snom M700
Multicell Deployment Guide
v1.0

Version1.0  Page|2

snom M700 multicell deployment guide
(Capacity Planning/Deployment/Installation)
Contents

Contents.............................................................................................................................................................2
DocumentHistory..............................................................................................................................................2
Introduction.......................................................................................................................................................3
IntendedAudience.............................................................................................................................................3
Abbreviations.....................................................................................................................................................3
DECTdeploymentassessment...........................................................................................................................4
DeploymentConsiderations..............................................................................................................................4
Range.....................................................................................................................................................4
CapacityPlanning...................................................................................................................................5
SitePlanning/CellCoverage.............................................................................................................................5
1.UsingtheHandsetforreceptionmeasurement............................................................................5
2.Placing2ndandfollowingbasestation...........................................................................................6
IPconfiguration..................................................................................................................................................7
M700/M5RepeaterPlacementRecommendations..........................................................................................7
M700VoIP/DECTdeploymentlimitations.........................................................................................................9
M700VoIP/DECTNetworkdeploymentconsiderations...................................................................................9
Installation....................................................................................................................................................13
DECTChain.......................................................................................................................................................15
Document History

RevisionAuthorIssueDateComments
0.1TimKoehler27‐Jun‐2014InitialVersion
1.0BenjaminZiebarth29‐Aug‐2014InitialRelease





Version1.0  Page|3


Introduction

ThisdocumentshallhelptosetupamulticellDECTsystem.BesideDECTandwirelessaspects,italso
addressesnetworkrequirementsandcapacityplanning.

Intended Audience

Thetargetaudienceforthisdocumentincludesnetworkadministratorsandanyonethatwillplanand
designamulticellDECTsolution.


Abbreviations

Forthepurposeofthisdocument,thefollowingabbreviationshold:

DHCP:DynamicHostConfigurationProtocol
(T)FTP:(Trivial)FileTransferProtocol
IOS: InternetworkingOperatingSystem
NAT: NetworkAddressTranslator
PCMA:A‐lawPulseCodeModulation
PCMU:µ‐lawPulseCodeModulation
RPN:RadioFixedPartNumber
RSSI:Receivedsignalstrengthindication
RTP:Real‐timeTransportProtocol
RPORT: ResponsePort(RefertoRFC3581fordetails)
SIP:SessionInitiationProtocol
SME: SmallandMediumscaleEnterprise
SRTP:SecureReal‐timetransportprotocol
STUN: SessionTraversalUtilitiesforNAT
TLS:TransportLayerSecurity(forSIPencryption
VLAN:VirtualLocalAccessNetwork
TOS: TypeofService(policybasedrouting)
URL: UniformResourceLocator
UA: UserAgent
UTC:CoordinatedUniversalTime(similartoGMTformat)



Version1.0  Page|4


DECT deployment assessment

DECTdeploymentassessmentisessentialtodetermineelementsnecessarytoachievetheoverall
expectationsoftheuser.Typicalnetworkrequirementsincludes(butnotlimitedto):

Thegeographicalareatobecovered
Thetypeorarchitectureofbuildingand/ortopology,etc.
Thisincludesthematerialofwalls,thicknessofwalls.
Theestimatedtrafficineachcoveragearea
Theblockingcriteriaineachcoveragearea.


Deployment Considerations

ThefollowingradiationrelatedconsiderationsmustbeexaminedbeforedeployingatypicalSNOM
M700System.Theseincludes(butnotlimitedto):

BuildingPenetration:

Whenasignalstrikesabuildingitisdiffractedorabsorbed;thereforetosomeextendthesignalis
reduced.Theamountofabsorptionisdependentofthekindofbuildinganditsenvironment,the
amountofsolidstructure.Thisisanimportantconsiderationincoverageplanning.

Note: Thestructureofthebuildingwillhaveanimpactofcoveragerange.

