illuminate.
WARNING: If desired tissue effect is not
being achieved, do not increase power
beyond the normal range without first inspecting
the integrity of the probe and neutral (return)
electrode.
8. During energy delivery, the generator sounds a
fluctuating tone. The tone pulsates slowly while
probe temperature is ramping up to the SET
TEMP. The tone will sound more rapidly as the
SET TEMP is approached. The tone is rapid and
steady when the SET TEMP is reached and while
it is held. Any variation in tone speed signals the
user that probe temperature is not at the target
temperature.
9. To begin RF energy delivery in the Power Control
Mode, depress and hold the selected footswitch
for the type of power to be delivered, according
to the probe’s Instructions for Use. Select the
yellow CUT pedal for the cut output and the blue
COAG pedal for the coagulation output. The green
RF POWER ON and yellow CUT or blue COAG
indicator lights will illuminate.
Note: During energy delivery in the Power Control
Mode, a steady tone will sound while RF energy is
being delivered. Different tones are generated for
CUT and COAG.
WARNING: Do not exceed the RF duty cycle
for the probe.
10. RF energy delivery may be discontinued at any
time by releasing the footswitch. To resume RF
energy delivery, press and hold the footswitch
again.
WARNING: Do not withdraw the probe while
energy delivery is activated; this may result
in an unintended patient burn or ignition of
flammable materials.
Cleaning and Sterilization
Generator Control Unit
The unit should be disconnected from the grounded
AC outlet when being cleaned. The exterior surface
of the control unit may be wiped down with any liquid
disinfecting solution; non-flammable solution should
be used. Care must be taken not to allow any liquid
to pass into any electrical connections or the interior
of the control unit. Let the surfaces dry thoroughly
before plugging in the device. DO NOT steam sterilize
the control unit. DO NOT immerse the generator
control unit in glutaraldehyde or other liquid sterilant
or disinfectant. DO NOT submerge control unit for any
reason.
Smith & Nephew VULCAN™
Extension Cable
The Smith & Nephew VULCAN Extension Cable
(REF 7209693) is reusable and may be cleaned and
sterilized as follows:
1. Rinse the cable with warm running tap water for a
minimum of two minutes or until all visible debris
is removed.
2. Place the cable in a bath containing Klenzyme…
(enzymatic detergent), prepared according to the
manufacturer’s instructions, for two minutes. Make
sure that there is sufficient detergent to cover the
cable.
3. Rinse the cable thoroughly under warm running
tap water for one minute.
4. Prepare a solution of commercially available
manual cleaner (i.e., Manu-klenz…) according to
the manufacturer’s instructions. Gently scrub the
cable using a soft, non-metallic brush while the
cable is immersed in the cleaning solution.

16 1061526 Rev. C VULCAN™ Generator Operations/Service Manual
Cleaning and Sterilization / Service and Maintenance
5. Rinse the cable thoroughly under warm running
tap water for one minute.
6. Dry the devices with a soft, clean cloth.
7. Autoclave using the following parameters:
– Dry time: No dry time needed.
– Pre-vac: Four minutes steam exposure at
132–135° C.
– Flash gravity: Ten minutes steam exposure at
131.5–133.5° C (target=132° C).
Note: Cables may be individually wrapped in surgical
kraft paper and then placed in individual sterilization
pouches prior to pre-vac sterilization.
Footswitch
The footswitch may be wiped down with any liquid
disinfecting solution; non-flammable solution should
be used.
CAUTION: Do not immerse the footswitch cable.
Probes
Smith & Nephew probes are disposable and are
intended for single-use only. Do not attempt to clean
or resterilize any Smith & Nephew probe.
Service and Maintenance
Service Philosophy
There are no user-serviceable components inside the
generator control unit. Repairs and adjustments are
to be performed only by Smith & Nephew authorized
service centers.
If service becomes necessary, call your authorized
Smith & Nephew Customer Service Representative
prior to returning the device and request a Return
Authorization (RA) number. Your representative can
also explain the available Service Replacement and
Repair Programs.
Service items should be carefully repackaged and
returned post-paid to Smith & Nephew. Your Smith
& Nephew Customer Service Representative can
provide additional instructions.
Note: Product returned that is found to have been
serviced by an unauthorized third party repair facility
and/or sterilized with a sterilization method other
than one approved by Smith & Nephew will incur
additional costs, regardless of warranty status.
It is not necessary to include accessory items (i.e.,
power cords, footswitches, etc.) when returning a
device for service.
Replacing Fuses
WARNING: To prevent electric shock, unplug
the control unit from the electrical outlet
before attempting to replace the fuses.
WARNING: To avoid fire hazard, use only
fuses of the correct type, voltage rating,
and current rating.
Note: Fuses that require frequent replacement may
indicate an internal problem with the control unit.
If fuses continue to blow, contact Smith & Nephew
Customer Service for assistance.
To Inspect and/or Replace Fuses
1. Unplug the power cord from the power outlet and
from the control unit.
2. Use a screwdriver to open the fuse compartment
door on the AC receptacle (Figure 3) and slide
out the two fuse carriers. Refer to the “Rear Panel
Layout” section to locate the AC receptacle on the
rear panel.
3. Replace fuses. See “Technical Specifications”
section for replacement fuse types.
4. Reinsert the fuse carriers using the arrows on the
inside of the fuse compartment door as a guide.
5. Snap the fuse compartment door closed.
ON/OFF Switch
Fuse Carrier
Fuse
Figure 3. AC receptacle with fuses

