SOLTEK SL-75DRV3/75DRV3+ User manual

R
The Soul Of Computer Technology
Mainboard
SL-75DRV3/75DRV3+
User Manual V1.0

Product Model SL-75DRV3/75DRV3+
Manual Revision V1.0
Release Date November 2001
• AMD Athlon ThunderbirdTM, DuronTM, and AthlonTM XP processors are trademarks of AMD
Corporation.
• V A, KT-133, VT8363 and VT82C686A are trademarks of V A Corporation.
T
his Users Guide & Technical Reference is to help system
manufacturers and end-users set up and install the mainboard.
Every effort has been made to ensure that the information in this
manual is accurate. Soltek Computer nc. is not responsible for printing or
clerical errors. nformation in this document is subject to change
without notice and does not represent a commitment on the part of
Soltek Computer nc.
No part of this manual may be reproduced, transmitted, translated
into any language in any form or by any means, electronic or
mechanical, including photocopying and recording, for any purpose
without the express written permission of Soltek Computer nc.
Companies and products mentioned in this manual are for identification
purpose only. Product names appearing in this manual may or may
not be registered trademarks or copyrights of their respective
companies.
Soltek Computer nc. provides this manual “As is “ without warranty
of any kind, either express or implied, including but not limited to the
implied warranties or conditions of merchantability or fitness for a
particular purpose. n no event shall Soltek Computer nc. be liable
for any loss or profits, loss of business, loss of use or data, interruption
of business, or for indirect, special, incidental, or consequential
damages of any kind, even if Soltek Computer nc. has been
advised of the possibility of such damages arising from any defect
or error in this manual or product.
Copyright © 2001 Soltek Computer Inc. All Rights Reserved.
N TICE

SOLTEK AROUND THE WORLD
S LTEK C MPUTER INC.
Address : 7F, No. 306-3, Ta-Tung Rd, Sec.1, Hsi-Chih, Taipei-
Hsien, Taiwan, R.O.C.
Telephone : [phone]
Fax : [phone]
E-mail : [email protected]
Web site : http://www.soltek.com.tw
S UL TECHN L GY EUR PE B.V.
Address : Hongkongstraat 55, 3047 BP Rotterdam. The Neth-
erlands
Telephone : [phone]
Fax : [phone]
E-mail : [email protected]
Web site : http://www.soultech-europe.com
S LTEK K REA INC.
Address : 1002, Chungjin Bldg. 53-5 Wonhyo-Ro, 3-Ka,
Yongsan-Ku Seoul 140-113, Korea
Telephone : [phone]
Fax : [phone]
E-mail : [email protected]

75DRV3/75DRV3+
4
CONTENT
Chaper 1 Introduction......................................................................9
1-1 Mainboard Specification ...................................................................... 10
1-1.1 Processor ...................................................................................................... 10
1-1.2 Chipset ......................................................................................................... 10
1-1.3 AWARD BI S V6.0 Supporting.................................................................. 10
1-1.4 Sound Controller .......................................................................................... 10
1-1.5 Power Management ..................................................................................... 10
1-1.6 Full Featured Accelerated Graphics Ports (AGP) Controller ...................... 11
1-1.7 Multi-I/ Function ....................................................................................... 11
1-1.8 Expansion Slots............................................................................................ 11
1-1.9 Advanced High Performance SDR/DDR DRAM Controller ...................... 11
1-1.10 Form Factor................................................................................................ 11
1-1.11 Hareware Monitoring ................................................................................. 12
1-1.12 Disk RAID (Redundant Array of Independent Disks) ............................... 12
1-2 Mainboard Layout ............................................................................... 13
1-2.1 Mainboard Layout --- 75DRV3 ................................................................... 13
1-2.2 Mainboard Layout --- 75DRV3+ ................................................................. 14
1-3 Chipset Diagram .................................................................................. 15
Chaper 2 Hardware Setup ............................................................17
2-1 CPU Installation................................................................................... 18
2-2 Memory Installation............................................................................. 19
2-3 HDD/FDD Installation......................................................................... 21
2-4 Switch Setting For CPU Frequency And Voltage ................................ 23
2-4.1 Information n AMD Socket 462 Processor (Model 4, 5 Products) ........... 23
2-4.2 Information n AMD Socket 462 Processor (Model 6, 7 Products) ........... 24
2-4.3 Processor Core Voltage Select (By SW1 DIP1-DIP6) ................................. 25

