SOLTEK SL-65EP User manual

The Soul Of Computer Technology
R
SL-65EP/65EP+ V1.0
USER MANUAL

USER NOTICE
Product Model : SL-65EP/65EP+
Manual Revision : V1.0
Release Date : Dece ber 2000
• Intel, Celeron, Pentium II, Pentium III are trademarks of Intel Corporation.
• Intel 8 815 Graphic Memory Controller Hub(GMCH), 8 801 I/O Controller Hub(ICH) are trade-
marks of Intel Corporation.
• VIA Cyrix III is trademark of VIA Corporation.
• Norton AntiVirus, Norton Ghost are trademarks of Symantec Corporation.
his Users Guide & Technical Reference is for assisting system
manufacturers and end-users in setting up and installing the
motherboard.
Every effort has been made to ensure that the information in this
manual is accurate. Soltek Computer Inc. is not responsible for print-
ing or clerical errors. Information in this document is subject to
change without notice and does not represent a commitment on the
part of Soltek Computer Inc.
No part of this manual may be reproduced, transmitted, translated
into any language in any form or by any means, electronic or
mechanical, including photocopying and recording, for any purpose
without the express written permission of Soltek Computer Inc.
Companies and products mentioned in this manual are for identifi-
cation purpose only. Product names appearing in this manual may
or may not be registered trademarks or copyrights of their respec-
tive companies.
Soltek computer inc. Provides this manual “As is “ without warranty
of any kind, either express or implied, including but not limited to
the implied warranties or conditions of merchantability or fitness for
a particular purpose. In no event shall Soltek computer inc. Be li-
able for any loss or profits, loss of business, loss of use or data,
interruption of business, or for indirect, special, incidental, or con-
sequential damages of any kind, even if Soltek computer inc. Has
been advised of the possibility of such damages arising from any
defect or error in this manual or product.
Copyright © 2000 So tek Computer Inc. A Rights Reserved.
T

SOLTEK AROUND THE WORLD
SOUL TECHNOLOGY EUROPE B.V.
Address : Sydneystraat 5 -54 3047 BP Rotterdam, the Nether-
lands
Telephone : [phone]
Fax : [phone]
E-mail : [email protected]
Web site : http://www.soultech-europe.com
SOLTEK KOREA INC.
Address : 100 , Chungjin Bldg. 53-5 Wonhyo-Ro, 3-Ka,
Yongsan-Ku Seoul 140-113, Korea
Telephone : 8 - -3 717400
Fax : 8 - -3 717405
E-mail : [email protected]
SOLTEK COMPUTER INC.
Address : 7F, No. 306-3, Ta-Tung Rd, Sec.1, Hsi-Chin, Taipei-
Hsien, Taiwan, R.O.C.
Telephone : 886- - 64 -9060
Fax : 886- - 64 -9065
E-mail : [email protected]
Web site : http://www.soltek.com.tw

4
65EP / 65EP+
C O N T E N T
CHAPTER 1
INTRODUCTION............................................................................ 7
1-1 ITEMLIST CHECKUP ............................................................................. 7
1- CPU ........................................................................................................ 7
1-3 CHIPSET ................................................................................................ 7
1-4 INTEGRATED SDRAM CONTROLLER ................................................. 7
1-5 BIOS ....................................................................................................... 8
1-6 FULL FEATURED ACCELERATED GRAPHICS PORTS(AGP)
CONTROLLER ....................................................................................... 8
1-7 MULTI-I/O FUNCTION ........................................................................... 8
1-8 EXTENSION SLOTS .............................................................................. 8
1-9 FORM FACTOR ..................................................................................... 9
1-10 SOUND CONTROLLER ....................................................................... 9
1-11 POWER MANAGEMENT ..................................................................... 9
1-1 HARDWARE MONITORING ................................................................ 9
1-13.1 MOTHERBOARD LAYOUT --- 65EP ............................................... 10
1-13. MOTHERBOARD LAYOUT --- 65EP+............................................. 11
1-14 CHIPSET SYSTEM BLOCK DIAGRAM ............................................. 1
1-15 MOTHERBOARD SPECIFICATION TABLE OF 65EP & 65EP+........ 13
CHAPTER 2
HARDWARE SETUP ................................................................... 15
-1 CPU INSTALLATION ............................................................................ 15
- CPU FREQUENCY .............................................................................. 16
-3 MEMORY INSTALLATION ................................................................... 17
-4 SUPPORTED SYSTEM BUS AND SYSTEM MEMORY BUS FREQUENCIES
TABLE ................................................................................................... 18
-5 ACCELERATED GRAPHICS PORT(AGP) PRO INSTALLATION ........ 19
-6 HDD/FDD INSTALLATION ................................................................... 0
-7 JUMPER DEFINITION ......................................................................... 1
-7.1 ONBOARD FAN (CPUFAN1/AUXFA1/CHAFA1) .............................. 1
-7. KEYBOARD POWER ON (JP1) ........................................................ 1
-7.3 BUS CLOCK SELECT (JP5/JP6) ......................................................
-7.4 USB PORT SELECT(1) (JP /JP8) ....................................................
-7.5 USB PORT SELECT( ) JP9/JP10) ...................................................
-7.6 USB WAKE UP FUNCTION (JP11) ...................................................

