Sony UP-CR10L User manual

2-666-583-16 (1)
Digital Photo Printer
UP-CR10L
© 2005 Sony Corporation
Operating Instructions
Before operating the unit, please read this manual thoroughly and
retain it for future reference.

2
Owner’s Record
The model and serial numbers are located at the rear.
Record these number in the space provided below.
Refer to these numbers whenever you call upon your Sony
dealer regarding this product.
Model No. ____________________
Serial No. ____________________
To reduce the risk of fire or electric shock, do not
expose this apparatus to rain or moisture.
To avoid electrical shock, do not open the
cabinet. Refer servicing to qualified personnel
only.
THIS APPARATUS MUST BE EARTHED.
Note
The location and design of the unit’s power control and the
supplied accessories differ depending on the serial number
found on the manufacturer label located at the rear of the
unit. These differences are described in this document
whenever they arise.
For units with serial numbers starting with
51 only
To disconnect the main power, unplug the AC IN
connector.
For units with serial numbers starting with
11 only
This unit has no power switch.
When installing the unit, incorporate a readily accessible
disconnect device in the fixed wiring, or connect the power
plug to an easily accessible socket-outlet near the unit.
If a fault should occur during operation of the unit, operate
the disconnect device to switch the power supply off, or
disconnect the power plug.
For the customers in the U.S.A.
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
You are cautioned that any changes or modifications not
expressly approved in this manual could void your
authority to operate this equipment.
All interface cables used to connect peripherals must be
shielded in order to comply with the limits for a digital
device pursuant to Subpart B of Part 15 of FCC Rules.
If you have any questions about this product, you may call;
Sony Customer Information Service Center 1-800-222-
7669 or http://www.sony.com/
For the customers in Canada
This Class B digital apparatus complies with Canadian
ICES-003.
Warning on power connection
Use a proper power cord for your local power supply.
1. Use the approved Power Cord (3-core mains lead)/
Appliance Connector/Plug with earthing-contacts that
conforms to the safety regulations of each country if
applicable.
2. Use the Power Cord (3-core mains lead)/Appliance
Connector/Plug conforming to the proper ratings
(Voltage, Ampere).
If you have questions on the use of the above Power Cord/
Appliance Connector/Plug, please consult a qualified
service personnel.
WARNING
Declaration of Conformity
Trade Name : SONY
Model : UP-CR10L
Responsible Party : Sony Electronics Inc.
Address : 16530 Via Esprillo, San Diego,
CA 92127 U.S.A.
Telephone Number: 858-942-2230
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
English

3
For the customers in Europe
The manufacturer of this product is Sony Corporation, 1-
7-1 Konan, Minato-ku, Tokyo, Japan.
The Authorized Representative for EMC and product
safety is Sony Deutschland GmbH, Hedelfinger Strasse
61, 70327 Stuttgart, Germany.
For any service or guarantee matters, please refer to the
addresses given in separate service or guarantee
documents.
For kundene i Norge
Dette utstyret kan kobles til et IT-strømfordelingssystem.
For the customers in the U.S.A.
Lamp in this product contains mercury. Disposal of these
materials may be regulated due to environmental
considerations. For disposal or recycling information,
please contact your local authorities or the Electronic
Industries Alliance (www.eiae.org).

4Table of Contents
Table of Contents
Chapter 1 Outline
What This Product Can Do .............................................................6
Supplied Documentation ................................................................7
Information Updates........................................................................7
Chapter 2 Preparations
Supplied Accessories .....................................................................8
Controls and Functions ..................................................................9
Front ...................................................................................................... 9
Rear ..................................................................................................... 10
Installation......................................................................................11
Connecting the Power Cord ................................................................ 11
Adjusting the Display Angle ............................................................... 11
Loading Paper Roll and Ribbon Cartridge .......................................... 12
Attaching the Paper Tray..................................................................... 18
Preparing an Expansion CompactFlash Card...................................... 19
Startup and Shutdown ..................................................................20
Startup ................................................................................................. 20
Shutdown............................................................................................. 21
Checking the Ribbon Cartridge Remainder ........................................ 21
Chapter 3 Setup
Setup Procedure ............................................................................22
Setting Items ..................................................................................23
System Tab .......................................................................................... 23
Screens Tab ......................................................................................... 24
Template Tab....................................................................................... 25
Text Input Screen ................................................................................ 25
Print Tab .............................................................................................. 26
Print Color Tab.................................................................................... 26
Pricing Tab .......................................................................................... 27
Administration Tab.............................................................................. 28

