Sony SRP-X351P User manual

2-347-110-12 (2)
2001 Sony Corporation
SRP-X351P
POWEREDMIXER
Table of Contents
Operating Instructions
Thank you for purchasing a Sony Powered Mixer.
Before operating, please read this manual carefully.
Be sure to keep it properly for future reference.
WARNING ....................................
Features .......................................
Location and Function of Parts .
Installation of The Tuner Unit ....
Dimensions..................................
Block Diagrams...........................
Specifications..............................
Troubleshooting..........................
2
3
4
9
11
12
13
Back Cover

2
WARNING
For customers in the U.S.A
To prevent fire or shock
hazard, do not expose the
unit to rain or moisture.
To avoid electrical shock, do
not open the cabinet. Refer
servicing to qualified
personnel only.
This symbol is intended to alert
the user to the presence of
uninsulated “dangerous
voltage” within the product’s
enclosure that may be of
sufficient magnitude to
constitute a risk of electric
shock to persons.
This symbol is intended to alert
the user to the presence of
important operating and
maintenance (servicing)
instructions in the literature
accompanying the appliance.
CAUTION
You are cautioned that any changes or
modification not expressly approved in
this manual could void your authority
to operate this equipment.
INFORMATION
This equipment has been tested and
found to comply with the limits for a
Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are
designed to provide reasonable
protection against harmful interference
in a residential installation. This
equipment generates, uses, and can
radiate radio frequency energy and, if
not installed and used in accordance
with the instructions, may cause
harmful interference to radio
communications.
However, there is no guarantee that
interference will not occur in a
particular installation. If this equipment
does cause harmful interference to
radio or television reception, which can
be determined by turning the
equipment off and on, the user is
encouraged to try to correct the
interference by one or more of the
following measures:
• Reorient or relocate the receiving
antenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment into an outlet
on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced
radio/TV technician for help.
Français
AVERTISSEMENT
Afin d’éviter tout risque d’incendie
ou d’électrocution, ne pas exposer
l’appareil à la pluie ou à l’humidité.
Afin d’écarter tout risque
d’électrocution, garder le coffret
fermé. Ne confier l’entretien de
l’appareil qu’à un personnel qualifié.
• Faites uniquement fonctionner cet
appareil sur une tension de 120 V
CA, 50/60 Hz.
For customers in Canada
This ClassB digital apparatus complies
With Canadian ICES-003.
Owner’s Record
The model and serial numbers are located
on the side of the unit. Record the serial
number in the space provided below.
Refer to them whenever you call upon
your Sony dealer regarding this product.
Model No. SRP-X351P
Serial No. _______________
IN NO EVENT SHALL SELLER BE
LIABLE FOR ANY DIRECT,
INCIDENTAL OR
CONSEQUENTIAL DAMAGES OF
ANY NATURE, OR LOSSES OR
EXPENSES RESULTING FROM
ANY DEFECTIVE PRODUCT OR
THE USE OF ANY PRODUCT.

3
Powered Mixer Has 170W+170W(4Ω) Power Amplifier,
and 4 Microphones, 3 Line Inputs.
Built-in power amplifier satisfy a small PA system with
170W+170W (4Ω) output.
Mixing of 4 microphone inputs and 3 stereo (line) inputs
Line input (ST3) can be select 4 AV's one.
Wireless Tuner Unit Can Be Installed
Two UHF SYNTHESIZED TUNER UNIT WRU-806A
can be installed.
Wireless microphone system can be easy to setup.
Wireless Remote Controller supplied
AV input selection, master volume and MUTING can be
controlled.
Simple work of Sony's CD player or MD player, Cassette
Deck can be operated*.
*AV equipment supplied with a wireless remote control or with
Control-S terminal only
Exclusive Input Connectors for Recording Equipment
Line input (ST2) is separated from REC bass to avoid
oscillation comes from flowing of its own signal.
Features
Enough Number of Input/Output Terminals, Various
Function
1The master input to connect equalizer or limiter.
2The ECHO SEND/RETURN terminals for connect
Echo equipment
3The ASSIGN SWITCH cuts the microphone signals
from MASTER OUTPUT.
4Tone control (BASS, TREBLE), BALANCE switch of
stereo/monaural and MUTING button.
5The MIC GROUP knob for centralized control of
summing signal from 4 microphone inputs.
6The CONTROL-S terminal
7The RS-232C REMOTE terminal
8EIA standard 19 inch rackmountable (3U high)

