Sound Sation Spire XL 440 User manual

SPIRE XL 440
Moving Head Beam-Spot-Wash 20R
Please read this manual carefully and properly take care of it
USER MANUAL
Leggete questo manuale e conservatelo per future consultazioni
MANUALE UTENTE

Dear customer,
First of all thanks far purchasing a SOUNDSATION® product. Our mission is to satisfy
all possible needs of musical instrument and professional audio users oering a wide
range of products using the latest technologies.
We hope you will be satised with this item and, if you want to collaborate, we are
looking for a feedback from you about the operation of the product and possible
improvements to introduce in the next future. Go to our website www.soundsation-
music.com and send an e-mail with your opinion, this will help us to build instruments
ever closer to customer’s real requirements.
One last thing: read this manual before using the instrument, an incorrect operation
can cause damages to you and to the unit. Take care!
The SOUNDSATION Team
Gentile Cliente,
Grazie per aver scelto un prodotto SOUNDSATION®. La nostra missione è quella di
orire ai nostri utenti una vasta gamma di strumenti musicali ed apparecchiature audio
e lighting con tecnologie di ultima generazione.
Speriamo di aver soddisfatto le vostre aspettative e, se voleste collaborare, saremmo
lieti di ricevere un vostro feedback sulla qualità del prodotto al ne di migliorare co-
stantemente la nostra produzione. Visitate il nostro sito www.soundsationmusic.com ed
inviateci una mail con la vostra opinione, questo ci aiuterà a sviluppare nuovi prodotti
quanto più vicini alle vostre esigenze.
Un’ultima cosa, leggete il presente manuale al ne di evitare danni alla persona ed al
prodotto, derivanti da un utilizzo non corretto.
Il Team SOUNDSATION

3
ENGLISH
TABLE OF CONTENTS
1. INTRODUCTION.........................................................................................................6
1.1. UNPACKING .............................................................................................................................................................6
1.2. Accessories...............................................................................................................................................................7
2. OVERVIEW..................................................................................................................7
3. PRODUCT FEATURES.................................................................................................7
4. MAINS CONNECTIONS .............................................................................................8
5. DMX CONNECTION...................................................................................................8
5.1. DMX Terminator.....................................................................................................................................................9
5.2. 3-Pin vs 5-Pin DMX cables.................................................................................................................................9
6. INSTALLATION.........................................................................................................10
7. FRONT PANEL DESCRIPTION .................................................................................12
8. REAR PANEL DESCRIPTION....................................................................................13
9. LCD TOUCH-SCREEN OPERATION .........................................................................14
9.1. Address Menu.......................................................................................................................................................14
9.2. Workmode Menu ..............................................................................................................................................16
9.3. Display menu .....................................................................................................................................................18
9.4. Scene Menu.........................................................................................................................................................21
9.5. Advanced Menu.................................................................................................................................................24
9.6. Status Menu...........................................................................................................................................................25
9.7. Escape Funcion .....................................................................................................................................................26
10. DMX CHANNEL MODES..........................................................................................27
10.1. 23CH DMX Channel Mode...............................................................................................................................27
10.2. 26CH DMX Channel Mode...............................................................................................................................31
11. GOBO and COLOR WHEELS ....................................................................................35
11.1. Color Wheel ...........................................................................................................................................................35
11.2. Fixed Gobo Wheel 1 ...........................................................................................................................................35
11.3. Fixed Gobo Wheel 2 ...........................................................................................................................................36
11.4. Rotating Gobo Wheel.........................................................................................................................................36
12. TROUBLESHOOTING ...............................................................................................37
13. SPECIFICATION ........................................................................................................38
14. WARRANTY AND SERVICE.....................................................................................39
15. WARNING.................................................................................................................40

