SOLTEK 86SP2 User manual

4
Contents
Contents
Item Checkup ........................................................ 7
Chapter 1 Specification ............................................. 8
1-1 Mainboard Layout ...................................................................9
1-2 Mainboard Specifications .................................................... 10
1-2.1 CPU Socket ................................................................................... 10
1-2.2 System Chipsets ........................................................................... 10
1-2.3 Memory ......................................................................................... 10
1-2.4 Advanced System Power Management .................................... 10
1-2.5 Accelerated Graphics Port (AGP) Interface........................... 11
1-2.6 AMI BIOS ..................................................................................... 11
1-2.7 Multi-I/O Functions :.................................................................. 11
1-2.8 Expansion Slots ............................................................................ 12
1-2.9 LAN on board (for 86SP2-L only) ............................................ 12
1-2.10 Hardware Monitor on board ................................................... 12
1-2.11 AC’97 Audio Codec on board ................................................. 12
1-2.12 Form Factor................................................................................ 12
1-3 Mainboard Specification Table ........................................... 13
1-4 Chipset System Block Diagram........................................... 14
Chapter 2 Hardware Setup ..................................... 16
2-1 CPU Installation with Socket 478B .................................... 17
2-1.1 To Identify a Pentium 4 CPU..................................................... 17
2-1.2 CPU Installation with Socket 478B .......................................... 18
2-2 Pentium 4 CPU Fan Installation: ....................................... 19
2-3 Memory Installation ............................................................. 20
2-3.1 To Install DDR SDRAM Module .............................................. 21

5
Contents
2-3.2 To Remove a DIMM .................................................................... 21
2-4 AGP 8X/4X Slot Installation ................................................ 22
2-5 IDE Connectors Installation................................................ 23
2-6 Serial ATA Connectors Installation .................................... 24
2-7 Floppy Drive Connector Installation ................................. 25
2-8 ATX V2.03 Power Supply Installation ............................... 26
2-9 Jumper Settings ..................................................................... 27
2-9.1 JFSB1 & JFSB2: CPU Frequency Select................................. 28
2-9.2 JBAT1: Clear CMOS .................................................................. 29
2-9.3 LJP1: LAN Controller Select (86SP2-L only) ........................ 30
2-9.4 JKB1: KB / Mouse Power On / Wake Up ................................ 30
2-10 Other Connectors Configuration...................................... 31
2-10.1 On Board Fan Connectors ....................................................... 31
2-10.2 USB Ports and USB Pin-headers ............................................ 32
2-10.3 Chassis Panel Connectors ........................................................ 33
2-10.4 CD-ROM Audio Connectors.................................................... 33
2-10.5 PS/2 Mouse And PS/2 Keyboard............................................. 34
2-10.6 Front Panel Audio Connector ................................................ 34
2-10.7 LAN Connector (86SP2-L Only) ............................................. 35
2-10.8 Thermal Resistor ....................................................................... 35
2-10.9 Complex Pin-header.................................................................. 36
Chapter 3 Software Setup ....................................... 38
3-1 To Open up the Support CD ................................................ 39
3-2 Intel Chipset Software Installation Utility........................ 40
3-3 AC’97 Audio Driver Installation......................................... 41
3-3.1 Install AC’97 6-channel Audio Driver ..................................... 41
3-3.2 Verify 6-channel Audio ............................................................... 42
3-4 To Install Hardware Monitor Utility.................................. 45
3-4.1 Installation ................................................................................... 45
3-4.2 Verification .................................................................................. 46
3-5 To Install LAN Drivers (for 86SP2-L only)....................... 47