Table of Contents 5
Chapter 4 Operation
Operation Outline ..........................................................................30
Print Types .......................................................................................... 30
Operation Flow.................................................................................... 31
Setting Memory Cards...................................................................32
Using a “Memory Stick” ..................................................................... 32
Using a CompactFlash Card................................................................ 32
Using a SmartMedia Card ................................................................... 33
Using a SD Card/MultiMediaCard...................................................... 33
Using a xD-Picture Card ..................................................................... 34
Using Bluetooth communication......................................................... 34
Selecting Images for Printing .......................................................34
Verifying Order Contents and Entering a Password ........................... 37
Using Index Print ...........................................................................38
Using Split Image Print .................................................................39
Using Border Print.........................................................................41
Printing All Images on a Memory Card........................................44
Image Editing .................................................................................45
Specifying the Layout (Crop & Rotate) .............................................. 46
Adjusting the Image Quality ............................................................... 47
Printing in Sepia or Black and White.................................................. 47
Compensating for the Red Eye Effect ................................................. 48
Adding the Date .............................................................................49
Printing From DPOF Settings .......................................................49
Printing With Bluetooth® Communication..................................50
Preparing for Bluetooth communication ............................................. 50
Printing from Bluetooth-compatible devices ...................................... 50
Entering Passwords Using Memory Cards
(Remote Password Input).......................................................52
Creating password files ....................................................................... 52
Entering passwords using memory cards ............................................ 52
Printing From a Computer ............................................................53
Installing the Printer Driver................................................................. 53
Connection to a Computer................................................................... 53
Appendix
Precautions ....................................................................................54
Supported Memory Cards and File Formats ...............................55
Notes on Using Memory Cards ........................................................... 55
Cleaning..........................................................................................58
Cleaning the Inside of the Printer........................................................ 58
Troubleshooting ............................................................................61
Ribbon Cartridge and Paper .........................................................61
Specifications ................................................................................62

6What This Product Can Do
Chapter 1 Outline
Chapter1
Outline
What This Product Can
Do
This device reads image data from memory cards used by
devices such as digital cameras and prints out photos of
superb quality. It also prints out data sent from a computer.
The product has the following features.
Versatile print services
Besides regular photo printout, the unit can produce split
image prints, prints with borders, and index prints. It also
allows the user to edit images before printing with
functions such as trimming and color adjustment.
Order numbers can be printed as a watermark, making
print sorting easy.
Selectable operation modes
To fit the environment where the unit is used, Full mode,
Quick Print mode, and Event mode can be selected.
Support for a wide range of memory cards
All major memory card formats used in digital cameras are
supported: “Memory Stick”, xD-Picture Card, SD Card,
MultiMediaCard, CompactFlash card, Microdrive, and
SmartMedia card.
High-speed high-quality printing
Using a newly developed print engine that features a
dyesublimation thermal transfer technology, it is possible
to print images of lasting beauty at high speed.
Easy operation by touch panel
An 8-inch touch panel display is used, allowing for easy
operation with just a touch of the screen.
Also, by incorporating a paper roll and ribbon cartridge
system, replacement of the paper and ribbon is a snap.
Customizable with original data
By inserting a memory card (expansion CompactFlash
card) carrying promotional images and border data into the
expansion slot, screen savers can be displayed and photos
can be combined with borders for printing.1) Original
images can be used for the screen saver and border data.
Printing with Bluetooth®wireless
technology
Using an optional Bluetooth USB adaptor 2), you can send
images from Bluetooth-compatible devices such as mobile
phones and print wirelessly. The versatile print services
available when printing from a memory card are also
available when sending images via Bluetooth
communication.
An expansion CompactFlash card is necessary to use this
function.
Compact, integrated body
The display and printer are housed in a single enclosure
which does not take up much space and easily fits on a
shop counter or similar.
In addition, the screen angle can be adjusted to eight
different settings to fit operation conditions.
1) A commercially available CompactFlash card or
Microdrive is required.
2) For more on compatible Bluetooth USB adaptors, see
“Optional accessories” on page 62 of “Specifications.”
The adaptor may not be commercially available
depending on your country or region. Consult your
local Sony dealer.