4
ENGLISH
SPIRE XL 440 User manual
IMPORTANT SAFETY SYMBOLS
The symbol is used to indicate that some hazardous live terminals are
involved within this apparatus, even under the normal operating con-
ditions, which may be sucient to constitute the risk of electric shock
or death.
The symbol is used in the service documentation to indicate that spe-
cic component shall be replaced only by the component specied in
that documentation for safety reasons.
Protective grounding terminal
Alternating current/voltage
Hazardous live terminal
Denotes the apparatus is turned on
Denotes the apparatus is turned o
WARNING: Describes precautions that should be observed to prevent the danger
of injury or death to the operator.
CAUTION: Describes precautions that should be observed to prevent danger of
the apparatus.
To protect the environment, please try to recycle the packing material
as much as possible
The projector is for indoor use only, IP20. Use only in dry locations.
Keep this device away from rain and moisture, excessive heat, humid-
ity and dust. Do not allow contact with water or any other uids, or
metallic objects.
Don’t throw this product away just as general trash, please deal with
the product follow the abandon electronic product regulation in your
country.
0.5m
Locate the xture in a well ventilated spot, away from any ammable
materials and/or liquids. The xture must be xed at least 50cm from
surrounding walls
TAKING CARE OF YOUR PRODUCT
fRead these instructions
fKeep these instructions
fHeed all warning
fFollow all instructions

5
ENGLISH
SPIRE XL 440 User manual
1) Water / Moisture
The apparatus should be protected from moisture and rain and can not be used near
water; for example near a bathtub, a kitchen sink, a swimming pool, etc.
2) Condensation
To avoid condensation to be formed inside, allow this unit to adapt to the surrounding
temperatures when bringing it into a warm room after transport. Condense sometimes
prevents the unit from working at full performance or may even cause damages.
3) Heat
The apparatus should be located away from heat sources such as radiators, stoves or
other appliances that produce heat. Don not use it when maximum ambient tempera-
ture is higher than 40°C This equipment shell temperature around 40°C (104°F) to 50 °C
(122°F) while work, do not touch the shell.
4) Ventilation
Do not block areas of ventilation opening. Failure to do could result in re. Always
install according to the manufacturer’s instructions.
5) Object and Liquid Entry
Objects do not fall into and liquids are not spilled into the inside of the apparatus for
safety.
6) Power Cord and Plug
Protect power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus. Do not defeat the safety
purpose of the polarized or grounding-type plug. A polarized plug has two poles; a
grounding-type plug has two poles and a third grounding terminal. The third prong is
provided for your safety. If the provided plug does not t into your outlet, refer to an
electrician for replacement..
7) Power Supply
The apparatus should be connected to the power supply only of the type as marked on
the apparatus or described in the manual. Failure to do could result in damage to the
product and possibly the user. Check whether the power supply and voltage are normal
before use. If the voltage uctuates greatly, it is recommended to use voltage stabilizer
or voltage regulatorUnplug this apparatus during lightning storms or when unused for
long periods of time.
8) Electrical Connection
Always disconnect from the power source before servicing or replacing fuse and be
sure to replace with same fuse size and type. Cut o power before moving, repairing
and cleaning the unit. Improper electrical wiring may invalidate the product warranty.
To avoid electric shock, all xtures must be connected to circuits with a suitable ground.

6
ENGLISH
SPIRE XL 440 User manual
9) Fuse
To avoid the risk of re and damage to the unit, use only the type of fuse described
in the manual. Before replacing the fuse, make sure the device is switched o and
unplugged.
10) DMX connection
When use DMX controller, please make sure that there is no interference sources (e.g.
intercom, high frequency radio waves and radiation source).
11) Cleaning
Clean only with a dry cloth. Do not use any solvents such as benzene or alcohol.
12) Servicing
Do not implement any servicing other than those means described in the manual. Refer
all servicing to qualied service personnel only. The internal components of the equip-
ment must be purchased from the manufacturer Only use accessories/attachments or
parts recommended by the manufacturer.
1. INTRODUCTION
Thank you for purchasing our SPIRE XL 440 moving head. Enjoy your new equipment
and make sure to read this manual carefully before operation!
This user manual is made to provide both an overview of controls, as well as informa-
tion on how to use them. In order to help you to understand the connections between
the various controls, we have gathered in groups according to their functions.
1.1. UNPACKING
Your SPIRE XL 440 moving head was carefully packed to ensure safe transport. Despite
this, we recommend you to carefully examine the package and its contents for any
signs of physical damage, which can occur during transport. Each unit has the following
parts:
fMoving Head
fPower Cord (EU plug – PowerCon)
f1 x DMX Cable (3-Pin XLR Male to Female)
f2 x Omega Clamps
fUser manual
ATTENTION: Packaging bag is not a toy! Keep out of reach of children!!! Keep
in a safe place the original packaging material for future use.
If anything damaged during transport, notify the shipper immediately and keep the
packing material for inspection. Again, please save the carton and all packing materi-

