socomec COUNTIS E23 User manual

COUNTIS E23/E24
Three-phase active energy meter
63A direct MODBUS
Operating instructions EN

2COUNTIS E23/E24 - Ref.: 542 103 A
Contents
1. DOCUMENTATION ...................................................................3
2. DANGER AND WARNING............................................................3
2.1. RISK OF ELECTROCUTION, BURNS OR EXPLOSION ..................................3
2.2. RISK OF DAMAGING DEVICE ........................................................3
3. PRELIMINARY OPERATIONS........................................................3
4. OVERVIEW ...........................................................................4
4.1. MAIN FUNCTIONS ..................................................................4
4.2. DISPLAY VIEWS ....................................................................4
5. INSTALLATION .......................................................................5
5.1. RECOMMENDATIONS...............................................................5
5.2. DIMENSIONS (MM) .................................................................5
5.3. TERMINALS ........................................................................5
5.4. CONNECTIONS.....................................................................6
5.4.1. 4-WIRE CONNECTION - 4-WIRE LOAD MONITORING .............................6
5.4.2. 4-WIRE CONNECTION - 3-WIRE LOAD MONITORING .............................6
5.5. SEALABLE COVERS ................................................................6
6. MODBUS COMMUNICATION........................................................7
6.1. GENERAL INFORMATION ...........................................................7
6.2. RECOMMENDATIONS...............................................................7
6.3. COMMUNICATION STRUCTURE .....................................................7
6.4. COMMUNICATION TABLE ...........................................................7
7. PROGRAMMING .....................................................................8
7.1. NAVIGATION PRINCIPLE ............................................................8
7.2. PROGRAMMING MENU OVERVIEW ..................................................8
7.3. DETAILED VIEW OF MODBUS PROGRAMMING MENU.................................9
8. OPERATION ..........................................................................10
8.1. DETAILED VIEW OF MENUS .........................................................11
8.2. DETAILED VIEW OF "PARTIAL ENERGIES" ............................................12
8.3. DETAILED VIEW OF "PARTIAL ENERGIES" RESET .....................................12
9. DIAGNOSTIC MESSAGES ...........................................................13
9.1. MISSING PHASES ..................................................................13
9.2. PHASE INVERSION .................................................................13
9.3. MALFUNCTION.....................................................................13
10. ASSISTANCE........................................................................13
11. ELECTRICAL AND TECHNICAL CHARACTERISTICS.............................14
12. MID COMPLIANCE .................................................................15

3
COUNTIS E23/E24 - Ref.: 542 102 A
COUNTIS E23/E24 MODBUS
1. Documentation
All the documentation for COUNTIS E23/E24 equipment is available
online at:
www.socomec.com/en/countis-e2x
2. Danger and warning
This equipment must only be installed by professionals.
The manufacturer shall not be held responsible for failure to comply with the instructions in this manual.
2.1. Risk of electrocution, burns or explosion
• Thedevicemustbeinstalledandservicedonlybyqualiedpersonnel.
• Alwaysuseanappropriatevoltagedetectiondevicetoconrmtheabsenceofvoltage.
• Replace all devices, doors, and covers before turning on power to this equipment.
• Always supply the device with the correct rated voltage.
Failure to take these precautions could cause serious injuries.
2.2. Risk of damaging device
Check the following:
• the mains frequency (50 Hz).
• the maximum voltage at the voltage input terminals is 276 VAC phase/neutral.
• a maximum current of 63 A.
3. Preliminary operations
For personnel and product safety, please carefully read the contents of these operating instructions before installation.
Check the following points as soon as you receive package containing the COUNTIS E23/E24:
• the packaging is in good condition,
• the product has not been damaged during transportation,
• the product reference number conforms to your order,
• the packaging contains the product, two sealable covers, two plastic seals and a Quick Start guide.

4COUNTIS E23/E24 - Ref.: 542 103 A
4. Overview
COUNTIS E23 and E24 are active modular electrical energy meters for monitoring kWh. They are designed for three-
phase networks and enable direct connection up to 63A. They are equipped with a MODBUS communication bus.
4.1. Main functions
• Measurement and display of total and partial active energy (Ea+/Ea-)
• Management of two tariffs: T1/T2
• Measurement of electrical parameters accessible via the communication
- Voltage P-P: U12/U23/U31
- Voltage P-N: V1, V2, V3
- Frequency: F
- Current: I1/I2/I3/In
-Activepower±:P1/P2/P3/∑P
-Reactivepower±:Q1/Q2/Q3/∑Q
-Apparentpower:S1/S2/S3/∑S
-Powerfactor±:PF1/PF2/PF3/∑PF
- Total and partial active energy: Ea+ / Ea-
- Total reactive energy: Er+
- Active energy per tariff: Ea+
- Reactive energy per tariff: Er+
• MODBUS communication
• MID version (according to reference)
Description Reference
COUNTIS E23 4850 3035
COUNTIS E24 (MID) 4850 3036
4.2. Display views
COUNTIS E23: ref. 4850 3035 COUNTIS E24 (MID): ref. 4850 3036
9-digit LCD display
Active energy imported ->/exported <-
Phase detection
Current tariff
Partial active energy
Metrological LED
Selection button
Button to display partial active energy
Configuration button