171061526 Rev. CVULCAN™ Generator Operations/Service Manual
Service and Maintenance
Software Upgrades
For information regarding software upgrades, please
contact your local authorized Smith & Nephew
representative.
Replacing/Returning Worn or Defective
Equipment or Parts
Contact Smith & Nephew Customer Service to order
replacement footswitches, extension cables, or any
other accessory, and for instructions on disinfection
and return of worn-out or defective equipment or
parts.
Other than fuses, the Smith & Nephew VULCAN™
Generator has no customer-serviceable parts. For
service, please contact your representative or Smith
& Nephew Customer Service.
Preventative Maintenance
The following inspections should be performed on an
annual basis to ensure safe operation of the Smith &
Nephew VULCAN Generator.
Inspection of Cables
Inspect the power cable and replace if signs of wear
or abrasion are visible.
Inspection of Connectors
Inspect all connectors on the control unit for signs
of wear or damage. Look specifically for bent or
damaged pins, loose fittings, etc. Contact Smith
& Nephew Customer Service for assistance if any
damage is detected.
Calibration of Temperature
Measurement Circuit
There is no method for the user to alter the
calibration of the temperature measurement
hardware in the field. However, Smith & Nephew
recommends that this calibration be checked on an
annual basis. If it is found to be out of specification,
the device should be returned to Smith & Nephew
for repair.
The generator performs a self-test during power-up
to verify power calibration. There is an internal,
100 ohm resistor which is measured and compared
to its specified value. The generator goes into a Fault
Mode if the calibration is out of specification. In
addition, the thermocouple amplifying circuits are
checked for calibration. However, there is no check
on the “absolute” temperature measured by a
temperature probe; therefore, this calibration must
be manually checked.
Equipment
• Thermometer
• TAC™-S Probe with connecting cable
• Beaker
Procedure
1. Fill the beaker with cool water (10–30° C).
2. Use the thermometer to measure and record the
temperature of the cool water.
3. Turn on the control unit and connect the cable of
the test TAC-S Probe. Verify that the control unit
goes into the Temperature Control Mode. The
TEMPERATURE should display room temperature.
4. Immerse the tip of the TAC-S Probe in the water
and record the actual temperature.
5. Repeat steps 1–4 using hot water (50–90° C).
The TEMPERATURE reading with the TAC-S Probe
should be +/- 3° C of the thermometer reading in
both cases.
If a greater difference is observed, contact Smith &
Nephew for assistance.

