SOLTEK SL-85DIV User manual

R
The Soul Of Computer Technology
Mainboard
SL-85DIV / 85DIV-L
User Manual V1.2

85DIV / 85DIV-L
2
NOTICE Product Model : SL-85DIV / 85DIV-L
Manual Re ision : V1.2
Release Date : April 2002
his Users Guide & Technical Reference is to help system manu-
facturers and end-users set up and install the mainboard.
Every effort has been made to ensure that the information in this
manual is accurate. Soltek Computer nc. is not responsible for print-
ing or clerical errors. nformation in this document is subject to
change without notice and does not represent a commitment on
Soltek Computer nc.
No part of this manual may be reproduced, transmitted, translated
into any language in any form or by any means, electronic or
mechanical, including photocopying and recording, for any purpose
without the express written permission of Soltek Computer nc.
Companies and products mentioned in this manual are for identifi-
cation purpose only. Product names appearing in this manual may
or may not be registered trademarks or copyrights of their respec-
tive companies.
Soltek Computer nc. provides this manual “as is “ without warranty
of any kind, either express or implied, including but not limited to the
implied warranties or conditions of merchantability or fitness for a
particular purpose. n no event shall Soltek Computer nc. be liable
for any loss or profits, loss of business, loss of use or data, interruption of
business, or for indirect, special, incidental, or consequential damages of
any kind, even if Soltek Computer nc. has been advised of the possibility
of such damages arising from any defect or error in this manual or product.
Copyright © 2002 Soltek Computer Inc. All Rights Reserve .
• ntel Pentium 4 and Northwood are trademarks of ntel Corporation.
• V A , V A Apollo P4X266, V A Appolo P4X266A, VT8233A and VT8233 are trademarks of V A
Technologies, nc.
T

3
85DIV / 85DIV-L
SOLTEK AROUND THE WORLD
SOLTEK COMPUTER INC.
Address : 7F, No. 306-3, Ta-Tung Rd, Sec.1, Hsi-Chih, Taipei-
Hsien, Taiwan, R.O.C.
Telephone : [phone]
Fax : [phone]
E-mail : [email protected]
Web site : http://www.soltek.com.tw
SOUL TECHNOLOGY EUROPE B.V.
Address : Hongkongstraat 55, 3047 BP Rotterdam. The Neth-
erlands
Telephone : [phone]
Fax : [phone]
E-mail : [email protected]
Web site : http://www.soltekcomputer.com
SOLTEK KOREA INC.
Address : 1002, Chung Jin Bldg. 53-5 Wonhyo-Ro, 3-Ka,
Yongsan-Ku Seoul 140-113, Korea
Telephone : [phone]
Fax : [phone]
E-mail : [email protected]

4
Contents
Contents
Chapter 1 Specification ........................................... 10
1-1 Mainboard Specifications ..................................................... 11
1-1.1 CPU Socket ................................................................................... 11
1-1.2 System Chipsets ........................................................................... 11
1-1.3 Memory ......................................................................................... 11
1-1.4 AWARD BIOS V6.0 ..................................................................... 11
1-1.5 Accelerated Graphics Port (AGP) Interface........................... 11
1-1.6 Ad anced system Power Management, supporting: ............ 12
1-1.7 Multi-I/O Functions: ................................................................... 12
1-1.8 Expansion Slots ............................................................................ 12
1-1.9 Hardware Monitor on board ..................................................... 13
1-1.10 AC’97 Audio Codec on board.................................................. 13
1-1.11 LAN (Local Area Network) on board (for 85DIV-L only)..13
1-1.12 Form Factor................................................................................ 13
1-2 Mainboard Specification Table ........................................... 14
1-3 Chipset System Block Diagram........................................... 15
Chapter 2 Hardware Setup..................................... 17
2-1 CPU Installation with Socket 478 ....................................... 18
2-2 Pentium 4 CPU Fan Installation: ....................................... 19
2-3 Memory Installation ............................................................. 20
2-3.1 To Install DDR SDRAM Module for this Mainboard : ........ 20
2-3.2 To Remo e a DIMM:................................................................... 20
2-4 AGP (Accelerated Graphics Port) Configuration : ......... 21
2-5 HDD/FDD Installation .......................................................... 22
2-6 ATX V 2.03 Power Supply Installation .............................. 24
2-7 Jumper and Switch Settings ................................................ 25

