SOLTEK SL-65MIE User manual

R
SL-65MIE
USER MANUAL V1.2

NOTICE
Product Model : SL-65MIE
Manual Revision : V1.2
Release Date : June 2 1
• Intel, Celeron, Pentium II, Pentium III are trademarks of Intel Corporation.
• Intel 82815 Graphic Memory Controller ub(GMC ), 82801 I/O Controller ub(IC ) are trade-
marks of Intel Corporation.
• VIA Cyrix III is trademark of VIA Corporation.
his Users’ Guide & Technical Reference is to help system
manufacturers and end-users set up and install the mainboard.
Every effort has been made to ensure that the information in this
manual is accurate. Soltek Computer Inc. is not responsible for print-
ing or clerical errors. Information in this document is subject to
change without notice and does not represent a commitment on the
part of Soltek Computer Inc.
No part of this manual may be reproduced, transmitted, translated
into any language in any form or by any means, electronic or
mechanical, including photocopying and recording, for any purpose
without the express written permission of Soltek Computer Inc.
Companies and products mentioned in this manual are for identifi-
cation purpose only. Product names appearing in this manual may
or may not be registered trademarks or copyrights of their respec-
tive companies.
Soltek Computer inc. Provides this manual “As is “ without war-
ranty of any kind, either express or implied, including but not limited
to the implied warranties or conditions of merchantability or fitness
for a particular purpose. In no event shall Soltek Computer inc. be
liable for any loss or profits, loss of business, loss of use or data,
interruption of business, or for indirect, special, incidental, or con-
sequential damages of any kind, even if Soltek Computer inc. has
been advised of the possibility of such damages arising from any
defect or error in this manual or product.
Copyright © 2001 Solt k Comput r Inc. All Rights R s rv d.
T

SOLTEK AROUND THE WORLD
SOLTEK COMPUTER INC.
Address : 7F, No. 306-3, Ta-Tung Rd, Sec.1, si-Chih, Taipei-
sien, Taiwan, R.O.C.
Telephone : [phone]
Fax : [phone]
E-mail : [email protected]
Web site : http://www.soltek.com.tw
SOUL TECHNOLOGY EUROPE B.V.
Address : ongkongstraat 55 3047 BR, Rotterdam, The
Netherlands
Telephone : [phone]
Fax : [phone]
E-mail : [email protected]
Web site : http://www.soultech-europe.com

65MIE
4
C O N T E N T
CHAPTER 1 INTRODUCTION .................................... 8
1- 1 MAINBOARD SPECIFICATION ................................................... 9
1-1-1 PROCESSOR ..................................................................................... 9
1-1-2 C IPSET ............................................................................................. 9
1-1-3 INTEGRATED SDRAM CONTROLLER .............................................. 9
1-1-4 FULL FEATURED ACCELERATED GRAP ICS PORTS ................... 9
(AGP) CONTROLLER ........................................................................ 9
1-1-5 MULTI-I/O FUNCTION ...................................................................... 10
1-1-6 EXPANSION SLOTS ......................................................................... 10
1-1-7 AWARD BIOS V6.0, SUPPORTING ................................................. 10
1-1-8 SOUND CONTROLLER .................................................................... 10
1-1-9 POWER MANAGEMENT .................................................................. 10
1-1-10 FORM FACTOR .............................................................................. 11
1-1-11 ARDWARE MONITORING ........................................................... 11
1-2 MOT ERBOARD LAYOUT --- 65MIE ........................................ 12
1-3 C IPSET SYSTEM BLOCK DIAGRAM...................................... 13
CHAPTER 2 HARDWARE SETUP............................ 15
2- 1 CPU INSTALLATION ................................................................. 16
2- 2 MEMORY INSTALLATION ......................................................... 17
2- 3 SUPPORTED SYSTEM BUS AND SYSTEM MEMORY BUS
FREQUENCIES TABLE ............................................................. 18
2- 4 DD/FDD INSTALLATION ......................................................... 19
2- 5 JUMPER SETTING FOR DEVICES ON BOARD: ..................... 21
2-5-1 JUMPER JBAT1/2 FOR CLEARING CMOS DATA: .......................... 21
2-5-2 KEYBOARD POWER ON (JP2) ........................................................ 22
2-5-3 USB WAKE UP (JP3) ........................................................................ 22
2-5-4 BUS CLOCK SELECT (JP7/JP8) ...................................................... 23
2-5-5 BIOS BOOT BLOCK LOCK (JP16) ................................................... 23