6
Contents
3-5.1 RTL8101L LAN driver on Windows ME / 2000 / XP ............ 47
3-5.2 RTL8101L LAN driver on Windows 9X .................................. 47
3-6 To Install USB 2.0 Driver for Windows 2000/XP ............. 49
Chapter 4 AMI BIOS Setup.................................... 50
4-1 About BIOS Setup ................................................................. 51
4-2 To Run BIOS Setup ............................................................... 51
4-3 About CMOS .......................................................................... 51
4-4 The POST ( Power On Self Test ) ....................................... 51
4-5 To Update BIOS ..................................................................... 52
4-6 BIOS SETUP --- CMOS Setup Utility................................ 54
4-6.1 CMOS Setup Utility .................................................................... 54
4-6.2 Standard BIOS Features ............................................................ 55
4-6.3 Advanced BIOS Features ........................................................... 57
4-6.3.1 CPU Configuration................................................................... 58
4-6.3.2 IDE Configuration.................................................................... 59
4-6.3.3 Floppy Configuration ............................................................... 63
4-6.3.4 Super IO Configuration ........................................................... 64
4-6.3.5 Hardware Health Configuration............................................. 66
4-6.3.6 ACPI Configuration ................................................................. 67
4-6.3.7 USB Configuration ................................................................... 69
4-6.3.8 Frequency/Voltage Control ...................................................... 71
4-6.3.9 Power Management .................................................................. 72
4-6.4 Advanced Chipset Features ....................................................... 74
4-6.4.1 NorthBridge Configuration ..................................................... 75
4-6.4.2 SouthBridge Configuration ..................................................... 77
4-6.5 PCI/PNP Resource Management .............................................. 78
4-6.6 Boot Configuration Setup .......................................................... 80
4-6.6.1 Boot Settings Configuration .................................................... 81
4-6.6.2 Boot Device Priority ................................................................. 82
4-6.7 Boot Security Features ............................................................... 83
4-6.7.1 Supervisor Password ................................................................ 83

7
Contents
Item Checkup
4-6.7.2 User Password........................................................................... 83
4-6.7.3 Change Supervisor Password .................................................. 84
4-6.7.4 Change User Password ............................................................ 85
4-6.7.5 Clear User Password ................................................................ 85
4-6.7.6 Boot Sector Virus Protection ................................................... 86
4-6.8 Save Changes and Exit ............................................................... 86
4-6.9 Discard Changes ( and Exit )..................................................... 87
4-6.10 Load Optimal Defaults ............................................................. 87
4-6.11 Discard Changes ........................................................................ 87
APPENDICES.......................................................... 88
Appendix-1 Identify Mainboard Model Number ................... 89
Appendix-2 Technical Terms ...................................................... 90
• Mainboard
• Multi-lingual Quick Installation Guide
• User Manual (Mainboard)
• Support CD
• Bundled Bonus Pack CD
• Bundled Bonus Pack Manual
• Cable :
ATA66/100 IDE Cable
2 x Serial ATA Cable
FDD Cable
USB Cable (Optional)

8
86SP2 / 86SP2-L
Topics included in this chapter are:
1-1 Mainboard Layout
1-2 Mainboard Specifications**
1-3 Mainboard Specification Table
1-4 Chipset Diagram
Introduction
Chapter 1 Specification
This series of mainboards features an integration of the powerful pro-
cessor Intel Pentium 4 and the single-chip North Bridge Intel
SPRINGDALE-P. The Intel P4 processor is a rapid execution engine
providing 800/533/400MHz system bus, while North Bridge Intel
SPRINGDALE-P is a high performance integrated chipset providing Dual
Channel DDR 333/266 SDRAM memory interface, Hub interface as well
as AGP interface.
Integrated with SPRINGDALE-P, South Bridge Intel ICH5 supports
the LPC I/O, upstream Hub interface, PCI interface, IDE interface, Serial
ATA interface, USB 2.0 interface, AC’97 2.2 (6-channel) Audio interface
and the interrupt control. This chapter is to introduce to users every
advanced function of this high performance integration.
** If any difference is found between the mainboard description
and the Mainboard you are using, please look up the Errata/
Update Slip enclosed inside for the correction or updated
information, or else contact the mainboard Dealer or visit our
Web Site for the latest manual update.