5
Contents
2-7.1 Switch 1 System Clock Adjust ................................................... 26
2-7.2 JBAT1 Clear CMOS.................................................................... 27
2-7.3 Jp7 Built-in LAN Select (for 85DIV-L only) ........................... 27
2-7.4 Jp6 CPU Clock Select: ................................................................ 28
2-8 Other Connectors Configuration........................................ 29
2-8.1 On Board FAN Connectors ........................................................ 29
2-8.2 CD-ROM Audio Connector CD_IN1........................................ 30
2-8.3 Chassis Panel Connector ............................................................ 30
2-8.4 Thermal Sensor Connector RT1, RT2 ..................................... 31
2-8.5 Complex Header .......................................................................... 32
2-8.6 USB Ports and USB Header (Header USB 3) ......................... 34
2-8.7 PS/2 Mouse And PS/2 Keyboard ............................................... 34
2-8.8 Rj45 Connector (for 85DIV-L only) ......................................... 35
2-9 IRQ Description..................................................................... 36
Chapter 3 Software Setup ....................................... 38
3-1 Open up Suport CD: ............................................................. 39
3-2 Proceed to VIA 4-in-1 Dri er Installation........................ 40
3-3 Proceed to AC’97 Audio Dri er Installation..................... 42
3-4 Proceed to Hardware Monitor Installation....................... 43
3-5 Install RTL8139C LAN Dri er (for 85DIV-L only) ......... 45
3-5-1. RTL8139C LAN dri er on Windows 9X ................................ 45
3-5-2. RTL8139C LAN dri er on Windows NT4.0 .......................... 47
3-5-3. RTL8139C LAN dri er on Win ME / 2000 / XP ................... 48
Chapter 4 BIOS Setup............................................. 50
4-1 About BIOS Setup ................................................................. 51
4-2 To Run BIOS Setup ............................................................... 51
4-3 About CMOS .......................................................................... 51
4-4 The POST ( Power On Self Test ) ....................................... 51

6
Contents
4-5 To Upgrade BIOS .................................................................. 52
4-5.1 Before Upgrading BIOS ............................................................. 52
4-5.2 Upgrade Process........................................................................... 52
4-6 BIOS SETUP --- CMOS Setup Utility................................ 55
4-6.1 CMOS Setup Utility .................................................................... 55
4-6.2 Standard CMOS Setup ............................................................... 56
4-6.3 Ad anced BIOS Features ........................................................... 59
4-6.4 Ad anced Chipset Features ....................................................... 63
4-6.5 Integrated Peripherals................................................................ 68
4-6.6 Power Management Setup ......................................................... 74
4-6.7 PNP / PCI Configuration............................................................ 80
4-6.8 SmartDoc Anti-burn Shield (PC Health status)..................... 83
4-6.9 Frequency / Voltage Control..................................................... 85
4-6.10 Load Optimized Defaults ........................................................ 87
4-6.11 SET SUPERVISOR / USER PASSWORD............................. 88
4-6.12 SAVE & EXIT SETUP .............................................................. 89
4-6.13 EXIT WITHOUT SAVING ...................................................... 89
Appendices ............................................................... 91
Appendix-1 Identify BIOS Version & BIOS Part Number ... 92
Appendix-2 Identify Mainboard Model Number ................... 93
Appendix-3 Technical Terms ...................................................... 94

7
Contents

8
85DIV / 85DIV-L
Mainboard
Support CD
Bundled Bonus Pack CD
Bundled Bonus Pack Manual
Temperature Sensor Cable (Optional)
ATA66/100/133 DE Cable
FDD Cable
User’s Manual
RS232 Cable
ITEM CHECKUP