Content
5
2-5-6 USB PORT SELECT (JP17/JP18) .................................................... 24
2-5-7 USB PORT SELECT (JP19/JP20) .................................................... 24
2-5-8 FACTORY DEFAULT (J1) ................................................................. 25
2-6 CONNECTORS CONFIGURATIONS ......................................... 26
2-6-1 ONBOARD FAN CONNECTOR (CPUFA1/AUXFA1/C AFA1) ......... 26
2-6-2 CD-ROM AUDIO CONNECTOR (CD32/CD33) ................................ 27
2-6-3 WAKE ON LAN FUNCTION (JWOL1) ............................................. 27
2-6-4 T ERMAL SENSOR CONNECTOR (RT2) ....................................... 28
2-6-5 COMPLEX EADER J2&J3 .............................................................. 29
2-6-6 C ASSIS PANEL CONNECTOR ...................................................... 30
2-6-7 SERIAL PORT CONNECTORS ........................................................ 31
2-6-8 SMART CARD READER CONNECTOR (SCR1) ............................. 32
2-6-9 ATX POWER SUPPLY CONNECTOR .............................................. 32
2-6-10 COMMUNICATION AND NETWORKING RISER SLOT (CNR) ...... 33
2-6-11 PS/2 MOUSE AND PS/2 KEYBOARD ............................................ 33
2-6-12 SECOND USB EADER (USB2) .................................................... 34
2-6-13 IRQS DESCRIPTION FOR VARIOUS DEVICES............................ 35
CHAPTER 3 SOFTWARE SETUP ............................ 37
3-1 INTEL C IPSET DRIVER INSTALLATION ................................. 38
3-2 INTELL ULTRA ATA STORAGE DRIVER INSTALLATION ......... 39
3-3 AC’97 DRIVER INSTALLATION .................................................. 41
3-4 INSTALLING ITE ARDWARE MONITOR UTILITY
(SMARTGUARDIAM) .................................................................. 42
CHAPTER 4 BIOS SETUP ........................................ 45
T E BIOS ......................................................................................... 45
4-1 W AT IS BIOS SETUP ............................................................... 46
4-2 OW TO RUN BIOS SETUP ...................................................... 46
4-3 W AT IS CMOS ......................................................................... 46
4-4 W AT IS POST .......................................................................... 46
4-5 BIOS UPGRADE......................................................................... 46

65MIE
6
4-5-1 BEFORE UPGRADING BIOS ........................................................... 47
4-5-2 UPGRADE PROCESS ...................................................................... 47
4-6 BIOS SETUP-- CMOS SETUP UTILITY ..................................... 51
4-6-1 STANDARD CMOS SETUP .............................................................. 52
4-6-2 ADVANCED BIOS FEATURES ......................................................... 55
4-6-3 ADVANCED C IPSET FEATURES .................................................. 60
4-6-4 INTEGRATED PERIP ERALS ......................................................... 64
4-6-5 POWER MANAGEMENT SETUP ..................................................... 69
4-6-6 PNP / PCI CONFIGURATION ........................................................... 73
4-6-7 PC EALT STATUS ........................................................................ 76
4-6-8 FREQUENCY/VOLTAGE CONTROL................................................ 77
4-6-9 LOAD OPTIMIZED DEFAULTS ......................................................... 78
4-6-10 SET SUPERVISOR / USER PASSWORD ...................................... 80
4-6-11 SAVE & EXIT SETUP ...................................................................... 81
4-6-12 EXIT WIT OUT SAVING ................................................................ 81
APPENDICES ................................................................. 82
APPENDIX-1 TEC NICAL TERMS INTRODUCTION .................... 83
APPENDIX-2 IDENTIFYING BIOS VERSION AND BIOS PART
NUMBER.................................................................... 84
APPENDIX-3 IDENTIFYING MAINBOARD / MODEL NUMBER ..... 86

Chapter 1 Introduction
7
Mainboard
Support CD
User’s Manual
Bundled Bonus Pack CD
Bundled Bonus Pack Manual
Temperature Sensor Cable
ATA66/100 IDE Cable
RS232 Cable
FDD Cable
======ITEMLIST CHECKUP

65MIE
8
CHAPTER 1
INTRODUCTION
• This chapter briefly introduces the characteristics of this mainboard. It
includes the information regarding the chipset, CPU types, built-in
functions and layout. Users will have more ideas about mainboards after
reading this chapter.
1-1 MAINBOARD SPECIFICATION
1-2 MAINBOARD LAYOUT
1-3 CHIPSET DIAGRAM
THIS CHAPTER CONTAINS THE FOLLOWING TOPICS :