5
65EP / 65EP+
-7.7 ONBOARD CREATIVE SOUND SELECT (JP 1) ............................. 3
-7.8 CLEAR CMOS DATA (JBAT1/JBAT ) ............................................... 3
-7.9 BIOS BOOT BLOCK LOCK (JP16) ................................................... 3
-7.10 WAKE ON LAN(WOL) FUNCTION (JWOL1) .................................. 4
-7.11 CD-ROM AUDIO CONNECTOR (CD_IN1/CD_IN ) ........................ 4
-7.1 TAD1/TV1 CONNECTOR ................................................................ 4
-7.13 THERMAL SENSOR CONNECTOR (RT ) ..................................... 5
-8 CONNECTORS .................................................................................... 6
-8.1 J J3 ................................................................................................... 6
-8. CHASSIS PANEL CONNECTOR ...................................................... 9
-8.3 ATX POWER SUPPLY CONNECTOR .............................................. 30
-8.4 SERIAL PORT CONNECTOR ........................................................... 31
-8.5 SMART CARD RDADER CONNECTOR(SCR1) .............................. 3
-8.6 COMMUNICATION AND NETWORKING RISER SLOT (CNR) ........ 33
-8.7 SECOND USB CONNECTOR........................................................... 34
-8.8 PS/ MOUSE AND PS/ KEYBOARD .............................................. 34
-8.9 IRQ DESCRIPTION .......................................................................... 35
CHAPTER 3
SOFTWARE SETUP .................................................................... 36
3-1 ABOUT THE SUPPORT CD ................................................................. 36
3- INTEL CHIPSET DRIVER INSTALLATION .......................................... 36
3-3 INTEL ULTRA ATA STORAGE DRIVER INSTALLATION ..................... 38
3-4 AC’97 DRIVER INSTALLATION (FOR 65EP ONLY) ............................ 40
3-5 CREATIVE SOUND DRIVER INSTALLATION (FOR 65EP+ ONLY) .... 4
3-5.1 HOW TO ENABLE THE REAR LINE OUT (SECOND PAIR OF
SPEAKERS) ......................................................................................... 43
3-5. IDENTIFYING CONNECTORS ON THE BUILD-IN AUDIO .............. 45
3-6 INSTALLING ITE HARDWARE MONITOR UTILITY (SMARTGUARDIAM) . 46
CHAPTER 4
BIOS SETUP ............................................................................... 48
4-1 INTRODUCE THE BIOS ...................................................................... 48
4- WHAT IS BIOS SETUP ........................................................................ 48
4-3 HOW TO RUN BIOS SETUP ............................................................... 48
4-4 WHAT IS CMOS ................................................................................... 49

