Sony UPD-X100 User manual

3-207-400-13(1)
Digital Photo Printer
© 2003 Sony Corporation
UP-DX100
Operating Instructions ______________________________________ GB

2
Owner’s Record
The model and serial numbers are located at the rear.
Record these number in the space provided below.
Refer to these numbers whenever you call upon your
Sony dealer regarding this product.
Model No. __________________________________
Serial No. __________________________________
To reduce the risk of fire or electric
shock, do not expose this apparatus to
rain or moisture.
To avoid electrical shock, do not open the
cabinet. Refer servicing to qualified
personnel only.
For the customers in the U.S.A.
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio
or television reception, which can be determined by
turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the
following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and
receiver.
– Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
– Consult the dealer or experienced radio/TV technician
for help.
You are cautioned that any changes or modifications not
expressly approved in this manual could void your
authority to operate this equipment.
All interface cables used to connect peripherals must be
shielded in order to comply with the limits for a digital
device pursuant to Subpart B of Part 15 of FCC Rules.
For the customers in the U.S.A.
If you have any questions about this product, you may
call:
Sony Customer Information Service Center
1-800-222-7669 or
http://www.sony.com/
For the customers in the U.S.A.
This transmitter must not be co-located or operated in
conjunction with any other antenna or transmitter.
For the customers in Canada
This Class B digital apparatus complies with Canadian
ICES-003.
Operation is subject to the following two conditions: (1)
this device may not cause interference, and (2) this
device must accept any interference, including
interference that may cause undesired operation of the
device.
The term “IC:” before the radio certification number
only signifies that Industry Canada technical
specifications were met.
WARNING
Declaration of conformity
Trade Name: SONY
Model: UP-DX100
Responsible Party: Sony Electronics Inc.
Address: 16530 Via Esprillo,
San Diego, CA 92127 U.S.A.
Telephone Number: 858-942-2230
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.

3
WARNING
This unit has no power switch.
When installing the unit, incorporate a readily
accessible disconnect device in the fixed wiring, or
connect the power plug to an easily accessible socket-
outlet near the unit. If a fault should occur during
operation of the unit, operate the disconnect device to
switch the power supply off, or disconnect the power
plug.
WARNING on Power Connection
Use a proper power cord for your local power
supply.
1. Use the approved Power Cord (2-core mains lead)/
Appliance Connector/Plug that conforms to the safety
regulations of each country if applicable.
2. Use the Power Cord (2-core mains lead)/Appliance
Connector/Plug conforming to the proper ratings
(Voltage, Ampere).
If you have questions on the use of the above Power
Cord/Appliance Connector/Plug, please consult a
qualified service personnel.
For the customers in Europe
Hereby, Sony Corporation, declares that this “UP-
DX100” is in compliance with the essential
requirements and other relevant provisions of the
Directive 1999/5/EC.
For details, please access the following URL :
http://www.compliance.sony.de/
Dotyczy klientów w Europie
Niniejszym Sony Corporation oświadcza, że model
„UP-DX100” jest zgodne z zasadniczymi
wymaganiami oraz innymi stosownymi
postanowieniami Dyrektywy
1999/5/WE.
Szczegółowe informacje znaleźć można pod
następującym adresem URL:
http://www.compliance.sony.de/
For the customers in Europe
The manufacturer of this product is Sony Corporation,
1-7-1 Konan, Minato-ku, Tokyo, Japan.
The Authorized Representative for EMC and product
safety is Sony Deutschland GmbH, Hedelfinger Strasse
61, 70327 Stuttgart, Germany. For any service or
guarantee matters please refer to the addresses given in
separate service or guarantee documents.
All companies and product names mentioned herein
may be the trademarks or registered trademarks of
their respective companies. Furthermore, “™” and
“®” are not mentioned in each case in this manual.
Duplication, edition, or printing of a CD, TV
programs, copyrighted materials such as pictures or
publications, or any other materials except for your
own recording or creation is limited to private or
domestic use only. Unless you hold copyright or have
permission of copyright holders for the materials to be
duplicated, use of those materials beyond this limit
may infringe the provisions of the copyright law and
be subject to the copyright holder’s claim for damages.
When using photo images with this printer, pay special
attention not to infringe the provisions of the copyright
law. Any unauthorized use or modification of others’
portrait may also infringe their rights.
For some demonstrations, performances, or exhibits,
photography may be forbidden.