9
Chapter 1 Specification
BIOS
mPGA478B
1
USB3
1
USB2
1
Fan1
+12V Power
AGP 8X/4X
1
IDE1IDE2
1
SPRINGDALE
Intel
ICH5
Intel
Dual Channel DDR 333/266MHz
ATA2
DIMM1
DIMM2
PCI 1
PCI 2
PCI 3
PCI 4
PCI 5
LPT1
COM1
COM2
PS/2 K/B (underside)
PS/2 Mouse
USB1 (underside)
USB0
FD1
1
Main
RTL
Winbond
W83627HF
Fan3
1
JBAT1
1
JKB1
RT2
CD-IN1
1
1
JFSB2
Intel 82865
P
(on top)
650
8101L
JAUD1
Battery
Li
ATA1
Power
HDD IR PWR
1
20
SPK RST
+
-
+
-
PWLED
NJ1
LED
ALC
Fan4
JFSB1
RJ45
(on top)
(middle)
Linein
(ontop)
Mic (underside)
LineOut
(middle)
USB3 (underside)
USB2 (middle)
Fan2
1
LJP1
1-1 Mainboard Layout
for 86SP2-L only
RJ45
LAN Controller
LJP1 }

10
86SP2 / 86SP2-L
1-2.4 Advanced System Power Management
• ACPI 1.0B compliant (Advanced Configuration and Power Interface),
including ACPI suspend mode support (See ACPI Configuration of
Advanced BIOS Features in BIOS Setup)
• APM V1.2 compliant (Legacy Power Management)
• Keyboard / Mouse Power On/Wake Up(See ACPI Configuration of
Advanced BIOS features in BIOS Setup)
• Supporting Wake-on-LAN
• Real Time Clock (RTC) with date alarm, month alarm, and century
field
1-2 Mainboard Specifications
1-2.1 CPU Socket
CPU Socket 478B on board, supporting Intel®Pentium 4 processors
(including Intel Hyper-Threading CPUs) in 478-pin package for :
-- 800/533/400MHz System Bus;
-- Hyper-pipelined technology;
-- Advanced dynamic execution;
-- Advanced transfer cache;
1-2.2 System Chipsets
North Bridge Intel SPRINGDALE-PE:
• Supporting 533/400MHz Front Side Bus officially
• Supporting 800MHz Front Side Bus by jumper setting
• A high performance integrated chipset providing processor interface
(including Hyper-Threading Technology), Dual channel DDR 333/266
SDRAM memory interface, Hub interface, AGP interface.
• Showing Hyper-Threading Logo when booting with a Hyper-thread-
ing CPU.
South Bridge Intel ICH5:
• Supporting the LPC I/O, upstream Hub interface, PCI interface, IDE
interface, Serial ATA interface, USB 2.0 interface, AC’97 2.2 (6-
channel) Audio interface and the interrupt control.
1-2.3 Memory
2 DDR DIMM 184-pin slots on board :
• Supporting unregistered, non-ECC Dual-channel DDR 333/266
SDRAM up to 2GBs
• DIMMs to be populated in identical pairs for Dual-channel operation
• SPD (Serial Presence Detect) Scheme for DIMM Detection supported

11
Chapter 1 Specification
1-2.7 Multi-I/O Functions :
• Serial ATA Controller integrated in ICH5, supporting:
-- 2x Serial ATA connectors supporting up to 150MByte/s transfer rate
• PCI EIDE Controller, supporting:
-- 2x UATA100/66/33 IDE connectors supporting up to 4 IDE devices
• Dedicated IR Functions:
-- Third serial port dedicated to IR function either through the two
complete serial ports or the third dedicated port Infrared-IrDA (HPSIR)
and ASK (Amplitude Shift Keyed) IR
• Multi-mode Parallel Data Transfer:
-- Standard mode, high speed mode ECP and enhanced mode EPP
• Floppy Disk Connector:
-- One FDD connector supporting 2 floppy drives with drive swap support
• Universal Serial Bus Transfer Mode:
-- USB V2.0 compliant; 480Mb/s USB Bus, supporting Windows 2000 or
later operating system (no support for Windows 9X/ME)
-- 4 built-in USB connectors and 2 USB Headers which require 2 additional
USB cables to provide 4 more optional USB ports
• PS/2 Keyboard and PS/2 Mouse
• UARTs (Universal Asynchronous Receiver / Transmitter):
-- Two serial ports (COM1 & COM2) on board
1-2.5 Accelerated Graphics Port (AGP) Interface
AGP Controller embedded on board, supporting:
• 1.5V (4x/8x) power mode only
• 8x 66MHz AD and SBA signalling, AGP pipelined split-transection
longburst transfers up to 2GB/sec
• AGP 8X/4X supported, AGP V3.0 compliant
1-2.6 AMI BIOS
Flash Memory for easy upgrade, supporting BIOS Writing Protection,
Year 2000 compliant, and supporting various hardware configuration
during booting system (See Chapter 4 BIOS Setup):
• Standard BIOS Features(Times, Date, System Information etc.)
• Advanced BIOS Features (CPU,IDE, Floppy, SuperIO, Hardware
Health, ACPI, USB, and Frequency/Voltage Control)
• Advanced Chipset Features (NorthBridge, SouthBridge Configuration)
• PCI/PNP Resource Management (IRQ Settings, Latency Timers etc.)
• Boot Configuration Setup (Boot Settings, Boot Device Priority etc.)
• BIOS Security Features (Supervisor Password, User Password)