6
65EP / 65EP+
4-5 WHAT IS POST .................................................................................... 49
4-6 BIOS UPGRADE .................................................................................. 49
4-6.1 BEFORE UPGRADE BIOS ............................................................... 49
4-6. UPGRADE PROCESS ...................................................................... 50
4-7 CMOS SETUP UTILITY ....................................................................... 53
4-8 STANDARD CMOS SETUP ................................................................. 54
4-9 ADVANCED BIOS FEATURES ............................................................ 57
4-10 ADVANCED CHIPSET FEATURES ................................................... 6
4-11 INTEGRATED PERIPHERALS ........................................................... 66
4-1 POWER MANAGEMENT SETUP ...................................................... 71
4-13 PNP / PCI CONFIGURATION ............................................................ 76
4-14 PC HEALTH STATUS ......................................................................... 79
4-15 FREQUENCY/VOLTAGE CONTROL ................................................. 80
4-16 LOAD OPTIMIZED DEFAULTS .......................................................... 8
4-17 SET SUPERVISOR / USER PASSWORD ......................................... 83
4-18 SAVE & EXIT SETUP ......................................................................... 84
4-19 EXIT WITHOUT SAVING ................................................................... 84

7
65EP / 65EP+
CHAPTER 1
INTRODUCTION
1-1 ITEMLIST CHECKUP
• Motherboard
• Support CD
• User’s Manual
• Bundle Bonus Pack CD
• Bundle Bonus Pack Manual
• Temperature Sensor Cable
• ATA66/100 IDE Cable
• RS 3 Cable
• FDD Cable
1-2 CPU
• Supports Intel® FC-PGA Pentium !!!TM up to 1GHz or above.
• Supports Intel® FC-PGA 370 Celeron & PGA 370 Celeron up to 800MHz
or above.
• Supports VIA Cyrix !!! up to 733MHz or above.
• Supports CPU voltage Auto-Detect circuit.
1-3 CHIPSET
• INTEL 8 815EP Memory Controller Hub (MCH) & INTEL 8 801BA I/O
Controller Hub (ICH )
• ITE 871 EC-LPC I/O chip
1-4 INTEGRATED SDRAM CONTROLLER
• Provides 3pcs DIMM slots supporting double-sided DIMMs.
• Supports 100/133MHz SDRAM spec.
• Supports total memory from 3 MB to 51 MB using 3 Mb/64Mb/1 8Mb/
56Mb technology.
• Supports up to 3 double sided DIMMs at 100MHz system memory bus.
• Supports up to double sided or 3 single sided DIMMs at 133MHz sys-
tem memory bus.
• Unbuffered , Non-ECC SDRAM only supported.

8
65EP / 65EP+
1-5 BIOS
• Award BIOS 6.0
• Supports Plug & Play V1.0.
• FLASH MEMORY for easy upgrade.
• Supports BIOS writing protection.
• Year 000 compliant.
1-6 FULL FEATURED ACCELERATED GRAPHICS PORTS(AGP)
CONTROLLER
• Provides 1x/ x/ 4x AGP controller
• AGP v .0 compliant
1-7 MULTI-I/O FUNCTION
• Integrated IDE Controller:
Supports Ultra ATA100/66/33, BMIDE and PIO modes Universal Serial Bus
connector:
USB v1.1 compliant
Provides build-in USB ports (another internal USB ports for extensible purpose require an op-
tional USB connect cable).
• Two UARTs for Complete Serial Ports.
• One dedicated IR connector:
Third serial port dedicated to IR function either through the two complete serial ports or the third
dedicated port Infrared-IrDA (HPSIR) and ASK (Amplitude Shift Keyed) IR.
• Multi-mode parallel connector:
Standard mode, ECP and EPP support.
• Floppy Disk connector:
One FDDs with drive swap support.
• Universal Serial Bus connector:
USB V1.1 compliant.
Provides build-in USB ports (another internal USB ports for extensible purpose require an
optional USB connect cable).
• PS/ Keyboard connector.
• PS/ Mouse connector.
1-8 EXTENSION SLOTS
• Five PCI bus Mater slots.
• One AGP Pro 4x mode slot.
• One CNR slot.
• Three DIMM slots.
• One SCR (Smart Card Reader) slot.

