Get the clarity of Sony’s SXRD™ 4K movie theater technology in
a brand new 4K Ultra HD projector with greater than 4x 1080p
resolution, anamorphic 3D, and HD to 4K upscaling. With
additional installation exibility you can experience immersive 4K
media in an array of rooms. Only from Sony.
• 4K resolution—4096x2160. That’s greater than 4
times 1080p
• HD to 4K upscaling turns your HD content into a
4K experience
• HDMI®2.0 compatible for 4K resolution at up to 60
frames per second
• 200,000:1 dynamic contrast ratio with SXRD™
technology
• Brightness of 1,700 ANSI lumens
• Auto Calibration function
• Flexible installation—2.1x motorized zoom,
85%(v)/31%(h) motorized shi and 1.38-2.83 throw
ratio
• Full immersion on larger screens and up close
viewing
• 3-year limited warranty
• Built in RF emitter for 3D viewing; two glasses
included
Features
An astonishingly immersive home theater experience
Features the same technology and resolution found in high-end, professional 4K movie theaters, providing an astonishingly
immersive home theater experience. 4K resolution is 4096 x 2160 pixels. That’s more than 4 times 1080p. Add a 200,000:1
dynamic contrast ratio, 1,700 ANSI lumen brightness, and Deep Color support and the VPL-VW600ES pulls you into your
favorite movies like no HD home theater projector you’ve ever experienced.
Recommended for up to a 200" screen
Because the VPL-VW600ES has such high resolution and brightness, you can install a 200" screen and still experience an
astonishingly crisp and bright picture in 2D. (Up to 150" if you want to use 3D.)
Enjoy your favorite 1080p HD movies and shows in 4K
Watch your favorite HD movies and television shows in 4K with Super Resolution upscaling. Sony’s proprietary Reality
Creation algorithm makes your best video content look better than ever before. And Sony’s proprietary “Mastered in 4K”
algorithm faithfully reproduces specially prepared movies to match the original 4K images.
Get the most out of your Sony 4K projector
The available 4K Ultra HD Media Player comes preloaded with 10 bonus feature lms and video shorts, and Sony’s Video
Unlimited 4K network video service provides access to a library of 4K movies and TV shows.3Control it all with a Sony
Tablet, both of which are optional.
Integrate into virtually any home environment
Installing the VPL-VW600ES is easy with its motorized lens, 85%(v)/31% (h) motorized shi and wide throw distance range.
Having a front air intake and exhaust allows the VPL-VW600ES to be positioned near a wall without having to worry about
cooling issues. Access to the lamp through a panel on top of the unit allows lamp changes without un-mounting the
projector.
Immersive, vibrant picture for any environment
By simply choosing the appropriate preset, the VPL-VW600ES’s 1,700 ANSI lm brightness and Deep color can be adjusted
for the ideal picture quality in any environment—whether gaming or watching sports in a lit room, or enjoying movies in a
dark theater.
VPL-VW600ES
Sony 4K Home Theater ES Projector
Bullets

3D Features
3D Features
2D to 3D Conversion Yes
3D Glasses Brightness Adjustment 2 Modes, Standard and High
Digitally Driven Panel Yes
Eect Adjustment(s) Yes
Format(s) Frame Packing/ Side by Side/ Over-Under/Simulated
3D/ESPN 3D format/ 720p / 60 SBS
Signal (HDMI inputs only) 1080:24p/60p/50p/60i/50i ;
720:60p/50p
Simulated 3D Yes
Transmitter Built-in RF
Convenience Features
Convenience Features
BRAVIA® Sync™ Yes
Image Flip HV, H, V, O
IR Receiver Front Rear, Front, Rear
Multiple Language Display 15 languages (including English, French, Spanish,
German and Chinese)
Power Save Mode Yes
Remote Control Yes (RM-PJ22)
Test Pattern Yes
Display
Display
Native Resolution 4K - 4096 x 2160
Screen Size 60"-200" recommended
Aspect Ratio 17:9
Display Resolution 4096 × 2160 (Full 4K)
Display Features
Display Features Display Technology SXRD™ Technology
Watch 2D high-denition content in 3D
Add a new dimension to your favorite movies, shows or videos with Sony’s unique 2D to 3D upconversion algorithm,
allowing high denition 2D content connected via HDMI® to be viewed in immersive Sony 3D even in 4K.2
Whisper-quiet fan
Forget that the projector is even in the room. Due to the VPL-VW600ES’s advanced air discharge system.
Built-in Auto-calibration Features
Over time, the aging of components like the lamp make changes to the look on the screen. A built in RGB sensor and
soware allow you to quickly adjust your picture to the way it looked when rst installed.
Integrated RF 3D Sync Transmitter
No need to wire an external 3D emitter. The built in RF emitter can adequately cover your home theater space and
features industry standard technology that allows for the use of Sony TDG-BT500A or compatible 3rd party 3D glasses.
Smoother, sharper motion
Enjoy smooth, sharp motion with Sony’s Motionow™ technology with Dark Frame Insertion and 24p True Cinema
technologies.
3-year limited warranty
Rest assured that Sony has you covered. All Sony Elevated Standard (ES) projectors enjoy 3-year limited warranties,
including a special tech support hotline in case you run into any problems.
Specications

