Solark LATAM 12K-3P-L Troubleshooting guide

February 2, 2023 1
INSTALLATION GUIDE USER MANUAL
RESIDENTIAL

February 2, 2023 2
READ THE INSTRUCTIONS COMPLETELY
BEFORE OPERATING THE EQUIPMENT.
Check the grid type before turning ON the unit.
Turn ON and program the unit using only batteries.
The unit will be programmed in 220V L-N/380V L-
L at a frequency of 50Hz, by default.
Not following the instructions may result in permanent damage to the
equipment.
Warning
STOP

February 2, 2023 3
WARNING SYMBOLS.............................................................................................................................................. 5
UPON RECEIVING SHIPMENT ................................................................................................................................. 6
WIRE GAUGE GUIDE (COPPER)............................................................................................................................... 9
WIRING DIAGRAMS ............................................................................................................................................. 10
GUI SCREENS........................................................................................................................................................ 16
PHYSICAL INSTALLATION ..................................................................................................................................... 19
INVERTER COMPONENTS................................................................................................................................................19
BACKUP CIRCUITS .........................................................................................................................................................20
MOUNTING THE SOL-ARK..............................................................................................................................................20
INTEGRATING BATTERIES................................................................................................................................................22
INTEGRATING A GENERATOR...........................................................................................................................................25
INTEGRATING SENSORS AND ACCESSORIES.........................................................................................................................27
POWERING-UP AND TESTING THE SOL-ARK .......................................................................................................................28
WI-FI / INTERNET CONNECTION.......................................................................................................................... 30
REMOTE MONITORING SETUP ........................................................................................................................................30
IP ADDRESS SETUP (PC OR SMART PHONE)........................................................................................................................31
PROGRAMMING GUIDE ....................................................................................................................................... 38
MAIN SCREEN (TOUCHSCREEN) ......................................................................................................................................39
BASIC SETUP ...............................................................................................................................................................41
SYSTEM ALARMS..........................................................................................................................................................42
BATTERY SETUP ...........................................................................................................................................................42
GRID SETUP ................................................................................................................................................................47
LIMITER (CT) SENSORS ......................................................................................................................................... 49
AUTOMATIC S LIMIT SENSORS CONFIGURATION. ...........................................................................................................50
INSTALL TIPS ........................................................................................................................................................ 50
OFF-GRID INSTALL TIPS ................................................................................................................................................51
NO BATTERY INSTALL TIPS .............................................................................................................................................51
BATTERIES ........................................................................................................................................................... 52
CHARGE CONTROLLER ...................................................................................................................................................52
PARALLEL SYSTEMS. ........................................................................................................... 54
ENABLING PARALLEL OPERATIONS ....................................................................................................................................54
TROUBLESHOOTING GUIDE WITH PHASE SEQUENCE. ............................................................................................................56
NOTE FOR BATTERY COMMUNICATION WITH MODBUS/CANBUS ........................................................................................56
TROUBLESHOOTING GUIDE.................................................................................................................................. 57
SOL-ARK 12K-3P-L ERROR CODES ..................................................................................................................................59
INSTALL VERIFICATION CHECKLIST ....................................................................................................................... 60
LIMITED WARRANTY: SOL-ARK 12K-3P-L............................................................................................................ 61
SOL-ARK 12K Installation guide & manual

February 2, 2023 4
Disclaimer
Unless specifically agreed to in writing, Sol-Ark:
(a) Does not warrant the accuracy, sufficiency or suitability of any technical or other information provided in
its manuals or other documentation.
(b) Assumes no responsibility or liability for any loss or damages, whether direct, indirect, consequential or

risk.
Sol-Ark is not responsible for system failure, damage or injury resulting from improper installation of its
products.
Information in this manual is subject to change without notice.
This version is only focused on the inverter labeled as: 12K-3P-L.
Contact us:
Phone (USA) 1-972-575-8875 ext. (2)
Email [email protected]
Website WWW.SOL-ARK.COM

February 2, 2023 5
Warning symbols
This symbol indicates information that, if ignored, could result in minor injury or
equipment damage.
This symbol indicates information that, if ignored, could cause serious injury,
equipment damage or death.
This symbol indicates relevant information that is not related to hazard situations.
Warnings
Read this entire document before installing or using the Sol-Ark 12K inverter. Failure to follow any of
the instructions or warnings in this document can result in electrical shock, serious injury, or death.
Damage to the 12K inverter is also possible, potentially rendering it inoperable.
High Life Risk Due to Fire or Electrocution ONLY qualified persons should install the Sol-Ark 12K
inverter.
The system must have Ground connections and Neutral connections. Ground MUST be bonded to
Neutral ONLY ONCE in the circuit.
Solar PV+/PV- are UNGROUNDED. Note, you may ground PV Racking/Mounts, but doing so directly to
the Sol-Ark will likely result in damage in the case of a direct lightning strike to the PV array.
DO NOT connect the grid to the Load Output Terminal Block.
DO NOT reverse the polarity of batteries. Damage WILL occur.
DO NOT exceed 800Voc on any MPPT on the Sol-Ark.
DO NOT use impact drivers to tighten any fasteners on the Sol-Ark.
MUST use Strain Reliefs ON ALL wires entering/exiting the Sol-Ark 12K user area.
MUST use conduit (or double insulated wire) for AC Wires entering/exiting Sol-Ark 12K user area.
ALL terminals/breakers, including battery, MPPT, and AC Terminal Block inputs, should only have one
conductor connecting to them.