7
ENGLISH
SPIRE XL 440 User manual
als. If the xture must be returned to manufacturer, it is important that the xture be
returned in the original manufacturer box and packing. Please do not take any action
without rst contacting us.
1.2. Accessories
SOUNDSATION can supply a wide range of quality accessories that you can use with
your SPIRE Series moving head, like Cables, Splitters, DMX controllers, and a wide range
of other xtures.
All products in our catalogue has been long tested with this device, so we recommend
you to use Genuine SOUNDSATION Accessories and Parts.
Ask your SOUNDSATION dealer or check out our website www.soundsationmusic.com
for any accessories you could need to ensure best performance of the product.
2. OVERVIEW
SOUNDSATION SPIRE Series is enriched with a new professional tool for medium-large
applications in both rental and xed-installation venues. The SPRE XL 440 is a 3-in-1
moving head with a standard 440W 20R-type lamp. The optics and the eects allow
the use as Beam, Spot or Wash xture. The quality of mechanics, motor precision and
high technology controls allow accurate, silent and precise movements. The presence
of three gobos wheels, one color wheel with CTO, CTW and CMY lters, and two prisms
make easy to play with color palette and eects, to satisfy even the most demanding
light designers. The 3.7 “touch-screen display and the front USB port allow the machine
to be quickly set up, even when the unit is switched o. The set consists of two moving
heads and a ight case with front doors and hook space, to facilitate the installation on
stage especially in live contexts.
3. PRODUCT FEATURES
f20R-Type Bulb Lamp.
f8000K Color Temperature.
fBeam/Spot/Wash Moving Head Operation.
fHigh-Precision X/Y Scan Movements, With Silent 3-Phase Motors and Electronic
Correction.
fSmooth Electronic Dimmer 0-100% with 1-20t/S Shutter
fBeam Angle from 2.3° to 56° with Electronic Linear Zoom and Focus.
fRainbow eect with color wheel.
fColor Wheel with 12 color + 2 CTO + 1 CTB + 1 CMY + White-Open + Semi-Color
Eect.
f2 Fixed-Gobo wheels and 1 Rotating- Gobo wheel, all with Bi-Directional Flow
Eect.

8
ENGLISH
SPIRE XL 440 User manual
f8-Facet and 16-Facet Prisms.
fFrost Eect for Wash Applications.
fDMX512 control with Remote Device Management.
fAccurate Cooling System with Intelligent Safety Protection System.
fFront Panel with 3.7” Touch-Screen Color Display, 4-Button interface.
fMicro-USB Port for External Power Adapter or Power-Bank, to allow Quick Unit
Setting without Switching On the Unit
f2 Channel Mode (23CH, 26CH)
fDMX512, Master/Slave, Auto, Sound, Scene Control Modes
4. MAINS CONNECTIONS
Connect the device to the mains with the supplied power cable. Please note that power
voltage and frequency are the same as the marked voltage and frequency of device
when connecting power. Wire correspondence is as follows:
Cable (EU) Pin International
Brown Live L
Blue Neutral N
Yellow/Green Earth
The earth must to be connected! Pay attention to the safety! Before taking
into operation for the rst time, the installation has to be approved by an
expert.
5. DMX CONNECTION
DMX xtures are designed to receive data through a serial Daisy Chain. A Daisy Chain
connection is where the DATA OUT of one xture connects to the DATA IN of the next
xture. The order in which the xtures are connected is not important and has no eect
on how a controller communicates to each xture. Use an order that provides for the
easiest and most direct cabling.
3-Pin XLR
Pin 1: GND
Pin 2: DMX -
Pin 3: DMX +
OUTPUTINPUT
DMX use of 3-Pin XLR Connectors
DMX Termonator
Unit 1 Unit 2 Last Unit
DMX 512
Connect xtures using shielded 2-conductor twisted pair cable with 3-pin XLR male to