InterferenceSources:

Signalsfromreceivingantennasareweakenedbyinterferencefromothersignals.Thesesignalsmay
befromthesamenetworkorotherobjects.AwellplannedDECTmulticellinstallationshouldidentify
potentialinterferencesourcesforoptimalplacementofBasestationsandrepeaters.

Note:OtherDECTsystemsordevicestransmittinginsimilarfrequencies,weakensreception.
Thereforeitisrecommendedtosetupbasestationssufficientlyclosetoeachother.

Radio/CellRange:

Thesuggesteddistancebetweentwobasestationsdependsonthephysicalpathbetweenthebase
stations.Ifthepathlossislessened,e.g.byminimizingamountofwalls/obstaclesinthepath,then
signalsfrombasestationswillcovermoredistance.Inatypicalofficebuildingthesuggesteddistance
betweentwobasestationsis20‐40m.

Note:Lessobstaclesbetweentwobasestationsincreasethepossibledistancebetweentwo
basestations.
Range
∙Officeareas:Upto40meters

Version1.0  Page|5

∙Officeareaswithobstructionslikeelevatorshafts,stairwells,metalwalls:Upto10meters
∙Shopfloors:Upto60meters
∙Exhibitionhallsorproductionareaswithoutobstacles:Upto100meters
∙Undergroundgarages:Upto20meters
∙Outdoorswithoutobstructions:Upto200‐300meters(forindooruseonly)
Capacity Planning

Eachbasestationhasamaximumlimitofparallelcalls.

ToavoidinsufficientuserexperiencethroughcongestedDECTnetwork,thecapacityfortheDECT
networkshouldbeplannedinadvance.

Duetodifferentusagepatterns,thenumberofbasestationrequiredtofulfilthedemandofvoice
channelsmayvary.

Thetotalcapacityinthecoverageareaofabasestationisalwayslimitedtothecapacityofasingle
basestation.

Site Planning / Cell Coverage

Theactualcellcoverageandqualityinaninstallationcanbedeterminedwithaspecialhandset
feature,inwhichthehandsetestablishesanaudioloop.
Snomurgentlyrecommendsto

Note:Thisfeaturecanbeusedwithbasestationsinaninfrastructure,butalsowithsingle
basestationswithoutEthernetconnection,sothefeatureallowstoidentifyobstacles
anddifficultiesinaninstallation.

1. Using the Handset for reception measurement

Beforestartingthedeploymentmeasuringmakesurethehandsetisproperlycharged.Identifythe
MACaddressofthebasestationtowhichyouwanttomeasure.AswellmanuallyreadtheMAC
addressonthebasestationlabelsonthebacksideforthedevicetobeusedwiththehandset.The
handsetdoesnotneedtobe(pre‐)registeredtoaparticularbase.
1. Press“Menu”followedbythekeys:*47*togetthehandsetintofindbasesmenu.

Note:Stayclosetothebasestationtostartthesearch.
NarrowbandWideband
Basestation8calls4calls
Repeater5calls2calls

Version1.0  Page|6

2. Usethecursordown/uptoselectthebaseMACaddressforthebasestation.
3. Selecttheintendedbase.
4. Thehandsetdisplaywillshowthe“RSSI”(Receivedsignalstrengthindication)levelofthebase.
5. Optional:Bypressing“hookoff”key(greenkey)anaudioloopbackconnectionwillbe
establishedwiththebasestation.
Note:ByplugginginaheadsetmodifiedforaMP3playerconnectionaudiofromthe
handset/MP3playerwillbeloopedbacktothehandsetearpiece.Thismakesitpossible
tolistentoaudioatthesametimeasreadingtheRSSIlevelsofthedisplay.
Snomrecommendsusingabuildingplanandcheckingthebasestationcoverageusingthehandset
signalstrengthindicationRSSIlevelfromeachbasestation.