5
COUNTIS E23/E24 - Ref.: 542 102 A
COUNTIS E23/E24 MODBUS
5. Installation
5.1. Recommendations
• avoid proximity to systems which generate electromagnetic interference,
• avoid vibrations with accelerations in excess of 1 G for frequencies below 60 Hz.
5.2. Dimensions (mm)
64
45
6
90
44
72
5.3. Terminals
64
45
6
90
44
72
0.61 in/15.5 mm
PZ2
exible or rigid 1.5
to 35 mm2
2 Nm
0.35 in/9 mm
PZ2
exible 1.5 to 2.5
rigid 1 to 4 mm2
0.8 Nm

6COUNTIS E23/E24 - Ref.: 542 103 A
5.4. Connections
5.4.1. 4-wire connection - 4-wire load monitoring
L1
L2
L3
N
L1 L1 L2 L2 L3 L3
N
7
1654
23
L1
L2
L3
N
L1 L1 L2 L2 L3 L3
3 x 63A
230/400 VAC 50 Hz
N
7
1654
23
230 VAC
COM RS485
MODBUS / Jbus
T1/2
120Ω -+NC
3 x 63A
230/400 VAC 50 Hz
230 VAC
COM RS485
MODBUS / Jbus
T1/2
120Ω -+NC
Tariff
1-2: Change of tariff only for COUNTIS E24:
0VAC -> Tariff 1
230VAC -> Tariff 2
(change of tariff via MODBUS for COUNTIS E23).
MODBUS
4: Activation of 120 ohm terminating resistors by connecting
terminals 4 and 5.
5: -
6: +
7: NC (not connected).
Mains
L1: Phase input
L1: Phase output.
L2: Phase input
L2: Phase output.
L3: Phase input
L3: Phase output.
N: Neutral connection.
5.4.2. 4-wire connection - 3-wire load monitoring
L1
L2
L3
N
L1 L1 L2 L2 L3 L3
N
7
1654
23
L1
L2
L3
N
L1 L1 L2 L2 L3 L3
3 x 63A
230/400 VAC 50 Hz
N
7
1654
23
230 VAC
COM RS485
MODBUS / Jbus
T1/2
120Ω -+NC
3 x 63A
230/400 VAC 50 Hz
230 VAC
COM RS485
MODBUS / Jbus
T1/2
120Ω -+NC
Tariff
1-2: Change of tariff only for COUNTIS E24:
0VAC -> Tariff 1
230VAC -> Tariff 2
(change of tariff via MODBUS for COUNTIS E23).
MODBUS
4: Activation of 120 ohm terminating resistors by connecting
terminals 4 and 5.
5: -
6: +
7: NC (not connected).
Mains
L1: Phase input
L1: Phase output.
L2: Phase input
L2: Phase output.
L3: Phase input
L3: Phase output.
N: Neutral connection.
5.5. Sealable covers
Plastic seal
Terminal covers
COUNTIS E24 MID
Label scaled
between front and
rear faces

7
COUNTIS E23/E24 - Ref.: 542 102 A
COUNTIS E23/E24 MODBUS
6. MODBUS communication
6.1. General Information
MODBUS®communication is performed via a RS485 serial port (2- or 3-wire) which enables products to be used
from a PC or an API.
Onastandardconguration,aRS485portcanbeusedtoconnect32productstoaPCoraPLCacross1200
meters.
R=120Ω
R=120Ω
R=120Ω
R=120Ω R=120Ω R=120Ω
R=120Ω
R=120Ω
R=120Ω
R=120Ω R=120Ω R=120Ω
MODBUS wiring
Wiring with repeater
≈1200mor32UL
≈1200mor32UL ≈1200mor32UL
Repeater
0 -> NC
0 -> NC
6.2. Recommendations
It is necessary to use a shielded twisted pair (LIYCY type). In an environment where there is interference or large
network (in terms of length) we recommend the use of a shielded twisted pair (type LIYCY-CY).
A repeater should be used to connect additional products if the distance of 1200 m and/or maximum number of 32
products is exceeded.
A120-ohmresistormustbexedatbothendsofthelink.
6.3. Communication structure
The product communicates via a MODBUS®protocol, which involves a dialogue using a master-slave structure. The
mode of communication is the RTU (Remote Terminal Unit) mode using hexadecimal characters of at least 8 bits.
MODBUS®frame structure(master -> slave exchange):
Slave address Function code Address Number of words to read CRC 16
1 byte 1 byte 2 bytes 2 bytes 2 bytes
6.4. Communication table
The communication tables and associated explanations are
available on the COUNTIS E23/E24 documentation page online at
the following address:
www.socomec.com/en/countis-e2x