Table of Contents
4
Table of Contents
Overview ................................................................ 5
Features .............................................................. 5
Location of Parts ................................................... 6
Preparations ........................................................... 8
Unpacking the Printer ........................................ 8
Preparing a Printing Pack ................................... 8
Loading the Print Cartridge ................................ 8
Changing the Print Cartridge ............................. 9
Attaching the Paper Holder ................................ 9
Inserting the Print Paper ................................... 10
Connecting the Printer to a Wall Outlet ........... 11
Connecting to a Computer ............................... 11
Menu ..................................................................... 12
Structure of the Menu ...................................... 12
Functions of Each Menu Item .......................... 12
Bluetooth .............................................................. 13
Bluetooth Wireless Technology ....................... 13
The “Basic Imaging Profile” ............................ 13
Communication Between the Printer and Another
Device Using the Bluetooth Function ............ 13
Authentication .................................................. 14
Giving Your Printer a Device Number ............. 15
Printing a Picture ................................................ 15
Reprinting a Picture Stored in Memory
(COPY PRINT) .............................................. 16
Adjustments ......................................................... 16
Adjusting the Printing Location
(PRINT SETTING) ........................................ 16
Adjusting the Print Quality
(COLOR ADJUST) ........................................ 17
Precautions ........................................................... 19
Safety ............................................................... 19
Installation ........................................................ 19
Cleaning ........................................................... 19
Specifications ....................................................... 20
Troubleshooting ................................................... 21
Printer ............................................................... 21
Bluetooth Function ........................................... 22
Error messages ................................................. 23

Overview 5
Overview
The Sony UP-DX100 Digital Photo Printer is an
extension printer for the UPX-C200/C300 Digital
Printing System. As a second or third printer for the
UPX-C200/C300 system, the UP-DX100 can receive
and print images from a digital camera that sends signals
to the printer using Bluetooth wireless technology.
Features
The UP-DX100 has the following features:
Photo-realistic printing
With its dye sublimation printing system, the printer can
make photo-realistic prints meeting a number of
different requirements.
Super Coat 2 feature
The Super Coat 2 enables high durability and moisture
or fingerprint resistance, keeping your prints in good
picture quality for an extended period of time.
Selection of print sizes
You can select from a large, dynamic Post card (4×6
inch) size (UPC-X46) or an economical Small
(3.5×4inch) size (UPC-X34) print.
If an UPA-DX100TR optional paper tray is inserted in
the printer, you can also use UPC-X45 print paper on
which stamping with water-based ink is possible (not
supported by the UPX-C300).
Paper tray allowing bulk printing of 25/30
sheets
With the supplied paper tray, you can print up to 25
sheets for Post card size and 30 sheets for Small size
print paper at one time.
Printing from your computer with a convenient
USB connection
By connecting the printer and your computer with a
USB cable (commercially available) and installing the
supplied printer driver software on your computer, you
can print images from your computer.
For details on connecting a computer, refer to “Read me
(English)” stored in the supplied CD-ROM.
Note
When connecting a computer using a USB cable,
depending on the type of computer, normal operation
may not be obtained. In such a case, use a commercially
available USB hub.
MENU
EXEC
DIGITAL PHOTO PRINTER
1
PRINT
ALARM
UP-DX100 Digital camera
Bluetooth wireless connection
MENU
EXEC
DIGITAL PHOTO PRINTER
1
PRINT
ALARM
UP-DX100 Computer, etc.
USB connection

Location of Parts
6
Location of Parts
Front
A1(on/standby) button and lamp
Press to turn on the printer, and the lamp lights. Pressing
it again makes the lamp go out, and the printer enters the
standby mode.
BPaper tray slot
Insert the paper tray.
COperation display
When the printer is turned on, the operation mode or
menu item appears.
DMENU button
Press to display the menu item or to cancel any changes
made on the menu items that you have not registered.
EEXEC button
Press to decide the selection for each Menu items.
FControl button
Press to select a menu item and to settle the selection.
GLamps
lamp: Lights when the Bluetooth function
is enabled.
PRINT lamp: Lights while printing is in progress, and
flashes while the printer is receiving image data.
lamp: Lights if paper runs out, the print cartridge
is out of ink, or cartridges and paper of different
types or sizes are mixed.
ALARM lamp: Lights in case of occurrence of
problem.
HCartridge compartment cover
Open the cover to insert and remove the print cartridge.
ICartridge compartment
Insert the print cartridge.
JCartridge eject lever
Push up the lever to eject the inserted cartridge.
Note
The lever is disabled while printing.
1
2
34 0956 8
7
PUSHOPEN
PRINT
EXEC
MENU
ALARM
DIGITALPHOTOPRINTER
PRINT
ALARM
Bluetooth antenna (inside)

Location of Parts 7
Rear
APaper jam remove cover
When a paper jam occurs, remove this cover, and
remove the jammed paper.
B-AC IN connector
Connect to a wall outlet using the supplied AC power
cord.
CUSB connector
Connect to the USB connector on a computer using a
USB cable.
Note
When connecting a computer using a USB cable,
depending on the type of computer, normal operation
may not be obtained. In such a case, use a commercially
available USB hub.
123
-AC IN