2. Placing 2nd and following base station

Inordertoplacethe2ndbasestation:
Placethe1stSNOMM700basestationexactatthedesiredposition,andpoweronthebase
Setupthehandsetasdescribedinprevioussection.
UsethebuildingplandrawingandcheckthebasestationcoverageusingthehandsetRSSI
levels.Markuptheacceptablespotsandnon‐acceptablespotsforplacingthe2ndbasestation
ontheplandrawing.AcceptablespotsarespotswherethehandsetshowsRSSIlevelsbetter
than075dBm(meaninglowernumericnumber)andwhereyouverifiedviaaudioloopback
thatthereceptionisclear.
ItisrecommendedtohaveaRSSIvaluebetterthan/equalto‐75dBm,andneverbelow‐90dBm.:
Lowernumericnumberthan075dBmonthehandsetscreen.Pleasenotethattheminusisnot
shownonthescreen.

Typically,installationssuchasofficebuildings,warehousesandhospitalityshouldbeequippedwith
bothbasestationsandrepeatersonseveralfloorstocreateuniformandcompleteradiocoverage.

Donotlinktwoormoremulticellbasestationviaarepeater.Arepeatershallbeonlyusedtoextend
thecoverageofasinglebasestation.IfEthernetisavailableitisrecommendedtouseamulticell
stationratherthanarepeater.

Openareascanbecoveredwithasparsenetworkofbasestations.Insuchapplications,thebase
stationsand/orrepeaterscoveranextendedrangeduetotheextendedline‐of‐sightradiopropagation
capability.



Version1.0  Page|7

IP configuration

ThesnomM700canoperateusingavarietyoftheIPnetworksettings,allowingittobeconfiguredfor
differentnetworks.

ThebasestationcanbeconfiguredforeitherdynamicIP‐addressretrievalusingDHCPorsetupfor
usageofafixedIP‐address.Bydefaultdynamicconfigurationisconfigured.

ThebasestationcanalsobeconfiguredforusageofavirtualLAN(VLAN),whichistherecommended
configuration,asadedicatedVLANforvoicetrafficinacorporatenetworkcanprovidethemost
optimalQualityofService(QoS).NoVLANtagisenabledasdefault.TheVLANcanbeconfigured
duringbootupviaDHCPOption132(VLANID)andOption133(VLANQoS).

DedicatedQoSsettingsintheIPpacketsforsupportofDiffServ,ToSandcanbeenabledusingthebase
stationconfigurationpageorsnomprovisioning.

ThecommunicationbetweenthebasestationsiseitherIPMulticastorPeer‐To‐Peercommunication.
IPMulticastisthepreferredoptionasitgeneratestheleasttraffic,butitrequireseitherasingleIP
subnetorIP‐Multicastpass‐throughinthenetworkswitches.

M700/M5 Repeater Placement Recommendations

Theantennasinthebasestationsareclosetoomnidirectional;therebythereisnoneedtoconsider
howthebasestationsfaceeachotherwhendeployingthem.
Thesearesomerecommendationsforplacementstrategies:

AroundCorridors:
Basestations/repeatershouldbedeployedverticallypreferablyatcorridorintersectionswhere
propagationpatternsfollowthecorridorpatterns.Incasetherearehighobjectsinthearea,thebase
station/repeatershouldbeinstalledabovethoseobjects.

Multi‐StoryBuildings:
Basestationsandrepeaterscanbeinstalledonoppositesidesofthefloorstotakeadvantageofthe
floor‐to‐floorcoverage.Thecoveragedesigncannotrelyentirelyonfloor‐to‐floorpropagation;each
casemustbeverifiedduetovariationsinlocalattenuationpatterns.

LargeHalls:
Basestationsandrepeaterscanbedeployedinlargehallsthatcontainacentralopenspaceareawith
windowstotheotherareas.Thisprovidesagoodcoveragefortheroomsintheinnercircleonall
floors.Inlargehalls,basestations/repeatershouldbeinstalledverticallyinthemiddleofthespace
belowtheceiling.