9
65EP / 65EP+
1-9 FORM FACTOR
• Micro ATX form factor 4 layers PCB.
• Motherboard size: 0.0cm x 4.5cm
1-10 SOUND CONTROLLER
• Build-in AC’97 Audio codec (for 65EP only).
• Build-in creative CT5880 Audio chip (for 65EP+ only).
1-11 POWER MANAGEMENT
• ACPI 1.0 compliant (Advanced Configuration and Power Interface).
• APM V1. compliant (Legacy power management).
• Supports ACPI suspend STR mode (Suspend To DRAM) and POS mode (Power
On Suspend).
• System event monitoring with two event classes.
• Supports PS/ Keyboard & Mouse power on.
• Supports Wake On LAN (WOL) & Wake On Modem.
• Supports real time clock (RTC) with date alarm, month alarm, and century field.
• USB wake-up Function.
1-12 HARDWARE MONITORING
• Programmable control, status, monitor and alarm for flexible desktop manage-
ment (software included).
• 5-positive voltage.
• -temperature monitoring.
• 3 Fan-speed monitoring.

10
65EP / 65EP+
1-13.1 MOTHERBOARD LAYOUT --- 65EP
• Default Setting: Intel Celeron 300A/66 MHz
Using non-comp iant memory with higher bus c ock (over c ocking) may severe y
compromise the integrity of system.
C ock
Generator
LED1
AGP PRO
1 4
1 4
J2 J3
SPK RST KEYLOCK T/LED
HDD/LED IR PWR SUSPEND
++
--
+-
1 15 1 15
I/O
Contro er
FWH
Inte
ICH2
SOCKET 370
LPT1
COM1
GAME/MIDI PORT
LINE OUT
LINE IN
MIC
PS/2 MOUSE PS/2 K/B
upper
ower
USB1 USB0
upper
ower
Inte
815EP
MCH
Li
Battery
RT1
DIMM2 DIMM1 DIMM3
PCI 1
PCI 2
PCI 3
PCI 4
PCI 5
COM2
JWOL1
CD_IN1
CD_IN2
CNR
SCR1
IDE2 IDE1
FDC1
1 3
1 3
JP2
JP8
JP9
JP10
1 3
JP11
1 3
JP1
CPUFA1
ATX POWER
AUXFA1
1 11
1 3 1 3
JP5 JP6
CHAFA1 RT2
AC'97
Codec
1 3
1 3
1 3
JBAT1
JBAT2
JP16
USB1
1
16

11
65EP / 65EP+
1-13.2 MOTHERBOARD LAYOUT --- 65EP+
• Default Setting: Intel Celeron 300A/66 MHz
Using non-comp iant memory with higher bus c ock (over c ocking) may severe y
compromise the integrity of system.
C ock
Generator
LED1
AGP PRO
1 4
1 4
9 16
1 8
J2 J3
SPK RST KEYLOCK T/LED
HDD/LED IR PWR SUSPEND
++
--
+-
1 15 1 15
I/O
Contro er
FWH
Inte
ICH2
SOCKET 370
LPT1
COM1
GAME/MIDI PORT
LINE OUT
LINE IN
MIC
PS/2 MOUSE PS/2 K/B
upper
ower
USB1 USB0
upper
ower
Inte
815E
MCH
Li
Battery
CT5880
RT1
DIMM2 DIMM1 DIMM3
PCI 1
PCI 2
PCI 3
PCI 4
PCI 5
COM2
JWOL1
TAD1
TV1
CD_IN1
CD_IN2
JP21
1 3
CNR USB1 SCR1
IDE2 IDE1
FDC1
1 3
1 3
JP2
JP8
JP9
JP10
1 3
JP11
1 3
JP1
CPUFA1
ATX POWER
AUXFA1
1 11
1 3 1 3
JP5 JP6
CHAFA1 RT2
1 3
1 3
1 3
JBAT1
JBAT2
JP16

12
65EP / 65EP+
Intel 82815EP MCH Chipset Diagram
1-14 CHIPSET SYSTEM BLOCK DIAGRAM
System
Memory
PCI
Agent
Super
I/O
Keyboard
Mouse,FD,PP
SP,IR
Inte 82815EP Chipset
Digita Video Out
64bit 66/
100/133MHz
FWH
(Firmware Hub)
ICH2
(I/O Contro er Hub)
Inte 82815EP
(MCH)
-Memory Contro er
-AGP Contro er
PCI Bus
GPIO
System Bus (66/100/133MHz)
4 USB Ports
4 IDE Drivers
U tra DMA100/66/33 PCI S ots
Audio Codec(s)
LAN Connect
Inte Pentium III Processor
or
Inte Ce eron Processor
AGP Connector
Disp ay Cache
(4MB SDRAM,
133MHz)
AGP Graphics
AGP 2.0
AC'97 2.1
LPC I/F