5
Content
2-4.4 CPU External Frequency Setting (By SW2)................................................ 26
2-5 Jumper Settings .................................................................................... 27
2-5.1 JP1 Power Lost Resume ..............................................................................28
2-5.2 JP11 n-board RAID Controller Select ...................................................... 28
2-5.3 JBAT1 For Clear CM S Data ..................................................................... 29
2-6 Connectors Configurations .................................................................. 30
2-6.1 n Board FAN Connector (FAN1, FAN2, FAN3, FAN4) ...........................30
2-6.2 W L1 Wake n LAN ................................................................................. 31
2-6.3 CD-R M Audio Connector (JCD_IN1) ...................................................... 31
2-6.4 Complex Header C N1 ............................................................................... 32
2-6.5 ATX Power Supply Connector ..................................................................... 33
2-6.6 Chassis Panel Connector .............................................................................. 34
2-6.7 Smart Card Reader Connector (SCR1) ........................................................ 35
2-6.8 Communication And Networking Riser Slot (CNR) ................................... 36
2-6.9 USB Ports and USB Headers (Header USB 2 & 3) ..................................... 37
2-6.10 PS/2 Mouse And PS/2 Keyboard ...............................................................37
Chaper 3 Software Setup ...............................................................39
3-1 pen up the Suport CD and choose Drivers and Utilities ................... 40
3-2 Proceed to VIA 4-In-1 Drivers Installation......................................... 41
3-3 Proceed to AC’97 Audio Driver Installation ....................................... 43
3-4 Proceed to Hardware Monitor Installation .......................................... 44
Chaper 4 BIOS Setup .....................................................................47
4-1 What Is BI S Setup ............................................................................. 48
4-2 How To Run BI S Setup..................................................................... 48
4-3 What Is CM S..................................................................................... 48
4-4 What Is P ST ...................................................................................... 48
4-5 BI S Upgrade ..................................................................................... 49
4-5.1 Before Upgrading BI S .............................................................................. 49

75DRV3/75DRV3+
6
4-5.2 Upgrade Process ..........................................................................................49
4-6 BI S Setup --- CM S Setup Utility ................................................... 53
4-6.1 CM S Setup Utility..................................................................................... 53
4-6.2 Standard CM S Setup ................................................................................. 54
4-6.3 Advanced BI S Features ............................................................................. 57
4-6.4 Advanced Chipset Features .......................................................................... 61
4-6.5 Integrated Peripherals .................................................................................. 66
4-6.6 Power Management Setup ........................................................................... 72
4-6.7 PNP / PCI Configuration ............................................................................. 78
4-6.8 SmartD C Anti-Burn Shield ....................................................................... 81
4-6.9 Frequency/Voltage Control ..........................................................................83
4-6.10 Load ptimized Defaults ........................................................................... 85
4-6.11 Set Supervisor / User Password ................................................................. 85
4-6.12 Save & Exit Setup ...................................................................................... 86
4-6.13 Exit Without Saving ................................................................................... 86
Chaper 5 Raid Controller ..............................................................88
5-1 Creating Your Disk Array .................................................................... 90
5-1.1 Creating An Array For Performance ............................................................ 90
5-1.2 Creating A Security (Mirror) Array With New Drives ................................ 92
5-1.3 Creating A Security (Mirror) Array With An Existing Data Drive .............. 94
5-2 Using FastBuildTM Configuration Utility .......................................... 97
5-2.1 Viewing FastTrak100-Lite BI S Screen ..................................................... 97
5-2.2 Navigating the FastBuildTM Setup Menu ................................................... 98
5-2.3 Using the Main Menu .................................................................................. 98
5-2.4 Creating Arrays Automatically .................................................................... 99
5-2.5 Viewing Drive Assignments ......................................................................101
5-2.6 View an Array ............................................................................................ 101
5-2.7 Adding Fault Tolerance to an Existing Drive ............................................ 102

