SOLTEK SL-61A Use and care manual

i
Notice to End Users
This UserÕs Guide & Technical Reference is for assisting system
manufacturers and end users in setting up and installing the
mainboard.
Every effort has been made to ensure that the information in this
manual is accurate. Soltek Computer Inc. is not responsible for
printing or clerical errors. Information in this document is subject to
change without notice and does not represent a commitment on the
part of Soltek Computer Inc.
No part of this manual may be reproduced, transmitted, translated
into any language in any form or by any means, electronic or
mechanical, including photocopying and recording, for any purpose
without the express written permission of Soltek Computer Inc.
Companies and products mentioned in this manual are for
identification purposes only. Product names appearing in this
manual may or may not be registered trademarks or copyrights of
their respective companies.
SOLTEK COMPUTER INC. PROVIDES THIS MANUAL ÒAS ISÓ
WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED,
INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR
CONDITIONS OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE. IN NO EVENT SHALL SOLTEK COMPUTER
INC. BE LIABLE FOR ANY LOSS OR PROFITS, LOSS OF BUSINESS, LOSS
OF USE OR DATA, INTERRUPTION OF BUSINESS, OR FOR INDIRECT,
SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES OF ANY
KIND, EVEN IF SOLTEK COMPUTER INC. HAS BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY DEFECT OR
ERROR IN THIS MANUAL OR PRODUCT.
© Copyright 1997 Soltek Computer Inc. All right reserved
Web site: http://www.soltek.com.tw
email: [email protected]; [email protected]
Edition: July 1997
Version: 2.0
SL-61A SERIAL

Contents iii
Contents
Chapter 1: Introduction --------------------------------------- 1
Features -------------------------------------------------------------------------1
CPU ------------------------------------------------------------------------1
Chipset -------------------------------------------------------------------- 1
L2 Cache ------------------------------------------------------------------1
Main Memory ----------------------------------------------------------- 1
BIOS ------------------------------------------------------------------------ 2
Super I/O Function ----------------------------------------------------2
Other Functions --------------------------------------------------------- 2
Mainboard Layout with Default Settings ------------------------------3
Chapter 2: Hardware Setup---------------------------------- 4
CPU Type Configuration---------------------------------------------------4
CPU 3.5X Clock Setting ----------------------------------------------- 4
Pentium II (klamath) Ð 233/66MHz -------------------------- 4
CPU 4.0X Clock Setting ----------------------------------------------- 5
Pentium II (klamath) Ð 266/66 MHz ------------------------- 5
System Memory Configuration------------------------------------------- 5
CPU Installation -------------------------------------------------------------- 6
Intel Single Edge Cartridge (S.E.C.) Cartridge Disassembly
Process Application Note ------------------------------------------------ 10
Thermal Plate Removal --------------------------------------------- 12
Tool ----------------------------------------------------------------- 12
Procedure --------------------------------------------------------- 12
Thermal Grease Removal ------------------------------------------- 14
Materials ----------------------------------------------------------- 14
Procedure --------------------------------------------------------- 14
Jumper Settings ------------------------------------------------------------- 16
Factory Fixed Jumpers----------------------------------------------- 16

iv
JP1, JP3: DIMM Connector Power Source---------------------- 16
JP11: AT/ATX Power Select--------------------------------------- 16
FAN: Onboard FAN (12V) Connector -------------------------- 16
JP9: Clear CMOS Data ---------------------------------------------- 17
SW1: 1Ð2 Bus Clock Select ----------------------------------------- 17
SW1: 3Ð6: Bus Ratio Select ----------------------------------------- 18
IDE LED Activity Light: (J1 pin1Ð4)------------------------------ 18
Infrared Port Module Connector (J1 pin6Ð10) ----------------- 18
J1 pin12, 13: PWR Switch------------------------------------------- 18
SLEEP Switch (J1 pin14, 15) ---------------------------------------- 19
Speaker Connector (J2 pin1Ð4) ------------------------------------ 19
Reset Switch (J2 pin5, 6)--------------------------------------------- 19
Power LED and Keylock Switch (J2 pin8Ð12)------------------ 19
Turbo LED (J2 pin14, 15)-------------------------------------------- 19
USB: USB Connector ------------------------------------------------ 20
J1 Switch Signal Summary ----------------------------------------- 21
J2 Switch Signal Summary ----------------------------------------- 22
AT Power Connector ------------------------------------------------ 22
Chapter 3: BIOS Setup ---------------------------------------23
Standard CMOS Setup ---------------------------------------------------- 24
BIOS Features Setup ------------------------------------------------------- 26
Chipset Features Setup --------------------------------------------------- 29
Power Management Setup ----------------------------------------------- 32
PnP/PCI Configuration Setup ------------------------------------------ 34
Load Setup Defaults ------------------------------------------------------- 36
Integrated Peripherals ---------------------------------------------------- 36
Supervisor/User Password---------------------------------------------- 41
IDE HDD Auto Detection ------------------------------------------------ 42
Save & Exit Setup ---------------------------------------------------------- 42
Exit Without Saving ------------------------------------------------------- 42