9
Chapter 1 Specification
85DIV / 85DIV-L -- Component Locations
mPGA478B
1
DIM 1 DIM 2
DDR 266
PCI 1
GAME/MIDI PORT
LPT1
USB1
PS/2 K/B
Mouse
(on op)
(underside)
USB0
(middle)
(underside)
Rj45
(on op)
FDC
IDE1 IDE2
VIA
P4X266A
VT8233A
VIA
Li
Ba ery
AGP 4X / 2X
RTL8139C
SW1
ON DIP
1 2 3 4
SPK RST
SMI
HDD/LED IR PWR
1
30
SUS LED
PWR LED
1
3
1
Power
IT8705F
LPC I/O
4
1
CD_IN1
AC'97
Audio
BIOS
RT1
RT2 USB3
FAN 2
1
FAN 1
1
FAN3
1
JBAT1
1
Jp6
1
COM1
MIC LINE
OUT
LINE IN
Peripheral
+12V Power
Main Power
PS/2
1
PCI 2
PCI 3
Jp3 Jp4
Jp7
COM2
1
10
for 85D V-L only
LAN Controller and Jp7 for 85D V-L only

10
85DIV / 85DIV-L
This mainboard features an integration of the powerful processor n-
tel Pentium 4 and the single-chip North Bridge V A P4X266A plus South
Bridge VT8233A, by which the whole system performance is upgraded
to 533/400 MHz system bus.
The ntel P4 processor is a rapid execution engine providing 400MHz
quadpumped system bus to allow 3.2GB data transfer rates possible,
while V A Apollo P4X266A North Bridge plus VT8233A South Bridge
supports ntel P4 processor to implement the AGP 4X external bus, the
LPC Super /O, the DDR SDRAM and UATA 133/100/66 data transfer
rate. This chapter is to introduce to users every advanced function of
this high performance integration.
Topics inclu e in this chapter are:
1-1 Mainboar Specifications
1-2 Mainboar Specification Table
1-3 Chipset Diagram
Intro uction
Chapter 1 Specification

11
Chapter 1 Specification
1-1.1 CPU Socket
CPU Socket 478B on board, supporting ntel® Pentium 4 and North-
wood processors in the 478-pin package for :
• 533/400 MHz System Bus;
• Hyper pipelined technology;
• Advanced dynamic execution;
• Advanced transfer cache;
1-1.2 System Chipsets
North Bridge V A P4X266A plus South Bridge VT8233A to work with
ntel Pentium 4 Processor for managing and arbitrating operations be-
tween all system interfaces.
1-1.3 Memory
2 DDR D MM 184-pin sockets on board for PC2100 and PC1600 DDR
SDRAMs, at 64bit data transfer rate:
• P4X266A directly supporting pseudo-synchronous SDRAM up to 2GB
unbuffered DDR SDRAMs.
• nstallation of mixed volumes of DDR SDRAM modules supported.
• D MM voltage adjustable in B OS
1-1.4 AWARD BIOS V6.0
• Supporting Plug & Play V1.0;
• Flash Memory for easy upgrade;
• Supporting B OS writing protection and Year 2000 compliant;
• B OS Setup supported (Please see Chapter 4 B OS Setup);
1-1 Mainboar Specifications
1-1.5 Accelerate Graphics Port (AGP) Interface
AGP Controller is embedded in chip, supporting:
• 1.5V (4x)/ 3.3V(2x) power mode;
• 2x/ 4x AD and SBA signalling, AGP pipelined split-transection long-
burst transfers up to 1GB/sec.;
• AGP v2.0 compliant; AGP voltage adjustable in B OS