7
Supplied Documentation / Information Updates
Chapter 1 Outline
Supplied Documentation
The product comes with the following documentation.
Instruction Manual (this document)
The Instruction Manual is aimed at owners of the product
and contains detailed information about the following
topics:
• Installation
•Setup
• Printing image data stored on memory cards
• Troubleshooting
Basic Operation Guide (PDF)
The Basic Operation Guide file contains simple
instructions and information about the topics listed below.
You should print out parts of this file as necessary and post
them near the product for user guidance.
• How to print photos in Full mode (aimed at customers)
• How to print photos in Quick Print mode (aimed at
customers)
• Maintenance (aimed at shop personnel)
Printer Driver Installation Guide (PDF)
The Printer Driver Installation Guide explains how to
install and use the printer driver for the unit on a computer.
Adobe Photoshop Plug-in Module User’s
Guide (PDF)
The Adobe Photoshop Plug-in Module User’s Guide
explains how to install the Photoshop plug-in and how to
use Photoshop to create templates for prints with borders.
Connection Manual to Job Ticket Printer
(PDF)
The Connection Manual to Job Ticket Printer explains the
steps involved in connecting the UP-CR10L to a
commercially available thermal receipt printer and
printing job tickets.
Trademarks
The following words are trademarks of their respective
owners.
• “Memory Stick”, “MagicGate Memory Stick”,
“Memory Stick Duo”, “Memory Stick PRO”, and
“Memory Stick PRO Duo” are trademarks of Sony
Corporation.
• CompactFlash is a trademark of SanDisk Corporation,
registered in the United States and other countries.
• SmartMedia is a registered trademark of Toshiba
Corporation.
• MultiMediaCard is a trademark of Infineon
Technologies AG.
• Microdrive is a registered trademark of Hitachi Global
Storage Technologies.
• miniSD is a trademark of SD Card Association.
• Adobe and Photoshop are either registered trademarks or
trademarks of Adobe Systems Incorporated in the
United States and/or other countries.
• xD-Picture Card is a trademark of Fuji Photo Film Co.,
Ltd.
• The Bluetooth®word mark and logos are owned by the
Bluetooth SIG, Inc. and any use of such marks by Sony
Corporation is under license.
• Other product names are the registered trademarks or
trademarks of their respective manufacturers.
Information Updates
For the latest information, please visit the UP-CR10L
support page at http://www.sony.net/snaplab.

8Supplied Accessories
Chapter 2
Preparations
Chapter2
Preparations
The location and design of the unit’s power control and the
supplied accessories differ depending on the serial number
found on the manufacturer label located at the rear of the
unit. These differences are described in this document
whenever they arise.
Supplied Accessories
Make certain you have received the following accessories:
• When taking the unit out of the carton box, be careful not
to hurt your back.
• The packaging materials are needed when transporting
the unit, so we suggest you keep them.
• Before transporting the unit, remove the ribbon cartridge
and paper roll from the unit.
• Before transporting the unit, also remove any paper
remnants from the paper holder. The paper remnants
may slip into the inner parts of the unit and result in
damage if not removed.
Note
Paper Tray (1)
USB Cable (with Ferrite Core) (1) 3)
Ferrite Core (1) 4)
CD-ROM (1)
Power Cord (1)
Paper Holder 1) These accessories are stored in the paper holder.
Paper Core (1) Adaptor (left,1) Adaptor (right,1)
Before Using this Printer (1)
Software License Agreement (1)
Warranty Card (1)
1) The paper holder is stored in the printer. Be sure to remove the paper holder from the inside of the printer before turning the power on.
2) For information on use, see the section “Cleaning the Inside of the Printer” on page 58.
3) For units with serial numbers starting with 11 only.
4) For units with serial numbers starting with 51 only.
Cleaning Cartridge (1) 2)
Notes

9
Controls and Functions
Chapter 2
Preparations
Controls and Functions
Front
aDisplay
Shows the operation screen. Because the display is a touch
screen, the user simply touches the field for the desired
operation. The angle of the display can be adjusted for best
viewing.
bAccess indicator
Lights when a memory card is inserted a slot, and flashes
when a memory card is being accessed.
c“Memory Stick” slot (page 32)
Holds a “Memory Stick” with stored image data.
dxD-Picture Card slot (page 34)
Holds an xD-Picutre Card with stored image data.
eSD Card/MultiMediaCard slot (page 33)
Holds an SD Card or MultiMediaCard with stored image
data.
fSmartMedia card slot (page 33)
Holds a SmartMedia card with stored image data.
gCompactFlash card slot (page 32)
Holds a CompactFlash card with stored image data.
To avoid loss of image data or damage to the main unit,
never attempt to insert a “Memory Stick”, SmartMedia
card, SD Card, or MultiMediaCard into a CompactFlach
type adapter set in the CompactFlach slot.
hEject slot
The printed photo emerges from this slot.
iPaper tray (page 18)
Printed photos are collected in this tray.
jPaper eject stopper (page 18)
When using the print pack 2UPC-C13, this stopper should
be raised.
kFront door (page 12)
Open this door to change the paper roll.
qsqa98
1
2
67
34 5
0
Note