12
86SP2 / 86SP2-L
1-2.11 AC’97 Audio Codec on board
AC’97 Audio Codec 2.2 compliant on board
• Supporting 6-channel display of PCM audio output
• 6 channel audio consists of Front Left, Front Right, Back Left, Back
Right, Center and Subwoofer for complete surround sound effect
• AC’97 Audio Codec Driver enclosed in Support CD for user’s
installation.
1-2.9 LAN on board (for 86SP2-L only)
PCI local bus single-chip Fast Ethernet Controller RTL8101L on board:
• Supporting 10/100Mb data transfer
• Supporting Wake On LAN function through the on-board RJ45 LAN
Connector
• LAN Driver enclosed in Support CD for user’s installation.
1-2.10 Hardware Monitor on board
• Hardware Monitor supported by W83627HF, providing monitoring and
alarm for flexible desktop management of hardware voltage, tempera-
tures and fan speeds.
• Utility Software Soltek Hardware Monitor for displaying system status
is enclosed in Support CD for user’s installation.
1-2.12 Form Factor
• ATX Form Factor, ATX Power Supply, version 2.03 compliant, sup-
ported by one Main Power Connector, one +12V Power Connector.
• Mainboard size: 305mm x 210mm
1-2.8 Expansion Slots
• 5 PCI Bus Master slots
• 1 AGP slot
• 2 DDR SDRAM DIMM slots

13
Chapter 1 Specification
1-3 Mainboard Specification Table
CPU
North Bridge
South Bridge
BIOS
Memory
I/O Chip
AGP interface
Audio
IDE Interface
SATA Interface
PCI Slots
I/O Connectors
Networking
Other common
features
Socket 478B for P4 CPU( HT CPU included)
Intel SPRINGDALE-P,supporting 533/400MHz
FSB
Intel ICH5
AMI BIOS
Supporting Dual-channel DDR 333/266 SDRAM,
up to 2GB in 2 DIMM slots
W83627HF, with Hardware Monitor
AGP8X/4X Mode only; 1 AGP Slot on board
AC’97 Audio 2.2 compliant, 6 channel audio
2 UATA 66/100 IDE ports
2 Serial ATA connectors
5 PCI Master slots on board
8 USB V2.0, 1 FDD port, 2 COM ports, 1 LPT,
1 IrDA, 1 PS/2 K/B, 1 PS/2 Mouse
LAN Controller RTL8101L and Connector RJ45
(for 86SP2-L only)
PS/2 Keyboard/Mouse Power On / Wake Up
ATX 2.03 Power Supply
ATX Form Factor
86SP2/86SP2-L Specifications and Features
86SP2 86SP2-L
No Yes
LAN Controller
on board
Optional
Features
Models

14
86SP2 / 86SP2-L
Pentium 4 + Intel SPRINGDALE-P + Intel ICH5 Diagram
System Bus 533/400MHz
SPRINGDALE-P
ICH5
PCI Bus
AC’97 2.2
ATA 100/66/33
2 IDE
Connectors
USB Bus V2.0
USB
Ports
5 PCI Slots
Audio Codec
(6-channel)
RTL8101L RJ45
(Optional)
IR
FDD
Mouse/Keyboard
Serial Ports
Printer Port
Game/MIDI
H/Monitor
BIOS
LPC I/O
W83627HF
1-4 Chipset System Block Diagram
System
Memory
DDR memory
Interface
DDR 333/
266 SDRAM
Intel
North Bridge
2 SATA ports Serial ATA
AGP Slot AGP 8X/4X
Intel Pentium 4 CPU
(Hyper-Threading Included)
266MB/s
Hub Interface
South
Bridge
Intel

