Sony CE-P13 User manual

CE-P13 / P15 / P17
© 2006 Sony Corporation Printed in China
2-683-001-E1 (1)
Operating Instructions

2 3
WARNING
To reduce the risk of fire or
electric shock, do not expose
this apparatus to rain or
moisture.
Do not install the appliance in a confined space,
such as a bookcase or built-in cabinet.
To reduce the risk of fire, do not cover the
ventilation of the apparatus with news papers,
tablecloths, curtains, etc. And don’t place lighted
candles on the apparatus.
To reduce the risk of fire or electric shock, do not
place objects filled with liquids, such as vases, on
the apparatus.
If you have any questions about this product:
Visit the Web site: http://service.sony.com.cn/KB/
Hot line: 800-820-9000
Table of Contents
Supplied Accessories........................................................................ 5
Locating controls ............................................................................... 6
HOME menu ...................................................................................... 8
Basic Operations......................................................10
Charging.......................................................................................... 10
Transferring files from a computer to your player ............................ 12
Listening to audio files..................................................................... 13
Changing the play mode ................................................................. 16
Playing a specified section repeatedly (A-B Repeat) .............. 17
Using the menus.......................................................18
Music menu ..................................................................................... 18
FM menu .......................................................................................... 20
Listening to FM radio................................................................ 20
Presetting the desired broadcast stations................................ 22
Recording FM radio.................................................................. 23
Rec menu......................................................................................... 24
Recording sound ...................................................................... 24
Playing back recorded sound .................................................. 26
Photo menu...................................................................................... 27
Viewing image files................................................................... 27
Using the options...................................................................... 28
Minimum System Requirements
• IBM PC/AT or compatible computer
preinstalled with the following Windows
operating systems.
– Windows 2000 Professional (Service Pack 4
or later),
– Windows XP Home Edition,
– Windows XP Professional,
– Windows XP Media Center Edition,
– Windows XP Media Center Edition 2004,
– Windows XP Media Center Edition 2005
• USB (USB 2.0) port
Notice for users
• Recorded music is restricted to private use only.
Use of recorded for any other purpose requires
permission from the copyright holders.
• Sony is not responsible for incomplete
recording/downloading or damaged file due to
problems with the player or computer.
• Certain types of text and characters may not be
displayed correctly on the player. This is due to:
– The capability of the connected player;
– The player is not functioning normally;
– The ID3 TAG information is written in a
language or with characters that are not
supported by the player.

4 5
Table of Contents (continued)
File menu ......................................................................................... 29
Storing non-audio file................................................................ 29
Selecting a folder and file......................................................... 30
Using the options...................................................................... 31
Clock menu...................................................................................... 32
Displaying the clock ................................................................. 32
Setting the time and date ......................................................... 33
Cal menu.......................................................................................... 34
Displaying the calendar............................................................ 34
Setup menu...................................................................................... 35
Selecting the Setup menu ........................................................ 35
Changing the settings .............................................................. 37
Using other functions ..............................................38
Changing the display mode ............................................................ 38
Setting the display mode (animation)....................................... 39
Other Information .....................................................40
Precautions ...................................................................................... 40
Troubleshooting ............................................................................... 42
Specifications .................................................................................. 49
Index................................................................................................ 53
Supplied Accessories
Please check the accessories in the package.
Player (1)
OPTION
HOME
b
b
B
B
m
M
Nx
MIC
Headphones (1)
USB cable (1)
Operating Instructions
(this manual) (1)
Warranty card (1)
About the serial number
The serial number provided for this player
is required for the customer registration.
The number is on a label on the rear of the
player. Do not remove the label.

6 7
Front side Rear side
Locating controls
For details about each part, refer to the pages in parentheses.
OPTION
HOME
b
b
B
B
m
M
Nx
MIC
5
6
2
1
3
4
VOL
DISP
REPEAT
MIC
RESET
HOLD
7
8
9
qs
qd
q
;
qa
qf
Headphones
(Headphone / AUDIO IN) jack
When recording from other equipment,
connect to the headphone output of the
equipment (page 24).
OPTION button (pages 18, 22, 23,
28, 31, 33, 39)
/ button (pages 8, 13)
 / / button (pages 8, 13)
HOME button (pages 8, 13)
/ button (pages 8, 13)
VOL +/– buttons
Adjust the volume.
DISP (Display) button (pages 15, 38)
REPEAT button (pages 16, 17)
USB jack (page 10)
MIC (Microphone)
HOLD switch
Prevents accidental operation when carrying
your player. Pressing any button while
HOLD is activated shows “HOLD” on the
display.
RESET button (page 42)
Strap guide
This is used to attach a strap. Run a strap
through the strap guide to attach.