4
Location and Function of Parts
1POWER button
Pressing it turns on the power.
2Wireless remote control sensor
It catches the signal from the infrared wireless remote
control.
If this sensor is covered by something, the remote
control may not function correctly. Place the unit so
that the sensor will be easy to receive the remote
control signal.
3ECHO/AUX SEND knob
It adjusts the mixed signals after each channel fader
and outputs to the ECHO SEND terminal.
4RF/SIGNAL indicators
They light up regardless of the position of channel
fader when sound signal of more than -20dB to the
standard input level are input.
As for MIC 1/MIC 2 would be light up when it
received the signal while the wireless tuner unit is
installed and switch of the microphone is turned on.
5ECHO RETURN switch
When it is ON, the signal from the ECHO RETURN
input are assigned to L/R and Rec Bus.
6MUTING button
Use muting outputs from MASTER OUTPUT,
MASTER INSERT, ECHO SEND, MIC GROUP
OUT, and SPEAKER output terminals.
7CLIP indicator
Too high an output level will cause signal distortion
and make the CLIP indicator light up. When this
happens, lower the MASTER volume or the MIC/
LINE level knob until the indicator turns off. If too
much signal output for an extended period, it may
cause the equipment to overheat or to damage the
speakers.
8PROTECTION indicator
It lights up while the protection circuit is working.
When the power is turned on, it also lights up for few
seconds and it turns off when the amplifier become
stable.
9EMG indicator
It lights up when the unit receives a signal from the
emergency broadcast facilities and turns to standby.
As for EMG, refer to P. 75.
0+48V indicator
It lights up while the DC+48V is supplied through the
MIC input terminal.
!¡ MASTER VOLUME
Use to adjust the volume of MASTER OUTPUT and
SPEAKER terminal.
!™ MIC 4 terminal
This is input terminal in front for wired microphone.
If the wired microphones are connected to the MIC 4
terminals both at front and rear panel, the front input
is given priority.
Note : When you use the MIC 4, check the balanced
connection.
12 34 5678 !¡ 90
!∞
!£
!™ !¢
Front panel
RF/
SIGNAL
ECHO/
AUX SEND
PLAYER PLAYER/RECORDER
ØON øOFF
A
B
C
D
ECHO RETURN
MUTING
MIC GROUP BASS
MIN MAX
CLIP PROTECTION
MASTER VOLUME
EMG +45V
+10
+5
0
-5
-15
-25
+10
+5
0
-5
-15
-25
+10
+5
0
-5
-15
-25
ØON øOFF
MIC4
MIC1
RF/
SIGNAL
MIC2
SIGNAL
MIC3
SIGNAL
MIC4
SIGNAL
ST1
SIGNAL
ST2
SIGNAL
ST3
TREBLE
MIN MAX
BALANCE
LR
!ª!¶!§ !• @£@™@¡@º

