Snom 320 User manual

Manual
© 2005 snom technology AG
All rights reserved.
Version 1.00
snom 320
VoIP Business Phone
www.snom.com

snom technology AG
Gradestr. 46
12347 Berlin, Germany
© 2005 snom technology Aktiengesellschaft.
All Rights Reserved. This document is supplied by snom
technology AG. No part of this document may be reproduced, republished
or retransmitted in any form or by any means whatsoever, whether
electronically or mechanically, including, but not limited to, by way of
photocopying, recording, information recording or through retrieval
systems, without the express written permission of snom technology AG.
snom technology AG reserves the right to revise this document
and make changes at any time and without the obligation to notify any
person and/or entity of such revisions and/or changes.
Product specifications contained in this document are subject to
change without notice.
Version 1.00/21.06.05
Copyright © 2005 snom technology AG. snom® is a registered trademark of snom technology AG and affiliates
in Germany, U.S.A. and certain other countries. Other trademarks or registered trademarks mentioned in this
document are the property of their respective manufacturers or owners.

snom technology AG • 3
Foreword
Congratulations on the purchase of your snom 320 Voice over IP
telephone!
Telephony is part of our everyday life. Over a period of more than
100 years, a form of communication has evolved which we feel cannot be
ignored. In spite of the new technology base of the snom 320, most of its
look and feel will be very familiar to you and you should be able to use it
intuitively.
On the other hand, the world of the Internet has opened a whole
range of new possibilities. Many users are using web browsers and own
one or more e-mail accounts. They will find it easy to manage the phone
via its web interface or to make a call to “sip:[email protected]”, for
example.
We are confident that developments in the computer industry will
follow those in the telecom world.
VoIP is not only about transporting speech over data networks.
It is about interoperability and breaking up a vertical market, as well as
streamlining business processes by seamlessly integrating the telephone
into computer networks and applications. With its technical flexibility,
our commitment to all open and relevant standards and our cooperation
with other vendors in the VoIP industry, the snom 320 represents a safe
investment for the future.
We would like to take this opportunity to wish you a great
experience in the VoIP world.
snom technology AG

4 •
[ SNOM 320 USER MANUAL V1.00 ]
Note to the reader
This manual describes the snom 320 running in administrator mode.
The phone supports SIP protocol only!
The default password to reach administrator mode is “0000” (four zeros).
The current version of this manual can be obtained from:
http://www.snom.com

snom technology AG • 5