Preparations
8
Preparations
Before using the printer for the first time, you need to
install a print cartridge and the paper tray,as indicated
below. These preparations are not needed for everyday
print operations, but are to be done as required.
Unpacking the Printer
Make sure that the following accessories are supplied
with your printer.
• AC power cord (1)
• Paper trays (2, large/small)
• Paper holder (2)
• Tray cover (1)
•CD-ROM(1)
- Sony UP-DX100 Printer Driver Software
- Operating Instructions
• Cleaning cassette (1)
• Operating Instructions (1)
•Software License Agreement (1)
Preparing a Printing Pack
You need an optional printing pack (UPC-X46 or UPC-
X34) designed for the printer. The pack contains a set of
print paper and a print cartridge.
Notes
• Do not rewind the ink ribbon and use the rewound
print cartridge for printing. Otherwise, proper
printing result will not be obtained, or even a
breakdown may occur.
• Use the printing pack for this printer only.
• Always use the print cartridge designed for the size of
the print paper you use. If you mix cartridges and
paper of different types or sizes, printing may not be
possible, or a paper jam or other trouble may occur.
• Do not print on the used print paper. Printing an image
twice on the same paper will not make the printed
image thicker. This may even cause a malfunction or
breakdown.
• Do not touch the ink ribbon of the print cartridge or the
printing surface of the print paper. If there are
fingerprints or dust on the printing surface or the ink
ribbon, the printing quality may deteriorate.
• For high quality prints, avoid placing the printing pack
in locations that are subject to high temperature, high
humidity, excessive dust, or direct sunlight.
• When storing a partially used pack of the print
cartridge and print paper, store it in its original bag or
in a similar container.
Loading the Print Cartridge
1 Push on PUSH OPEN, and open the cartridge
compartment cover.
2 Insert the print cartridge into the printer firmly until
it clicks into place.
3 Close the cartridge compartment cover.
PRINT
EXEC
MENU
ALARM
DIGITALPHOTOPRINTER
Cartridge
compartment cover
PRINT
EXEC
MENU
ALARM
DIGITALPHOTOPRINTER
Print cartridge

Preparations 9
Changing the Print Cartridge
When the print cartridge runs out, the lamp lights
and an error message appears on the operation display.
Replace the print cartridge.
1 Push on PUSH OPEN, and open the cartridge
compartment cover.
2 Press up the cartridge release lever.
The cartridge pops out. Remove the cartridge.
3 Insert a new print cartridge, and close the cover.
Notes
• Never put your hand into the cartridge compartment.
The thermal head reaches high temperatures,
especially after repeated printing.
• Do not rewind the ink ribbon and use the rewound
print cartridge for printing. Otherwise, proper
printing result will not be obtained, or even a
breakdown may occur.
• If the print cartridge does not click into place, remove
it and then re-insert it. If the ink ribbon is too slack to
be loaded, wind the ink ribbon in the direction of the
arrow to remove the slack.
• If the print cartridge is not loaded when you turn on
the printer, the lamp lights up.
• Do not touch the ink ribbon or place the print cartridge
in a dusty location. Fingerprints or dust on the ink
ribbon may result in imperfect printing.
• Do not change the print cartridge while printing.
• Avoid placing the print cartridge in a location subject
to high temperatures, high humidity, excessive dust or
direct sunlight
• When you are going to store a partially used cartridge,
store it in its original bag.
Attaching the Paper Holder
Attach the supplied paper holder to the paper tray as
follows:
1 Insert the tips of both ends of the paper holder into
the holes located at the bottom of the paper tray,
pinching the portions near the two ends.
2 Push the paper holder into the stoppers firmly until
it snaps into place, making a click sound.
Removing the paper holder
Push out the paper holder gently from the stoppers, and
remove it,pinching the portions near the two ends.
PRINT
EXEC
MENU
ALARM
DIGITAL PHOTO PRINTER
Cartridge release
lever
PRINT
EXEC
MENU
ALARM
Notes on storing the print cartridge
Paper tray
Paper holder
Stoppers

