Sony Ericsson K600i User manual

Confidential
1(8)
Document number Revision
2/006 71-4/FCP 101 1640/6 Uen R1D
Prepared by Date
EMEA Customer Services, Ralph Tronser 7/28/2005
Contents responsible if other than preparer Remarks
Approved by
Note: Any hard copy of this document is for reference only. Due to template and application dependencies the header and footer may fail to display correct data. It is
the responsibility of the user to ensure that they have a correct and valid version. Any outdated hard copy is invalid and must be removed from possible use.
To all EMEA Customer Service Managers
Regional Service Plan
K600i, V600i & K608i
1GENERAL
1.1 Product escription
Product description GSM 900/1800/1900 + MTS (2100)
K600 V600 K608
Product name Mirai Nanami Yui
Customisation Generic Vodafone T-Mobile & Hutchinson
Availability 05w26 05w26 05w31
Display: 262k colour TFT 262k colour TFT 262k colour TFT
Colours: Aluminium Silver Traditional Green, Moonlight
Silver
Silky White
Free user memory p to 37Mb p to 37Mb p to 37Mb
Memory stick: No No No
Camera: 1.3 Megapixel 1.3 Megapixel 1.3 Megapixel
Camera Zoom: Digital 4x Digital 4x Digital 4X
Autofocus No No No
FM radio Yes - RDS Yes - RDS Yes - RDS
Fast Port No No No

Confidential
PLAN 2(8)
Document number Revision
2/006 71-4/FCP 101 1640/6 Uen R1D
Talk time: p to 8hrs 15 min (GSM),
up to 2 hrs 10 min ( MTS)
p to 8hrs 15 min (GSM),
up to 2 hrs 10 min ( MTS)
p to 8hrs 15 min (GSM),
up to 2 hrs 10 min ( MTS)
Standby time: p to 370 hrs (GSM),
up to 290 hrs ( MTS)
p to 370 hrs (GSM),
up to 290 hrs ( MTS)
p to 370 hrs (GSM),
up to 290 hrs ( MTS)
Battery: NEO 3.6 V, 900 mAh, Li-Ion,
Exchangeable
NEO 3.6 V, 900 mAh, Li-Ion,
Exchangeable
NEO 3.6 V, 900 mAh, Li-Ion,
Exchangeable
Size: 104.3 x 44 x 18.9 mm 104.3 x 45 x 19,2 mm TBA
Weight: 105 g 105 g
Messaging: MMS/EMS/SMS/Email MMS/EMS/SMS/Email MMS/EMS/SMS/Email
Wireless Village: Yes Yes Yes
PIM: Yes Yes Yes
Polyphonic ring tones: 72 tones 72 tones 72 tones
Bluetooth Yes Yes Yes
IrDA Yes Yes Yes
PC – Software package:
Image Editor Yes Yes/No Yes
Adobe Photoshop starter
edition
Yes Yes/No Yes
Modem Drivers Yes Yes/No Yes
Sony Ericsson file manager Yes Yes/No Yes
Sony Ericsson mobile
networking wizard
Yes Yes/No Yes
PC Suite Yes Yes/No Yes
Note the products still utilize the standard connector.