13
65EP / 65EP+
1-15 MOTHERBOARD SPECIFICATION TABLE OF 65EP
& 65EP+
Mode 65EP
Memory
Contro er Hub Inte 82815EP (MCH)
Inte 82801BA (ICH2)
ITE 8712
I/O
Contro er Hub
LPC I/O Chip
AGP Interface AGP 4X Pro Mode
Creative CT5880
On-Chip AC'97
Memory Supports PC133 and PC100 SDRAM up to 512GB
3 DIMM S ots
Audio
IDE 2 x ATA 33/66/100
IDE ports
2 x ATA 33/66/100
IDE ports
I/O
Yes
Yes*
(Provides a Smart Card Reader connector)
Yes
Yes
4 x USB ports, 1 x FDD port, 2 x COM ports,
1 x LPT port, 1 IrDA, 1 PS/2 Mouse, 1 PS/2 K/B
PCI s ot 5 PCI Master S ots
CNR s ot 1 x CNR s ot
Hardware
Monitoring
Smart card
reader support
BIOS writing
Protection
Keyboard power
on function &
USB wake up
Function
Remark
65EP+

14
65EP / 65EP+
ATTENTION !!!
1. P ease refer to your processor insta ation or other
documentation attached with your CPU for detai ed
insta ing instruction.
2. Insta ing a heat sink and coo ing fan is necessary for
proper heat dissipation from your CPU. Uncorrected
insta ation may resu t in overheating and damage of
your CPU.
3. Before changing the setting of CPU Vcore from BIOS
program, user SHOULD make sure of correct specifi-
cation both of CPU CLOCK and RATIO. Uncorrected
setting may cause damage to your CPU.

15
65EP / 65EP+
CHAPTER 2
HARDWARE SETUP
2-1 CPU INSTALLATION
1. Pull the lever sidways away from the socket, and then raise the lever up
to a 90-degree angle.
. Take note of the red circle as below picture. When insert the CPU into
socket, you can find out there is a definite pin orientation for CPU and
socket.
SOCKET 370
SOCKET 370
WARNING !!!
Never run you processor without the heat sink properly and firmly attached.
PERMANET DAMAGE WILL RESULT!

16
65EP / 65EP+
SOCKET 370
2-2 CPU FREQUENCY
• The CPU’s “CPU CLOCK RATIO” and “CPU HOST/PCI CLOCK” set-
tings are automatica y detected to be defau t va ue by BIOS in the
“Frequency/Vo tage Contro ” section.
• We do not suggest and assume the responsibi ity for any action that
changes the CPU defau t setting such as overc ocking. Uncorrect
CLOCK RATIO and HOST/PCI CLOCK settings may cause damage
to your CPU.
3. Make sure that the CPU positions in the socket tightly, and then put the
lever down to complete the CPU installation.

17
65EP / 65EP+
C ock
Generator
LED1
SOCKET 370
LPT1
COM1
GAME/MIDI PORT
LINE OUT
LINE IN
MIC
PS/2 MOUSE PS/2 K/B
upper
ower
USB1 USB0
upper
ower
Inte
815EP
MCH
RT1
D
IMM2
D
IMM1
D
IMM3
2 1
FDC1
1 3
1 3
JP2
JP8
JP9
JP10
1 3
JP11
1 3
JP1
CPUFA1
ATX POWER
AUXFA1
1
1 3 1 3
JP5 JP6
NOTICE : When LED1 light is on ,
meaning that 3.3V is conducting DIMM
slots , please do not add or remove
memory modules .
Removing:
• Press the holding clips on both sides of socket out ward to release the
DIMM, Gintly pull the DIMM out of the socket.
2-3 MEMORY INSTALLATION
168-Pin DIMM Notch Key Definitions(3.3V)
DRAM Key Position Vo tage Key Position
Unbuffered 3.3V
WARING !!!
• Make sure that you unplug your power supply when adding or removing
memory modules or other system components, failure to do so may cause
severe damage to both your motherboard and expansion cards.
• Be careful when inserting or removing DIMM, forcing a DIMM in or out of a
socket can be damaged the memory module or the socket. Some of DIMMs
contain EDO or FPM DRAM. These DIMM types are incompliant with the
motherboard, the M/B only supports 3.3V Non-ECC SDRAM DIMMs.
Insta ing DIMM:
• Make sure you have the correct memory module type for your motherboard
• Insert the mdule(s) as shown, DIMMs have 168-pins and two notches that
will match with the onboard DIMM socket, memory modules are installed by
inserting them straight into the slot until they “click” into place. They only fit
in one direction so do not force them into place.