5
!£ MIC 1/MIC 2 fader knobs
Use to adjust the mixing level of MIC 1/MIC 2.
Either the wireless microphone or the wired micro-
phone can be used in MIC 1/MIC 2.
(Refer to page 6 and page 9.)
When the WRU-806A (optional) is put in to the tuner
unit compartment at the rear panel, the wireless
microphone is given priority while it is on.
!¢ MIC 3 fader knob
Use to adjust the mixing level of MIC 3.
Only the wired microphone can be used in MIC 3.
!∞MIC 4 fader knob
Use to adjust the mixing level of MIC 4.
!§ ST1 fader knob
Use to adjust the mixing level of ST1.
A playback equipment will be connected to it mainly.
!¶ ST2 fader knob
Use to adjust the mixing level of ST2.
The sound signal of this channel is not output to the
REC OUTPUT terminal; you can use without being
bothered about oscillation from signal loop.
!ª SELECT buttons
Use to select one of the unit connected to ST3 A to D
input.
S VIDEO and VIDEO signal from the selected input
is directly output to the MASTER OUTPUT and the
REC OUTPUT.
The mixing level of the sound signal can be adjusted
by ST3 fader knob.
@º MIC GROUP knob
Use to adjust the level of the signal after mixing in
MIC 1 to 4 in a lump.
The signal will be output from the MIC GROUP OUT
terminal.
@¡ BASS control knob
Use to adjust low frequency among the sound from
the MASTER OUTPUT or SPEAKER terminal.
@™ TREBLE control knob
Use to adjust high frequency among the sound from
the MASTER OUTPUT or SPEAKER terminal.
@£ BALANCE adjustment knob
Use to adjust the balance of left and right of the sound
from the MASTER OUTPUT or SPEAKER terminal.
Note
When the PROTECTION indicator lights up
The protection circuit triggers and the PROTECTION indicator
lights up in following conditions. In this case, the speaker and
amplifier are protected by cutting output.
•When direct-current voltage appears in the SPEAKER
terminal from a malfunction.
•When rated temperature of amplifier internal heat sink is
exceeded.
•When impedance of the connected speaker is too low, or
when speaker outputs are shorted.
When the above happens, turn off the POWER switch, find
and fix the cause of the problem, and restart.
!• ST3 Fader knob
Use to adjust the level of the signal from AV equip-
ment selected by the SELECT button stated in !ª.
SRP-X351P Recorder/Player
When
recording
OUTPUT
INPUT
INPUT
OUTPUT
×REC
Sound signal of
except ST2
ST2
MASTER

6
1ANT IN (antenna input) A/B terminals
Use to connect the antenna for wireless tuner. When
installing the tuner unit, connect the optional UHF
antenna AN-820A.
Note
Before locating and connecting the antenna, read carefully the
instructions supplied with the antenna.
Incorrect location of the antenna may cause a bad reception
such as intermittent sounds. If it is not easy to relocate the
antenna after location, check carefully if the performance will
be satisfied with the location.
Use the coaxial cable of impedance 50 ohms/75 ohms (5D-FB,
5C-2V, etc.). The cable can be extended up to about 50 m with
5D-FB, and up to about 25 m with 5C-2V.
2Tuner unit slot (MIC1, MIC2)
These are for installation of the optional wireless
tuner unit WRU-806A. Up to two units can be
installed. (Refer to page 9 and page 10)
Before installation, read carefully also the instructions
of WRU-806A.
3REMOTE terminals
CONTROL S input terminal
Connect to the S output terminal of another equip-
ment.
When this terminal is plugged in, the sensor of this
unit is not functioning.
Input signals are directly output from control S output
terminal.
CONTROL S output terminal
This terminal outputs the signal input from CON-
TROL S input terminal or the sensor.
RS-232C (serial input/output) terminal
This model can be controlled by the external controll
equipment through this terminal using a null modem
cable.
Terminal : D-sub 9 pin, male,
inch type screw
Electrical specification : Based on RS-232C standard
Recommended cable : Multicore shielded cable for
data communication
Cable length : 15m or under
For protocols, please consult your dealer.
1234567
0
89 !∞!£!™ !¢
Rear panel
!§
Pin No. Signal Function
1 N.C Not connected
2 RD Received data
3 TD Transmission data
4 ER Data terminal ready
5 SG Signal line grand
6 DR Data set ready
7 RS Transmission request
8 CS Transmission approval
9 N.C Not connected
15
69
!¡
Location and Function of Parts
!¶