1.2 Product Structure
Language Packages MMI Mirai MMI Nanami MMI Yui
EMEA 1 English, Estonian, Polish
Latvian, Lithuanian, Russian
Ukrainian
EMEA 2 English, Czech, Croatian
Serbian, Slovenian, Slovak
EMEA 3 English, Greek, Albanian
EMEA 4 English, Romanian, Hungarian
Bulgarian, Russian
EMEA 5 English, Arabic, Hebrew
Russian, French, Farsi
EMEA 6 English, Arabic, Russian
French, Farsi
EMEA 7 English, Turkish, Russian
Europe 1 English, Portuguese, Spanish
French
Europe 2 English, French, German
Turkish, Sesotho, Zulu
Europe 3 English, Dutch, French
German
Europe 4 English, Finnish, Danish
Icelandic, Swedish, Norwegian
Europe 5 English, French, German, Italian
Customer FS
Orange 1 generic Orange UK English, Orange
French, Orange Dutch, Orange
Romanian, Orange Slovak, Orange

Confidential
PLAN 3(8)
Document number Revision
2/006 71-4/FCP 101 1640/6 Uen R1D
Polish
Orange 2 Switzerland Orange CH English, Orange CH
French, Orange CH Italian, Orange
CH German
Orange 3 Belgium Mobitel
Orange BE English, Orange BE
French, Orange BE Dutch, Orange
BE German
E-Plus English, French, German
Spanish, Dutch, Turkish
TIM English (TIM), French (TIM)
German (TIM), Italian (TIM)
T-Mobile Int A English, German, Dutch, Czech
Polish, Turkish
T-Mobile Int B English, Hungarian, Croatian
Slovak
Hutchinson TBA
Vodafone 1 English (VFE), Dutch (VFE)
Greek (VFE), Portuguese (VFE)
Spanish (VFE), Swedish (VFE)
Vodafone 2 English (VFE), French (VFE)
German (VFE), Italian (VFE)
Arabic (VFE), Hungarian (VFE)
Turkish (VFE)
Vodafone 3 English (VFE_BE), French (VFE_BE)
Dutch (VFE_BE), German (VFE_BE)
Croatian (VFE_BE),
Slovenian(VFE_BE)
Vodafone 4 Japanese, English, Spanish
Portuguese
Standard kit contents includes :
1x Mobile Phone K600/V600/K608
1x Standard battery BST-37
1x Standard charger
1x ser manual
1x SB Cable
1x Lanyard
1x Stereo PHP
1x Product CD
1x Documentation set
In Box Promotion Leaflet
Service & Support leaflet
Quickguide
Warranty card
2Repair Concept
The products will be supported within SEMC service & support structure
The general repair packages are software update, mechanical repairs, electrical repairs and
extended electrical repairs.

Confidential
PLAN 4(8)
Document number Revision
2/006 71-4/FCP 101 1640/6 Uen R1D
2.1 Software level
On software level the software of the phone can be updated.
EMMA III Application will be used for software upgrades. See Software section.
2.2 Mechanical level
On mechanical level most of the mechanical parts will be available.
2.3 Electrical level
On electrical level some electrical and electro-mechanical parts that are expected to have a
high failure rate will be available.
The products are lead free and must be handled according to SEMC lead free repair
instructions.
2.5 Extended repair
Extended repair is an addition to the electrical repair level.
Extended repair will be released on a later date (generally RTL+5 weeks).
2.6 Build swap level
On the build swap level there will be a possibility to build swap units out of repaired units.
DPY/Z units will be used as swap units. DPY/Z kits will only consist of a phone (without
battery & battery cover) and box. To customize the DPY/z, repair center will need to re-
label, change co-brand inlay (if necessary), and customize software.