February 2, 2023 6
Upon Receiving Shipment
Inspect Shipment.
A. The box should include all items shown in the component guide.
B. If there are damages or missing parts, call immediately (USA) 972-575-8875 Ext. 2
Components guide.
Object
Description
Qty
A
12K-3P-L inverter
1
B
Metal mounting bracket (French mount)
1
C
Expansion plugs for concrete M8x80mm
4
D
CAT 5E communication cable
1
E
Allen key
1
F
Temperature sensor (3m)
1
G
User manual
1
H
Wi-Fi (Dongle)
1
I
Current transformer sensors 
3
J
MC4 connectors - (PV+/PV-)
3 pairs
A
D
B
C
E
F
I
G
H
J

February 2, 2023 7

February 2, 2023 8
Sol-Ark 12K-3Phase torque values application note

1.2 NM

1.2 NM

1.2 NM
Neutral / Ground (busbar)
1.2 NM
Cover Screws
3 NM
Battery Connection
10 NM
Minimum upper clearance = 500 mm
Temperature derating.
Optimum: -25°C to 60°C
Derating: >45°C
Shutdown with DC @100°C
Shutdown with AC @82°C
Do not use impact drivers to tighten any fasteners on the Sol-Ark.
Units expressed in mm

























































February 2, 2023 9
PV panel conductor CT sensors (included)
Battery cables AC breaker CT extension
Wire Gauge Guide (copper)



Max distance
0m 10m: 12 AWG
10m90m: 10 AWG
D=16.1mm
Cable length: 4m



* AC Input/Outputs: GRID-Breaker 60A MAX allowing 45A passthrough , 6 AWG conductor.
LOAD-Breaker 60A MAX allowing 45A passthrough, 6 AWG conductor.
*It is possible to use 10AWG conductors if using the inverter for grid sell only.
*Wire gauge should be selected in compliance with your local electrical code.
Sensors: 20-24 AWG / CT Sensors: 4m (13ft) included.
Battery temperature sensor: 3m.
RJ45 Cat 5 cable: 2m included.
Battery Cables: 2/0 AWG (Based on  rating)
3 pole single throw

   
 

  
Pins in the inverter

February 2, 2023 10
Wiring Diagrams
These Wiring Diagrams are examples of common use-cases for Sol-Ark
inverters.
Sol-Ark does not provide custom diagrams; however, you may contact
[email protected] for any questions about existing Wiring Diagrams.
Diagram 1

February 2, 2023 11
Diagram 2
Diagram 3

February 2, 2023 12
Diagram 4
Diagram 5

February 2, 2023 13
Diagram 6
Diagram 7

February 2, 2023 14
Diagram 8

February 2, 2023 15
Diagram 9

February 2, 2023 16
GUI Screens
Main Menus
Basic Setup

February 2, 2023 17
c
Battery Setup
Limiter

February 2, 2023 18
Grid Setup
(All the values shown on this manual are meant for illustration purposes. If you do not know the appropriate setting, contact technical
support).

February 2, 2023 19
Physical installation
Inverter components
Table 1: Sol-Ark 12K-3P-L parts identification.
ID
Element
ID
Element
A
ON/OFF Button
G
WI-FI port DB9
B
LCD screen
H
Sensor input board
C
Battery terminals (+|-)
I
GRID terminal
D
RJ45 port (Parallel A/Parallel B)
J
LOAD terminal
E
RJ45 port (BMS)
K
GEN terminal
F
PV disconnect
A
C
B
D
E
F
G
H
I
J
K

February 2, 2023 20
Backup circuits
A. The sub panel powered by the LOAD terminal will be considered the critical loads panel.
B. You must keep the critical loads panel within the limitations of the unit:
•It must be sized to cover 12KW in loads.
Mounting the Sol-Ark
A. Considering the dimensions of the inverter, find a suitable location for the system(s), see Figure (1.1), there must
be at least 50cm of upper clearance for proper heat dissipation. Heat transfer is done from bottom to top at a rate
of 290W/hr.
B. NEMA 3R - IP65 enclosure, rated for outdoor installation (can be installed indoors) .
C. PROTECT LCD screen from direct exposure to UV light.
D. Mount the Sol-Ark on the installed French cleat / ensure Sol-Ark is level and sits properly (French cleat dimensions
can be seen on page 8).
Figure (1.1) Upper space.