7
Content
5-2.8 Making a FastTrak100-Lite Disk Array Bootable ..................................... 103
5-2.9 Creating a “Hot” Spare Drive for Mirroring Arrays ..................................104
5-2.10 How FastTrak100-Lite rders Arrays ..................................................... 104
5-2.11 How FastTrak100-Lite Saves Array Information .................................... 105
5-2.12 Deleting An Array .................................................................................... 105
5-2.13 Rebuilding A Mirroring Array ................................................................. 107
5-2.14 Viewing Controller Settings ..................................................................... 109
5-2.15 Halting FastTrak BI S n Bootup Errors ............................................... 109
5-3 INSTALLING DRIVERS .................................................................. 110
5-3.1 For Windows 2000 ..................................................................................... 110
5-3.2 Windows 95/98 .......................................................................................... 112
5-3.3 D S/Windows 3.1x ................................................................................... 115
5-3.4 Windows NT4.0 ......................................................................................... 116
Appendix ......................................................................................... 118
Appendix-1 Identifying BI S version and BI S part Number .............. 119
Appendix-2 Identifying Mainboard model Number ............................... 120
Appendix-3 Technical Terms ................................................................... 121

75DRV3/75DRV3+
8
Mainboard
====Support CD
====User’s Manual
====Bundled Bonus Pack CD
====Bundled Bonus Pack Manual
====Temperature Sensor Cable
====ATA66/100 DE Cable
====RS232 Cable
FDD Cable
ITEM LIST CHECKUP

Chapter 1 Introduction
9
Chaper 1
Introduction
This chapter contains the following topics
1-1 Mainboard Specification
1-2 Mainboard Layout
1-3 Chipset Diagram
• This chapter briefly introduces the characteristics of the mainboards. t includes
the information regarding the chipset, CPU types, built-in functions and layout.
Users will have more ideas about mainboards after reading this chapter.

75DRV3/75DRV3+
10
1-1 Mainboard Specification
1-1.1 Processor
• Supporting AMD Athlon™ Thunderbird processor up to 1.5GHz or above.
• Supporting AMD Duron™ processor up to 1.2GHz or above.
• Supporting 200MHz & 266MHz FSB bus.
• Supporting Processor V D(voltage D) and F D(Frequency D) auto
detection.
• Supporting Atholon™ XP Processors.
1-1.2 Chipset
• V A VT8366A DDR V-Link Host North Bridge.
• V A VT8233 V-Link Client South Bridge.
• TE 8705 LPC /O.
1-1.3 AWARD BIOS V6.0 Supporting
• Plug & Play V1.0.
• Flash Memory for easy upgrade.
• Year 2000 compliant.
• B OS writing protection.
• SmartDOC Anti-Burn shield.
1-1.4 Sound Controller
• SoundBlaster Pro Hardware and Direct Sound Ready AC97 Digital Audio
Controller with Codec onboard.
1-1.5 Power Management
• ACP 1.0 compliant (Advanced Configuration and Power nterface).
• APM V1.2 compliant (legacy power management).
• Supporting ACP suspend STR mode (Suspend To RAM) and POS mode
(Power On Suspend).
• System event monitoring with two event classes.
• Supporting PS/2 Keyboard & Mouse power on.
• Supporting Wake On LAN (WOL) & Wake On Ring.
• Supporting Real Time Clock (RTC) with date alarm, month alarm, and
century field.
• USB boot-up Function.

Chapter 1 Introduction
11
1-1.6 Full Featured Accelerated Graphics Ports (AGP) Controller
• AGP v2.0 compliant.
• Supports Side Band Addressing(SBA) mode (non-multiplexed address /
data).
• Supporting 66MHz 1x, 2x, and 4x modes for AD and SBA signaling.
1-1.7 Multi-I/O Function
• Two UltraDMA-33/66/100 Master Mode PC E DE ports.
• Two UARTs for complete Serial Ports.
• One dedicated R connector:
--At third serial port dedicated to R function either through the two complete serial
ports or the third dedicated port nfrared- rDA (HPS R) and ASK( Amplitude Shift
Keyed) R.
• Multi-mode parallel connector supporting:
--Standard mode, ECP and EPP.
• Floppy Disk connector supporting:
--One FDD with drive swap function.
• Universal Serial Bus connector supporting:
-- USB v1.1 and ntel Universal HC v1.1 compatible.
-- 2 built-in USB connectors, in addition to one internal USB header which requires
a USB cable to support 2 more optional USB ports.
• PS/2 keyboard connector.
• PS/2 Mouse connector.
1-1.8 Expansion Slots
• Six PC bus Master slots.
• One CNR slot.
• One AGP 4x mode slot.
• Three 184-pin D MM slots.
• One SCR (Smart Card Reader) slot.
1-1.9 Advanced High Performance SDR/DDR DRAM Controller
• Supporting memory size up to 3GB.
• Supporting 184-pin DDR SDRAM type only.
• Supporting PC1600 and PC2100 DDR SDRAM.
1-1.10 Form Factor
• ATX form factor, 4- layer PCB.
• Mainboard size 22.0cm x 30.5cm.