Preparations
10
Inserting the Print Paper
1 Set the print paper into the tray.
Riffle the print paper. Then insert the print paper
with its printing surface (the side with no imprint)
facing up and the arrow pointing in the same
direction as the arrow in the tray.
You can set 25 sheets when the UPC-X46 is used,
and 30 sheets when the UPC-X34 is used.
2 Remove the protective sheet on the print paper.
Note
Be sure to keep the protective sheet, which is used
for cleaning the inside of the printer.
3 Insert the tray to the printer.
Note
Do not touch the printing surface. Fingerprints on
the printing surface may result in imperfect
printing.
Notes
• Set the paper of the UPC-X46 into the large paper tray,
and that of the UPC-X34 into the small paper tray. If
the paper size and tray size do not match, a paper jam
may occur.
• Do not remove or insert the paper tray during printing.
• If print paper does not feed automatically, the
lamp lights. Pull out the paper tray and check for a
paper jam.
• When adding print paper to a partially full tray, make
sure that the total number of sheets does not exceed 25
for the UPC-X46 or 30 for the UPC-X34. Do not
place different types or sizes of paper in the tray.
Otherwise, a paper jam or malfunction may occur.
• Do not write or type on the printing surface of the
paper before printing. You may not be able to proceed
with printing. If you want to write greetings or draw
on the printed surface after printing, use an oil ink pen.
• Do not attach stickers or anything else on the printing
surface before printing.
• Do not print on the used print paper. Printing an image
twice on the same paper will not make the printed
image thicker. This may even cause a malfunction or
breakdown.
• Before printing, do not fold or bend the print paper.
• Do not leave more than five sheets of ejected printed
paper on the paper tray because they may cause a
paper jam.
• Avoid placing the print paper in a location subject to
high temperatures, high humidity, excessive dust or
direct sunlight.
• Avoid storing the paper with the printed faces
touching each other or in contact with rubber or plastic
products including vinyl chloride or plasticizer for an
extended period of time; color changes or
deterioration of the printed image may occur.
• When you are going to store partially-used print paper,
store it in its original bag.
Attaching the tray cover
Keep the supplied tray cover attached to the paper tray
when not in use to protect print paper placed in the tray
from dust. The tray cover can be attached to either paper
tray for the UPC-X46 or for the UPC-X34.
Print paper
PUSH OPEN
PRINT
EXEC
MENU
ALARM
DIGITALPHOTOPRINTER
Notes on storing the print paper
Tr ay c o ve r

Preparations 11
Connecting the Printer to a Wall
Outlet
Connect the supplied AC power cord to the AC IN
connector of the printer and then to wall outlet.
Connecting to a Computer
To print images from your computer, connect the USB
connectors of the printer and a computer (a PC with
Windows) using a commercially available USB cable,
and install the supplied printer driver on the computer.
For details on installation and operation of the printer
driver, refer to “Read me (English)” contained on the
supplied CD-ROM.
Notes
• For connection, use a commercially available A-B
TYPE USB cable less than 3 meters long. As the
proper cable may differ according to the type of
computer, determine the type of cable you need,
consulting the instruction manual for your computer.
• Refer to the instruction manual for your computer, as
well.
• The supplied Sony UP-DX100 Printer Driver does not
support a network printer, nor can be used with a
commercially available printer buffer unit.
• Do not connect or disconnect the USB cable during
data transfer or printing. Proper printing resultsmay
not be obtained.
• When connecting a computer using a USB cable,
depending on the type of computer, normal operation
may not be obtained. In such a case, use a
commercially available USB hub.
-AC IN
-AC IN
UP-DX100
AC power cord
(supplied)
to wall outlet
-AC IN
UP-DX100
USB cable
Computer

Menu
12
Menu
Structure of the Menu
Functions of Each Menu Item
COLOR ADJUST CYN-RED (–7 to +7)
COLOR(S)* MAG-GRN (–7 to +7)
YEL-BLU (–7 to +7)
DARK (–7 to +7)
LIGHT (–7 to +7)
SHARPNESS (0 to +7)
GAMMA (–7 to +7)
SAVE SETTING (1/2/3)
LOAD SETTING (1/2/3)
COLOR ADJUST CYN-RED (–7 to +7)
B/W(S)* MAG-GRN (–7 to +7)
YEL-BLU (–7 to +7)
DARK (–7 to +7)
LIGHT (–7 to +7)
SHARPNESS (0 to +7)
GAMMA (–7 to +7)
SAVE SETTING (1/2/3)
LOAD SETTING (1/2/3)
Bluetooth SETTING Bluetooth ADDR
PASSKEY INPUT PASSKEY INPUT [1:2:3:4]
MY DEVICE NAME Sony UP- DX100 [NONE – 9]
CONNECTION RECORD 1. Sony DKC-C200X/DKC-C300X
2. NONE
3. NONE
MODULE POWER POWER: (ON/OFF)
PRINT SETTING PRINT OFFSET: (–2/–1/0/1/2)
COPY PRINT COPY PRINT: 1 [1 – 9]
TOTAL PRINTS
* When the UPC-X45 print paper is used,
(S) is displayed.
Menu item Function Setting
COLOR ADJUST
COLOR
You can adjust the print quality for color
pictures.
CYN-RED: The cyan and the red are adjusted.
MAG-GRN: The magenta and the green are adjusted.
YEL-BLU: The yellow and the blue are adjusted.
DARK: The brightness of a dark area is adjusted.
LIGHT: The brightness of a bright area is adjusted.
SHARPNESS: The sharpness of edges of objects in a picture is
adjusted.
GAMMA: The tone of a picture is adjusted.
SAVE SETTING (1/2/3): The adjusted values are stored in the
built-in memory.
LOAD SETTING (1/2/3): The adjusted values stored in memory
are loaded.
COLOR ADJUST
B/W
You can adjust the print quality for black-
and-white pictures.
Bluetooth SETTING You can make Bluetooth settings. Bluetooth ADDR: The Bluetooth address is displayed.
PASSKEY INPUT: A passkey is set or changed.
MY DEVICE NAME: The printer can be assigned a number.
CONNECTION RECORD: The connection record is displayed.
MODULE POWER: The power of the Bluetooth circuits is
turned on or off.
PRINT SETTING The printing location on print paper of the
UPC-X46 is fine-adjusted.
PRINT OFFSET (–2/–1/0/1/2)
The printing location can be shifted by 0.5 mm.
COPY PRINT The newest data stored in memory is
reprinted.
[1 – 9]
The number of sheets to be printed is set.
TOTAL PRINTS The total number of sheets printed is shown. —