General
General
Integration Partner
Yes (Control4 Certied, AMX Device Discovery,
Crestron Integrated Partner, Savant Partner in
Excellence, RTI URC)
Lens 4K All Range Crisp Focus (ARC-F)
Projection Picture Size 60" to 300" measured diagonally
General Features
General Features
Acceptable Computer Signals fH: 19 to 72 kHz, fV: 48 to 92 Hz, fV: 60 Hz
Information Menu Horizontal and Vertical frequency display
Input A D-sub 15 Pin, Analog RGB/Component
Lens Control Motorized focus, shi and zoom with servo/memory
Speaker 14 element with aspheric front element
Standby Mode Yes
Vertical Keystone Yes
Inputs and Outputs
Inputs and Outputs
12V Trigger Output(s)
Mini Jack - Power On: DC 12V, output impedance:
4.7 kilohms Power O: 0V (Two, selectable power /
anamorphic zoom.)
HDMI™ Connection(s) (Total) 2 (Side) Digital RGB/Y/Cb(Pb)Cr(Pr)
IR Input(s) 1 (Side)
Remote Network Connection(s) 1 (Side) RS-232C: D-sub 9-pin (female)
RS-232C Input(s) Yes
RS232 Control Yes
Optional Accessories
Optional Accessories Optional Accessories Ultra High Pressure Replacement Lamp (LMP-H260)
Accessories
Accessories Supplied Accessories
Remote Control (RM-PJ24)
Instruction Manual
AC Cord
Size AA batteries x 2
Certicate for two RF 3D glasses (TDG-BT500A)
Lens Cap
Service and Warranty Information
Service and Warranty Information Limited Warranty Term
Product Warranty - Limited 3 Years Parts and Labor
except the lamp. Lamp Warranty - 90 Days from date
of purchase.
TV System
TV System Color System Auto, NTSC, PAL, SECAM
Video
Video
Brightness 1700 Lumens
Contrast Ratio 200,000:1 Dynamic Contrast
Deep Color Yes
Picture Modes 9 modes
Video Calibration Settings 11 Gamma Modes, HSV adjust by color, Custom Color
Space, Auto Calibration for factory presets
Video Features

1. Requires 3D content, 3D player, 3D glasses, and HDMI®cable (at least 10.2 Gbps).
2. Simulated 3D image will vary based on source content.
3. Ethernet connection required. Fees may apply for 4K networked video service.
4. 60p display based on 4:2:0 source.
© 2013 Sony Electronics Inc. All rights reserved. Reproduction in whole or in part without written permission is prohibited. Features and specications are subject to change without notice.
Sony, the Sony make.believe logo, SXRD, and Motionow are trademarks of Sony. HDMI is a trademark of HDMI Licensing LLC. All other trademarks are trademarks of their respective
Video Features
3D Anamorphic Yes, via picture position or external lens
4K resolution upscaling Yes - 3840 x 2160 (QFHD)
Acceptable Video Signals
Composite video, Y/C video, 15 kHz (RGB/
Component) 50/60Hz; Progressive component 50/60
Hz; DTV (480/60i, 480/60p, 575/50i, 575/50p, 720/50p,
720/60p, 1080P24sF(48i),1080/50i, 1080/50p, 1080/60i),
HDMI inputs only: 1080/60p, 1080/24p
Anamorphic Yes, lens-less anamorphic via picture position
Deep Color Yes
Film Mode Yes
Lens Shi Function Yes +85%/-80%(v), 31%(h)
Motionow™ Technology Yes (120 Hz with Dark Frame Insertion)
Picture Position Yes, 5 Modes (including lens-less anamorphic)
Pixel Alignment Yes, 1/10" Pixel increments, 153 zones
Title Area Control Yes
Vertical Position Yes
Video Processing Optional
Wide Mode Yes
x.v.Color™ Technology Yes
Color Space Supports sRGB (Rec 709)