Chapter 1 Introduction
9
1- 1 MAINBOARD SPECIFICATION
1-1-1 PROCESSOR
• Supporting Intel® FC-PGA Pentium !!!TM up to 1G z.
• Supporting Intel® FC-PGA 370 Celeron & PPGA 370 Celeron up to 850M z.
• Supporting VIA Cyrix !!! up to 800M z.
• Supporting CPU voltage Auto-Detect circuit.
1-1-2 CHIPSET
• INTEL 82815 Graphics and Memory Controller ub (GMC ) & INTEL
82801BA I/O Controller ub (IC 2).
• ITE 8712 EC-LPC I/O chip.
1-1-3 INTEGRATED SDRAM CONTROLLER
• Provides 3pcs DIMM slots supporting double-sided DIMMs.
• Supporting 100/133M z SDRAM spec.
• Supporting total memory from 32MB to 512MB using 32Mb/64Mb/128Mb/
256Mb technology.
• Supporting up to 3 double sided DIMMs at 100M z system memory bus.
• Supporting up to 2 double sided or 3 single sided DIMMs at 133M z
system memory bus.
• Unbuffered , Non-ECC SDRAM only supported.
1-1-4 FULL FEATURED ACCELERATED GRAPHICS PORTS
(AGP) CONTROLLER
• Supporting 64-bit 66/ 100/ 133 M z System Bus Frequency.
• Provides 1x/ 2x/ 4x AGP controller.
• Integrated 2D & 3D Graphics Engines.
• Integrated /W Motion Compensation Engine.
• Integrated 24-bit 230 M z DAC.
• Supporting 133M z System Memory while running in non-CPC mode:
--AGP v2.0 compliant.
--Full 2D /W Acceleration.
--2D Graphics up to 1600 x 1200 in 8--bit Color at 85 z Refresh.
-- /W Motion Compensation Assistance for S/W MPEG2 Decode.
--Integrated Graphics Memory Controller can be disabled to support an
external AGP Card or PCI Graphics card.
--Provided an AGP 4X Slot which is compatible for AGP 1X/2X/4X mode
and AGP In-Line Memory Module (AIMM) up to 4 MB.

65MIE
1
1-1-5 MULTI-I/O FUNCTION
• Integrated IDE Controller.
• Supporting Ultra ATA33/66/100, BMIDE and PIO modes.
• Two UARTs for complete Serial Ports.
• One dedicated IR connector:
--Third serial port dedicated to IR function either through the two complete serial
ports or the third dedicated port Infrared-IrDA ( PSIR) and ASK( Amplitude Shift
Keyed) IR.
• Multi-mode parallel connector supporting:
--Standard mode, ECP and EPP.
• Floppy Disk connector supporting:
--Two FDDs with drive swap function.
• Universal Serial Bus connector supporting:
--USB v1.1 and Intel Universal CI v1.1 compatible.
--2 built-in USB connectors, in addition to one internal USB header which requires
a USB cable to support 2 more optional USB ports.
• PS/2 keyboard connector.
• PS/2 Mouse connector.
1-1-6 EXPANSION SLOTS
• Three PCI bus Master slots.
• One AGP 4x mode slot.
• One CNR slot.
• Three DIMM slots.
• One SCR (Smart Card Reader) slot.
1-1-7 AWARD BIOS V6.0, SUPPORTING
• Plug & Play V1.0.
• Flash Memory for easy upgrade.
• Year 2000 compliant.
• BIOS writing protection.
1-1-8 SOUND CONTROLLER
• AC 97 Link for Audio and Telephony CODECs.
• AC 97 2.1 compliant.
1-1-9 POWER MANAGEMENT
• ACPI 1.0 compliant. (Advanced Configuration and Power Interface)
• APM V1.2 compliant. (legacy power management)
• Supporting ACPI suspend POS mode. (Power On Suspend)

Chapter 1 Introduction
11
• System event monitoring with two event classes
• Supporting PS/2 keyboard & Mouse power on
• Supporting Wake On LAN (WOL) & Wake On Modem
• Supporting real time clock (RTC) with date alarm, month alarm, and cen-
tury field
• Supporting USB wake-up Function
1-1-10 FORM FACTOR
• Micro ATX form factor, 4 layer PCB.
• Motherboard size: 20.0cm x 24.5cm
1-1-11 HARDWARE MONITORING
• Programmable control, status, to provide monitoring and alarm for flex-
ible desktop management of hardware temperature. (software included
in support CD)
• 8 positive voltages status monitoring.
• 3 fan speeds status monitoring.
• 2 temperature status monitoring.