7
‘’
4MASTER INSERT (Tip: output, Ring:
input, Sleeve: GND)
These are input/output terminals for MASTER
OUTPUT. An external equipment can be inserted
before master volume.
5EMG input terminals
This terminal receives signal from the emergency
broadcast facilities and makes this unit be in standby.
In this case, the EMG indicator on the front panel
lights up.
Select one of following two ways of connection as
follows.
When using the BREAK CONTACT terminal
Remove the short bar and connect the Relay of the
emergency broadcast facilities. When the relay is
contact is breaked, all AUDIO outputs of this unit will
be cut off.
When using the +24V IN terminal
This terminal receives signals of DC24V from the
emergency broadcast facilities.
When DC24V is cut off, all AUDIO outputs of this
unit will be cut off.
8MIC input terminals (1:GND 2:HOT
3:COLD)
This is the input terminals for microphones.
In MIC1 and MIC2, wireless microphone has priority
while the tuner unit is used. (Refer to page 44.)
9+48V button
It supplies the DC+48V to the MIC 1 - 4 terminals for
condenser microphones.
When it is ON, DC+48V is output for the MIC
terminals except for the MIC4 on the front panel.
Notes
•Make sure to turn the MIC fader toward minimum before
connecting or disconnecting any cable or turning the +48V
button to ON.
•Make sure to connect a line equipment to ST1 to ST3 inputs.
•When using a microphone powered by +48V and a dynamic
microphone simultaneously, the dynamic microphone may
not show its performance to the full.
6CIRCUIT BREAKER
When over-current flows into the unit, the circuit
breaker cuts the power. In this case, remove the cause
of over-current and reset the breaker by pressing
RESET button.
7SPEAKER output terminals
Connect with the speakers. Connect + of the speaker
to the red terminal and - to the black terminal. Use
the speaker of 4 to 16 impedance.
0ST1/ST2 input terminals
Use them for inputs from audio equipment.
Connect a player mainly to ST1 and a recorder to
ST2.
!¡ ST3 (AV) input terminals
Use them for inputs from AV equipment.
Each of input A to D is selected by the SELECT
button on the front panel.
!™ MASTER OUTPUT terminals
Signal routed through the Master Volume are output
here.
!£ REC OUTPUT terminals
Signal not routed through the tone control (BASS,
TREBLE), BALANCE and Master Volume are output
here.
Video signal is the same as for MASTER OUT signal.
Remove the short bar of the
BREAK CONTACT terminal
BREAK
CONTACT
Relay
‘’ ‘ ’
←or →
(+24V output)
The emergency broadcast facilities
(＋24VIN)

8
Remote control
1FUNCTION button
Use to select one of ST3 A to D input.
2CD deck operation buttons
Use to operate the Sony Compact Disc Player.
3MD deck operation buttons
Use to operate the Sony Mini Disc Recorder.
4TAPE deck operation buttons (A, B)
Use to operate the Sony Tape Cassette Deck.
5MASTER VOLUME operation knob
Use to adjust the master volume level.
6MUTING button
Use to mute the output signal from MASTER OUT-
PUT, MASTER INSERT, ECHO SEND, MIC
GROUP OUTPUT or SPEAKER output terminals.
!¢ ECHO SEND/RETURN terminals
Connect effectors such as reverbrators and delay units
to this terminal.
SEND terminal
This terminal outputs audio signals mixed by ECHO/
AUX SEND knob of MIC1 to MIC4 and ST1 to ST3
in monaural
RETURN terminals
This is an input terminal for signal returned from the
effector. When the ECHO RETURN switch on the
front panel is set to ON, these are assigned to L and to
R.
Adjust the input level using effector's level controller.
!∞MIC GROUP and ASSIGN switch
MIC GROUP OUTPUT terminal
It outputs signal of which level is adjusted by MIC
GROUP knob.
ASSIGN switch
This is normally on.
When this switch is set to OFF, the microphone signal
for MASTER OUTPUT and SPEAKER terminals are
cut off.
Using this, turn it OFF when a PA system with ceiling
speakers and external power amplifier.
INSERT terminal (Tip: output, Ring: input, Sleeve:
GND)
Use it to connect an external graphic equalizer or a
feedback reducer.
!§ MODE switch
It will be monaural when MASTER INSERT, MAS-
TER OUTPUT and SPEAKER output are set to
MONO.
!¶ POWER cord
Inserting batteries into the remote
AB
C
CD
DISC SKIP
MUTING
MD
TAPE DECK A
TAPE DECK B
MASTER
VOLUME
D
1
2
3
4
5
6
You can control this unit with using the supplied remote.
Insert two R6 (size AA) batteries by matching the + and –
on the batteries. When using the remote, point it at the
remote sensor on the equipment.
When to replace batteries
With normal use, the batteries should last for about six
months. When the remote no longer operates the equip-
ment, replace all the batteries with new ones.
Notes
•Do not leave the remote near an extremely hot or humid
place.
•Do not drop any foreign object into the remote casing,
particularly when replacing the batteries.
•Do not expose the remote sensor to direct sunlight or lighting
apparatuses. Doing so may cause a malfunction.
•If you don't use the remote for an extended period of time,
remove the batteries to avoid possible damage from battery
leakage and corrosion.
Location and Function of Parts