2.7 Spare Parts
The following Mechanical parts will be available (for Mirai)
Service
Level Part nr. R-state Description Material Group Shared
Mechanical BKE90333 R1A Vibrator EM1 Mirai / Nanami / Yui
Mechanical RLC509433 R1A Microphone EM1 Mirai / Nanami / Yui
Mechanical RLE90830 R1B Receiver EM1 Mirai / Nanami / Yui
Mechanical RLE90831 R1B Loudspeaker EM1 Mirai / Nanami / Yui
Mechanical RNH942217 R1B LCD EM4 Mirai / Nanami / Yui
Mechanical KNC20123 R1A Camera (Rear) EM6 Mirai / Nanami / Yui
Mechanical KNC20124 R1A Camera (Front) EM6 Mirai / Nanami / Yui
Mechanical SXA1095467
R1B Frame (PWB) ME1 Mirai / Nanami / Yui
Mechanical SXA1095468
R1A Lightguide (PL) ME1 Mirai / Nanami / Yui
Mechanical SXA1094884
R1B Water Indicator ME4 Mirai / Nanami / Yui
Mechanical SXA1095469
R1A Grommet (Cam_F) ME4 Mirai / Nanami / Yui
Mechanical SXA1095472
R1B Cushion (Cam_R) ME4 Mirai / Nanami / Yui
Mechanical SXA1095473
R1B Sheet (Cam_F) ME4 Mirai / Nanami / Yui
Mechanical SXA1095475
R1A Screw 1.4 x 5.5 ME4 Mirai / Nanami / Yui
Mechanical SXA1095476
R1A Screw 1.7 x 8 ME4 Mirai / Nanami / Yui
Mechanical SXA1095623
R1B Sheet, Shield (RF-
D) ME4 Mirai / Nanami / Yui
Mechanical SXA1095734
R1B Packing(PL) ME4 Mirai / Nanami / Yui

Confidential
PLAN 5(8)
Document number Revision
2/006 71-4/FCP 101 1640/6 Uen R1D
Mechanical SXA1095791
R1A Cushion(Speaker) ME4 Mirai / Nanami / Yui
Mechanical SXA1095896
R1A Mirai/Sheet (LCD_CON) ME4 Mirai / Nanami / Yui
Mechanical SXA1095897
R1A Mirai/Cushion (KEY_MAIN) ME4 Mirai / Nanami / Yui
Mechanical SXA1095450
R1B Bearing, Cover
(Cam_R) Mirai ME1 Mirai / Yui
Mechanical SXA1095624
R1A Screw 1.4 x 4.5W ME4 Mirai / Yui
Mechanical SXA1095640
R1A Magnet ME4 Mirai / Yui
Mechanical SXA1095639
R2A Frame Antenna EM2 Mirai
Mechanical SXA1095449
R1B Cover(Cam_R)
Mirai ME1 Mirai
Mechanical SXA1095452
R1B Cover (USB) Mirai ME1 Mirai
Mechanical SXK1096313
R1B Sub Assembly Case (Front) Mirai ME1 Mirai
Mechanical SXK1096314
R1B Sub Assembly Case (Rear) Mirai ME1 Mirai
Mechanical SXA1095454
R1B Key(Main) Mirai ME1 Mirai
Mechanical SXA1095456
R1A Key (Volume) Mirai ME1 Mirai
Mechanical SXA1095457
R1A Key (Videophone) Mirai ME1 Mirai
Mechanical SXA1095458
R1A Key (Internet) Mirai ME1 Mirai
The following Mechanical parts will be available (for Nanami)
Service
Level Part nr. R-state Description Material Group Shared
Mechanical BKE90333 R1A Vibrator EM1 Mirai / Nanami / Yui
Mechanical RLC509433 R1A Microphone EM1 Mirai / Nanami / Yui
Mechanical RLE90830 R1B Receiver EM1 Mirai / Nanami / Yui
Mechanical RLE90831 R1B Loudspeaker EM1 Mirai / Nanami / Yui
Mechanical RNH942217 R1B LCD EM4 Mirai / Nanami / Yui
Mechanical KNC20123 R1A Camera (Rear) EM6 Mirai / Nanami / Yui
Mechanical KNC20124 R1A Camera (Front) EM6 Mirai / Nanami / Yui
Mechanical SXA1095467 R1B Frame (PWB) ME1 Mirai / Nanami / Yui
Mechanical SXA1095468 R1A Lightguide (PL) ME1 Mirai / Nanami / Yui
Mechanical SXA1094884 R1B Water Indicator ME4 Mirai / Nanami / Yui
Mechanical SXA1095469 R1A Grommet (Cam_F) ME4 Mirai / Nanami / Yui