8COUNTIS E23/E24 - Ref.: 542 103 A
7. Programming
7.1. Navigation principle
Theprogrammingmodeenablesthecommunicationparameterstobemodied.Theprocesstonavigateinsidethe
programming mode is described in the following steps:
Access to item to set
> 4 sec Enter programming mode
(press button for 4 seconds)
Value to be modified
> 4 sec Validate the value
7.2. Programming menu overview
By pressing for 4 seconds, the device will enter the programming mode.
The various screens are accessible according to the sequence:
Programming mode
Primary address
Communication speed

9
COUNTIS E23/E24 - Ref.: 542 102 A
COUNTIS E23/E24 MODBUS
7.3. Detailed view of MODBUS programming menu
x 4
Primary address
4
sec
4
sec
x1
Communication speed
4
sec
4
sec
x1

10 COUNTIS E23/E24 - Ref.: 542 103 A
8. Operation
The total and partial active energy values are accessible via the dedicated buttons. Pressing the appropriate button
several times displays all the available measurements. All the available information and measurements are described
in the following diagram:
Total energy Partial energy
Tariff T1
Ea+ (kWh)
Tariff T1
Ea+ (kWh)
______________ ______________
Tariff T1
Ea- (kWh)
Tariff T1
Ea- (kWh)
______________ ______________
Tariff T2
Ea+ (kWh)
Tariff T2
Ea+ (kWh)
______________ ______________
Tariff T2
Ea- (kWh)
Tariff T2
Ea- (kWh)
______________ ______________
Primary MODBUS address
______________
Communication speed
______________
Software version
______________
"Checksum" software
checking
______________
Display screen checking

11
COUNTIS E23/E24 - Ref.: 542 102 A
COUNTIS E23/E24 MODBUS
8.1. Detailed view of menus
Ea+ (kWh) Tariff T1/T2*
or
Ea- (kWh) Tariff T1/T2*
*Depending on the current tariff and energy
x1
Ea- (kWh) Tariff T1/T2*
or
Ea+ (kWh) Tariff T1/T2*
*Depending on the current tariff and energy
x3
MODBUS
x1
x1
Software version
x1
"Checksum"
software checking
x1
Display screen checking
x1

12 COUNTIS E23/E24 - Ref.: 542 103 A
8.2. Detailed view of "Partial energies"
Ea+ (kWh) Tariff T1/T2*
or
Ea- (kWh) Tariff T1/T2*
*Depending on the current tariff and energy
x1
Ea+ partial (kWh)
Tariff T1/T2
or
Ea- partial (kWh)
Tariff T1/T2
x1
x1
x1
x1
8.3. Detailed view of "Partial energies" reset
Reset
Ea+ partial (kWh)
Tariff T1/T2
or
Reset
Ea- partial (kWh)
Tariff T1/T2
20
sec
Menu
4
sec
x1

13
COUNTIS E23/E24 - Ref.: 542 102 A
COUNTIS E23/E24 MODBUS
9. Diagnostic messages
The following messages appear when there is a connection error or malfunction error.
9.1. Missing phases
• If one or more phases cannot be detected, the corresponding icons will not be displayed on-screen.
Example: phase 2 (L2) is not detected.
9.2. Phase inversion
• If a phaseinversionisdetected,thephaseiconsash.
• To clear this message, without changing the connection, press and hold the OK button for 4 seconds.
(Warning: the measurement may be wrong).
9.3. Malfunction
• When these messages are displayed, the meter has malfunctioned and should be replaced.
10. Assistance
Causes Solutions
Missing phases on display Verify the connections
Phase inversion on display Checkmainsconguration
Error message Check that the meter is working correctly