MountingPositions:
WhenBasestationsandrepeateraremountedverticallyonawall,theradiocoverageinfrontofthese
devicesistwiceaslargeasthecoverageattherear.Thebasestationsshouldalwaysbemounted
higherthattheobstructiveobjectsinthearea–e.g.minimumhigherthan2mabovefloor.
Repeatersshouldbeinstalledinthemiddleofcorridorsandsmallrooms.

MetallicStructures/Objects:

Version1.0  Page|8

Basestationsandrepeatersshouldnotbedeployednearlargemetallicobjects.Thisincludesmetallic
inshelvesinwarehouses.

ReinforcedConcreteStructures:
Thesestructuresreducesignalstrengthdramaticallyinsidethebuilding.Theyreducetheradio
coveragerangeoftheBasestationsandrepeatersandthereforerequireahighernumberofbase
stationsorrepeatersinthebuilding.Lightertypesofconstructionmaterialsrequirefewerbase
stationssinceattenuationfiguresareconsiderablylower.


Version1.0  Page|9

M700 VoIP/DECT deployment limitations

TheM700systemisaverypowerfulDECTsystem.Comparedtomostcompetitorsitdoesnotrequire
specialcontrollersorlicensesforbuildingyourDECTnetwork.Aninstallationcanbeextendedwith
additionalM700basestations.
Duetothehighlyintegratedsystemandthe“sharing”ofresourcestherearesomelimitationsand
thingstoconsiderwhileplanningorextendinganexistinginstallation:
Onebasestationwillbecomethemasterbasestation,whichwill“organize”theinstallation
andsynchronizetheotherbasestations(slavebasestations)withthenetworktopology.
Outgoingfromthe“masterbasestation”,amaximumof6additionalbasestationslevelscan
beinstalled.Thismeansamaximumof7levelsofbasestationsinaline(row)includingthe
master.
Themaximumamountofusers/handsets/SIP‐registrationsis200.
Eachbasestationcanholdamaximumof30users,soyouneedatleast7basestationsto
achievethemaximumamountofusers(butmorethan7won’tallowmorethan200users).
Eachbasestationallowstohave8narrowbandcallsinparallel


M700 VoIP/DECT Network deployment considerations

TodeployamulticellDECTnetwork,therearesomerequirementstofollowandsomelimitations.

AmulticellDECTnetworkisbasedonamaster/slavearchitecture.Themasterbasestationwillensure
thatalltheslavereceivethenetworklayout.Thismeanstheslavecellsare“synchronized”andare
“aware”ofeachothertoallowseamlesshandoverforusershandsets.

Amaximumof7synclevelsaresupported,thatmeansstartingfromthesyncMaster(Level1),youcan
deployandcascadeupto6additionalbasestations(slaves)outgoingfromthemaster.Thismeans,if
youwanttocoveralongcorridor,youshouldsetupthemasterbasestationinthemiddle,thisallows
thelevelstobeinbothdirections.

Case#1:SynchronisationChainwithOneMasterSync.


Version1.0  Page|10



a) TheSynchronisationchainmustalwaysoverlapwithotherBasestationsinordertolatcheach
other.
b) InthisillustrationBasestation#39istheSyncMaster,RPN00(RadioFixedPartNumber)
c) Amaximumof7synclevels(Includingthemasterbases)canbeusedinadeployment.
d) TheotherslavebasestationsorrepeatersareconnectedtotheSyncMasterthroughthe
synchronisationchain.
e) Ifoneofthebaseorrepeaterunitsinthesyncchainisbrokenornotworking,thentheunitsthat
followthenon‐workingdevicearecutofffromthesyncchain,andair‐interfacesynchronization
canbelost.Whentheairinterfacesynchronizationislosthandoverbetweenthetwoclustersis
notpossible.


Thesynclevelconceptisillustratedbelow,wherebases#08and#02areatsynclevel1,andBS#03is
atlevel2.





