Sony ECM-B10 Reference guide
Help Guide
Shotgun Microphone
ECM-B10
Use this Help Guide when you have issues or questions on how to use your shotgun microphone.
5-036-505-11(1) Copyright 2021 Sony Corporation
Supported camera models
This unit is a microphone compatible with the Multi Interface Shoe.
For camera models compatible with this unit, view here. (Another window will open.)
In combination with any camera model that is not listed on the website, the unit does not work.
Identifying the parts
Preparations
Unpacking
Attaching/removing to/from the camera
About the pickup pattern and the frequency response
About this unit
Notes on use
Specifications
Trademarks
When the message “This accessory is not supported by the device and cannot be used.” is displayed on
the camera:
1
Help Guide
Shotgun Microphone
ECM-B10
Identifying the parts
Top, Side, and Bottom
Back
Microphone1.
Micro USB port (for maintenance and service use)2.
Lock dial3.
Multi Interface foot
Note
Do not touch the connector of the Multi Interface foot with bare hands.
4.
Connector protect cap5.
Directivity selection switch
: Super-directional
Provides a sharp directivity to pick up the sounds coming from the front. You can focus on recording the sounds
coming from the camera front while minimizing the surrounding sounds.
: Unidirectional
1.
2
About the wind screen
By fitting the wind screen over the microphone of the unit, you can minimize the noise caused by the wind or breath
hitting the microphone to be included in the recording.
Note
If the wind screen is exposed to rain and wet, remove it from the unit and let it dry in the shade.
You can record the sounds coming across from the front while minimizing those coming from the back.
: Omnidirectional
Provides the same directivity to pick up the sounds coming from every direction. Select this directivity when you want
to record environmental sounds in particular or include the voice of a photographer in the recording.
ATT switch
Select the option suitable for the audio recording volume. To record loud sounds while minimizing distortion, select
“20dB.” To record quiet sounds while amplifying the sounds, select “0dB.” It is recommended that you select an
option while monitoring the volume level meter on the camera or the audio recording volume with headphones.
2.
AUTO/MAN switch
AUTO: The recording volume level is automatically adjusted.
MAN: Adjust the recording volume with the AUDIO LEVEL dial.
3.
AUDIO LEVEL dial
The recording volume level can be adjusted manually for fine tuning when the AUTO/MAN switch is set to “MAN.”
It is recommended that you adjust the level while monitoring the volume level meter on the camera or the audio
recording volume with headphones.
4.
FILTER switch
NC: Select this option to use the noise cut filter function. Unpleasant noises are effectively eliminated by digital signal
processing. If the sound quality does not seem appropriate, select “OFF.”
LC: Select this option to use the low cut filter function. Unwanted noises, such as wind noise, air-conditioning noise,
and vibration noise, are minimized.
OFF: Select this option to disable either of the filter functions.
Note
Hand-held use of the attached camera in a quiet place may cause a soft vibrating sound to be recorded.
If the recorded vibrating sound is disturbing, set the FILTER switch to “LC” and try all over again.
5.
DIGITAL/ANALOG switch
Select the digital or analog input type.
If your camera is compatible with the digital audio interface of the Multi Interface Shoe, set the switch to
“DIGITAL.”
This allows the unit and the attached camera to communicate with each other with digital signals and provide
audio recording with minimum noise insertion.
If your camera is not compatible with the digital audio interface of the Multi Interface Shoe, set the switch to
“ANALOG.”
When the message “This accessory is not supported by the device and cannot be used.” is displayed on the
camera, set the switch to “ANALOG.”
If this does not help, see here.
6.
3
Help Guide
Shotgun Microphone
ECM-B10
Unpacking
If you find anything missing, please contact your dealer.
The number in the parentheses indicates the quantity.
Shotgun Microphone (1)
Wind screen (1)
Connector protect cap (attached) (1)
Pouch (1)
Set of printed documentation
5-036-505-11(1) Copyright 2021 Sony Corporation
5
Help Guide
Shotgun Microphone
ECM-B10
Attaching/removing to/from the camera
Attach the shotgun microphone to a camera.
Note
Before attaching/removing this unit to/from a camera, turn off the power to the camera.
Remove the connector protect cap from this unit.
1
Attach this unit to the camera ( ) and rotate the lock dial in the “LOCK” direction ( ) to firmly secure the
unit.