9
ENGLISH
SPIRE XL 440 User manual
female connectors. The shield connection is pin 1, while pin 2 is Data Negative (S-), and
pin 3 is Data positive (S+).
CAUTION: Wires must not come into contact with each other; otherwise the
xtures will not work at all, or will not work properly.
5.1. DMX Terminator
DMX is a resilient communication protocol, however errors still occasionally occur.
In order to prevent electrical noise from disturbing and corrupting the DMX control
signals, a good habit is to connect DMX output of last xture in the chain to a DMX
terminator, especially over long signal cable runs.
The DMX terminator is simply an XLR connector with a 120Ω (ohm), 1/4 Watt resistor
connected across Signal (-) and Signal (+), respectively, pins 2 and 3, which is then
plugged into the output socket on last projector in the chain. The connections are
illustrated below.
120ohm, 1/4
W
Resistor
DMX Terminator
Complimentary signal cable can transmits signals to 20 unit xtures at most.
Signal amplier is a must to connect more xtures.
5.2.3-Pin vs 5-Pin DMX cables
DMX connection protocols used by controllers and xtures manufacturers are not stan-
dardized around the world. However, two are the most common standards: 5-Pin XLR
and 3-Pin XLR system. If you wish to connect MOOD 185 WASH to a 5-Pin XLR input
xture, you need to use an adapter-cable or make it by yourself.
Following the wiring correspondence between 3-Pin and 5-Pin plug and socket stan-
dards
5-Pins XLR (plug)
Pin 1: GND (Screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
Pin 4: N/C
Pin 5: N/C
3-Pins XLR (socket)
Pin 1: GND (Screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
5-Pins XLR (socket)
Pin 1: GND (Screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
Pin 4: N/C
Pin 5: N/C
3-Pins XLR (plug)
Pin 1: GND (Screen)
Pin 2: Signal (-)
Pin 3: Signal (+)

10
ENGLISH
SPIRE XL 440 User manual
6. INSTALLATION
Pay attention to safety! Please respectively consider the EN 60598-2-17 and
the national standard during the installation. The authorized dealer must
only carry out the installation.
The installation of the xture has to be built and constructed in a way that it can hold
10 times the weight for 1 hour without any harming demolition. The installation must
always be secured with a secondary safety attachment, e.g. an appropriate catch net.
This secondary safety attachment must be constructed in a way that no part of the
installation can fall down if the main attachment fails.
When rigging, de-rigging or servicing the xture staying in the area below the instal-
lation place, on bridges, under high working places and other endangered areas is
forbidden. The operator has to make sure that the safety measure and the machine’s
technical installation is approved by an expert before taking into operation for the rst
time and after changes before taking into operation anther time. He has also to make
sure that an expert approves safety measure and the machine’s technical installation
once a years.
WARNING: The xture should be installed outside areas where persons may
walk by or be seated.
IMPORTANT: Overhead rigging requires extensive experience, including (but
not limited to) calculating working load limits, installation material being
used, and periodic safety inspection of all installation material and the pro-
jector. If you lack these qualications, do not attempt the installation your-
self, but instead use a professional structural rigger. Improper installation can
result in bodily injury or property loss.
If the xture shall be lowered from the ceiling or high joists, professional trussing
systems have to be used. The xture must never be xed swinging freely in the room.
Before rigging make sure that the installation area can hold a minimum point load of
10 times the projector’s weight.
CAUTION: Fixture may cause severe injuries when crashing down. If you have
doubts concerning the safety of a possible installation, do not install the
xture!
CAUTION: Use two appropriate clamps to rig the xture on the truss. Follow
the instructions mentioned at the bottom of the base. Make sure that the
device is xed properly! Ensure that the structure (truss) to which you are
attaching the xtures is secure.
DANGER OF FIRE! When installing the device, make sure there is no highly
inammable material (decoration articles, etc.) within a distance of minimum
0.5 meter.