Version1.0  Page|11

Case#2:SynchronisationChainwithoutAlternativeSyncPaths



Dependingonthesystemsetup,itisrecommendedtoplacetheSyncsourceMasterinthemiddleof
thebuildingandtoassignnumbers/addresses,radioID(RPN),etc.toeachbasestationorrepeaterfor
easyidentification.

Continuousline:Showstheprimarysyncpaths,withtherelevantbaseschainedinthemulti‐
cellnetwork.
Dottedline:Alternativesyncpaths.


Case#3:SynchronisationChainwithAlternativeSyncPaths

Theillustrationbelowshowsamulti‐cellnetworkwithalternativeSynchronisationpaths.Afailureof
onebaseunitdoesnotmeanhandsetoruserscannotperformhandoverstootheractivecells.

Version1.0  Page|12



BS#39istheSYNCMaster,ifBS#05isdown,mostuserhandoverscanbeformedvia3other
alternativecells(i.e.BS#06,BS#02andBS#04),butcannotoperateinthecoverageareaofBS#05
wherenootherbasestationcanreachthehandset.

Furthermoreobservethefollowing:
BS#04andBS#01arelevel1toBS#39.
BS#05isprimarysynctoBS#04(level2)whilealternativesyncisBS#02inlinewithBS#01
(level3)
BS#03isprimarysynctoBS#02(level3)whilealternativesyncisBS#06inlinewithBS#05and
BS#04(level4)

Anotherillustrationbelowshowsamulti‐cellnetworkwithoutalternativesynchronisationpaths.A
failureofonebaseunitwillaffectthefurtherlevelsofthetopology.

Version1.0  Page|13




BS#24orBS#26cannotreachBS#20(master)directly,butonlythroughBS#25
BS#21orBS#23cannotreachBS#20(master)directly,butonlythroughBS#22

Installation

Startwiththeintendedmasterbasestation.Itisrecommendedtoupdateandresetallbasestations
priortoinstallingtheminamulticellsetup.Secondarybasestationsmustberesettodefaults!
Important:Secondarybasestationsmustnotcontainany(SIP)“Server”inputs.Disabletheoption
“Plug&Play”inthemenu“Network”topreventanautomatedsetupofa(SIP)serverifyouhave
relatedDCHPoptionsrunninginyournetwork.
Onlyforthemasterbasestation:
Followallstepsfromthe“snomM300andM700administrationandinstallationguide”:
oSetupaSIPserver
oCreateauseraccount
oRegisterhandsets
Usethewebbrowsermenuandnavigateto“Time”settings(leftcolumn).Entertherelevant
parametersonthispageandpresstheSavebutton.Makesurethatthe“Timeserver”is
working,otherwisetheMulti‐cellfeaturewillnotwork.

Basestationsmustberebootedafterthetimeserverhasbeenset.

Version1.0  Page|14


Navigateto“Multicell”menu.Bydefaultanewbasestationhas“Multicellsettings”feature
disabled.

Descriptionofparameters
MulticellsystemEnablethisoptiontoallowtheBaseunittobesetinmulti‐cellmode(can
besetasmasterorslaveinthemulti‐cellchainsystem).ValidInputs:
Enable,Disable
SystemchainIDThisisanidentifier(usuallyinstringformatfore.g.2275)thatisunique
foraspecificmulti‐cellsystem.
Note:Therecanbeseveralmulti‐cellsystemsinthenetwork.
ValidInput:8bitString
Synchronizationtime(s)Thisspecifiestheperiodorwindowinsecondselements/nodes(fore.g.
Baseunits)inaspecificMulti‐cellshouldsynchronisetoeachother.