9
Tunerunit
Tunercover
Installation of The Tuner Unit
1Turn off the power of this unit.
2Remove the tuner cover.
3Check the up and down sides of the tuner unit, and
insert it into the slot.
The upper slot corresponds to MIC1 and the lower slot
to MIC2. (Set the group and channel of the tuner unit
to same as wireless microphone's one.)
NOTICE
To prevent breakdown or injury, do not put your hand
inside of the slot except when you install or remove the
tuner unit.
Insert it deeply into the compart-
ment.
Do not insert or remove the tuner
unit while the power is on. This
may be cause of noise or
malfunction of the connector.
4Fix the tuner cover.
After installation of the tuner unit, turn on the power
of the unit and turn on the power of the wireless
microphone to check it is receiving. While receiving,
the RF/SIGNAL indicator lights up. Note that the
RF/SIGNAL indicator will not light up when the
setting channel of the microphone is different from
the setting of the tuner unit, or when the microphone
power is consumed.
Notes
Take the following precautions to prevent interference
and noise.
•If there is a TV broadcasting station nearby, to avoid
possible interference from its broadcasting, do not
use that station's channel.
•When simultaneously using two tuners, always set
the tuners to different channels within the same group
(other than group 00).
•Please make a choice of model in accordance with
your area to use picking up an unused TV channel.
•Make sure that the channel selected on the micro-
phone is the same as that selected on the tuner being
used in the same system.

10
RF AF
DISPLAY
GP CH
BATT
GP
AF
GP CH
BATT
CH
+
_
RF
1
13
24
2
3
4
5
7
6
1AF (audio frequency) indicator
2AF (audio frequency) level indications
The indicator lights and the indications appear when
the audio output level is higher than the reference
level.
3BATT (battery) indicator
4BATT (battery) indication
Indicate the condition of the wireless microphone
transmitter batteries. The indicator and indication
appear and start flashing about one hour before the
transmitter batteries go flat.
The time at which flashing begins will depend on the
type of battery used in the transmitter, and its
condition.
5GP/CH (group/channel) indication
Shows the reception channel group and respective
channel number.
Pressing the + button changes this indication to the
frequency indication.
6RF (ratio frequency) level indications
7RF (ratio frequency) indicator
The indicator lights and the indications (dots) appear
when the antenna reception is optimal. Depending on
the RF input level, the number of dots changes.
Please refer to the table Sony 800MHz-band system models frequency range in the Operating Manual of Wireless Micro-
phone or Transmitter.
1GP (group) button
To change the group, press the + or –button while
holding this button down.
2CH (channel) button
To change the channel in a group, press the + or –
button while holding this button down.
3+ button
To go to a higher group or channel, press this button
while holding the GP or CH button.
Press this button changes the indication from GP/CH
to frequency.
4– button
To go to a lower group or channel, press this button
while holding the GP or CH button.