16
86SP2 / 86SP2-L
Chapter 2 Hardware Setup
1. We recommend to install your CPU before any other components.
For detailed installation instructions of processor, you can also refer
to the pamphlet enclosed in your CPU package.
2. Installing a cooling fan with a good heat sink is a must for proper
heat dissipation for your CPU. Get ready an appropriate fan with
heat sink for proper installation. Improper fan and installation will
damage your CPU.
3. In case CPU Vcore, CPU clock or Frequency Ratio is adjustable on
board, please follow the instructions described in the User’s manual
for proper setup. Incorrect setting will cause damage to your CPU.
The following topics are included in this chapter:
To Get Things Ready for Hardware Setup !
2-1 CPU Installation with Socket 478B
2-2 Pentium 4 CPU Fan Installation
2-3 Memory Installation
2-4 AGP 8X/4X Slot Installation
2-5 IDE Connectors Installation
2-6 Serial ATA Connectors Installation
2-7 Floppy Drive Connector Installation
2-8 ATX V2.03 Power Supply Installation
2-9 Jumper Settings
2-10 Other Connectors Configuration

17
Chapter 2 Hardware Setup
2-1 CPU Installation with Socket 478B
2-1.1 To Identify a Pentium 4 CPU
1) CPU Working Frequency
4) CPU Voltage Vcore
On the heatsink side of a Pentium 4 CPU, there printed a line of figures
to identify its specifications. The line consists of 4 parts:
1. CPU Working Frequency: this part depicts the working frequency of
the CPU. For example,
2.4 GHz depicts that this CPU is locked to 2.4 GHz working frequency
(18 x 133MHz CPU clock);
2A GHz depicts that this CPU is an A version, locked to 2.0 GHz
working frequency (20 x 100MHz CPU clock)
3.06GHz depicts that this is a 3.06GHz hyper-threading CPU
2. CPU L2 Cache: this part depicts the L2 Cache size. For example,
512 stands for 512 KB L2 Cache; 256 stands for 256 KB L2 Cache
3. System Clock: this part depicts the System Clock (Front Side Bus)
provided by the CPU. For example,
533 stands for a 533MHz system clock provided by a 133MHz CPU
times 4;
400 stands for a 400 system clock provided by a 100 MHz CPU x 4.
4. CPU Voltage Vcore: this part depicts the CPU Voltage. For example,
1.5V stands for a CPU of 1.5V Vcore.
Note: System Clock vs CPU Clock
P4 CPU is a quadpumped CPU. The system bus is provided by
the CPU clock x 4. Therefore, users can figure out the P4 CPU
clock by the System Clock divided by 4.
(Hyper-Threading CPU included)
Intel
pentium 4
2.4 GHz / 512 / 533 / 1.5V
2) CPU L2 Cache
3) System Clock

18
86SP2 / 86SP2-L
mPGA478B
Intel Pentium 4
mPGA478B
Pin 1
2-1.2 CPU Installation with Socket 478B
This mainboard is built with CPU
Socket 478B ( 478-pin) supporting
the Intel Pentium 4 CPU:
• Follow the steps described in this
section to install the 478-pin Pen-
tium 4 CPU into the on board
Socket 478.
• After installation of Pentium 4 CPU,
you must also install the specific
Pentium 4 CPU fan designed in
tandem with this CPU. This CPU
Fan installation is described in next
section.
• This mainboard supports Hyper-
threading dual-in-one CPU, the
function of which can be enabled
by Windows XP. (See illustration
on the right.)
1. First pull sideways the lever of
Socket 478, and then turn it up
900so as to raise the upper layer
of the socket from the lower
platform.
3. Make sure that all CPU pins have
completely entered the socket
and then lower down the lever
to lock up CPU to socket.
2. Configure Pin 1 of CPU to Pin 1
of the Socket, just as the way
shown in the diagram on the
right. Adjust the position of CPU
until you can feel all CPU pins
get into the socket with ease.
mPGA478B
Intel Pentium4
Pin 1
( If Hyper-threading CPU is
installed successfully with O/S
Win XP, the O/S will enable the
dual-in-one CPU function.)