18 1061526 Rev. C VULCAN™ Generator Operations/Service Manual
Troubleshooting)
Troubleshooting
Generator Control Unit
The generator control unit includes a message
display that provides a text description of any alarm
or fault messages. If the system is not operating as
expected, check the message display.
WARNING: To prevent electric shock, do not
remove the control unit cover. There are no
user-serviceable components inside. Dismantling
the equipment will void the warranty. Refer
servicing to qualified Smith & Nephew personnel.
Alarm and Fault Messages
The generator detects two types of error conditions:
alarms and faults.
An alarm is generated to inform the user that the
output of the device is being disabled to prevent
injury to the patient or damage to the device. Alarms
are automatically cleared once the alarm condition
returns to its acceptable value.
A fault is a more serious error condition and typically
occurs as a result of a hardware failure, such as
a stuck footswitch or a conversion circuit that is
out of calibration. The FAULT indicator light will be
illuminated, and requires that the control unit be
reset by cycling power. Refer to the “Troubleshooting”
section for those faults that can be corrected by the
user. If a fault other than those listed occurs, contact
Smith & Nephew for assistance.

191061526 Rev. CVULCAN™ Generator Operations/Service Manual
Troubleshooting (continued)
Type Message Condition Possible Remedy
Alarm OPEN TC- RF disabled
in Temp Control mode
(Note: “OPEN TC” refers to an
open thermocouple circuit.)
RF output is not allowed in
the Temperature Control
Mode unless a valid
temperature measurement
is returned from the probe’s
temperature sensor.
• Check probe connection to
generator control unit.
• Replace probe.
Alarm Cannot use CUT pedal
in Temp Control mode
RF output is disabled in the
Temperature Control Mode
if the yellow CUT footswitch
is pressed.
Use COAG pedal.
Alarm RF Disabled - Check
Return Electrode
RF output is disabled in
any monopolar mode if
the impedance between
the electrodes on the
split grounding pad is
greater than the calculated
threshold.
Check that the return
electrode is properly applied
to the patient and that the
cable is properly connected to
the generator control unit.
Alarm LOW LOAD IMPEDANCE-
Output power reduced
RF output is reduced to
below 5 watts whenever the
measured load impedance
is less than 40 ohms (or
20 ohms depending on the
probe).
Keep active electrode away
from metallic surfaces during
use.
Alarm NEM CIRCUIT SHORTED-
Use split-pad return
If the impedance calculated
during NEM initialization is
less than 5 ohms, the unit
indicates a NEM contact
failure.
• Check that split grounding
pad is being used.
• Check that the split
grounding pad is properly
applied to the patient and
that the pad is properly
connected to the front of
the control unit.
• To test for proper operation
of the NEM circuitry, unplug
the neutral electrode and
connect a 100 ohm, non-
inductive resistor across
the two pins of the neutral
electrode connector. The
impedance should be
sufficiently high to clear
the alarm. If the alarm
persists, contact Smith &
Nephew.*
*Call Smith & Nephew Technical Support at 1-800-343-5717 in the U.S., or your local Smith & Nephew representative.
Alarm and Fault Messages (continued)

20 1061526 Rev. C VULCAN™ Generator Operations/Service Manual
Troubleshooting (continued)
Type Message Condition Possible Remedy
Alarm POWER FACTOR LOW -
Output power reduced
RF output is reduced to
below 5 watts whenever the
calculated power factor is
less than 0.2.
Keep active electrode away
from metallic surfaces during
use.
Alarm Can’t use COAG pedal
with this probe
The use of the COAG pedal
is not supported with the
connected probe.
Use the CUT pedal.
Alarm RF Disabled - No
Probe Detected
A footswitch was pressed
when no probe was
connected.
Connect a probe prior to
pressing a footswitch.
Alarm Cannot use Temp Cont
Probe in Power Mode
A thermocouple was
detected on a probe.
Use the Temperature Control
Mode.
Alarm Cannot use CUT pedal
with Electroblade
The CUT pedal was used
with the Smith & Nephew
DYONICS™ Electroblade™
Resector
Use the COAG pedal.
Fault CJC Out of Range The cold-junction
compensator (CJC) portion
of the thermocouple circuit
has detected a room
temperature outside the
expected range of 10–35° C.
This may occur if the control
unit was exposed to extreme
temperatures.
Let generator reach room
temperature.
Fault Footswitch Stuck On One or both footswitches
was activated during start-
up.
• Check each footswitch to
make sure a cord or other
object is not interfering with
the footswitch connection.
• Reset the control unit by
turning it off and then back
on again.
Alarm and Fault Messages (continued)