12
85DIV / 85DIV-L
1-1.7 Multi-I/O Functions:
• PC E DE Controller, supporting:
-- 2x Ultra ATA 133/100 / 66 / 33 DE Connectors supporting up to 4 DE
devices;
• Dedicated R Functions:
-- Third serial port dedicated to R function either through the two com-
plete serial ports or the third dedicated port nfrared- rDA (HPS R) and ASK
(Amplitude Shift Keyed) R.
• Multi-mode parallel Data transfer:
-- Standard mode, ECP and EPP support;
• Floppy Disk connector:
-- One FDD connector with drive swap support;
• Universal Serial Bus Transfer Mode:
-- USB V1.1 compliant;
-- 2 built-in USB connectors and one USB Headers (USB3) which requires
one optional USB cable to provide 2 more optional USB ports;
• PS/2 Keyboard
• PS/2 Mouse
• UARTs (Universal Asynchronous Receiver / Transmitter):
-- Two complete Serial Ports (COM1 & COM2) on board;
1-1.8 Expansion Slots
• 3 PC bus Master slots;
• One AGP 4x/2X slot;
• Two DDR D MM slots;
1-1.6 A vance system Power Management, supporting:
• ACP 1.0B compliant (Advanced Configuration and Power nterface);
• APM V1.2 compliant (Legacy power management);
• POS (Power On Suspend);
• Wake On Modem (External) and Wake On LAN supported by Ring
Power On Control;
• Real time clock (RTC) with date alarm, month alarm, and century
field.

13
Chapter 1 Specification
1-1.9 Har ware Monitor on boar
Programmable hardware status, to provide monitoring and alarm for
flexible desktop management of hardware temperatures. Utility Soft-
ware is enclosed in Support CD to help display monitoring statuses of:
-- 8 voltages, 3 types of hardware temperatures, 2 Fan speeds;
1-1.10 AC’97 Au io Co ec on boar
AC’97 Audio Codec supported by AC’97 Link on chip VT8233A;
1-1.12 Form Factor
• Micro-ATX form factor, power supply in ATX spec. version 2.03
compliant, supported by one Main Power Connector, one +12V Power
Connector and one Peripheral Power Connector;
• Mainboard size: 245mm x 245mm;
1-1.11 LAN (Local Area Network) on boar (for 85DIV-L only)
PC local bus single-chip Fast Ethernet Controller RTL8139C on board:
• Supporting 10/100Mb data transfer
• Supporting Wake on LAN function through the on-board Rj45 LAN
Connector

14
85DIV / 85DIV-L
1-2 Mainboar Specification Table
Model/Series 85DIV / 85DIV-L
Memory
Con roller Hub Nor h Bridge VIA P4x266 A
Sou h Bridge VIA VT8233A
ITE IT8705F
I/O
Con roller Hub
I/O Chip
AGP In erface AGP 4X / 2X Mode
Memory Suppor ing 2GB unbuffered
DDR SDRAMs wi h 2 DDR DIMM Slo s
Audio
Onboard IDE 2 x UATA 33/66/100/133 IDE por s
I/O Connec ors
Buil -in
Buil -in
4 x USB por s, 1 x FDD por , 2 x COM por s,
PCI slo 3 PCI Mas er Slo s
LAN Con roller (for 85DIV-L only) RTL8139C on board, suppor ing 1 Rj45
Hardware
BIOS wri ing
AC'97 Audio Codec
CPU Socke Socke PGA478B for In el Pen ium 4 478-pin package CPU
1 x LPT por , 1 IrDA, 1 PS/2 Mouse, 1 PS/2 K/B
Pro ec ion
Moni oring

15
Chapter 1 Specification
Intel Pentium 4 + VIA P4X266A + VT8233A Diagram
1-3 Chipset System Block Diagram
Single-chip
Pen ium 4
DDR
PC2100/1600
DDR Memory Bus
UATA33/66/100/133
PS/2 keyboard
PCI Bus
P4x266A
Nor h Bridge
CPU
AGP
Slo
533/400 MHz FSB
SM Bus LPC
66MHz QDR, 8Bi V-Link
Super I/O
Serial / IR
Parallel
Floppy Disk
PCI Slo s
478-pin package
Modem Codec Game Por
H/W Moni or
BIOS
VT8233A
V-Link
Clien Sou h
In el
AGP 2X/4X Bus
SDRAMs
USB
AC'97 Audio
PS/2 Mouse
R l8139C LAN Connec or
(For 85DIV-L only)