19
Chapter 2 Hardware Setup
2-2 Pentium 4 CPU Fan Installation:
The above pictures are taken from sample mainboards as installation illustr-
ation. The layout in the pictures may be different from your mainboard.
1.Press down 4 latches.
CPU Fan Connector Pentium 4 Fanbase
3.Connect Fan Connector to CPU FAN connector
2.Press down the 2 levers to lock fan to fanbase

20
86SP2 / 86SP2-L
BIOS
mPGA478B
1
USB3
1
USB2
1
Fan1
+12V Power
AGP 8X/4X
1
IDE1IDE2
1
SPRINGDALE
Intel
ICH5
Intel
Dual Channel DDR 333/266MHz
ATA2
DIMM1
DIMM2
PCI 1
PCI 2
PCI 3
PCI 4
PCI 5
LPT1
COM1
COM2
PS/2 K/B (underside)
PS/2 Mouse
USB1 (underside)
USB0
FD1
1
Main
RTL
Winbond
W83627HF
Fan3
1
JBAT1
1
JKB1
RT2
CD-IN1
1
1
JFSB2
Intel82865
P
(on top)
650
8101L
JAUD1
Battery
Li
ATA1
Power
HDD IR PWR
1
20
SPK RST
+
-
+
-
PWLED
NJ1
LED
ALC
Fan4
JFSB1
RJ45
(on top)
(middle)
Linein
(ontop)
Mic (underside)
LineOut
(middle)
USB3 (underside)
USB2 (middle)
Fan2
1
LJP1
2-3 Memory Installation
How to tackle the memory Modules:
• Make sure to unplug your power supply before adding or removing
memory module.
• Pay attention to the orientation of the DIMM slots.
• Dual Channel Memory Configuration is formed by couple of identical
DDR SDRAMs.
• Dual Channel memory configuration provides higher performance than
Single Channel configurations.
• Matched DIMMs need to have identical density, DRAM technology,
DRAM bus width, and equal number of memory banks.
• This series supports up to 2GB unbuffered Dual-channel DDR 333/
266 SDRAM, with 2 DDR DIMM slots on board. Do not insert other
type of modules into these slots.
• The dual memory controller can double the DDR memory bandwidth
up to 5.4GB/s with couple of DDR333 and 4.2GB/s with couple of
DDR266.
Dual Channel Memory Features
DDR DIMM Slots
(184-pin)

21
Chapter 2 Hardware Setup
2-3.2 To Remove a DIMM
Power off the system first, and then press down the holding latches on
both sides of slot to release the module from the DIMM slot.
2-3.1 To Install DDR SDRAM Module
DDR Rib
(2.5V Voltage Key)DDR Notch
184-Pin DIMM Notch Key Definition
DIMM1
DIMM2
DIMM1+DIMM2 = Dual Channel Memory
• To enable Dual-channel memory function, users should insert totally
identical (size and frequency) DDR module pair into the bank-pair.
• DDR DIMM slot has 184 pins and one notch. Insert a DDR SDRAM
vertically into the 184-pin slot with the notch-to-rib matching.
DRAM Key Position Voltage Key Position
Module Latch

22
86SP2 / 86SP2-L
2-4 AGP 8X/4X Slot Installation
BIOS
mPGA478B
1
USB3
1
USB2
1
Fan1
+12V Power
AGP 8X/4X
1
IDE1IDE2
1
SPRINGDALE
Intel
ICH5
Intel
Dual Channel DDR 333/266MHz
ATA2
DIMM1
DIMM2
PCI 1
PCI 2
PCI 3
PCI 4
PCI 5
LPT1
COM1
COM2
PS/2 K/B (underside)
PS/2 Mouse
USB1 (underside)
USB0
FD1
1
Main
RTL
Winbond
W83627HF
Fan3
1
JBAT1
1
JKB1
RT2
CD-IN1
1
1
JFSB2
Intel82865
P
(on top)
650
8101L
JAUD1
Battery
Li
ATA1
Power
HDD IR PWR
1
20
SPK RST
+
-
+
-
PWLED
NJ1
LED
ALC
Fan4
JFSB1
RJ45
(on top)
(middle)
Linein
(ontop)
Mic (underside)
LineOut
(middle)
USB3 (underside)
USB2 (middle)
Fan2
1
LJP1
AGP Accelerator
notch
AGP 8X/4X Slot
The AGP slot on board supports 1.5V AGP 8X/4X card only. A Rib is
specifically added to the 8X/4X slot so as to match the AGP 8X/4X card.
To insert a 3.3V AGP 2X card into the AGP 4X slot will damage the
system chip and burn the 1.5V circuitry.
An AGP 8X card will support a data transfer rate up to 2GB/sec, while
an AGP 4X card will provide 1GB/sec transfer rate.