65MIE
12
1-2 MOTHERBOARD LAYOUT --- 65MIE
Using non-compliant m mory with high r bus clock than d fault fr qu ncy (ov r
clocking) may s v r ly compromis th r liability of syst m.
SOCKET 370
LPT1
VGA1 COM1
GAME/MIDI PORT
LINE OUT
LINE IN
MIC PS/2
MOUSE PS/2 K/B
upp r
low r
USB1 USB0
upp r
low r
RT1
Int l
815E
GMCH
ATX POWER
DIMM1 DIMM2 DIMM3
Clock
G n rator
1
1 1
IDE2 IDE1 FDC1
COM2
CPUFAN1
I/O Controll r
Int l
ICH2
Li
Batt ry
J2 J3
SAPK RST PLED SLED
HDD/LED IR PWR SUSPEND
++
--
+-
1 15 1 15
CHAFA1
SCR1
AUXFA1
FWH
16
1
USB2
1 4
1 4
CD32
CD33
1 3
1 3
JP7
JP8
J1
1 3
1 3
1 3
JP16 JP17 JP18 JP19 JP20
JBAT1 JBAT2
JWOL1
AC'97
Cod c
RT2
LED1
1 3
JP2 JP3
1
14
AGP 4X
PCI 1
PCI 2
PCI 3
CNR 1

Chapter 1 Introduction
13
Intel 82815 GMCH Chipset Diagram
1-3 CHIPSET SYSTEM BLOCK DIAGRAM
Syst m
M mory
PCI
Ag nt
Sup r
I/O
K yboard
Mous ,FD,PP
SP,IR
Int l 82815 Chips t
64bit /
66/100/133MHz
FWH
(Firmwar Hub)
ICH2
(I/O Controll r Hub)
Int l 82815
(GMCH)
-M mory Controll r
-AGP Controll r
-Graphics Controll r
-3D Engin
-2D Engin
-Vid o Engin
PCI Bus
GPIO
Syst m Bus (66/100/133MHz)
4 USB Ports
Analog Display
4 IDE Driv rs
Ultra DMA100/66/33 PCI Slots
Audio Cod c(s)
LAN Conn ct
Sok t 370 Proc ssor
AGP Conn ctor
Display Cach
(4MB SDRAM,
133MHz)
AGP Graphics
AGP 2.0
AC'97 2.1
LPC I/F


65MIE
14
MEMO

Chapter 2 Hardware etup
15
CHAPTER 2
ATTENTION !!!
1. Pl as r f r to your proc ssor installation or oth r
docum ntation attach d with your CPU for mor
d tail d installing instruction.
2. Installing a h at sink and cooling fan is n c ssary for
prop r h at dissipation from your CPU. Incorr ct
installation may r sult in ov rh ating and damag of
your CPU.
3. B for changing th s tting of CPU Vcor from BIOS
program, us r SHOULD mak sur of corr ct sp cifi-
cation both of CPU CLOCK and RATIO. Incorr ct s t-
ting may caus damag to your CPU.
HARDWARE SETUP
2-1 CPU INSTALLATION
2-2 MEMORY INSTALLATION
2-3 SUPPORTED SYSTEM BUS AND SYSTEM MEMORY
BUS FREQUENCIES TABLE
2-4 HDD/FDD INSTALLATION
2-5 FOR DEVICE ON BOARD
2-6 CONNECTORS CONFIGURATION
THIS CHAPTER CONTAINS THE FOLLOWING TOPICS :

65MIE
16
2- 1 CPU INSTALLATION
WARNING !!!
Never run you processor without the heat sink properly and firmly attached.
PERMANENT DAMAGE ILL RESULT!
SOCKET 370
• Pull out the lever from the
socket, and then raise the le-
ver up to a 90-degree angle.
1
SOCKET 370
• Take notice of the red circles
as shown below. While insert-
ing the CPU into the socket,
you can find out there is a defi-
nite pin orientation for CPU
and socket.
2
SOCKET 370
• Make sure that the CPU is
placed into the socket tightly.
Then lower down the lever to
complete the CPU installation.
3

Chapter 2 Hardware etup
17
Installing DIMM
• Make sure you have the correct memory module type for your mainboard.
• Insert the module(s) as shown below, DIMMs have 168-pins and two
notches that will be matched by the onboard DIMM socket. Memory mod-
ules are installed by inserting them straight into the slot until they “click” in
the right place. They only fit in one direction, so do not force them in by a
wrong direction.
R moving DIMM
• Press down the holding clips on both sides of a DIMM socket and the
module will be released from it.
WARING !!!
• Make sure that you unplug your power supply when adding or removing memory
modules or other system components, failure to do so may cause severe damage to both
your mainboard and expansion cards.
• Be careful when inserting or removing DIMM, forcing a DIMM in or out of a socket
can be damaged the memory module or the socket. Some of DIMMs contain EDO or
FTP DRAM that accept only 5V power. These DIMM types are incompliant with the
mainboard, the M/B only supports 3.3V true SDRAM DIMMs.
2- 2 MEMORY INSTALLATION
168-Pin DIMM Notch K y D finitions(3.3V)
DRAM K y Position Voltag K y Position
Unbuff r d 3.3V