75DRV3/75DRV3+
12
1-1.11 Hareware Monitoring
• Programmable control, status to provide, monitoring and alarm for flexible
desktop management (software include).
• 5 positive voltage statuses monitoring.
• 2 temperatures statuses monitoring.
• 2 Fan-speeds statuses monitoring.
1-1.12 Disk RAID (Redundant Array of Independent Disks)
• Promise FastTrak100-Lite RA D controller on board.
• Supporting striping (RA D 0) and mirroring (RA D 1) Disk Arrays.
• Supporting Ultra ATA/100 / 66 /33 specification up to 100MB/sec.
• Two RA D Connectors DE3 and DE4 on board, compatible with Ultra
ATA/100/66/33 and E DE, supporting up to 2 RA D disks.

Chapter 1 Introduction
13
1-2 Mainboard Layout
1-2.1 Mainboard Layout --- 75DRV3
Using non-compliant memory with higher bus clock (over clocking) may
severely compromise the integrity of system.
1 3
USB0 USB1
PS/2 MOUSE PS/2 K/B
LPT1
COM1COM2
GAME/MIDI PORT
MIC LINE
OUT
LINE IN
FDC1
NJP1
SAPK RST PLED KEYLOCK SLED
HDD/LED IR PWR SMI
++
--
+-
1
30
Li
B ttery
SCR1
CNR1
FLASH BIOS
PCI 1
PCI 2
PCI 3
PCI 4
PCI 5
PCI 6
LPC I/O
Controller
Clock
Gener tor
AGP 4X
VIA
VT8366A
DDR 266
SSF1
ZD1
VIA
VT8233
SW2
ON DIP
1 2 3 4 5
SW1
ON DIP
1 2 3 4 5 6
CN1
JCD_IN1
IDE1 IDE2
USB2
1
16
1
16
USB3
SOCKET A
RT1
FAN1
FAN2
1 3
FAN4
1 3
1 3
WOL1
1 3
AC'97
Codec
FAN3
1 3
JBAT1
1 4
DIMM1 DIMM2 DIMM3
3 1
JP1

75DRV3/75DRV3+
14
1-2.2 Mainboard Layout --- 75DRV3+
Using non-compliant memory with higher bus clock (over clocking) may
severely compromise the integrity of system.
1 3
USB0 USB1
PS/2 MOUSE PS/2 K/B
LPT1
COM1COM2
GAME/MIDI PORT
MIC LINE
OUT
LINE IN
FDC1
NJP1
SAPK RST PLED KEYLOCK SLED
HDD/LED IR PWR SMI
++
--
+-
1
30
Li
B ttery
SCR1
CNR1
FLASH BIOS
PCI 1
PCI 2
PCI 3
PCI 4
PCI 5
PCI 6
IDE RAID controller
LPC I/O
Controller
Clock
Gener tor
AGP 4X
VIA
VT8366A
DDR 266
SSF1
ZD1
VIA
VT8233
SW2
ON DIP
1 2 3 4 5
SW1
ON DIP
1 2 3 4 5 6
CN1
JCD_IN1
IDE1 IDE2
IDE3
IDE4
USB2
1
16
1
16
USB3
SOCKET A
RT1
FAN1
FAN2
1 3
FAN4
1 3
1 3
1 3
WOL1
1 3
AC'97
Codec
FAN3
1 3
JP11
JBAT1
1 4
DIMM1 DIMM2 DIMM3
3 1
JP1

Chapter 1 Introduction
15
1-3 Chipset Diagram
• The VT8366A and VT8233 chipset is a high performance, cost-effective
and energy efficient system controller for the implementation of AGP /
PC / SA desktop personal computer system based on 64-bit Socket-A
(AMD Athlon) processors.
DDR Vlink
Host North
552 BGA
VT8233
Vlink
Client South
352 BGA
3D
Graphics
Controller
Athlon
Host CPU
SDR/VCM
& DDR
SDRAM
Clock
Buffer
Clock
Generator
SDR/DDR Memory Bus
AGP Bus
SYSCLK, SYSCLK#
INTR, NMI, SM#, STPCLK#,
IGNNE#, FERR#, A20M#,
PWROK, INIT#, RESET#
GCLK
PCLK
PCKRUN#
ATA33/66/100
MII/LAN
6x USB
LPC
SMBus
Power Plan & Peripheral Control
GPIO and ACPI Events
PCI Bus
CKE#
MCLK
HCLK
PCLK
CPUSTP#
PCISTP#
SUSCLK,
SUSST1#
GCKRUN#
Address
Out
CFWDRST
CONNECT
PROCRDY
In
Data
VT8366A
Diagram of Apollo Pro266A System Block Using the VT8233 V-Link
South Bridge