14 COUNTIS E23/E24 - Ref.: 542 103 A
11. Electrical and Technical characteristics
Generalities
Case 4 DIN 43880 modules
Mounting DIN EN 60715 rail
Width 72 mm
Operating specications
Connectivity Three-phase - 4-wire 230/400V
Storageofenergyvaluesandconguration Yes: EEPROM
Tariffdisplayidentier T1 and T2
Power supply
CertiedvoltageUn 230 VAC
Operating voltage range 184 ... 276 VAC
Certiedfrequencyfn 50 Hz
Rated power consumption (max.) Pv ≤8VA(0.6W)
Overload
Direct voltage Un 480 VAC phase/phase
Instantaneous voltage Un (1 s) 800 V phase/phase
Direct current Imax 63 A
Instantaneous current Imax (10 ms) 1890 A
Display
Screen 9 digits (2 decimal places)
Active energy: 1 9-digit screen 0.01 -> 9999999.99 kWh
Measurement updating period 1 s
Measurement accuracy
Active power and energy (E23) Class 1 IEC 62053-21
Active power and energy (E24) Class B EN 50470-3
Input measurement
Connection type 400 V phase/phase
Voltage measurement range 184 ... 276 VAC phase/N
Current Iref 5 A
Current Imin 0.25 A
Current measurement range (Ist ... Imax) 0.015 ... 63 A
Certiedfrequency 50 Hz
Start-up current for energy measurement (Ist) 15 mA
Optical interfaces
Pulse value 1 Wh/imp
Safety
Internal meter yes
Degree of pollution 2
Operating voltage 300 VAC
AC voltage test (EN 50470-3, 7.2) 4 kV
Voltage pulse test 6 kV
Protection class (EN 50470) Class II
Casereresistanceclass Class V0
Integrated communication
MODBUS 2400 to 38,400 bps
Connection terminals
Cross-section of phase connections exibleorrigid:1.5to35mm2
Cross-section of tariff and communication connections exible1.5to2.5/rigid1to4mm2
Environmental conditions
Mechanical environment M1
Electromagnetic environment E2
Operating temperature -25 ... +55°C
Storage temperature -25 ... +70°C
Relative humidity ≤80%
Amplitude of 50 Hz vibrations ±0.075 mm
IP rating IP51(*)/IP20
(*) For installation in an enclosure with at least IP51 protection.

15
COUNTIS E23/E24 - Ref.: 542 102 A
COUNTIS E23/E24 MODBUS
12. MID compliance
The COUNTIS E24 meter complies with the MID directive for connection of three-phase networks (see "5.4.
Connections", page 6).
Afterconnectingtheproduct,checkthattheterminalcoversarecorrectlyttedandsecuredbythe2plasticseals
supplied with the product (see "5.5. Sealable covers", page 6). If the terminal covers must be removed, ensure
that the same seal part numbers are used (ref. 4850 304U).
The information given via the communication bus is only sent by way of information and has no legal value.
TheassignedoperatingconditionsguaranteeingMIDcomplianceareavailableinthetechnicalspecicationstables.
The MID declaration of conformity for the COUNTIS E24 is available
online at: www.socomec.com/en/countis-e2x

Ref. 542 103 A - EN - 09/13
VALID FOR FRANCE
www.socomec.com
hEAD OFFICE
SOCOMEC GROUP
S.A. SOCOMEC capital 10 951 300 €
R.C.S. Strasbourg B 548 500 149
B.P. 60010 - 1, rue de Westhouse
F-67235 Benfeld Cedex - FRANCE
InTERnATIOnAL SALES
DEpARTMEnT
SOCOMEC
1, rue de Westhouse - B.P. 60010
F - 67235 Benfeld Cedex - FRANCE
Tel. [phone]
Fax [phone]
[email protected]
Socomec worldwide
In wESTERnEUROpE
BELGIUM
B - 1070 Bruxelles
Tel. [phone]
[email protected]
FRANCE
F - 94132 Fontenay-sous-Bois Cedex
Tel. [phone]
[email protected]
GERMANY
D - 76275 Ettlingen
Tel. [phone]
[email protected]
ITALY
I - 20098 San Giuliano Milanese (MI)
Tel. [phone]
[email protected]
NETHERLANDS
NL - 3991 CD Houten
Tel. [phone]
[email protected]
SPAIN
E - 08329 Teià (Barcelona)
Tel. [phone]
[email protected]
UNITED KINGDOM
Hitchin Hertfordshire SG4 0TY
Tel. [phone]
[email protected]
In EASTERnEUROpE,
MIDDLE EAST, AFRICA
POLAND
01-625 Warszawa
Tel. [phone]
[email protected]
ROMANIA
023383 Bucharest
Tel. [phone]
[email protected]
RUSSIA
125167 - Moscow
Tel. [phone]
[email protected]
SLOVENIA
SI - 1000 Ljubljana
Tel. [phone]
[email protected]
TURKEY
34775 Istanbul
Tel. [phone]-22
[email protected]
UNITED ARAB EMIRATES
Dubai, U.A.E.
Tel. [phone]
[email protected]
Non contractual document. © 2013, Socomec SA. All rights reserved. - To help protect the environment, this document has been printed on PEFC paper (Programme for the Endorsement of Forest Certification)
In ASIA
CHINA
P.R.C 200052 Shanghai - China
Tel. [phone]
[email protected]
INDIA
122001 Gurgaon, Haryana - India
Tel. [phone]
[email protected]
SINGAPORE
Singapore 408723
Tel. [phone]
[email protected]
In nORThAMERICA
USA, CANADA & MEXICO
Cambridge, MA 02142 USA
Tel. [phone]
[email protected]
YOUR DISTRIBUTOR