16
85DIV / 85DIV-L
MEMO
MEMO

17
Chapter 2 Hardware Setup
Chapter 2 Hardware Setup
1. We recommend to install your CPU before any other components.
For detailed installation instructions of processor, you can also refer
to the pamphlet enclosed in your CPU package.
2. nstalling a cooling fan with a good heatsink is a must for proper heat
dissipation for your CPU. Get ready an appropriate fan with heatsink
for proper installation. mproper fan and installation will damage your
CPU.
3. n case CPU Vcore, CPU clock or Frequency Ratio is adjustable on
board, please follow the instructions described in the User manual
for proper setup. ncorrect setting will cause damage to your CPU.
The following topics are inclu e in this chapter:
2-1 Pentium 4 CPU Installation
2-2 Pentium 4 CPU Fan Installation
2-3 Memory Installation
2-4 AGP (Accelerate Graphic Port) Installation
2-5 HDD/FDD Installation
2-6 ATX 2.03 Power Supply Installation
2-7 Jumper an Switch Settings
2-8 Other Connectors Configuration
To Get things rea y for Har ware setup !

18
85DIV / 85DIV-L
mPGA478B
Pin 1
2-1 CPU Installation with Socket 478
This mainboard is built with CPU Socket 478 ( 47-pin) supporting the
ntel Pentium 4 CPU:
• Follow the steps described in this section to install the 478-pin Pen-
tium 4 CPU into the on board Socket 478.
• After installation of Pentium 4 CPU, you must also install the specific
Pentium 4 CPU fan designed in tandem with this CPU. This CPU
Fan installation is described in next section.
1. First pull sideways the lever of
Socket 478, and then turn it up
900 so as to raise the upper layer
of the socket from the lower
platform.
3. Make sure that all CPU pins have
completely entered the socket
and then lower down the lever
to lock up CPU to socket.
2. Configure Pin 1 of CPU to Pin 1
of the Socket, just as the way
shown in the diagram on the left.
Adjust the position of CPU until
you can feel all CPU pins get
into the socket with ease.
mPGA478B
ntel Pentium 4
mPGA478B
ntel Pentium 4
Pin 1
Pin 1

19
Chapter 2 Hardware Setup
Connect Fan Connector to CPU FAN connector
Press down 4 corners to lock fan to fanbase
Pentium 4 Fanbase CPU Fan Connector
2-2 Pentium 4 CPU Fan Installation:

20
85DIV / 85DIV-L
184-Pin DIMM Notch Key Definitions (2.5V)
DRAM Key Position Voltage Key Position
2.5V
2-3.2 To Remove a DIMM:
Press down the holding latches on both sides of socket and the module
will be released from the D MM socket.
2-3 Memory Installation
• This mainboard only supports up to 2GB unbuffered DDR SDRAM,
with 2 DDR D MM sockets on board. Do not insert other type of mod-
ules into these sockets.
• DDR D MM socket has 184-pins and one notch. nsert a DDR SDRAM
vertically into the 184-pin socket with the notch matching the one in
the socket. Press the Module down in a gradual way until it surely
reaches the bottom and clicks straight up the two latches on the left
and right of the socket. f any one of the latches has not turned up
completely, you should unplug the module and press it down the
socket a bit more firmly.
How to tackle with the memory Modules:
• Make sure to unplug your power supply before adding or removing
memory module. Failure to do so may cause severe damage to both
your main board and the memory module.
• Pay attention to the orientation of the D MM slots. Forcing a D MM in
a socket improperly will damage the memory module and socket.
• Make sure you have the right type of memory module for your
mainboard.
Module Latch
2-3.1 To Install DDR SDRAM Mo ule for this Mainboar :