Bluetooth 13
Bluetooth
Bluetooth Wireless Technology
The Bluetooth1) wireless technology allows
communication between various Bluetooth devices
without using cables. Devices which can use this
technology include computers, computers peripheral
devices, PDAs, and mobile phones.
This omnidirectional communications system enables
communication even if the Bluetooth device is in a bag
or if there are obstacles between the devices.
Also, the Bluetooth wireless technology has advanced
security functions, such as scrambled frequencies and
data encruption.
• When using the Bluetooth function, the distance
between the camera and the printer you intend to
connect must be within 10 m (33 feet) without
obstacles.
1) The trademark is owned by their proprietor and
used by Sony Corporation under license. The word Bluetooth
is printed in plain text throughout this document.
The “Basic Imaging Profile”
The “Basic Imaging Profile” (BIP) is the specifications
used when sending or receiving still images between
Bluetooth devices. The main features of the BIP enable
sending or receiving images, and use of the remote
shutter feature of a digital still camera.
To connect with your printer, the Bluetooth device must
be compatible with the “Image Push Feature” of the
“Basic Imaging Profile” (BIP).
Before using the Bluetooth device, check the Bluetooth
and BIP specifications of the device.
Communication Between the
Printer and Another Device Using
the Bluetooth Function
For communication between the printer and another
device with Bluetooth functions, the following settings
are required:
• The same passkey is set on the printer and the other
device.
•TheBluetooth lamp is lit.
Checking the current setting
You can check the current passkey settings on the printer
as follows:
1 Turn on the printer.
2 Press the MENU button.
3 Press Vof the control button to display “Bluetooth
SETTING [>>]” on the operation display.
4 Press Bof the control button.
The Bluetooth address appears.
5 Press Vof the control button to display “PASSKEY
INPUT [>>]” on the operation display.
6 Press Bof the control button.
The passkey currently set appears on the PASSKEY
INPUT display.
7 Press the EXEC button.
To exit the MENU operation, press the MENU button.
If the Bluetooth lamp is off
If the Bluetooth lamp is off, turn it on in the following
manner:
1 Press the MENU button.
2 Press Vof the control button to display “Bluetooth
SETTING [>>].”
3 Press Bof the control button.
“Bluetooth ADDR None” appears.
4 Press Vof the control button to display “MODULE
POWER [>>].”
5 Press Bof the control button.
ALARM
PRINT
MENU
EXEC
DIGITAL PHOTO PRINTER
1
1 2 4,6
7 3,5
Lit

Bluetooth
14
6 Press bor Bof the control button to set the
POWER to ON.
7 Press the EXEC button.
“REBOOTING” appears. Then the printer is restarted,
and the Bluetooth lamp lights.
Authentication
What's a passkey
Passkey is used to authenticate two Bluetooth devices
that have not previously connected to each other and
create a trusted relationship between them.
You need to enter the same characters (passkey) to each
device on passkey authentication process. This printer
uses a 4-digit number as a passkey.
Once authentication of the device has been confirmed,
the printer registered the device as a record. Since then
you can connect the device without entering a passkey.
To ensure proper security, the passkey entry has a time
limit (30 seconds), based on the Bluetooth standards.
The passkey entry may be required when the
authentication valid period of the printer orother device
is expired, the record is deleted, or the security setting is
changed.
Passkey entry may be required, depending on devices,
each time you intend to connect.
This “Passkey” is also referred to as a “Bluetooth
passkey” etc. “PIN” is also used with the same meaning.
When the passkey entry screen appears
on the other device
Enter the desired passkey on your printer. Then, enter
the same passkey on the other device
Entering the passkey
Enter the same passkey on the printer and the other
device to be connected, as follows:
1 Turn on the printer.
“Ready BT RSSI [----]”appears on the operation
display.
2 Press the MENU button.
3 Press Vof the control button to display “Bluetooth
SETTING [>>].”
4 Press Bof the control button.
“Bluetooth ADDR” appears.
5 Press Vof the control button to display
“PASSKEY INPUT [>>].”
6 Press Bof the control button.
“PASSKEY INPUT <1> [X:X:X:X]” appears.
||
Current digit to be set Passkey
7 Press bor Bof the control button to select a digit
of the passkey to be set.
This <1> shows the leftmost digit, and <4> shows
the rightmost digit.
8 Press vor Vof the control button to set the value
of the passkey.
Value from 0 to 9 can be used.
Repeat Steps 7and 8until the four-digit passkey is
set.
9 Press the EXEC button.
“PASSKEY INPUT Saving. . .” appears, and your
passkey setting is stored.
10 When the setting is completed, press the MENU
button.
ALARM
PRINT
MENU
EXEC
DIGITAL PHOTO PRINTER
1
1 2,10 7 4,6
3,5
98