10 Controls and Functions
Chapter 2
Preparations
Front door open
APaper holder (page 12)
The paper roll is inserted here.
The white areas between printouts are cut off and
collected in the top portion of the paper holder.
BPaper holder release button (page 12)
Press this button to remove the paper holder.
lSide door (page 15)
Open this door for replacing the ribbon cartridge and
inserting the expansion CompactFlash card.
Side door open
ARibbon cartridge access opening (page 15)
Mount the ribbon cartridge here.
BExpansion CompactFlash card slot (page 19)
When using border print, promotional images display,
text input, or print spool, insert the expansion
CompactFlash card here.
Rear
For units with serial numbers starting with 11
For units with serial numbers starting with 51
aUSB port (host)
Allows connection of a USB device.
You can connect a commercially available card reader or
USB flash memory device to this port and use it to read
data.1)
To use Bluetooth communication, insert a Bluetooth USB
adaptor here.
1) Correct operation with every card reader and USB flash
memory device is not guaranteed.
Operation is not guaranteed when connected by a USB
hub.
PictBridge is not supported.
bUSB port (device) (page 53)
Use a USB cable to connect the unit to a computer.1)
1) Operation is not guaranteed when connected by a USB
hub.
AB
AB
1
2
3
5
4
6
7
The seven-digit serial number
is located here.
1
8
2
3
4
6
7

11
Installation
Chapter 2
Preparations
c~ AC IN (Power Source) Connector (page 11)
Connect the supplied power cord here.
dDisplay stand
Use this stand to adjust the angle of the display.
eOn/Standby button (for units with serial numbers
starting with 11 only)
Press this button to turn on power to the unit. Press it again
to enter the standby mode.
To restart the unit from standby mode, wait at least 5
seconds in standby mode, and then press the On/Standby
button.
fRS-232C interface
Serves for future expansion. Currently not used.
gAir vent
Features a built-in filter for the thermal head cooling fan.
hPOWER switch (for units with serial numbers
starting with 51 only)
Turns the unit on or off.
Installation
Connecting the Power Cord
Connect the supplied power cord to the ~ AC IN connector
on the back of the unit, and then connect the plug to a
power outlet.
Adjusting the Display Angle
The display angle can be adjusted to make the display
more easily viewable. Eight settings are available for angle
adjustment.
When storing the unit, pull the display forward until
completely upright and then push it backward until
horizontal.
Power cord (supplied)
Power outlet

12 Installation
Chapter 2
Preparations
Loading Paper Roll and Ribbon
Cartridge
Handling the paper roll and ribbon
cartridge
• The print pack contains two ribbon cartridges and two
paper rolls. Be sure to use the ribbon cartridge and paper
roll in the same carton as a set. (See “Ribbon Cartridge
and Paper” on page 61.)
• The number of sheets that can be printed depends on the
print pack type. The table below lists the image count for
one ribbon cartridge and paper roll set.
• Do not replace the ribbon cartridge and paper roll before
they are used up. Otherwise the above number of sheets
may not be achieved.
• Place the paper roll vertically. If you place the paper roll
horizontally, the paper roll may roll around and fall. This
may cause an injury.
• Hold the paper roll with both hands so that you do not
drop it, because it is heavy. Dropping may result in an
injury.
• An IC board is incorporated in the ribbon cartridge. Do
not touch the terminal of the IC board with anything,
including your fingers or metallic objects. Also, do not
strike, bend, or drop the IC board.
Attaching adaptors to paper holder
Paper roll widths vary according to the print pack. When
using the 2UPC-C14 print pack, attach an adaptor to the
paper holder to compensate for the width difference.
1 Open the front door.
2 Press the paper holder release button and pull the paper
holder out.
Notes
Print pack 2UPC-C13 2UPC-C14 2UPC-C15
Number of
sheets
300 (sheets) 200 (sheets) 172 (sheets)
Print size 89 × 126 mm
±2 mm
(3.5 × 5 inches
±3/32 inch)
101 × 152 mm
±2 mm
(4 × 6 inches
±3/32 inch)
126 × 178 mm
±2 mm
(5 × 7 inches
±3/32 inch)
Hold the paper roll with both hands.
IC board