MulticelldebugEnablethisfeature,ifyouwantthesystemtocataloguelowlevelmulti‐
celldebuginformationortraces.
EnabletheMulticellsettingfromthedropdownmenu.
Entertherelevantvaluesfor“SystemchainID”and“Synchronizationtime(s)”respectively.
The“SystemchainID”isageographicallyuniqueDECTcellidentityallocatedtobridgeseveral
basestationstogetherinachain.Anexampleis2275.Inonemulticellinstallationallbase
stationsmusthavethesame“SystemchainID”.
TheSynchronizationtime(s)parameterisdefinedaswindow/periodoftimeinsecondsa
specificbasestationsynchronisestothemasterbasestationunit(bydefault60).
Clickon“Save”buttontokeepmodifiedchangesofmulticellsettingsintothebasestation.
Oneachconfigurationinterfaceforthebasestation(s)navigatetothe“Home/Status”page
andClickthe“Reboot”button.
Repeatallstepsasexplainedaboveforalltheintendedbasestationsinmulticelloperation.

Ittakesuptomaximum5minutes(synchronizationtime)toaddanewbasestationtoaMultiCell
System.

NavigatebacktotheMulticellsettingspagebyclicking“Multi‐cell”.TherevisedMulticell
settingspageshowstherelevantbasestationssynchronizedtogether.Bydefault,thesystem
usesthefirstregisteredbasestationasthemasterbaseunit.
OntheMulti‐cellsettingspage,scrolltotheDECTsystemsettingsandEnableorDisablethe
“AutoconfigureDECTsyncoptionsourcetree”(Seedescriptioninthetablebelow).Usually
theDECTsystemRFPIparameterisrecordedbythesystem(It’softengreyedinamulti‐cell
systemconfiguration).

Note:Enablethistoallowthenetworktoautomaticallysynchronisethemulti‐cellchain/tree.

Version1.0  Page|15


DECT Chain

AfteraMulticellinstallationyoucanmanuallyconfigurethesynchronisationsourcetree.Onthe
settingspage,scrolltothe“Multicell”settingsandEnableorDisablethe“AutoconfigureDECTsync
optionsourcetree”.



IDBaseunitidentityinthechainednetwork.
RPNTheRadioFixedPartNumberisan8‐bitDECTcellidentityallocatedby
theinstaller.TheallocatedRPNwithintheinstallationmustbe
geographicallyunique.Basestations’andrepeater’sRPNmustonlydiffer
onleastsignificantbitsthataremaskedoutbythehandovermask.
MADAddressContainsthehardwareEthernetMACaddress.Pleaserefertothe
productlabels.
VersionBasestationcurrentfirmwareversion.
StatusCurrentBasestationbehaviourintheSMEnetwork.
PossibleOutputs:
‐Connected:TherelevantBasestation(s)isonlineinthenetwork
‐ConnectionLoss:Basestationunexpectedlylostconnectiontonetwork
‐ThisUnit:CurrentBasestationwhosehttpWebInterfaceiscurrently
beingaccessed
DECTSyncTheadministratorcanchoosetherelevant“multicellchain”level.
Maximumnumberof“multi‐cellchain”levelsis6.

Version1.0  Page|16

Inthedropdownmenuyoucanseethesignalstrengthindicationtoall
otherpossiblebasestations.
DECTPropertyBasestationcharacteristicsinconnectiontothecurrentmulticell
network.PossibleOutput(s)
‐Primary:Masterbasestationuntowhichallothernodesinthechain
synchronisesto.
‐Locked:TheBaseunitiscurrentlysynchronizedandlockedtothemaster
Baseunit.
‐Searching:BaseunitintheprocessoflocatingtoaMaster/slaveas
specifiedinDECTsyncsource.
‐FreeRunning:AlockedBaseunitthatsuddenlylostsynchronisationto
theMaster.
‐Unknown:NocurrentconnectioninformationfromspecificBaseunit.
ItisrecommendedtohaveaRSSIvaluebetterthan/equalto‐75dBm,andneverbelow‐90dBm.

Nextstepinvolvesaddingextensionstothesystem.Followallstepsfromthe“snomM300andM700
administrationandinstallationguide”.