8 9
HOME menu
The HOME menu is the starting point to play files, listen to FM radio, and change settings.
To display the HOME menu
1Press and hold the  button until the display comes on.
2Press the HOME button.
The HOME menu is displayed.
3Press the (up) / (down) / / buttons to select a menu and
press  to confirm.
Clock ............................. 32
To display the clock and set the date and time.
FM .................................. 20
To listen FM radio, preset stations, and record
FM radio.
Cal ................................. 34
To display the calendar.
File ................................. 29
To check stored file.
Music ........................13, 18
To listen to audio files, select the equalizer, and
animation display.
Photo ............................. 27
To display image files.
Setup ............................. 35
To change settings.
Rec ................................ 24
To record sound.
Back
To return to the previous screen.
Tip
• To cancel a selection in a menu, press the
button.

10 11
Charging
You can charge your player by connecting it to a computer with the supplied USB cable.
When the remaining battery indicator of the display shows , charging is complete
(charging time is approx. 4 hours*1). Fully charge your player before using it for the first
time.
*1 This is the approximate charging time when the battery power is low and the player is connected to
the computer directly using the supplied USB cable at typical room temperature. The charging time
will vary depending on remaining battery power and battery condition. If the battery is charged in a
low-temperature environment, the charging time will be longer. It will also be longer if you transfer
file(s) to the player while charging.
1Connect your player to the computer with the supplied USB cable.
Connect the small connector of the supplied USB cable to the USB jack on your
player, and the large connector to a USB port on the computer.
After “USB mode” is displayed, “Charging” is displayed and charging starts
automatically.
Basic Operations
to the USB jack to a USB port
USB cable (supplied)
Battery duration*2
MP3 format playback (128 kbps): Approximately 18 hours
FM radio reception: Approximately 18 hours
*2 This is when the Power Saving setting is set to “10 sec” (page 36). The battery duration will vary
depending on temperature and usage.
On the remaining battery indication
The battery icon in the display changes as shown below.
The battery power decreases as shown by the battery icon. When “Low Battery” is
displayed, your player cannot play back. In this case, charge the battery.
Notes
• Charge the battery in an ambient temperature of between 5 to 35ºC (41 to 95ºF).
• While “USB mode” is displayed, you can transfer files from the computer to your player, but you
cannot operate the controls on your player.
• The icon above “USB mode” in the display is animated while the player accesses the computer. Do
not disconnect the USB cable when the icon is moving or the file being transferred may be destroyed.
• Use of the player with a USB hub or a USB extension cable is not guaranteed. Always connect the
player to the computer directly using the supplied USB cable.
• Some USB devices connected to the computer may interfere with the proper operation of the player.
• The control buttons on the player are all disabled while it is connected to a computer.
Basic Operations

12 13
Transferring files from a computer to your player
You can transfer files from a computer to your player. Follow the procedure below.
1Connect your player to the computer.
“USB mode” appears on the display.
Tip
• Your player is automatically charged when you connect it to a computer with the
supplied USB cable.
2Click [My Computer]-[removable disk:] on the computer.
3Drag the files you want to transfer to your player and drop them to
the removable disk.
You can also transfer files to your player by dragging a folder.
Notes
• This player is unable to use SonicStage software.
• Do not disconnect the USB cable while file is being transferred. If you do, the file being transferred
may be damaged.
• If the USB cable is disconnected while file is being transferred, unnecessary file may be left in your
player. In this case, transfer usable files back to the computer and format your player (page 36).
• Some files may not be played back with the player due to copyright protection.
• Although you can transfer up to 65,535 files, it may take time to start up the player or display the
file/folder list when using many files or folders.
• Folders of up to 16 levels can be displayed on this player.
Basic Operations (continued)
Listening to audio files
Charge the built-in rechargeable battery before use (page 10) and transfer audio files to
your player (page 12).
Notes
• Before listening to audio files;
− Be sure to disconnect your player from the computer.
− Be sure to deactivate the HOLD function.
• Only MP3/WMA files can be played on this player.
1Connect the headphones to the (Headphone / AUDIO IN) jack
(page 6).
2Press and hold the  button until the display comes on.
3Press the HOME button.
The HOME menu is displayed.
4Press the (up) / (down) / / buttons to select (Music) and
press the  button to confirm.
5Press the (up) / (down) buttons to select an audio file.
To open a folder, press the (up) / (down) buttons to select the folder and press
the  or button to confirm.
6Press the  or button.
The selected audio file starts playing.
Basic Operations

