Sony UNI-PMA1 User manual

OUTDOOR HOUSING MOUNTING BRACKET
Installation and Operation Instructions for the following models:
UNI-PMA1, SNCAPM3
(1) Supplied Parts
(1) Mount bracket
(4) Hex head bolts (3/8" - 16 x 1")
(4) Lockwasher (3/8")
(4) Flat washers (3/8")
UNI-CMA1, SNCACA2
(1) Supplied Parts
(1) Wall mount bracket
(4) Hex head bolts (3/8" - 16 x 1")
(4) Lockwasher (3/8")
(4) Flat washers (3/8")
(1) Operation Instruction Manual
12/27/05 81-IN6564

UNI-CMA1/SNCACA2 Dimensions
UNI-PMA1/SNCAPM3 Dimensions
INSTALLING THE POLE MOUNT ADAPTER
(UNI-PMA1 or SNCAPM3)
GENERAL INSTRUCTIONS:
Tools Required: .100" Flat Head Screwdriver
Phillips Head Screwdriver
1Both the pole mount adapter and the corner
mount adapter are designed for outdoor use in
conjunction with a wall mount bracket.
2The combined weight of camera, lens, housing,
pan/tilt, and the wall mount bracket must not
exceed 75 lbs. (34 kg).
3Select a location where the combined weight of
the bracket, housing, pan/tilt and the wall mount
bracket can be properly supported.
PRECAUTIONS ON INSTALLATION
1Mount the bracket assembly to the pole using
metal straps (not provided). Place the straps
through the slots on the UNI-PMA1 or SNCAPM3
and then around the pole. Tighten straps.
2Combine the wall mount bracket with the pole
mount adapter and securely attach the four
hex head bolts, lock washers, and at washers
provided into the 3/8" inserts on the adapter.
Figure 1
INSTALLING THE CORNER MOUNT ADAPTER
(UNI-CMA1 or SNCACA2)
1Mount the bracket assembly to the selected
corner location using appropriate hardware (not
provided).
2Combine the wall mount bracket with the corner
mount adapter and securely attach the four
hex head bolts, lock washers, and at washers
provided into the 3/8" inserts on the adapter.
Figure 2
2X .75Ø
76˚
5.50
.88
2.00
1.00
2.00
.75
7.00
4.00
2.62
(4) 3/8-16 inserts
.40
1.80
2.55
5.69
45˚
6.70
11.87
3.82
2X .75Ø
1.00
.88
7.25
1.00
1.00
2.00
5.50
(4) .438" DIA. holes
(4) 3/8-16 inserts