65MIE
18
2-3 SUPPORTED SYSTEM BUS AND SYSTEM MEMORY
BUS FREQUENCIES TABLE
• The 82815E GMC has a new type of clocking architecture. It has inte-
grated SDRAM buffers that run at either 100 or 133 M z, independent of
the system bus frequency. See table below for supported system bus and
system memory bus frequencies.
Front Sid Bus
Fr qu ncy
Syst m M mory
Bus Fr qu ncy
AGP Bus
Fr qu ncy
PCI Bus
Fr qu ncy
Support d
Maximum DIMM
numb rs
66MHz 66MHz 33MHz 3singl sid s DIMMs
3singl sid s DIMMs
2 doubl d sid s or 3
singl sid s DIMMs
2 doubl d sid s or 3
singl sid s DIMMs
33MHz
33MHz
33MHz
66MHz
66MHz
66MHz
100MHz 100MHz
100MHz
100MHz
133MHz
133MHz 133MHz

Chapter 2 Hardware etup
19
SOCKET 370
LPT1
VGA1 COM1
GAME/MIDI PORT
LINE OUT
LINE IN
MIC
PS/2 MOUSE PS/2 K/B
upp r
low r
USB1 USB0
upp r
low r
RT1
Int l
815E
GMCH
ATX POWER
DIMM1 DIMM2 DIMM3
Clock
G n rator
1
1 1
IDE2 IDE1 FDC1
COM2
CPUFAN1
I/O Controll r
Int l
ICH2
Li
Batt ry
J2 J3
SAPK RST PLED SLED
HDD/LED IR PWR SUSPEND
++
--
+-
1 15 1 15
CHAFA1
SCR1
AUXFA1
FWH
16
1
USB2
1 4
1 4
CD32
CD33
1 3
1 3
JP7
JP8
J1
1 3
1 3
1 3
JP16 JP17 JP18 JP19 JP20
JBAT1 JBAT2
JWOL1
AC'97
Cod c
RT2
LED1
1 3
JP2 JP3
1
14
AGP 4X
PCI 1
PCI 2
PCI 3
CNR 1
2- 4 HDD/FDD INSTALLATION
• To install DD ( ard Disk Drive), you may connect the cable’s blue
connector to the mainboard’s primary (IDE1) or secondary IDE connector,
and then connect the gray connector to your slave device and the black
connector to your master device. If you install two hard disks , you must
configure the second drive to Slave mode by setting its jumper accordingly.
Please refer to your hard disk documentation for the jumper settings.
Hard Disk Driv Conn ctor:
Orient the red line on the IDE
ribbon cable to Pin1.
black connector
gray connector
blue connector
IDE Cabl
red line

65MIE
2
SOCKET 370
LPT1
VGA1 COM1
GAME/MIDI PORT
LINE OUT
LINE IN
MIC
PS/2 MOUSE PS/2 K/B
upp r
low r
USB1 USB0
upp r
low r
RT1
Int l
815E
GMCH
ATX POWER
DIMM1 DIMM2 DIMM3
Clock
G n rator
1
1 1
IDE2 IDE1 FDC1
COM2
CPUFAN1
I/O Controll r
Int l
ICH2
Li
Batt ry
J2 J3
SAPK RST PLED SLED
HDD/LED IR PWR SUSPEND
++
--
+-
1 15 1 15
CHAFA1
SCR1
AUXFA1
FWH
16
1
USB2
1 4
1 4
CD32
CD33
1 3
1 3
JP7
JP8
J1
1 3
1 3
1 3
JP16 JP17 JP18 JP19 JP20
JBAT1 JBAT2
JWOL1
AC'97
Cod c
RT2
LED1
1 3
JP2 JP3
1
14
AGP 4X
PCI 1
PCI 2
PCI 3
CNR 1
FDD Cabl
To 1st Floppy Drive To mainboard
To 2nd Floppy Drive
Floppy Disk Driv Conn ctor:
Orient the red line on the
floppy ribbon cable to Pin1.
red line
• To install FDD (Floppy Disk Drive), connect the end with single connector
to the mainboard, and connect other end with two connectors to the floppy
drives.