16
75DRV3/75DRV3+
MEMO
MEM
O

17
Chapter 2 Hardware Setup
2-1 CPU Installation
2-2 Memory Installation
2-3 HDD/FDD Installation
2-4 Switch Setting For CPU Frequency And Voltage
2-5 Jumper Settings
2-6 Connectors Configuration
This chapter contains the following topics
ATTENTI N !!!
1. Please refer to your processor installation or other
documentation attached to your CPU for detailed in-
stalling instruction.
2. Installing a heat sink and cooling fan is necessary
for proper heat dissipation from your CPU. Incorrect
installation may result in overheating and damage
of your CPU.
3. Before changing the setting of CPU Vcore from BI S
program, user SH ULD make sure of correct speci-
fication both of CPU CL CK and RATI . Incorrect
setting may cause damage to your CPU.
Chaper 2
Hardware Setup

18
75DRV3/75DRV3+
WARNIN !!!
• Make sure that +5V DCV and +3.3 DCV capabilities of your power supply
are suitable for the processor.
• Any attempt to operate the AMD Athlon or Duron processor without a
suitable coolin Fan will dama e processor and other component.
2-1 CPU Installation
SCKET 462
SCKET 462
AMD
Take notice of the red circles
as shown below. While inserting
the CPU into the socket, you
can find out there is a definite
pin orientation for CPU and
socket.
2
Pull out the lever from the
socket, and then raise the
lever up to a 90-degree angle.
1
AMD
SCKET 462
Make sure that the CPU is
placed into the socket tightly.
Then lower down the level to
complete the CPU installation.
3

19
Chapter 2 Hardware Setup
Installing DIMM
• Make sure you have the correct memory module type for your mainboard.
• nsert the module(s) as shown below, D MMs have 184-pins and one
notch that will be matched by the onboard D MM socket. Memory modules
are installed by inserting them straight into the slot until they “click” in the
right place. They only fit in one direction, so do not force them in by a
wrong direction.
184-Pin DIMM Notch Key Definitions(2.5V)
DRAM Key Position Voltage Key Position
2.5V
2-2 Memory Installation
Removing DIMM
• Press down the holding clips on both sides of a D MM socket and the
module will be released from it.
WARNING!!!
• Make sure to unplu your power supply before addin or removin memory
modules or other system components. Failure to do so may cause severe
dama e to both your mainboard and expansion cards.
• Be careful when insertin or removin DIMM. Forcin a DIMM in or out
of a socket improperly may dama e the memory module or the socket.
Some DIMMs which contain EDO or FTP DRAM are incompliant with
the mainboard. The M/B supports 2.5V true SDRAM DIMMs only.

20
75DRV3/75DRV3+
1 3
USB0 USB1
PS/2 MOUSE PS/2 K/B
LPT1
COM1COM2
GAME/MIDI PORT
MIC LINE
OUT
LINE IN
FDC1
NJP1
SAPK RST PLED KEYLOCK SLED
HDD/LED IR PWR SMI
++
--
+-
1
30
Li
B ttery
SCR1
CNR1
FLASH BIOS
PCI 1
PCI 2
PCI 3
PCI 4
PCI 5
PCI 6
LPC I/O
Controller
Clock
Gener tor
AGP 4X
VIA
VT8366A
DDR 266
SSF1
ZD1
VIA
VT8233
SW2
ON DIP
1 2 3 4 5
SW1
ON DIP
1 2 3 4 5 6
CN1
JCD_IN1
IDE1 IDE2
USB2
1
16
1
16
USB3
SOCKET A
RT1
FAN1
FAN2
1 3
FAN4
1 3
1 3
WOL1
1 3
AC'97
Codec
FAN3
1 3
JBAT1
1 4
DIMM1 DIMM2 DIMM3
3 1
JP1
NOTICE: When LED “ZD1”
is on, meanin that 2.5V is
operatin and flowin into
DIMM slots, please do not
add or remove memory
modules .