13
Installation
Chapter 2
Preparations
3 Press the latch on top of the paper holder and open the
holder.
4 Adjust the width of the paper holder.
When using the print pack 2UPC-C14
Attach adaptors to both ends of the paper holder.
Make sure the color of the label on the upper part of the
adaptors matches the color of the label on the paper
holder.
Insert the adaptors firmly and completely into the
paper holder.
When using the print pack 2UPC-C13 or
2UPC-C15
Remove the adaptors from the paper holder.
Store the adaptors in a safe place so as not to lose them.
Loading the paper roll and ribbon
cartridge
When using the printer for the first time, you must first
load a paper roll and ribbon cartridge. When using the
2UPC-C14, adaptors must be installed in the paper holder,
as described in the section “Attaching adaptors to paper
holder” on page 12.
For information on how to remove a spent paper roll and
ribbon cartridge, see the section “Removing the paper roll
and ribbon cartridge” on page 16.
• Always use a designated print pack.
• Always replace the paper roll and ribbon cartridge
together as a set.
Loading the paper roll
1 Insert the paper core into the paper roll.
Memo
Note
Note
Notes

14 Installation
Chapter 2
Preparations
• If the edges of the paper roll are uneven, make sure
to even them out before installing the paper roll.
Otherwise a malfunction may occur.
• If the paper is wound loosely around the core, make
sure to wind it tightly before installing the paper roll.
Otherwise a malfunction may occur.
• Do not grasp the paper too tightly or strike it against
a hard object, because the paper may tear or crease,
effecting the print quality.
2 Open the front door.
3 Press the paper holder release button and pull the paper
holder out.
4 Press the latch on top of the paper holder and open the
holder.
5 Insert the paper roll into the paper holder.
The arrow on the label in the center of the paper roll
must point inwards.
When installing the paper roll, make sure the paper
holder is completely open. Otherwise a malfunction
may occur.
6 Remove the label in the center of the paper roll.
• Make sure to fully remove all labels from the paper
roll. If labels remain inside the printer, operation
problems may occur.
• After inserting the paper roll, do not touch the
printing surface (the inner surface of the rolled
paper). Fingerprints, sweat, creases etc. can lead to
reduced print quality.
• Insert the paper roll firmly and completely into the
paper holder.
Notes
Note
Notes

15
Installation
Chapter 2
Preparations
7 Close the paper holder.
When closing the paper holder, take care that the
leading edge of the paper roll does not stick out of the
paper feed opening.
8 Return the paper holder into the unit.
Insert the paper holder until you hear a sharp click.
9 Close the front door.
Loading the ribbon cartridge
1 Open the side door.
2 Insert the ribbon cartridge completely.
Note

16 Installation
Chapter 2
Preparations
• If it is difficult to insert the ribbon cartridge, remove
it and try inserting it again. Reduce the ribbon slack
by turning the cartridge spool in the direction of the
arrow only if the ribbon cartridge cannot be inserted
due to slack in the ribbon.
• Do not rewind the ribbon cartridge for reuse in
printing. Printing will not be performed properly,
and it may cause a malfunction to occur.
• Do not try to replace the ribbon cartridge while
printing is in progress.
• Immediately after printing, the thermal head inside
the unit will be hot. When loading a cartridge, do not
insert your hand into the ribbon cartridge access
opening, to prevent the risk of burns.
3 Close the side door.
Notes on storage
• Avoid placing where subject to:
– high temperatures
– high humidity or dust
– direct sunlight
• After opening the bag, use the ribbon cartridge and the
paper as soon as possible.
• When storing after partial use, put the ribbon and the
paper back in their bags.
• There is extra paper on the paper roll. When the ribbon
cartridge is finished, remove the remainder of the paper
roll and install a new ribbon cartridge and paper roll.
• Make sure to use a matching paper roll and ribbon
cartridge set. Using an unmatched combination will not
only prevent you from obtaining normal print results but
may cause a paper jam or a malfunction.
• Do not touch the printing surface of the paper roll or the
ink on the ribbon cartridge. Fingerprints and other
pollutants can lead to reduced print quality.
Removing the paper roll and ribbon
cartridge
Removing the paper roll
1 Open the front door.
2 Press the paper holder release button and pull the paper
holder out.
Notes Notes