Attaching this unit to a camera automatically switches the audio input from the built-in microphone to the external
microphone (this unit). When it is difficult to insert the Multi Interface foot into the shoe, rotate the lock dial
counterclockwise until it stops, and then try again.
2
Operate the camera to start recording.
For details, refer to the Help Guide provided for the camera.
3
6
To remove the shotgun microphone
Turn off the power to the camera, rotate the lock dial counterclockwise until it stops, and then slide out the Multi Interface
foot from the shoe.
5-036-505-11(1) Copyright 2021 Sony Corporation
7
Unidirectional frequency response
Omnidirectional pickup pattern
Omnidirectional frequency response
9
5-036-505-11(1) Copyright 2021 Sony Corporation
10
Help Guide
Shotgun Microphone
ECM-B10
Notes on use
To protect the connector of the Multi Interface foot from damage while carrying around this unit, remove the unit from
the camera, attach the connector protect cap to the foot and put the unit in the supplied pouch.
While recording is in progress, operation and handling noises of a camera or a lens may be recorded. Touching this
unit while recording is in progress causes a noise to be included in the recording.
Monitoring or recording voice with the microphone of a camera may cause a slight delay of the voice.
Before changing the lens, make sure that no wind screen fibers are present on the surface of the lens and the
camera body. If present, clean them off with a blower etc. and then change the lens.
If dust or water droplets are present on the surface of the microphone, a successful recording may not be possible.
Be sure to clean the microphone surface before using this unit.
5-036-505-11(1) Copyright 2021 Sony Corporation
11
Help Guide
Shotgun Microphone
ECM-B10
Specifications
Design and specifications are subject to change without notice.
5-036-505-11(1) Copyright 2021 Sony Corporation
Type Back electret condenser type
Frequency response 40 Hz to 20 000 Hz
Pickup pattern Super-directional / unidirectional / omnidirectional (selectable)
Front sensitivity*1 -20 dBFS (0.1 Pa, 1 kHz)
Intrinsic noise*1 *2 15 dB SPL or less (0 dB = 2×10-5 Pa)
Wind noise*1 *3 50 dB SPL or less (without the wind screen attached)
30 dB SPL or less (with the wind screen attached)
Maximum input sound pressure level 120 dB SPL*1 *4
Dynamic range*2 105 dB or more
Operation temperatures 0 °C to 40 °C (32 °F to 104 °F)
Storage temperatures -20 °C to +55 °C (-4 °F to +131 °F)
Dimensions (Approx.)
27.4 mm × 81.7 mm × 79.3 mm
(Width/Height/Depth)
(1 1/8 in. × 3 1/4 in. × 3 1/8 in.)
(excluding the wind screen and projecting parts)
Mass (Approx.) 72 g (2.6 oz)
Acquired by setting the AUTO/MAN switch and the ATT switch to “AUTO” and “10dB,” respectively.
*1
Acquired by setting the DIGITAL/ANALOG switch to “DIGITAL.”
*2
Equivalent sound pressure level value converted from the average value of the noise that is output from the microphone when a wind velocity of
2 m/sec. is applied. (0 dB = 2×10 -5 Pa)
*3
Equivalent sound pressure level value converted from the input level value that is acquired when 1% waveform distortion is produced by 1 kHz
output signals from the microphone. (0 dB = 2×10 -5 Pa)
*4
12
Help Guide
Shotgun Microphone
ECM-B10
When the message “This accessory is not supported by the device and cannot be
used.” is displayed on the camera:
Do the following in the listed order.
5-036-505-11(1) Copyright 2021 Sony Corporation
Make sure that your camera is compatible with this unit.
For camera models compatible with this unit, visit the website at:
https://www.sony.net/dics/b10/
Note
In combination with any camera model that is not listed on the above website, the unit does not work.
1
To use a camera that is not compatible with the digital audio interface in combination with this unit, set the
DIGITAL/ANALOG switch on the unit to “ANALOG.”
2
Clean the contacts on this unit and the camera. When either or both of the contacts are soiled with dust or
the like, the camera may fail to detect that the unit is attached. To clean the contacts, use a cotton swab or
a dry, soft cloth (e.g., a cleaning cloth). Do not use water or chemicals for cleaning.
3
14
