Sonoff DW2-RF User manual

DW2-RF
User manual V1.0
RF无线门窗传感器
RF Wireless Door/Window Sensor
中文---------------- 1-7 English-------------- 8-13

Shenzhen Sonoff Technologies Co.,Ltd. 中 文
本设备需要连接SONOFF 433MHz RF网关进行智能操作，可与
其他产品互联互通。
设备支持其他无线协议为433MHz的网关，具体以实际产品为准。
使用说明
eWeLink
1. 下载“易微联”APP
1
eWeLink
works with everything
>

电池需另行购买。
>
2-2. 根据正负极标识，装上电池。
Shenzhen Sonoff Technologies Co.,Ltd. 中 文
2
2. 安装电池
2-1. 打开发射器后盖。
2-3. 合上后盖。

Shenzhen Sonoff Technologies Co.,Ltd. 中 文
3
打开eWeLink APP，选择要连接的网关，点击 "添加" 选择报警器，
听到“滴”网关进入配对模式，然后将“发射器”和“磁铁”分离
大于20mm直到LED指示灯长亮1-2秒，听到网关发出“滴滴”两声，
即添加完成。
>
ZBB rid ge
已添加遥控器:0
暂无遥控器，请添 加
添加
如添加失败，请将设备移近网关后再重新添加。
3. 添加子设备
添加子设备前，请先连接网关。
>20mm

安装设备
1. 撕下3M胶保护膜。
2. 安装时发射器和磁铁上的安装对位标识尽量对齐。
3. 分别粘贴在所需开合区域。
<5mm
发射器和磁铁安装间隙门窗在闭合状态下小于5mm。
设备重量＜1Kg，建议安装高度＜2米。
Shenzhen Sonoff Technologies Co.,Ltd. 中 文
4

产品参数
产品型号 DW2-RF
工作电压 DC12V(型号：27A 12V)
静态电流
发射电流
安装距离 <5mm
工作温度 -10℃~40℃
材料
产品尺寸
≤1.5uA
≤20mA
RF 433.92MHz
PC
发射器: 70x31x19mm 磁铁: 42x14x16mm
Shenzhen Sonoff Technologies Co.,Ltd. 中 文
产品介绍
LED指示灯
安装对位标识
发射器
磁铁
5

Shenzhen Sonoff Technologies Co.,Ltd. 中 文
产品特点
低功耗 报警记录查询 场景联动
DW2-RF是一款低功耗的无线门窗传感器，通过发射器与磁铁的靠
近与分开感知门窗开/合状态，通过添加场景联动设置控制其它设备。
请勿安装在户外容易被破坏的位置；
请勿安装在基础不牢固或有雨淋的位置；
请勿安装在线路旁或磁性物体附近；
使用场景
注意事项：
门 窗户
6

Shenzhen Sonoff Technologies Co.,Ltd. 中 文
更换电池
拆下外壳 取出电池
7

eWeLink
works with everything
>
Shenzhen Sonoff Technologies Co.,Ltd. English
The device can be operated intelligently via working with the
SONOFF 433MHz RF Bridge to communicate with other devices.
The d evi ce ca n wor k wit h oth er ga tew ays s upporti ng
433 MHz wir ele ss prot ocol . Detai led inf orm ation is in
accordance with the final product.
eWeLink
eWeLink
Operation instruction
1. Download APP
8

The battery is not included, please purchase it separately.
>
2-2. Insert batteries into the battery compartment based on
identifiers of positive and negative poles.
2-1. Remove the back cover of the transmitter.
2-3. Close the back cover.
2.Install batteries
Shenzhen Sonoff Technologies Co.,Ltd. English
9

>
ZBB rid ge
已添加遥控器:0
暂无遥控器，请添 加
添加
>20mm
3. Add sub-devices
Connect the Bridge before adding the sub-device.
If the addition failed, move the sub-device closer to the Bridge
and try again.
Access the eWeLink APP and select the Bridge, tap "Add" to
select the alarm, and a "Beep" means the Bridge enters the pairing
mode. Then seperate the magnet for more than 20 mm from the
transmitter until the LED indicator stays on for 1 to 2s, and the
pairing is complete when you hear "Beep Beep".
Install the device
1. Tear off the protective film of the 3M adhesive.
Shenzhen Sonoff Technologies Co.,Ltd. English
10

2. Try to align the mark line on the magnet with that on the
transmitter during installation.
3. Install them in the opening and closing area separately.
<5mm
Make sure the installation gap is less than 5mm when the door or
the window is closed.
The device weight is less than 1 kg.
The installation height of less than 2 m is recommended.
Shenzhen Sonoff Technologies Co.,Ltd. English
11

DW2-RF
DC12V(Model: 27A 12V)
<5mm
-10℃~40℃
≤1.5uA
≤20mA
RF 433.92MHz
PC
Specifications
Model
Material
Dimension
Working temperature
Working voltage
Quiescent current
Emission current
Installation gap
Transmitter: 70x31x19mm
Magnet: 42x14x16mm
Product Introduction
LED indicator
Align the mark lines
Transmitter
Magnet
Shenzhen Sonoff Technologies Co.,Ltd. English
12

Alarm recordings check
DW2-RF is a ZigBee low-energy wireless door/window sensor that
makes you know the opening/closing status of door and window by
separating the magnet from the transmitter. Connect it with the
Bridge and you can create a smart scene to trigger other devices.
Features
Low-energy Smart scene
Application
Note:
● Do not install outside the door/window.
● Do not install in the unstable position or in the place exposed to
rain or moisture.
● Do not install near wiring or magnetic object.
Door Window
Shenzhen Sonoff Technologies Co.,Ltd. English
13

Replace batteries
Take the batteries outRemove the back cover
Shenzhen Sonoff Technologies Co.,Ltd. English
14
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits
set forth for an uncontrolled environment. This transmitter
must not be co-located or operating in conjunction with any
other antenna or transmitter.
FCC Warning
Changes or modifications not expressly approved by the party
responsible for compliance could avoid the user’s authority to
operate the equipment.
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device
must accept any interference received, including interference
that may cause undesired operation.

Shenzhen Sonoff Technologies Co., Ltd.
Room 1001, 10F, Building 8, Lianhua Industrial Park,Longyuan
Road, Longhua District, Shenzhen,GD, China
ZIP code: 518000 Website: sonoff.tech
MADE IN CHINA
Note: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide re a
so n a b l e p ro te c ti o n a g a i n s t h a rmfu l interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee
— Reorient or relocate the receiving antenna.
— Increase the separation between the equipment and receiver.
— Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
— Consult the dealer or an experienced radio/TV
technician for help.
that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