14 15
Playback stops automatically after the last audio file is played, unless the repeat mode
(page 16) is set.
Display
XXXXXXXXXX
XXXXXXXXXX
XXXXXXXXXX
Artist
Album
Track Name
Jazz SHUF
001:23
00002/00020
3 4 5 6
1 2
7
Basic Operations (continued)
To pause playback
Press the  button.
Press again to start playback from the paused point.
To stop playback
Press and hold the  button for 2 seconds.
Press again to start playback from the beginning of the audio file.
Tip
If you keep pressing the  button, the player turns off.
To search for an audio file
To Button operation
Skip to the beginning of the next audio file Press the button.
Skip to the beginning of the current audio file Press the button.
Skip to the beginning of the previous audio file Press the button twice.
To display lyrics
When you store a lyric file (.lrc) of the same name as an audio file in the same folder, the
lyrics are displayed during playback.
1While playing an audio file, press the DISP button to select the track
name and lyric mode (page 38).
Tip
• For information on FM tuner display and operation, see “FM menu” (page 20).
Basic Operations
Artist name/album title/track name
Displays artist name, album title, and track
name currently played back.
Lyrics/information display
Lyrics are displayed during playback
(pages 15, 38).
The file information is displayed when you
switch the display mode to Property mode
(page 38).
Playing status indication
Display the current playback mode (:
playback, : pause) and elapsed time.
EQ mode indication
Displays the current equalizer mode
(page 19).
Repeat mode indication
Displays the current repeat mode if one is
set.
Remaining battery indication
Displays the remaining battery power
(page 11).
Current track number/total track
number
Displays the track number currently selected
or being played back and the total number
of tracks. (Not displayed when you switch
the display mode to Track name and lyrics
mode.)

16 17
Changing the play mode
You can select the play mode by pressing the REPEAT button repeatedly.
Each press changes the mode icon as follows:
Mode Operation
Normal Playback stops automatically after the last
audio file is played.
Repeat All audio files are played back repeatedly.
Single
Repeat
The current audio file is played back
repeatedly.
Folder
Repeat
All audio files in the selected folder are
played repeatedly.
Shuffle All audio files are played back in random
order.
Shuffle
Repeat
All audio files are played back in random
order repeatedly.
A-B
Repeat
The selected section is played back
repeatedly.
Note
• “A-B Repeat” is displayed only when sound is played back.
None (Normal play)
(Repeat)
1 (Single Repeat)
(Folder Repeat)
SHUF (Shuffle)
SHUF (Shuffle Repeat)
A tB (A-B Repeat)
Basic Operations (continued)
Playing a specified section repeatedly
(A-B Repeat)
While playing an audio file, you can set the start point (A) and end point (B) for a section
you wish to play repeatedly.
1Press the REPEAT button while playing an audio file.
2Select the A-B Repeat mode from the play mode.
“A ” is displayed and blinks.
3Press  button to set the start point (A) while playing back.
“B” blinks.
4Press the  button to set the end point (B).
“A B” is displayed and the specified section is played back repeatedly.
Notes
• You cannot set A-B Repeat for a section that overlaps two or more audio files.
• If you do not set the end point (B), it is automatically set to the end of the audio file.
Basic Operations

18 19
Using the menus
3Press the (up) / (down) buttons to select an option and press
the  or button to confirm.
Setting option Description
EQ Selects the equalizer mode from Normal, Pop, Rock, Classics, Jazz,
Bass, or User EQ. When selecting User EQ, you can adjust the
frequency and level using the (up) / (down) / / buttons.
Animation Selects the animation displayed when Animation display mode is
selected (page 39).
Delete* Deletes the selected file.
* Note the following.
– Files cannot be deleted during playback or pause.
– Folders cannot be deleted on the Music option menu.
– If there is no audio file on your player, the “Delete” option does not appear.
4Press the (up) / (down) buttons to set the value and press the
 or button to confirm.
5To set another item, repeat steps 3 and 4.
Using the menus
Music menu
You can select the equalizer, and animation display.
1On the HOME menu, press the (up) / (down) / / buttons to
select (Music) and press the  button to confirm.
2Press the OPTION button.
EQ:Normal
Animation:A
Delete
Option
