QUICK START GUIDE
CHS 8Ci
Bluetooth Cordless Scanner
This document pertains to the following model:
CHS 8Ci - Black SKU# CX2881-1476 (P/N 8550-00069)
CHS 8Ci - White SKU# CX2893-1497 (P/N 8550-00072)

PACKAGE CONTENTS
© 2013 Socket Mobile, Inc. All rights reserved. Socket and the Socket logo are registered
trademarks or trademarks of Socket Mobile, Inc. The Bluetooth word mark and logo are
registered trademarks of the Bluetooth SIG, Inc. USA, and any use by Socket Mobile, Inc.
is under license. All other trademarks and trade names contained herein may be those of
their respective owners.
CHS 8Ci Lanyard USB Charging Cable

PRODUCT INFORMATION
3

PRODUCT SPECIFICATIONS
Light Source 630nm +- 30nm visible red LED
Scan Rate 5 scans / sec
Sensor Linear CMOS sensor
Resolution 5mil / 0.127mm
Bluetooth Prole SPP, HID
Battery Life 8 hours (1 scan / 5 sec)
Charge Time 4 hours fully charged
Wireless Range 10M / 33ft line of sight
Operating Temp 0° to 50° C (32° to 122° F)
Symbologies All major 1D barcodes
4

CHARGE THE BATTERY
Charge the CHS
The CHS must be fully charge before rst use. Initial charging takes 4
hours with the USB charging cable connected to a USB charging port.
Insert the Micro USB side of the USB Charging Cable (included) into
the CHS port and the USB side of the Charging Cable into the USB con-
nector of an AC adapter (not included). The CHS will beep twice when
connected to a USB Charging Port.
Power On
Press and hold down the small power button until the CHS beeps (low-
high tone).
See below for instructions on pairing and connecting your scanner
with your Apple or Android devices.
5
4 Hours

GETTING STARTED
Successful Scanning
1. Hold the scanner 5-7 cm away
from the barcode.
2. Aim the scan beam straight
across the entire barcode.
3. Keep your hand steady!
6

BLUETOOTH MODE  HID  SPP  iOS
The CHS 8Ci supports three modes of Bluetooth wireless
communication: HID, SPP, and iOS.
By default, the CHS 8Ci is set to HID Keyboard mode.
Operating System Apple Android Windows
HID ✓✓✓
SPP ✓ ✓
iOS ✓
HID (Human Interface Device): Default mode. No software installation
required.
SPP (Serial Port Prole): Recommended for Android, Windows
and other operating systems. Allows two-way communications.
SocketScan 10 software (available at socketmobile.com) or another
third party SDK application is required.
iOS: Recommended for Apple. Allows two-way communications.
Compatible application developed with SocketScan 10 SDK required.
Learn more about HID and SPP at http://www.socketmobile.com/
pdf/techbrief/socketscan-10-sdk_white-paper.pdf 7

BLUETOOTH BASICS
Pair and Connect
When Bluetooth is activated on your device and the CHS is in
discoverable mode, Bluetooth pairing will begin. When the two devices
recognize each other, they can pair.
Once the devices have paired, it is necessary to connect. (Follow the
instructions in the following pages to connect the CHS to your device.)
Once the devices have connected, they will automatically recognize
each other whenever they are within range, and it will not be
necessary to connect again.
If the CHS is connected to a device and gets disconnected, it will try to
reconnect. Make sure the computer or device is on and in range. If the
CHS cannot reconnect, it will beep long. Power o then on again to
reconnect.
To unpair from the last connected host, press and hold the trigger
button while turning o the scanner.
8

The CHS 8Ci keeps the pairing information of the last connected host.
Power o to disconnect the scanner, then power on to reconnect the
scanner.
To disconnect your CHS:
1. Power o - press and hold down the power button until the CHS
beeps (high-low tone).
2. Power on - press and hold down the power button until the CHS
beeps (low-high tone).
Your CHS is ready to reconnect.
BLUETOOTH BASICS
9

APPLE  BLUETOOTH MODE HID (KEYBOARD EMULATION)
Connect your CHS with an Apple device using HID mode.
(HID is the default mode.)
1. Power on the CHS.
2. Scan this barcode to set the CHS to HID mode.
3. Enable Bluetooth on the Apple device. A Bluetooth device search
will begin.
4. Select Socket CHS in the list of found devices.
5. Tap Pair if prompted.
6. The CHS will beep once to conrm connection.
Now you are ready to scan barcodes in HID mode using your Apple
device!
10

