SRS-Z050V
US Model SERVICE MANUAL
STEREO ACTIVE SPEAKER SYSTEM
MICROFILM
SPECIFICATIONS
This section is extracted
from instruction manual.
This product is marked in combination
with theVAIO Digital Studio Computer.
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK !OR DOTTED LINEWITH
MARK !ON THE SCHEMATIC DIAGRAMS AND INTHE PARTS
LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE
COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS
APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS
PUBLISHED BY SONY.
Ver 1.0 1999. 05
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

SECTION 2
DIAGRAMS
2-1. SCHEMATIC DIAGRAM
SRS-Z050V
Note on Schematic Diagram:
• All capacitors are in µF unless otherwise noted. pF: µµF
50 WV or less are not indicated except for electrolytics
and tantalums.
• All resistors are in Ωand 1/4W or less unless otherwise
specified.
• % : indicates tolerance.
•C: panel designation.
•U: B+ Line.
• Power voltage is dc 9 V and fed with regulated dc power supply
from external power voltage jack.
• Voltages and waveforms are dc with respect to ground under no-
signal (detuned) conditions.
• Voltages are taken with a VOM (Input impedance 10 MΩ).
Voltage variations may be noted due to normal production toler-
ances.
• Signal path.
F: AUDIO
— 3 — — 4 —
204GD
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

— 5 — — 6 —
2-2. PRINTEDWIRING BOARD SECTION 3
EXOPLODEDVIEW
Note on PrintedWiring Board:
•X: parts extracted from the component side.
•b: Pattern from the side which enables seeing.
NOTE:
• -XX, -X mean standardized parts, so they may
have some differences from the original one.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delayshouldbe anticipatedwhenorderingthese
items.
• Themechanical parts with no referencenumber
in the exploded views are not supplied.
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
SRS-Z050V
1 X-4951-822-1 GRILLE ASSY
2 4-211-620-11 CABINET (L), FRONT
3 3-831-441-99 CUSHION
4 4-211-621-11 CABINET (L), REAR
*5 A-4542-548-A AMPLIFIER BOARD,COMPLETE
*6 1-670-677-11 LED BOARD
7 4-213-000-01 CUSHION (LEDM’T)
8 4-211-625-21 BUTTON (POWER)
9 3-740-607-01 CUSHION
10 4-211-627-21 KNOB (VOLUME)
11 4-212-999-01 CUSHION, VOLUME
12 4-211-624-01 HOLDER, VOLUME
13 1-769-080-31 CORD (WITH PLUG)
14 4-211-629-11 CABINET (R), REAR
15 4-211-628-11 CABINET (R), FRONT
SP1 1-529-138-11 SPEAKER (057F016)
SP2 1-529-138-11 SPEAKER (057F016)
#1 7-685-646-79 SCREW +BVTP 3 ×8 TYPE2 N-S
#2 7-685-648-79 SCREW +P 3 ×12 TYPE2 NON-SLIT
#3 7-685-135-19 SCREW +P 2.6 ×10 TYPE2 SLIT
Ref. No. Location
D1 C-3
D2 C-3
D3 E-2
IC1 C-3
IC2 C-5
Q1 B-4
Q2 B-5
• Semiconductor
Location
DC IN 9V
11
(11)
11
(11)
ON
OFF
JK1
JK3
INPUT
JK2
R OUT
RV1
VOLUME
S1
POWER
(POWER)
C31
C29
C6 C5 C3
C17
C15
85 9
1
16 12
C13
C27 C14 C16
C10
C28
C9
R19
D3
C18
R4
R18 R17
R16 R15
R5 R7
C4
R6 R8
R3
Q2Q1
C30
C20
C12C11
C7
C32
C2
C26
C1
C8
C33
R10R9
R1
R2
-2 -1
R14
R13
R11
R12
C23
C24
C21 C19 C22
C25
D2
D1
RED BLKYEL
RED
RED
WHT
BLK YEL
1-670-677-
SP1
IC1
85 9
1
16 12
IC2
1-670-676-
AMPLIFIER BOARD
LED BOARD
12
A
B
C
D
E
34567
16
1
2
3
4
3
3
5
3
13
14
15
9
9
1
10
876
11 12
SP1
SP2
#1
#1
#2
#2
#1
#1
#3
#3
Supplied with RV1
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