Printing a Picture 15
Giving Your Printer a Device
Number
When two or more printers are used in a system, it is
convenient that each printer have a device number (from
1 to 9).
1 Turn on the printer.
“Ready BT RSSI [----]” appears on the operation
display.
2 Press the MENU button.
3 Press Vof the control button to display “Bluetooth
SETTING [>>].”
4 Press Bof the control button.
5 Press Vof the control button to display “MY
DEVICE NAME [>>].”
6 Press Bof the control button.
“Sony UP-DX100 [NONE-9: EXEC]” appears.
7 Press vor Vof the control button to set the device
number.
8 Press the EXEC button.
“DEVICE NAME Saving. . .” appears, and the
device number you have set is stored.
9 When the setting is completed, press the MENU
button.
Printing a Picture
The UP-DX100 automatically receives and prints the
image sent from the camera that is connected with the
Bluetooth functions. Only JPEG-format graphic-image
files can be received. Graphic images sent from a
computer connected with the printer using a USB cable
can also be printed out.
During printing of graphic images sent from the camera
or computer, the process is displayed on the operation
display, as follows:
When printing is completed, “Ready BT RSSI [))))]”
appears.
Receiving Image
BT [>>>>>>>>>>]
Receiving image data
(This is an example of the
Bluetooth connection.)
PROCESSING Processing received data
PRINTING
[YELLOW]
Printing the yellow
PRINTING
[MAGENTA]
Printing the magenta
PRINTING
[CYAN]
Printing the cyan
PRINTING
[LAMI]
Laminating a printout

Adjustments
16
Reprinting a Picture Stored in
Memory (COPY PRINT)
The data of the last picture printed is stored in the
memory of the printer. You can reprint the picture.
Note
When the printer is set to standby mode, data stored in
memory are deleted. You cannot reprint the picture.
1 Press the MENU button.
2 Press Vof the control button to display “COPY
PRINT [>>].”
3 Press Bof the control button.
“COPY PRINT:1 [1-9 PRINT:EXEC]” appears.
4 Press vor Vof the control button to set the number
of sheets to be printed.
Avalue from 1 to 9 can be set.
5 Press the EXEC button.
The number of pictures set in Step 4is printed.
When printing is completed, the display returns to
“Ready.”
Adjustments
The printing location and print quality can be adjusted.
After checking the printing results, make any
adjustments, necessary.
Adjusting the Printing Location
(PRINT SETTING)
Adjust so that a printed image is correctly located on the
print paper when the UPC-X46 is used. The printing
location can be shifted by 0.5 mm.
1 Turn on the printer.
2 Press the MENU button.
3 Press vor Vof the control button to display
“PRINT SETTING.”
4 Press Bof the control button.
“PRINT OFFSET:” appears.
5 Press bor Bof the control button to select the
offset value.
6 Press the EXEC button.
The offset value selected in Step 5is registered, and
the display returns to “PRINT SETTING.”
Make a test printout and check if the image is printed in
the correct location on the print paper. If further
adjustment is needed, repeat the above steps.
To exit PRINT SETTING
Press the MENU button. The display returns to “Ready,”
and the printer is ready to print.
ALARM
PRINT
MENU
EXEC
DIGITAL PHOTO PRINTER
1
13
2
54
ALARM
PRINT
MENU
EXEC
DIGITAL PHOTO PRINTER
1
1234
65