Mechanical SXA1095472 R1B Cushion (Cam_R) ME4 Mirai / Nanami / Yui
Mechanical SXA1095473 R1B Sheet (Cam_F) ME4 Mirai / Nanami / Yui
Mechanical SXA1095475 R1A Screw 1.4 x 5.5 ME4 Mirai / Nanami / Yui
Mechanical SXA1095476 R1A Screw 1.7 x 8 ME4 Mirai / Nanami / Yui
Mechanical SXA1095623 R1B Sheet, Shield (RF- D) ME4 Mirai / Nanami / Yui
Mechanical SXA1095734 R1B Packing(PL) ME4 Mirai / Nanami / Yui
Mechanical SXA1095791 R1A Cushion(Speaker) ME4 Mirai / Nanami / Yui
Mechanical SXA1095896 R1A Mirai/Sheet (LCD_CON) ME4 Mirai / Nanami / Yui
Mechanical SXA1095897 R1A Mirai/Cushion
(KEY_MAIN) ME4 Mirai / Nanami / Yui
Mechanical SXA1095450 R1B Bearing, Cover (Cam_R) Mirai ME1 Mirai / Yui

Confidential
PLAN 6(8)
Document number Revision
2/006 71-4/FCP 101 1640/6 Uen R1D
Mechanical SXA1095624 R1A Screw 1.4 x 4.5W ME4 Mirai / Yui
Mechanical SXA1095640 R1A Magnet ME4 Mirai / Yui
Mechanical SXA1095639 R2A Frame Antenna EM2 Mirai
Mechanical SXA1095449 R1B Cover(Cam_R) Mirai ME1 Mirai
Mechanical SXA1095452 R1B Cover (USB) Mirai ME1 Mirai
Mechanical SXK1096313 R1B Sub Assembly Case (Front) Mirai ME1 Mirai
Mechanical SXK1096314 R1B Sub Assembly Case (Rear) Mirai ME1 Mirai
Mechanical SXA1095454 R1B Key(Main) Mirai ME1 Mirai
Mechanical SXA1095456 R1A Key (Volume) Mirai ME1 Mirai
Mechanical SXA1095457 R1A Key (Videophone) Mirai ME1 Mirai
Mechanical SXA1095458 R1A Key (Internet) Mirai ME1 Mirai
The following Mechanical parts will be available (for Yui)
Service
Level Part nr. R- State Description Material Group Shared
Mechanical BKE90333 R1A Vibrator EM1 Mirai / Nanami / Yui
Mechanical RLC509433 R1A Microphone EM1 Mirai / Nanami / Yui
Mechanical RLE90830 R1B Receiver EM1 Mirai / Nanami / Yui
Mechanical RLE90831 R1B Loudspeaker EM1 Mirai / Nanami / Yui
Mechanical RNH942217 R1B LCD EM4 Mirai / Nanami / Yui
Mechanical KNC20123 R1A Camera (Rear) EM6 Mirai / Nanami / Yui
Mechanical KNC20124 R1A Camera (Front) EM6 Mirai / Nanami / Yui
Mechanical SXA1095467 R1B Frame (PWB) ME1 Mirai / Nanami / Yui
Mechanical SXA1095468 R1A Lightguide (PL) ME1 Mirai / Nanami / Yui
Mechanical SXA1094884 R1B Water Indicator ME4 Mirai / Nanami / Yui
Mechanical SXA1095469 R1A Grommet (Cam_F) ME4 Mirai / Nanami / Yui
Mechanical SXA1095472 R1B Cushion (Cam_R) ME4 Mirai / Nanami / Yui
Mechanical SXA1095473 R1B Sheet (Cam_F) ME4 Mirai / Nanami / Yui
Mechanical SXA1095475 R1A Screw 1.4 x 5.5 ME4 Mirai / Nanami / Yui
Mechanical SXA1095476 R1A Screw 1.7 x 8 ME4 Mirai / Nanami / Yui
Mechanical SXA1095623 R1B Sheet, Shield (RF- D) ME4 Mirai / Nanami / Yui
Mechanical SXA1095734 R1B Packing(PL) ME4 Mirai / Nanami / Yui
Mechanical SXA1095791 R1A Cushion(Speaker) ME4 Mirai / Nanami / Yui
Mechanical SXA1095896 R1A Mirai/Sheet (LCD_CON) ME4 Mirai / Nanami / Yui
Mechanical SXA1095897 R1A Mirai/Cushion (KEY_MAIN) ME4 Mirai / Nanami / Yui
Mechanical SXA1095450 R1B Bearing, Cover (Cam_R) Mirai ME1 Mirai / Yui
Mechanical SXA1095624 R1A Screw 1.4 x 4.5W ME4 Mirai / Yui

Confidential
PLAN 7(8)
Document number Revision
2/006 71-4/FCP 101 1640/6 Uen R1D
Mechanical SXA1095640 R1A Magnet ME4 Mirai / Yui