23
Chapter 2 Hardware Setup
BIOS
mPGA478B
1
USB3
1
USB2
1
Fan1
+12V Power
AGP 8X/4X
1
IDE1IDE2
1
SPRINGDALE
Intel
ICH5
Intel
Dual Channel DDR 333/266MHz
ATA2
DIMM1
DIMM2
PCI 1
PCI 2
PCI 3
PCI 4
PCI 5
LPT1
COM1
COM2
PS/2 K/B (underside)
PS/2 Mouse
USB1 (underside)
USB0
FD1
1
Main
RTL
Winbond
W83627HF
Fan3
1
JBAT1
1
JKB1
RT2
CD-IN1
1
1
JFSB2
Intel82865
P
(on top)
650
8101L
JAUD1
Battery
Li
ATA1
Power
HDD IR PWR
1
20
SPK RST
+
-
+
-
PWLED
NJ1
LED
ALC
Fan4
JFSB1
RJ45
(on top)
(middle)
Linein
(ontop)
Mic (underside)
LineOut
(middle)
USB3 (underside)
USB2 (middle)
Fan2
1
LJP1
2-5 IDE Connectors Installation
To install IDE Connector, you may connect the blue connector of IDE
cable to the primary (IDE1) or secondary (IDE2) connector on board,
and then connect the gray connector to your slave device and the black
connector to your master device. If you install two hard disks, you must
configure the second drive to Slave mode by setting its jumpers correctly.
Please refer to your hard disk documentation for the jumper settings.
Orient the red line on the IDE
Flat Cable to Pin1.
Pin 1 (to Red Line)
Hard Disk Drive Connector
IDE1
IDE2
Gray connector
Blue connector
Black connector
Red line
(To Mainboard)
(To Slave device)
(To Master Device)
IDE Flat Cable
80-conductor
cable

24
86SP2 / 86SP2-L
BIOS
mPGA478B
1
USB3
1
USB2
1
Fan1
+12V Power
AGP 8X/4X
1
IDE1IDE2
1
SPRINGDALE
Intel
ICH5
Intel
Dual Channel DDR 333/266MHz
ATA2
DIMM1
DIMM2
PCI 1
PCI 2
PCI 3
PCI 4
PCI 5
LPT1
COM1
COM2
PS/2 K/B (underside)
PS/2 Mouse
USB1 (underside)
USB0
FD1
1
Main
RTL
Winbond
W83627HF
Fan3
1
JBAT1
1
JKB1
RT2
CD-IN1
1
1
JFSB2
Intel82865
P
(on top)
650
8101L
JAUD1
Battery
Li
ATA1
Power
HDD IR PWR
1
20
SPK RST
+
-
+
-
PWLED
NJ1
LED
ALC
Fan4
JFSB1
RJ45
(on top)
(middle)
Linein
(ontop)
Mic (underside)
LineOut
(middle)
USB3 (underside)
USB2 (middle)
Fan2
1
LJP1
2-6 Serial ATA Connectors Installation
The Serial ATA is designed to improve the Parallel ATA with the capabil-
ity of Hot Plug and offer a data bandwidth of 150Mbytes/second. It also
reduce voltage and pin count and can be implemented with thin cables
which improve the inner ventilaton of PC cases.
2 Serial ATA connectors are built on board, supported by the SATA Con-
troller for SATA Hard Disk Drives.
Serial ATA Connector ATA1 and ATA2
Serial ATA Hard Disk
Serial ATA Cable