Adjustments 17
Adjusting the Print Quality
(COLOR ADJUST)
With the MENU function, you can adjust the picture
quality. You can check the adjusted results by printing a
guide image.
Three sets of adjusted values for color pictures and for
black-and-white pictures can be stored in memory and
retrieved later.
Print quality adjustment from the printer is only enabled
when the camera and printer are connected via
Bluetooth in a UPX-C200 system.
Notes
• When the printer is connected to the computer via
USB, you can adjust print quality using the printer
driver installed on the computer. For details on
installation and operation of the printer driver, refer to
“Read me (English)”contained on the supplied CD-
ROM.
• When using a UPX-C300 system, you can adjust print
quality using the camera. For details, refer to the
operating instructions for the UPX-C300.
Adjusting the print quality for color
pictures
1 Turn on the printer.
2 Press the MENU button.
“COLOR ADJUST COLOR [>>]” appears.
3 Press Bof the control button.
“CYN-RED:” appears.
4 Press bor Bof the control button for adjustment.
5 Press Vof the control button.
“MAG-GRN:” appears.
Repeat Steps 4and 5to make necessary
adjustments. Adjustable content for each
adjustment item is as follows:
CYN-RED: Pressing bgives the picture more
cyan, while pressing Bmakes it more reddish.
MAG-GRN: Pressing bgives the picture more
magenta, while pressing Bmakes the picture
more greenish.
YEL-BLU: Pressing bmakes the picture more
yellowish, while pressing Bmakes the picture
more bluish.
DARK: Contrast in the dark areas is adjusted.
Pressing Bincreases the darkness.
LIGHT: Contrast in the bright areas is adjusted.
Pressing Bincreases the brightness.
SHARPNESS: Pressing Bmakes the edges of
objects in a picture sharper.
GAMMA: Pressing bmakes the color tone of the
whole picture lighter, while pressing Bmakes it
deeper.
6 Press the EXEC button when the adjustment is
completed.
The display returns to “COLOR ADJUST COLOR
[>>].”
Adjusting the print quality for black-and-
white pictures
When you press Vof the control button after pressing
the Menu button in step 2in “Adjusting the print quality
for color pictures,” COLOR ADJUST B/W [>>]
appears, and you can adjust the print quality for black-
and-white pictures. The adjusting method is the same as
that for color pictures.
Printing out a guide image
To check the results of your adjustments, print out the
camera’s guide images.
Operate the camera to select Guide Print-RGB or Guide
Print-DLGm, and then print.
For details, refer to the Instruction Manual (Advanced
Operations) for the UPX-C200 or the operating
instructions for the UPX-C300.
Storing your adjustments
Once the color adjustment is completed, save the
adjusted values as follows:
1 In the COLOR ADJUST COLOR [>>] or B/W
[>>] display, press Bof the control button.
2 Press Vof the control button repeatedly until
“SAVE SETTING” appears.
ALARM
PRINT
MENU
EXEC
DIGITAL PHOTO PRINTER
1
123
64 5

Adjustments
18
3 Press bor Bof the control button to select the
memory-cell number (1, 2, or 3).
4 Press the EXEC button.
The adjusted values are stored in the memory cell
with the number selected in Step 3.
Loading the adjusted values
Adjusted values stored in the memory can be retrieved.
1 In the COLOR ADJUST COLOR [>>] or B/W
[>>] display, press Bof the control button.
2 Press Vof the control button repeatedly until
“LOAD SETTING” appears.
3 Press bor Bof the control button to select the
memory-cell number (1, 2, or 3).
4 Press the EXEC button.
The adjusted values stored in the memory cell with
the number selected in Step 3are retrieved and in
force.
To exit COLOR ADJUST
After a menu operation, such as COLOR ADJUST
setting, saving of adjusted values, or retrieving of stored
values, is completed, press the MENU button. The
display returns to “Ready.”

Precautions 19
Precautions
Safety
• Operate the printer using the power source specified in
“Specifications” on page 20.
•This unit is not disconnected from the mains as long as
it is connected to the mains outlet, even if the unit
itself has been turned off.
• Be careful not to damage the power cord by placing or
dropping heavy objects on it; it is dangerous to use the
printer with a damaged power cord.
• If you do not intend to use the printer for a long time,
disconnect the power cord.
• Unplug the power cord by grasping the plug, not the
cord itself.
• Do not apply mechanical shock or drop the unit.
• Do not disassemble or convert the unit.
• Do not remove the cover. There is a danger of electric
shock from the internal parts.
• Be careful not to spill water or other liquids on the
unit, or to allow combustible or metallic material to
enter the cabinet. If used with foreign matter in the
cabinet, the unit is liable to fail, or present a risk of fire
or electric shock.
• Ventilation holes are provided to prevent the printer
from overheating. Be careful not to obstruct them
with other units or by covering the printer with a cloth
etc.
• If the printer malfunctions or if a foreign body falls
into the cabinet, disconnect the power immediately
and consult your Sony service facility or your Sony
dealer.
Installation
• Avoid placing the printer in a location subject to:
– mechanical vibration
– high humidity
– excessive dust
– where it is exposed to rain
– direct or excessive sunlight
– extremely high or low temperatures
– close to sources of strong magnetism
– close to sources of powerful electromagnetic
radiation, such as radios or TV transmitters
• Do not use other electronic equipment near the printer.
It will not work properly in strong electromagnetic
fields.
• Do not place a heavy object such as a monitor on the
printer.
Condensation
• If the printer is subject to wide and sudden changes in
temperature, such as when it is moved from a cold
room to a warm room or when it is left in a room with
a heater that tends to produce large amounts of
moisture, condensation may form inside the printer.
In such cases the printer will probably not work
properly, and may even develop a fault if you persist in
using it. If condensation forms, set the printer to
standby mode and leave the printer to stand for at least
one hour.
• If the printing pack is subjected to wide and sudden
changes in temperature, condensation may form on
the print cartridge or paper. This will cause the printer
to malfunction. Also, if the printing pack is used in
this state, spots are likely to appear on the printout.
Therefore, avoid storing the printing pack in locations
subject to wide and sudden changes of temperature.
• To store a half-used printing pack, replace it in its
original packing and reseal the package. If possible,
keep the sealed printing pack in a cool, dark location.
To subsequently use the printing pack, place it, in its
sealed package, in a warm room for several hours.
Doing so prevents condensation from forming when
the printing pack is removed from its package.
Location
To prevent internal heat built-up, leave enough room
around the printer for air to circulate through the vents
on the left hand side of the cabinet.
On transportation
• Do not transport the printer with the supplied
accessories. Doing so may cause malfunction.
• Retain the original carton and packing materials in
case you have to transport the unit in the future.
Cleaning
• Before cleaning the printer, press the on/standby
button of the printer so that the lamp goes out, and
unplug the power cord.
• Clean the cabinet, panel and controls with a soft dry
cloth, or a soft cloth lightly moistened with a mild
detergent solution. Do not use any type of solvent,
such as alcohol or benzine, which may damage the
finish.