11
ENGLISH
SPIRE XL 440 User manual
The moving head can be placed directly on the oor or rigged in any orientation on a
truss, without altering its operation characteristics. Please refer to the picture below and
strictly follow the instructions.
5
1
2
3
5
5
4
90°
2
6
6
fUse clamps suitable for the section of the truss on which you want to x the mov-
ing head.
fInsert the screw in the central hole of the bracket n.2, and tighten the nut supplied
with the clamp (and any washers always supplied with the clamp).
fPlace the plugs with wings n.3 in the direction of the holes n.5 placed under the
base of the moving head. Screw them clockwise for about 90°, until you hear a click
that indicates the achievement of the correct and safe position.
fHook the moving head to the truss through the two clamps now perfectly xed to
the base, and screw the wing-screw n.4 so as to tighten the moving head and avoid
as much as possible vibrations during the use of the xture.
fFor overhead use, always install a safety rope that can hold at least 10 times the
weight of the xture. Hook the safety cable to the hole n.6 located under the base
of the moving head.

12
ENGLISH
SPIRE XL 440 User manual
7. FRONT PANEL DESCRIPTION
UPDATE
1
001 DMX . . .
SPIRE XL 440
SIG
MIC
MENU
UP
DOWN
ENTER
2
3
4
56
7
8
1) LCD TOUCH SCREEN GRAPHIC DISPLAY
It shows the operating mode and other system information. Thanks to the touch screen
feature, it is possible to change all the parameters of the moving head directly from the
display.
2) ENTER BUTTON
This button allows access to the functions from the main menu and conrms the pa-
rameter values once set
3) DOWN BUTTON
It scrolls down individual items in the selection menu and sub-menus for system set-
tings (Address, Mode, Display etc.) and decreases the values/settings of parameters.
4) UP BUTTON
It scrolls up individual items in the selection menu and sub-menus for system settings
(Address, Mode, Display etc.) and increases the values/settings of parameters.
5) MENU BUTTON
Pressing this button returns to the main menu
6) POWER USB Connection
External power function with USB connection (for power bank, Laptop, etc.) for moving
head parameters setting using display without the device being turned on using the
power button.
7) SIG LED
The status of this blue LED (ON, OFF, Blink), depends on the connection to a DMX con-
troller and how the “DMX Indicate” parameter is set in the “Display” section.

13
ENGLISH
SPIRE XL 440 User manual
8) MIC LED
This red LED blinks when the device is set to “SOUND” mode, and indicates that the
microphone is active
8. REAR PANEL DESCRIPTION
dmx
power
fuse
on
432 1
10a
inout
ac 110 ~ 240v 50/60hz
1 = g round
2 = d ata -
3 = d ata +
off
5
1) POWER ON/OFF SWITCH
2) FUSE HOLDER
Fuse holder with F10AL / 250 V fuse (5 x 20 mm). In case of fuse burn, to prevent the
risk of re and damaging the unit, please use only a spare of the recommended fuse
type as described. Before replacing the fuse, make sure the unit turned o and discon-
nected from the AC outlet
3) POWER IN SOCKET
Plug the power-cord into an AC socket properly congured for your particular model.
4) DMX INPUT
Male 3-pin XLR sockets for connection to a DMX control device
5) DMX OUTPUT
Female 3-pin XLR socket for sending the DMX control signal.

