Disassembly and cleaning instructions
POLARSTEM◊stem inserter
SAP/Art. No. 75004650/21000300
This disassembly and cleaning instruction is designed to supplement the existing instruction ”Processing
(cleaning, disinfection and sterilization) of instruments from Smith & Nephew Orthopaedics AG” Lit. No. 03389
Key
1. Tube with handle (cannot be removed) 21000300 (I/III) or Spare Part Handle 75102465
2. Fin stabilizer for stem inserter 21000667/75023745
3. Threaded ring 21000300 (III/III) or Spare Part Nut 75102467
4. Flat Wrench for stem inserter 21000673/75100194
5. Threaded rod with handle (cannot be removed) 21000300 (II/III) or Spare Part Rod 75102466
1
2
4
5
3
Pre-cleaning
In accordance with the instruction “Processing (cleaning,
disinfection and sterilization) of instruments from
Smith & Nephew Orthopaedics AG” Lit. No. 03389.
The following applies in addition to the instructions:
• Manually pre-clean all drill holes, passages and threads

Smith & Nephew Orthopaedics AG
Oberneuhofstrasse 10d
6340 Baar
Switzerland
www.smith-nephew.com ◊Trademark of Smith+Nephew
All Trademarks acknowledged
©2021 Smith+Nephew
21365-en (1688) V2 02/21
1
2
3
5
4
0123
Disassembly
In accordance with the instruction “Processing (cleaning,
disinfection and sterilization) of instruments from
Smith & Nephew Orthopaedics AG” Lit. No. 03389.
The following applies in addition to the instructions:
• Disassembly is carried out in reverse order to assembly
• Unscrew threaded rod (5)
• Unscrew thread ring (3) with flat wrench (4)
• Remove the fin stabilizer (2) from the tube (1)
Machine cleaning and disinfection
In accordance with the instruction “Processing (cleaning,
disinfection and sterilization) of instruments from
Smith & Nephew Orthopaedics AG” Lit. No. 03389.
The following applies in addition to the instructions:
• Please take special care to ensure that any cavities can
be properly rinsed
Drying
In accordance with the instruction “Processing (cleaning,
disinfection and sterilization) of instruments from
Smith & Nephew Orthopaedics AG” Lit. No. 03389.
The following applies in addition to the instructions:
• All drill holes and passages can also be dried with
pressurized air
Inspection and maintenance
In accordance with the instruction “Processing (cleaning,
disinfection and sterilization) of instruments from
Smith & Nephew Orthopaedics AG” Lit. No. 03389.
The following applies in addition to the instructions:
• Check the thread (pos. 1, 2 and 3) for damage
Assembly
In accordance with the instruction “Processing (cleaning,
disinfection and sterilization) of instruments from
Smith & Nephew Orthopaedics AG” Lit. No. 03389.
The following applies in addition to the instructions:
• It is essential that the fin stabilizer (2) is assembled as
shown in the image (laser markings to match up with
laser markings)
• Screw threaded ring (3) into position with flat wrench (4)
• Screw threaded rod (5) into place
Servicing
In accordance with the instruction “Processing (cleaning,
disinfection and sterilization) of instruments from
Smith & Nephew Orthopaedics AG” Lit. No. 03389.