Mechanical SXA1095934 R1A Frame Antenna (YUI) EM2 Yui
Mechanical SXA1095776 R1A Cover (CAM_R)Yui ME1 Yui
Mechanical SXA1095777 R1A Cover (USB) Yui ME1 Yui
Mechanical SXK1096502 R1A Sub Assembly
Case (Front) Yui ME1 Yui
Mechanical SXK1096504 R1A Sub Assembly Case (Rear) Yui ME1 Yui
Mechanical SXA1095756 R1A Key (Volume) Yui ME1 Yui
Mechanical SXA1095757 R1A Key(Main) Yui ME1 Yui
Mechanical SXA1095758 R1A Key (Videophone) Yui ME1 Yui
Mechanical SXA1095759 R1A Key (Internet) Yui ME1 Yui
2.8 Service tools
No unique service tools required.
2.9 Test equipment
No unique test equipment is required for GSM/WCDMA test. See supported test equipment
in CSPN.
2.10 Software
2.10.1 EMMA III
a. Flash software
Support is only planned in EMMA III. There will be no support in EMMA II.
b. Service software
ser data swap service software will not be available.
Other service software will be supported in EMMA III.
2.10.2 Update Service
SE S will be supported from MR1 sw release onwards.
pdate Service Pro will be supported from MR1 sw release onwards.

Confidential
PLAN 8(8)
Document number Revision
2/006 71-4/FCP 101 1640/6 Uen R1D
2.10.3 Customer Services Customization Application
CSCA will be available for the products & will be supported in EMMA III.
2.10.4 FOTA (Firmware Over the Air)
FOTA will not be supported in the products.
2.11 Repair Training
The products will not be implemented in Learning Community for repair course. All needed
information about how to repair the products can be found in CSPN. There will also be no
test and certification.
3. Support Concept
a. Phone Setup
WAP OTA (Over the Air) configuration of WAP Settings
MMS OTA (Over the Air) configuration of MMS Settings
E-mail OTA (Over the Air) configuration of E-mail Settings
b. Product Information
Getting Started Short guide on how to use a specific feature/application manual
ser Guides Manuals
Facts and Features Product Specification
Environment Environmental declaration of the product
SAR Information Information about the SAR value for the product
Service & Warranty Information about Service & Warranty
c. Software
Here the user will find different applications and drivers for the product and PC that are
supported by SEMC.
Themes, ring tones, games etc are not available through the support web site. Non support
related information is generally available on the Fun & Download pages.
If there are applications that have a limited support, trials etc then it has be clearly marked
with a disclaimer and/or notification.
d. Troubleshooting
Trouble-shooter Animation that will explain for the consumer how to fix the
simplest problems that are counted as no trouble found (only the
product generic variant will be animated)
FAQ Frequently Asked Questions
Knowledge base Advanced search tool where users can ask questions in
English
Contact us Contact information for e-mail and phone
e. More
Accessories All accessories compatible with this phone
Did you know? Tips on how to get the most out of your product
Sony Ericsson pdate Service pdate the phone software