14
ENGLISH
SPIRE XL 440 User manual
9. LCD TOUCH-SCREEN OPERATION
At machine power-on, all the electrical and mechanical parts reset and, the display
shows the reset operations during their execution.Once the start-up procedure is
nished, the main MENU appears and the display will show the current DMX operating
mode, the current start DMX channel and other information relating to the current
device status:
SUPER CMY SPOT 3IN1
001
23CHB 01. 01
00:58:17
ADDRESS
WORKMODE
DISPLAY
SCENE
ADVANCED
STATUS
001 12.0 NOR FULL
By pressing the [UP] and / or [DOWN] buttons on the control panelyou can select
the desired sub-menu which can be accessed by pressing the [ENTER] button on the
control panel. The desired sub-menu can be accessed directly by touching the graphic
button shown on the display.
9.1. Address Menu
The Address Menu allows you to set the DMX channel, the DMX Mode and also to re-
set the machine. To access this sub menu, touch the [ADDRESS] graphic button on the
display ( gure below ).
SUPER CMY SPOT 3IN1
001
23CHB 01. 01
00:58:17
ADDRESS
WORKMODE
DISPLAY
SCENE
ADVANCED
STATUS
001 12.0 NOR FULL
Address
Workmode
Display
Scene
Advanced
Status
Escape
001
23CHB 01. 01
Previous
Next
Channel SysRst
1) DMX Mode
By touching the [Channel] graphic button on the display, one of the two DMX modes
available in the device can be selected. The DMX mode (23CH or 26CH) will be dis-
played below the DMX channel information

15
ENGLISH
SPIRE XL 440 User manual
2) SysTEM RESET
By touching the [SysRst] graphic button on the display, the device will reset its electron-
ic / mechanical parts and all the parameters by setting them with the default values.
3) CHANNEL MODE start DMX Address
By touching the [Previous] or [Next] graphic buttons, it is possible to select the starting
address based on the selected channel mode. For example if the selected DMX channel
is 1 and the DMX mode is 26CH, touching the graphic button [Next], the starting ad-
dress will become 27 and each time the [Next] button is touched, the starting address
will be added the value 26. In DMX mode 23CH, the value added will be 23. Pressing
the [Previous] button, the value corresponding to the current DMX mode (23 or 26) will
be subtracted to the value set for the DMX channel.
4) DMX Address
By touching on the display the area where the current DMX address is displayed, a
window will open to make the change ( gure below ).
Address
Workmode
Display
Scene
Advanced
Status
Escape
001
23CHB 01. 01
Previous
Next
Channel SysRst
Address
Workmode
Display
Scene
Advanced
Status
Escape
Previous
Next
Channel SysRst
001
23CHB 01. 01
001
Address
By using the [UP]/[DOWN] buttons on the control panel, it is possible to modify the
DMX address value. By pressing the [ENTER] button on the control panel, the value
selected will be conrmed and the device will return to display the “Address” submenu.
To exit the DMX address editing environment without any saving, simply press the
[MENU] button on the control panel.
All the operations explained above are also possible using the graphic buttons shown
on the touch screen display. By touching the / graphic buttons it is possible to
modify the DMX address value. To save the set value touch the graphic button.
To exit the DMX address editing environment without any saving, touch “Escape” on
the display. You can also change the DMX address value by touching the red square
and dragging it to the right or left as shown in the gure below.
001
Address