17
Installation
Chapter 2
Preparations
3 Remove any paper remnants from the paper holder.
4 Press the latch on top of the paper holder and open the
holder.
5 Remove the paper roll.
6 Pull out the paper core from the paper roll.
You will need to reuse the paper core. Be careful not
to misplace it.
Removing the ribbon cartridge
1 Open the side door.
2 Pull back the latch on the ribbon cartridge to release
the lock, and then grasp the ribbon cartridge and
remove it.
If the ink ribbon breaks, you can reconnect it with a
piece of tape and use the remaining ribbon.
Immediately after printing, the thermal head inside the
unit will be hot. When removing a cartridge, do not
insert your hand into the ribbon cartridge access
opening, to prevent the risk of burns.
Note
Memo
Note

18 Installation
Chapter 2
Preparations
3 Close the side door.
Attaching the Paper Tray
Attach the supplied paper tray.
When using the print pack 2UPC-C14 or 2UPC-
C15
About 100 sheets of printouts can be left on this paper tray.
However, the number of printouts which can be
accumulated on the paper tray changes according to the
environment condition where the printer is used or the
printed image. Remove the printed sheets accumulated on
the paper tray as soon as possible.
When using the printing pack 2UPC-C13
About 100 sheets of printouts can be left on this paper tray.
However, the number of printouts which can be
accumulated on the paper tray changes according to the
environment condition where the printer is used or the
printed image. Remove the printed sheets accumulated on
the paper tray as soon as possible.
Do not touch the printouts until they have been ejected
from the printer. If a printout gets stuck in the eject slot,
remove it from the slot immediately.
To remove the paper tray
Grasp the bottom of the paper tray, lift it up while keeping
it horizontal, and pull it out.
Note
Raise the eject paper stopper.

19
Installation
Chapter 2
Preparations
Preparing an Expansion
CompactFlash Card
For using the following functions, an expansion
CompactFlash card is required:
• Border print
• Promotional images display
• Text input
• System logs and print logs export
• Printing with Bluetooth communication
To create the expansion CompactFlash card, a
commercially available CompactFlash card is used.
The CompactFlash card can be a Type I, Type II, or
Microdrive.
We recommend using a CompactFlash card with at least
512 MB of free space.
Creating the expansion CompactFlash card
The supplied CD-ROM contains sample templates for
border prints and sample promotional images. You can
create an expansion CompactFlash card by copying this
data onto a CompactFlash card with your computer. If your
computer cannot use CompactFlash cards, you can copy
the data to another type of memory card temporarily and
then copy it to a CompactFlash card with the unit.
1 Insert the CompactFlash card into the computer.
2 Copy the promotional images.
Create the folder “\Sony\UPCR\” in the root folder of
the CompactFlash card, and copy the entire folder
“\Sony\UPCR\Promotion” into it from the supplied
CD-ROM.
3 Copy the border print templates.
The templates are stored in the folder
“\Sony\UPCR\Template” on the supplied CD-ROM.
The folder is divided into subfolders for each print size
(3×5, 4×6, and 5×7). Create the folder
“\Sony\UPCR\Template” in the root folder of the
CompactFlash card, and copy the entire folder for each
desired print size into it.
A CompactFlash card with at least 512 MB of free
space is required to copy all the data stored on the CD-
ROM.
If you have copied the CD-ROM data to a memory card
other than a CompactFlash card, you will need to use the
unit to copy it from that memory card to a CompactFlash
card.
For details on copying the data, see “Template Tab” on
page 25.
Inserting the expansion CompactFlash card
1 Open the side door.
2 Insert the expansion CompactFlash card that you have
created into the expansion CompactFlash card slot.
3 Close the side door.

20 Startup and Shutdown
Chapter 2
Preparations
Startup and Shutdown
Startup
Start the unit as follows.
For units with serial numbers starting with 11
Verify that no memory card is inserted in any of the front-
side memory card slots of the unit. Then press the on/
standby button.
For units with serial numbers starting with 51
Verify that no memory card is inserted in any of the front-
side memory card slots of the unit. Then turn on the
POWER switch.
The unit starts up, and the following screen appears.
For details on subsequent steps, see the section
“Operation” on page 30.