APPLE  BLUETOOTH MODE iOS
Connect your CHS with an Apple device using iOS mode.
(This is required only the rst time you connect.)
1. Power on the CHS.
2. Scan this barcode to set the CHS to iOS mode. (This is often part of
a program setup.)
3. Enable Bluetooth on the Apple device. A Bluetooth device search
will begin.
4. Select Socket CHS in the list of found devices.
5. The CHS will beep once to conrm connection.
Now you are ready to scan barcodes in iOS mode using your Apple
device!
Use ScannerSettings (available at the App Store - http://www.
socketmobile.com/appstore) or other compatible applications
developed with the SocketScan SDK on your Apple device.
11

ANDROID  SPP  INSTALL SOCKETSCAN 10
To install the software:
1. Use this QR code to nd SocketScan 10
software for your Android device in the
Google Play Store, or search for it manually
using keyword “SocketScan 10.”
2. If you installed barcode scanning software
for your device camera, you can scan this
barcode to launch the SocketScan 10 page
in Google Play. Alternatively, open Google Play
and search for SocketScan 10 Keyboard Wedge
software using the keyword “Socket”.
3. Follow the on-screen instructions to download and install
SocketScan 10.
4. If prompted, allow the app to access your
Bluetooth settings / USB storage / SD card /
WiFi access / Coarse location.
12
Scan the QR code
with your Android
device (requires QR
scanning app).

ANDROID  SPP  CONFIGURE DEVICE
13
Congure your device:
1. Open SocketScan 10 application.
2. If prompted, allow SocketScan 10 to turn on Bluetooth.
3. When prompted to set SocketScan 10 as the keyboard language,
tap Back .
4. Tap Home , then Menu .
5. Tap on Settings, then Language and Keyboard. In the same
settings you can congure the keyboard language or congure
the volume up button to trigger a scan.
6. Under Keyboard Settings, select SocketScan 10.
7. Open SocketScan 10 on your device.
8. When prompted to enable SocketScan 10 as Input Method,
tap Back .
9. Tap Menu , then select Input Method.
10. On the next screen, select SocketScan 10.
11. Tap Back .

ANDROID  SPP  BLUETOOTH CONNECTION
To pair and connect the CHS and Android device:
(Required only the rst time you connect)
1. Power on the CHS.
2. Enable Bluetooth on your Android device.
3. Tap Input Method and select SocketScan 10 as the input method.
4. In SocketScan 10, tap Menu then select Socket EZ Pair.
5. Scan the barcode on the screen to put your scanner in SPP mode.
The CHS will beep 3 times.
6. Tap [On screen] button.
7. On the next screen, tap [1D Scanner] button.
8. Scan the barcode on the screen (provides Bluetooth address). The
CHS will beep 3 times.
14

ANDROID  SPP  BLUETOOTH CONNECTION
10. When notied of a pairing request, swipe the notication down
then tap Pairing request.
11. On the next screen, tap Pair.
12. The CHS will beep once when it has connected and is ready to
scan barcodes. Tap Back to close Socket EZ Pair.
13. A CHS registration icon will appear on top of the screen. Swipe
the icon down to open the registration software. Follow the
instructions to register your CHS.
Now you are ready to scan barcodes in SPP mode using your
Android device!
15

USING THE SCANNER
Scanning Barcodes
After connecting the CHS to your device, open an application. Place
the cursor where you want to enter data.
Hold the CHS about 5-7 cm from the
barcode and press and hold the trigger
button. Make sure the red aiming beam
covers the entire width of the barcode.
Keep your hand steady.
By default, the CHS will beep, vibrate,
and the side LED will ash green to
conrm that the barcode was decoded
and sent to the host device.
For more details, please refer to the User’s Guide.
16

USING THE SCANNER WITH THE KLIP CASE
Scanning Barcodes Using the Klip Case
The Klip Case connects the CHS 8Ci to various phone models allowing
for single-handed scanning and multi-tasking operations.
Socket provides Klip Cases that t with the following phone models:
• Apple iPhone 5 and 5S
• Apple iPhone 5c
• Apple iPod touch 5th
Generation
• Samsung Galaxy S4
Attach the Klip Case to your
phone, then attach the CHS to
the Klip Case. (See diagrams
following.)
Also available is a Universal Klip
Case with permanent adhesive.
CAUTION: Use a protective
case. Attachment directly to the
phone will be permanent and
removal could cause cosmetic
damage. 17

USING THE SCANNER WITH THE KLIP CASE
1. Place front end of the scanner in the Klip Case.
2. Push the back end of the scanner down until it clicks into place.
18

USING THE SCANNER WITH THE KLIP CASE
The bottom of the scanner and the Klip Case surface should lay ush
against each other, with no room to wiggle.
Press tab to remove scanner from Klip Case.
19

SINGLEHANDED SCANNING
For single-handed scanning and multi-tasking operation of the CHS,
attach the Klip Case to your phone or iPod touch. Make sure the scan
beam window of the CHS is pointing in the same direction as the TOP
of your phone or iPod touch.
Top of phone
or iPod touch
Scan beam window