11
RF/
SIGNAL
ECHO/
AUX SEND
PLAYER PLAYER/RECORDER
ØON øOFF
A
B
C
D
ECHO RETURN
MUTING
MIC GROUP BASS
MIN MAX
CLIP PROTECTION
MASTER VOLUME
EMG +45V
+10
+5
0
-5
-15
-25
+10
+5
0
-5
-15
-25
+10
+5
0
-5
-15
-25
ØON øOFF
MIC4
MIC1
RF/
SIGNAL
MIC2
SIGNAL
MIC3
SIGNAL
MIC4
SIGNAL
ST1
SIGNAL
ST2
SIGNAL
ST3
TREBLE
MIN MAX
BALANCE
LR
336 (13 1/4)
482 (19)
57.2 (2 3/8)
24 (31/32)
52
(2 1/8) 350 (13 7/8) 30 (1 3/16)
13 (17 /32)
238 (9 3/8)
132 (5 1/4)
8 (11/32)
Dimensions
Unit;mm(inches)

12
Block Diagrams
WRU-806A
WIRELESS
+48V
+48V
+48V
+48V
HA
HA
LCF
LCF
RF/Signal IND
MIC GROUP BUS
MIC
GROUP MIC
ASSIGN
SW
MONO
STEREO
MODE
TREBLE BASS
BALANCE
MASTER
MASTER INSERT
MASTER OUTPUT
REC OUTPUT
REMOTE
CONTROL-S OUT
S-Video
Video
-5dBu
L
R
S-Video
Video
-10dBu
EMG
EMG CONTROL
AC IN
POWER
SW
CIRCUIT BRAKER
L
R
L
R
SREAKERS OUTPUT
125W+125W 8Ω
170W+170W 4Ω
L
R
PROTECTION
CLIP
MIC GROUP OUTPUT
-10dBu
MIC GROUP INSERT
-10dBu
ECHO SEND
-10dBu
ECHO BUS
REC L
REC R
Signal IND
Signal IND
Signal IND
Signal IND
ECHO
ECHO
MIC 1
-54dBu
MIC 2
-54dBu
MIC 3
-54dBu
MIC 4
-54dBu
ST 1
-10dBu
for Player
ST 2
-10dBu
ST 3 Ach
ST 3 Bch
ECHO
RETURN
L
A B C DMute
RECHO
RETURN
ECHO
ECHO
ECHO
ECHO
REMOTE
RS-232C
RS-232C Controller
REMOTE
CONTROL S IN
IR
Same as ST3 Ach
Same as MIC1
Same as MIC4
(without phone jack)
Same as ST3 Ach
Same as ST3 Ach
ST 3 Cch
ST 3 Dch
for Player/
Recorder
CH Fader
CH Fader
-10dBu
S-Video
Video
L
R
L
R
L
R
M
Main Controller