Specifications
20
Specifications
Printer
Power supply 100 – 240 V AC, 50/60 Hz
Current consumption
1.1 A max. (during printing)
Operating temperature
5°C to 35°C (41°F to 95°F)
Storage/transport temperature
–20°C to +60°C (–4°F to +140°F)
Operating humidity
20% to 80% (non condensation)
Maximum dimensions (w/h/d)
203 × 85 × 305 mm
(8 × 33/8× 121/8inches)
Mass Approx. 2.7 kg (5 lb 15 oz) (main unit
only)
Printing method Four-surface sequential sublimation
thermal transfer process
(yellow, magenta, cyan, laminate)
Printing resolution
403 × 403 dpi
Thermal head 403 dots/inch
Printing gradations
8 bits for yellow, magenta, cyan
Printing time UPC-X46: 100 sec./sheet
UPC-X34: 65 sec./sheet
Paper supply method
Autofeed from paper tray
Maximum capacity of paper tray
UPC-X46: 25 sheets
UPC-X34: 30 sheets
Paper eject method
Front ejection
Sheets are ejected in order on top of
paper tray
Printing capacity of ribbon cartridge
UPC-X46: 25 sheets
UPC-X34: 30 sheets
Inputs AC IN (power inlet)
Maximum print size
UPC-X46: 101.6 × 151.4 mm
(4 ×61/8inches) (no border)
UPC-X34: 70.1 × 95.3 mm
(27/8× 37/8inches) (with border)
Print pixels UPC-X46: 1664 × 2440 dots
UPC-X34: 1112 × 1512 dots
USB interface
Data-transmission system
Compliant with the Universal Serial
Bus Specification Revision 1.1
Pin assignment of the USB connector
Bluetooth specifications
Communication type
Bluetooth specification, ver.1.1
Maximum transmission speed1)
About 723 Kbps
Output Bluetooth specification, Power Class
2
Communication distance2)
About 10 m (3.3 feet) without
obstacles
Compatible Bluetooth profile3)
Basic Imaging Profile (Image Push
Responder)
Frequency band 2.4GHz (2.400 GHz – 2.4835 GHz)
1) Maximum data transmission speed based on Bluetooth
specification, Ver.1.1. This speed depends on the distance
between the devices, obstacles, radio wave conditions,
application software, or the OS.
2) This distance depends on the distance between the devices,
obstacles, radio wave conditions, application software, or the
OS.
3) This specification is in accordance with the intended use
between two Bluetooth devices. This is defined by the
Bluetooth specification.
Supplied accessories
Paper tray for the UPC-X46 (1)
Paper tray for the UPC-X34 (1)
Tray cover (1)
Paper holder (2)
AC power cord (1)
Cleaning cassette (1)
CD-ROM (1)
Operating instructions (1)
Software License Agreement (1)
Optional accessories
UPA-DX100TR Paper Tray
10UPC-X46 Self-laminating Color Printing Pack
(250 sheets)
10UPC-X45 Self-laminating Color Printing Pack
(250 sheets)
10UPC-X34 Self-laminating Color Printing Pack
(300 sheets)
Design and specifications are subject to change without
notice.
I/O Signal Function
VCC Cable power, maximum current:
100 mA
I/O –Data Data
I/O +Data Data, can be pulled up to +3.3 V
via a 1.5-kohm resistor
GROUND Cable ground