16
ENGLISH
SPIRE XL 440 User manual
9.2. Workmode Menu
This sub-menu can be accessed both from the main menu and from the window where
all the sub-menus are listed as shown in the gure below.
SUPER CMY SPOT 3IN1
001
23CHB 01. 01
00:58:17
ADDRESS
WORKMODE
DISPLAY
SCENE
ADVANCED
STATUS
001 12.0 NOR FULL
Address
Workmode
Display
Scene
Advanced
Status
Escape
001
23CHB 01. 01
Previous
Next
Channel SysRst
After selection, the display will show all the operating modes of the “Workmode” sub-
menu as shown in the gure below.
Address
Workmode
Display
Scene
Advanced
Status
Escape
DMX Ctrl
Auto Run
Sound Ctrl
Scene Mode Auto
M/S Choose Master
Light Switch OFF
By pressing the [UP] and / or [DOWN] buttons on the control panel you can select the
desired operating mode and then by pressing the [ENTER] button on the control panel
it will be actitvated. To exit the “Workmode” sub -menu, press the [MENU] button on
the control panel. The device will return to display the main menu. When an operating
mode is selected on the left side of the display the [ ] symbol is shown.
All the operations explained above are also possible using the touch screen display.
In fact, touching the desired operating mode with the nger on the display will imme-
diately select it.
1) DMX Ctrl
When this operating mode is selected it means that the device must be managed by a
DMX controller. If DMX Ctrl is selected but, the device is not connected to any control-
ler or no DMX signal is received, in the main menu, at the bottom left, the information
relative to the DMX address will blink.
00:58:17
DISPLAY STATUS
001 12.0 NOR FULL

17
ENGLISH
SPIRE XL 440 User manual
2) AUTO RUN
Fixture automatically run according to built-in program. In the main menu, at the bot-
tom left, the display will show the current operating mode. (Refer to the gure below).
00:58:17
DISPLAY STATUS
AUTO 12.0 NOR FULL
3) SOUND CTRL
If the “Sound Ctrl” mode is selected and the integrated microphone detects strong
sounds, the device will run automatically a scene according to the built-in program,
otherwise, the previous scene will be maintained. On the control panel the MIC LED
will blink and, in the main menu, at the bottom left, the display will show the current
operating mode. (Refer to the gure below).
00:58:17
DISPLAY STATUS
SOUND 12.0 NOR FULL
4) SCENE MODE
This operating mode runs a set of scenarios, supporting up to 10 custom editable
scenarios. By touching “Scene Mode”, it is possible to select the “Auto” Scene Mode or
one of the 10 scenarios available. In the “Auto” scene mode , the scene is automatically
looped in the set time (≠0) sequence and the scene with time set to 0 is ignored and
then skipped. When one of the 10 possible scenarios is selected, it will be automatically
executed. The selection of the desired scenario or the “Scene Auto” mode can also be
made using the buttons on the control panel. The [UP] / [DOWN] buttons must be used
to select the “Scene” operating mode and the [ENTER] button to activate this mode.
Once this operating mode has been selected, the [ENTER] button can be used to select
one of the 10 scenarios or “Auto scene mode”. In the main menu, at the bottom left,
the display will show the current operating mode. (Refer to the gure below).
00:58:17
DISPLAY STATUS
SCEN 12.0 NOR FULL
5) M/S CHOOSE
This option gives the possibility to set the device as Master or Slave. Obviously to make
this setting it is necessary to have 2 or more devices available. Set one of the machines
as “Master”, select one of the automatic modes (Auto Run, Sound Ctrl, Scene Mode),
set the other machine as the Slave. The “Slave” machine must have the DMX address
set to 001 to be connected to the DMX signal of the “Master” machine. At this time, the
slave machine accepts the host control, and the functions are synchronized with the
current function. The “M/S Choose” option allows three settings: Master, Slave or Auto.
By using the Auto setting, if there is no signal from DMX, the xture will operate by
built-in program; otherwise, the xture will operate by DMX signal. To select one of the
three settings, touch the display screen at “M/S Choose”.