18
65EP / 65EP+
2-4 SUPPORTED SYSTEM BUS AND SYSTEM MEMORY
BUS FREQUENCIES TABLE
• The 8 815EP MCH has a new type of clocking architecture. It has inte-
grated SDRAM buffers that run at either 100 or 133 MHz, independent of
the system bus frequency. See table below for supported system bus and
system memory bus frequencies.
Front Side Bus
Frequency
System Memory
Bus Frequency
AGP Bus
Frequency
PCI Bus
Frequency
Supported
Maximum DIMM
numbers
66MHz 66MHz 33MHz 3sing e sides DIMMs
3sing e sides DIMMs
2 doub ed sides or 3
sing e sides DIMMs
2 doub ed sides or 3
sing e sides DIMMs
33MHz
33MHz
33MHz
66MHz
66MHz
66MHz
100MHz 100MHz
100MHz
100MHz
133MHz
133MHz 133MHz

19
65EP / 65EP+
AGP Acce erator
AGP Pro s ot
blockader
Acce erated Graphics Port (AGP) Pro S ot
Rib(inside slot)
0-pin bay Rib(inside slot) 8-pin bay
2-5 ACCELERATED GRAPHICS PORT(AGP) PRO INSTALLATION
• The AGP Pro s ot is an extension of the existing AGP s ot and it
accepts exiting AGP Card.
CAUTION!!
The AGP Pro s ot is shipped with a warning abe over the 20-pin bay.Do not remove
this ab e and the safety tab underneath it if you wi be using an AGP card without
a retention notch.Removing may cause the card to shift and may cause damage to
your card , s ot , and motherboard. Remove ONLY when you wi be using an AGP
Pro card.

20
65EP / 65EP+
C ock
Generator
LED1
AGP PRO
1 4
1 4
J2 J3
SPK RST KEYLOCK T/LED
HDD/LED IR PWR SUSPEND
++
--
+-
1 15 1 15
I/O
Contro er
FWH
Inte
ICH2
SOCKET 370
LPT1
COM1
GAME/MIDI PORT
LINE OUT
LINE IN
MIC
PS/2 MOUSE PS/2 K/B
upper
ower
USB1 USB0
upper
ower
Inte
815EP
MCH
Li
Battery
RT1
DIMM2 DIMM1 DIMM3
PCI 1
PCI 2
PCI 3
PCI 4
PCI 5
COM2
JWOL1
CD_IN1
CD_IN2
CNR
SCR1
IDE2 IDE1
FDC1
1 3
1 3
JP2
JP8
JP9
JP10
1 3
JP11
1 3
JP1
CPUFA1
ATX POWER
AUXFA1
1 11
1 3 1 3
JP5 JP6
CHAFA1 RT2
AC'97
Codec
1 3
1 3
1 3
JBAT1
JBAT2
JP16
USB1
1
16
2-6 HDD/FDD INSTALLATION
• To insta HDD (Hard Disk Drive), you may connect the cab e’s b ue
connector to the motherboard’s primary (IDE1) or secondary IDE
connector, and then connect the gray connector to your s ave de-
vice and the b ack connector to your master device.If you insta two
hard disks , you must configure the second drive to S ave mode by
setting its jumper according y.P ease refer to your hard disk docu-
mentation for the jumper settings.
• To insta FDD (F oppy Disk Drive), you may connect the sing e end
to the board , and connect two p ugs on the other end to the f oopy
drives.
F oppy Disk Drive Connector:
Orient the red markings on
the f oppy ribbon cab e to
Pin1.
Hard Disk Drive Connector:
Orient the red markings on
the IDE ribbon cab e to Pin1.