Introduction 1
Chapter 1
Introduction
Features
CPU
1. Supports Intel Pentium II (klamath) CPU using SLOT1
at 166 ~ 533 MHz
2. Supports CPU voltage autodetect circuit
Chipset
1. Intel 82440FX chipset
2. PCI Rev 2.1 compliant
L2 Cache
1. CPU Card supports 256K/512k write back cache with
Pipelined Burst SRAMs
Main Memory
1. Memory range from 8MB (minimum) to 384MB
(maximum) with DRAM Table Free configurations
2. Supports Fast Page Mode/EDO/BEDO DRAM with
50ns/60ns/70ns DRAM speed
3. Supports 4 pcs 72pin SIMM sockets and 2 pcs 168pin
DIMM sockets (3.3V or 5V EDO/FP type)
4. DRAM supports ECC or Parity function

2
BIOS
1. AWARD Plug and Play BIOS
2. Supports Advanced Power Management Function
3. Flash Memory for easy upgrade
Super I/O Function
1. Integrated USB (Universal Serial Bus) controller with
two USB ports.
2. Supports 2 IDE channels with 4IDE devices (including
120MB IDE floppy)
3. Provides PCI IDE Bus Master function
4. One floppy port (including 3.5", 1.2MB Mode 3 function)
5. Two high speed 16550 FIFO UART ports
6. One parallel port with EPP/ECP/SPP capabilities
7. PS/2 mouse connector
8. Built-in RTC, CMOS, keyboard controller on single I/O
chip
9. Peripherals boot function (with ATX power)
Other Functions
1. BABY AT size 22cm x 33cm
2. 4 PCI Master slots and 4 ISA slots
3. Supports SCSI/CD-ROM Boot function.

Introduction 3
Mainboard Layout with Default Settings
The default settings of the following figure is for the
Pentium II (Klamath) 233/66 and AT power
SL7 SL5 SL3 SL1
PCI1 PCI2 PCI3 PCI4
I/O
PS/2
Mouse K/B
AT Power Con
ATX Power Con
Printer Con
FDD Con
IDE1 Con
IDE2 Con
82371SB
SM4SM3SM2SM1
M1
M2
USB
9
1
COM2
COM1
82441FX
82442FX
FLASH BIOS
+
–
BAT
PENTIUM II SLOT1 Pentium II-233
KLAMATH
W49C65-03
JP11
JP1
(5V)
1
2
JP3
(3.3V)
1
JP9
J1
J2
HDDLED
SPK RESET KEYLOCK T/LED
IR CON PWRSLEEP
1
1
2
1FAN PWR
PCI SLOTS
ISA SLOTS
DIMM for EDP/EP DRAM
On
6
Off
5
On
On
4
Off
32
On
1
ON
SW1
Figure 1Ð1. Motherboard Layout

4
Chapter 2
Hardware Setup
CPU Type Configuration
CPU 3.5X Clock Setting
Pentium II (klamath) – 233/66MHz
82371SB 82441FX
Pentium II (Klamath)-233
KLAMATH
On
6
Off
5
Off
On
4
Off
32
On
1
ON
SW1
Figure 2Ð1. CPU Type Configuration

Hardware Installation 5
CPU 4.0X Clock Setting
Pentium II (klamath) – 266/66 MHz
82371SB 82441FX
Pentium II (Klamath)-266
KLAMATH
Off
6
Off
5
On
Off
4
Off
32
On
1
ON
SW1
Figure 2Ð2. CPU Type Configuration
System Memory Configuration
This 82440FX motherboard supports 72-pin SIMMs and 168
pin DIMM of 4MB, 8MB, 16MB, or 32MB to form a memory
size between 8MB to 384MB. Each bank must have 2 pcs of
DRAM modules (w/i same size and type) installed.
82440FX chipsets provide ÒTable-FreeÓ function. It means
that users can install DRAM with any configuration and in
any bank, and that is why the DRAM table is not needed.

6
CPU Installation
Follow the following steps in order to install your Intel
Pentium II (Klamath) properly.
Step 1:
Be sure you are in contact with heat sink vendors for
attaching the heat sink on to the CPU.
Heat Sink
Latch
Intel Pentium II (Klamath)
CPU Side View
Heat Sink
Intel Pentium II (Klamath)
Latch
CPU Top View
Notice that the heat sink may be different from the drawings
shown here.
Step 2:
Install the 2 pairs of screws, which are shown in the
following drawing, onto the mainboard under the word
KLAMATH.
Two of the screws are right around the word of KLAMATH
and the other pair of screws should be inserted opposite the
first pair.