18
ENGLISH
SPIRE XL 440 User manual
6) LiGHT SWITCH
Allows you to turn the lamp on or o. This command is useful when you want to reduce
the consumption of the lamps, making sure that it is always o at moving head pow-
er-on. It will then be possible to switch it on via DMX command only when the light
show starts.
Address
Workmode
Display
Scene
Advanced
Status
Escape
DMX Ctrl
Auto Run
Sound Ctrl
Scene Mode Auto
M/S Choose Master
Light Switch OFF
Light Switch
SURE NO
By touching on the display the “Light Switch” option, a window will open to conrm the
lamp ON/OFF operation. In the main menu, at the bottom, the information related to
the lamp will be the change color of the lamp symbol (Black=O - Yellow=On).
00:58:17
DISPLAY STATUS
SCEN 12.0 NOR FULL
9.3. Display menu
This sub-menu can be accessed both from the main menu and from the window where
all the sub-menus are listed as shown in the gure below.
SUPER CMY SPOT 3IN1
001
23CHB 01. 01
00:58:17
ADDRESS
WORKMODE
DISPLAY
SCENE
ADVANCED
STATUS
001 12.0 NOR FULL
Address
Workmode
Display
Scene
Advanced
Status
Escape
DMX Ctrl
Auto Run
Sound Ctrl
Scene Mode Auto
M/S Choose Master
Light Switch OFF
After selection, the display will show all the “Display” sub-menu options as shown in the
next gure.

19
ENGLISH
SPIRE XL 440 User manual
Address
Workmode
Display
Scene
Advanced
Status
Escape
Screen Saver
DMX Signal LED
DMX LED Bright 010
Screen Light
English
OFF
Screen Rot Auto
Mode3
010
Touch Enable OFF
Touch Rectify
Language
In the rst line at the top of the display, you can select the display language between
English and Chinese by touching one of the two options.
Screen Saver
Activates the screen saver and chooses among three modes (OFF, Mode1, Mode2,
Mode3). The screen saver selection could be done by touching the “Screen saver”
option.
Screen Rot
This option is used to select the screen direction. (Forward ,Reverse, Auto). The selec-
tion could be done by touching the “Screen Rot” option.
When “Auto” mode is selected, the device position will be automatically detected and
then the display will be rotated in the right direction.
DMX Signal LED
It selects the indication mode for the SIG LED on the front panel.
- Mode1: The SIG LED lights on when there is a DMX signal and goes o
when there is no signal.
- Mode2: The SIG LED is o when there is a DMX signal and lights up when
there is no signal.
- Mode3: The SIG LED blinks when there is a DMX signal and goes o
when there is no signal.
DMX LED Bright
By touching the “Signal Bright” option with your nger, you can change the illumina-
tion intensity of the SIG LED. A window will appear on the display where you can make
the change. By touching the / graphic buttons it is possible to increase/decrease
the LED SIG brightness. To save the set value touch the graphic button. You can
also change the value by touching the red square and dragging it to the right or left as
shown in the gure below.
007
DMX LED Bright

20
ENGLISH
SPIRE XL 440 User manual
Screen Light
By touching the “Screen Light” option with your nger, you can change the illumination
intensity of the display. A window will appear on the display where you can make the
change. By touching the / graphic buttons it is possible to increase/decrease the
display brightness. To save the set value touch the graphic button. You can also
change the value by touching the red square and dragging it to the right or left as
shown in the gure below.
009
Screen Light
Touch Enable
This option allows you to Enable/Disable the Touch function on the screen. A window
will open to conrm the operation.
Address
Workmode
Display
Scene
Advanced
Status
Escape
Screen Saver
DMX Indicate
Signal Bright 010
Screen Light
English
OFF
Screen Rot Auto
Mode3
010
Touch Enable OFF
Touch Rectify
Sound Ctrl
Scene Mode Auto
M/S Choose Master
Touch Enable
SURE NO
Once the “Touch” function is disabled, to re-enable it, use the [UP] and [DOWN] but-
tons on the control panel. The “Touch Enable” window will appear again and using the
[UP] and [DOWN] buttons, you will need to select “Sure” and then press the [ENTER]
button.
Touch Rectify
This option must be selected when the display needs to be re-calibrated. A window will
open to conrm the operation as shown in the gure below.
Address
Workmode
Display
Scene
Advanced
Status
Escape
Screen Saver
DMX Indicate
Signal Bright 010
Screen Light
English
OFF
Screen Rot Auto
Mode3
010
Touch Enable OFF
Touch Rectify
Sound Ctrl
Scene Mode Auto
M/S Choose Master
Touch Rectify
SURE NO