13
AUDIO INPUT/OUTPUT SPECIFICATIONS
Name Connector Type Number of channels
Reference Max Input
input output level input output level output impedance
MIC IN (REAR) XLR-3-31 4 -54dBu -24dBu 2.2kΩ
(FRONT) PHONE
ST1 input Phono Jack 1(Stereo) -10dBu +20dBu 20kΩ
ST2 input Phono Jack 1(Stereo) -10dBu +20dBu 20kΩ
ST3 input(A,B,C,D) Phono Jack 4(Stereo) -10dBu +20dBu 20kΩ
Echo return input Phono Jack 1(Stereo) -10dBu +10dBu 20kΩ
Mic group output Phono Jack 1 -10dBu +10dBu 470Ω
Echo send Phono Jack 1 -10dBu +10dBu 470Ω
Master output Phono Jack 1(Stereo) -5dBu +15dBu 470Ω
Rec output Phono Jack 1(Stereo) -10dBu +10dBu 470Ω
Speakers output Screw type 1(Stereo) Rated output 125W + 125W (8Ω1kHz THD 0.1%)
binding terminal 170W + 170W (4Ω1kHz THD 0.1%)
VIDEO INPUT/OUTPUT SPECIFICATIONS
ST3 input(A,B,C,D)
(S-VIDEO) Mini-DIN 4 1Vp-p(Y) 75Ω
(VIDEO) Phono Jack 4 1Vp-p 75Ω
Master output /Rec output
(S-VIDEO) Mini-DIN 2 1Vp-p(Y) 75Ω
(VIDEO) Phono Jack 2 1Vp-p 75Ω
CONTROL TERMINAL SPECIFICATIONS
RS-232C terminal D-sub 9 male 1 7 function is controled
CONTROL-S input φ 3.5 jack 1
CONTROL-S output φ 3.5 jack 1 Through out from input
EMG CONTROL Screw type 1 Break contact, 24V signal control (Active "break")
terminal
OTHER TERMINALS
Antenna in BNC 2 DC 9V out 35mA max
+48V power supply MIC 1 to 4 XLR terminals only
ELECTRICAL CHARACTERISTICS
ITEM MEASUREMENT CONDITIONS STANDARD
Frequency response 20 to 20kHz, 1kHz reference, master output +0.5, -1dB
Total harmonic distortion MIC IN-Master output, 1kHz -54dBu input less than 0.05%
ST input -Master output, 1kHz -10dBu input less than 0.01%
Input conversion noise level MIC IN input, 150Ωtermination, IHF-A less than -126dBu
S/N ratio ST input, input short, IHF-A more than 85dB
Residual noise level Master volume 0, IHF-A, Speaker output less than 100µV
Crosstalk 1kHz, between L-R channels less than -60dB
1kHz, between input channels less than -80dB
TONE MIC L.C.F fc=100Hz -12dB/oct
TREBLE 10kHz (shelving type) ±12dB
BASS 60Hz (peaking type) ±12dB
Frequency response 50 to 10MHz, reference 3.58MHz +0.5dB, -1dB
Crosstalk 3.58MHz, 1Vp-p less than -50dB
S/N ratio 100kHz, H.P.F, 5MHz, L.P.F more than 65dB
Frequency response 50 to 10MHz, reference 3.58MHz +0.5dB, -1dB
Crosstalk 3.58MHz, 1Vp-p less than -50dB
S/N ratio 100kHz, H.P.F, 5MHz, L.P.F more than 65dB
0 dBu = 0.775 V
Specifications
Power requirement AC 120V 60Hz
Power consumption 4A
Dimensions 482 ×132 ×350 mm (w/h/d)
(19 ×5 1/4 ×13 7/8 inches)
(excluding protrusions)
Mass 15kg (33 lb 1 oz)
Operating temp. 0°C to 40°C
Storage temp. -20°C to 60°C
Supplied accessories Operating instructions (1)
Remote control (SRP-351RM) (1)
Battery R6 SIZE AA (2)
Recommend accessory UHF antenna AN-820A
Wireless tuner unit WRU-806A
Design and specifications are subject to change without notice.
AUDIO SYSTEM VIDEO
SYSTEM
S-VIDEO

14
Troubleshooting
Power will not turned on. •Is the power cord unplugged?
•Is the circuit breaker working? (See page 7.)
No sound. •Does the EMG indicator turn off? (See pages 4 and 7.)
•Does the PROTECTION indicator turn off? (See page 4.)
No sound is output to MASTER OUTPUT •Has the ASSIGN switch been set to OFF? (See page 8.)
or SPEAKER terminals from microphone. •Has the MIC GROUP knob been set to –∞? (See page 5.)
No sound from wireless microphone. •Is the channels of microphone and tuner unit matching?
And does the RF/SIGNAL indicator light on when the microphone
is turned on? (See page 9.)
•Is the antenna connected correctly?
Sound is heard in monaural. Has the MODE switch been set to STEREO? (See page 8.)
Sound is distorted. Is the CLIP indicator lighting on? (See page 4.)
No sound from MIC4. Has another microphone been connected to MIC4 terminal
on the front panel?(See page 4.)
Wireless remote control does not function. •Has a plug been connected to CONTROL-S input terminal
on the rear panel?(See page 6.)
•Are the remote control batteries dead?(See page 8.)
Signal of the ST2 can not be recorded. Signal from ST2 does not output to REC OUTPUT. (See page 5.)
http://www.world.sony.com/
Printed on recycled paperSony Corporation Printed in Japan