— 7 — — 8 —
SECTION 4
ELECTRICAL PARTS LIST
SRS-Z050V
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delayshould beanticipated whenordering these
items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
*A-4542-548-A AMPLIFIER BOARD, COMPLETE
*************************
< CAPACITOR >
C1 1-124-903-11 ELECT 1uF 20% 50V
C2 1-124-903-11 ELECT 1uF 20% 50V
C3 1-130-469-00 MYLAR 680PF 5% 50V
C4 1-130-469-00 MYLAR 680PF 5% 50V
C5 1-126-957-11 ELECT 0.22uF 20% 50V
C6 1-126-957-11 ELECT 0.22uF 20% 50V
C7 1-124-903-11 ELECT 1uF 20% 50V
C8 1-124-903-11 ELECT 1uF 20% 50V
C9 1-126-933-11 ELECT 100uF 20% 16V
C10 1-126-933-11 ELECT 100uF 20% 16V
C11 1-124-443-00 ELECT 100uF 20% 10V
C12 1-124-443-00 ELECT 100uF 20% 10V
C13 1-126-933-11 ELECT 100uF 20% 16V
C14 1-126-933-11 ELECT 100uF 20% 16V
C15 1-124-443-00 ELECT 100uF 20% 10V
C16 1-124-443-00 ELECT 100uF 20% 10V
C17 1-124-443-00 ELECT 100uF 20% 10V
C18 1-124-443-00 ELECT 100uF 20% 10V
C19 1-130-497-00 MYLAR 0.15uF 5% 50V
C20 1-130-497-00 MYLAR 0.15uF 5% 50V
C21 1-130-497-00 MYLAR 0.15uF 5% 50V
C22 1-130-497-00 MYLAR 0.15uF 5% 50V
C23 1-124-907-11 ELECT 10uF 20% 50V
C24 1-124-907-11 ELECT 10uF 20% 50V
C25 1-126-966-11 ELECT 33uF 20% 16V
C26 1-124-907-11 ELECT 10uF 20% 50V
C27 1-162-306-11 CERAMIC 0.01uF 30% 16V
C28 1-126-935-11 ELECT 470uF 20% 16V
C29 1-126-926-11 ELECT 1000uF 20% 10V
C30 1-162-294-31 CERAMIC 0.001uF 10% 50V
C31 1-162-294-31 CERAMIC 0.001uF 10% 50V
C32 1-162-294-31 CERAMIC 0.001uF 10% 50V
C33 1-162-294-31 CERAMIC 0.001uF 10% 50V
< DIODE >
D1 8-719-911-19 DIODE 1SS119
D2 8-719-911-19 DIODE 1SS119
< IC >
IC1 8-759-512-88 IC TEA2025B
IC2 8-759-512-88 IC TEA2025B
< JACK >
JK1 1-569-966-11 JACKE, DC (DC IN)
JK2 1-565-376-31 JACK (R OUT)
JK3 1-565-376-31 JACK (INPUT)
< TRANSISTOR >
Q1 8-729-205-83 TRANSISTOR 2SC2458L-GR
Q2 8-729-205-83 TRANSISTOR 2SC2458L-GR
< RESISTOR >
R1 1-249-421-11 CARBON 2.2K 5% 1/4W F
R2 1-249-421-11 CARBON 2.2K 5% 1/4W F
R3 1-247-843-11 CARBON 3.3K 5% 1/4W
R4 1-247-843-11 CARBON 3.3K 5% 1/4W
R5 1-249-432-11 CARBON 18K 5% 1/4W
R6 1-249-432-11 CARBON 18K 5% 1/4W
R7 1-249-427-11 CARBON 6.8K 5% 1/4W F
R8 1-249-427-11 CARBON 6.8K 5% 1/4W F
R9 1-247-806-11 CARBON 91 5% 1/4W
R10 1-247-806-11 CARBON 91 5% 1/4W
R11 1-249-417-11 CARBON 1K 5% 1/4W F
R12 1-249-417-11 CARBON 1K 5% 1/4W F
R13 1-249-416-11 CARBON 820 5% 1/4W F
R14 1-249-429-11 CARBON 10K 5% 1/4W
R15 1-249-429-11 CARBON 10K 5% 1/4W
R16 1-249-429-11 CARBON 10K 5% 1/4W
R17 1-249-407-11 CARBON 150 5% 1/4W F
R18 1-249-407-11 CARBON 150 5% 1/4W F
< VARIABLE RESISTOR >
RV1 1-225-673-11 RES, VAR, CARBON 5K/5K (VOLUME)
************************************************************
*1-670-677-11 LED BOARD
*********
< LED >
D3 8-719-073-27 LED 204GD (POWER)
< RESISTOR >
R19 1-249-417-11 CARBON 1K 5% 1/4W F
< SWITCH >
S1 1-771-496-11 SWITCH, PUSH (POWER)
************************************************************
MISCELLANEOUS
**************
13 1-769-080-31 CORD (WITH PLUG)
SP1 1-529-138-11 SPEAKER (057F016)
SP2 1-529-138-11 SPEAKER (057F016)
************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
!1-467-817-11 ADAPTOR, AC (AC-S911)
3-864-194-11 MANUAL, INSTRUCTION (ENGLISH,SPANISH)
Ref. No. Part No. Description Remarks
AMPLIFIER LED
Sony Corporation
Personal Audio Company 99E1618-1
Printed in Japan ©1999.5
Published by General Engineering Dept.
9-927-128-11
The components identified by mark !or dotted
line with mark !are critical for safety.
Replace only with part number specified.
The components identified by mark !or
dotted line with mark !are critical for safety.
Replace only with part number specified.
