Spagna Vetro 168 Series Assembly instructions

Installation Guide
and Users Manual
Wall Mount Range Hood
168/198 Series Wall Hood
IMPORTANT:
Read and save these instructions.
NOTICE:
Installer: Leave this guide with the homeowner
Homeowner: Keep this guide for future reference
Suitable for:
Standard Class
“R” Class
“E” Class
Rev. 1016u.3c

Important Safety Notice
Read all Instructions before Installing and operating this appliance
The installation in this manual is intended for qualied installers, service technicians or persons with •
similar qualied background. Installation and electrical wiring must be done by qualied profession-
als and in accordance with all applicable codes and standards, including re-rated construction.
DO NOT• attempt to install this appliance yourself. Injury could result from installing the unit due to
lack of appropriate electrical and technical background.
Range hood may have very sharp edges; please wear protective gloves if it is necessary to remove any •
parts for installing, cleaning or servicing.
Activating any switch ON before completing installation may cause ignition or an explosion.•
Due to the size and weight of this range hood, two people installation is recommended.•
To reduce the risk of re, electric shock, or injury to persons:
For general ventilating use only. • DO NOT use to exhaust hazardous or explosive materials and va-
pors.
The combustion air ow needed for safe operation of fuel-burning equipment may be affected by this •
unit’s operation. Follow the heating equipment manufacturer’s guideline and safety standards such
as those published by the National Fire Protection Association (NFPA), and the American Society of
Heating, Refrigeration and Air Conditioning Engineers (ASHRAE), and the local code authorities.
Before servicing or cleaning unit, switch power OFF at service panel and lock service panel to pre-•
vent power from being switched ON accidentally.
Clean grease laden surfaces frequently. To reduce the risk of re and to disperse air properly, make •
sure to vent air outside. DO NOT vent exhaust into spaces between walls, crawl spaces, ceiling, attics
or garages.
Ducted fans MUST always be vented to the outdoors.•
Use only metal ductwork and this unit MUST be grounded.•
Sufcient air is needed for proper combustion and exhausting of gases through the duct to prevent •
back drafting.
When cutting or drilling into wall or ceiling, be careful not to damage electrical wiring or other hid-•
den utilities.
All electrical wiring must be properly installed, insulated and grounded.•
Old duct work should be cleaned or replaced if necessary to avoid the possibility of a grease re.•
Check all joints on duct work to insure proper connection and all joints should be properly taped.•
Use this unit only in the manner intended by the manufacturer. If you have questions, contact the •
vendor.
To reduce the risk of a stove top grease re:
Keep all fan, bafe, spaces, lter, grease tunnel, oil container and grease-laden surfaces clean. Grease •
should not be allowed to accumulate on fan, bafe, spaces, lter, grease tunnel and oil container.
Always turn range hood ON when cooking at high heat or when cooking aming foods. •
Use high settings on cooking range only when necessary.•
Never leave surface units unattended at high settings. Boil overs cause smoking and greasy spillovers •
that may ignite. Heat oils slowly on low or medium settings. Page 1

Page 2
Important Safety Notice
Read all Instructions before Installing and operating this appliance
The manufacturer and/or distributor/reseller declines all responsibility in the event of failure to ob-
serve the instructions given here for installation, maintenance and suitable use of the product.
The manufacturer and/or distributor/reseller further declines all responsibility for injury due to neg-
ligence and the warranty of the unit automatically expires due to improper maintenance.
The manufacturer and/or distributor/reseller will not be held responsible for any damages to per-
sonal property or real estate or any bodily injuries whether caused directly or indirectly by the range
hood.
Clean ventilating fan frequently.•
Always use appropriate cookware and utensils size.•
Always use cookware appropriate for the size of the surface element.•
To reduce the risk of injury to persons in the event of a stove top grease re:
SMOTHER FLAMES with a close-tting lid, cookie sheet, or metal tray, then turn OFF the burner. •
BECAREFUL TO PREVENT BURNS. NEVER PICK UP A FLAMING PAN—you may be burned.
KEEP FLAMMABLE OR COMBUSTIBLE MATERIAL AWAY FROM FLAMES. If the ames DO
NOT go out immediately, EVACUATE AND CALL THE FIRE DEPARTMENT or dial your local
emergency service immediately.
DO NOT USE WATER, including wet dishcloths or towels — a violent steam explosion will result.•
Use an extinguisher ONLY if:•
You know you have a Class A, B, C extinguisher, and you already know how to operate it.•
The re is small and contained in the area where it is started.•
The re department is being called.•
You can ght the re with your back to an exit.•
To reduce the risk of injury to persons in the event of a gas leaks:
Extinguish any open ame.•
DO NOT turn on the range hood fan or any type of ventilator.•
DO NOT turn on the lights or any type of appliance.•
Open all doors and windows to disperse the gas. If you still smell gas, call the gas company and re •
department, or dial your local emergency service immediately.
WARNING
Your safety and the safety of others is very important. We have provided many important safety mes-
sages in this manual and on your appliance. Always read and obey all safety messages. All safety mes-
sages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you
what can happen if the instructions are not followed.
This is the safety alert symbol. This symbol alerts you to potential hazards that can hurt you and others.
All safety messages will follow the safety alert symbol and the word “WARNING”.

Tools needed:
Page 3
Level
Flat-blade and
Phillips screw-
drivers
Powered
screwdriver
or drill
Measuring
tape
Utility knife
Marker or
pencil
Table of Contents
INSTALLATION
Tools needed....................................................3
Parts supplied...................................................4
Venting requirements.......................................5
Mount heights & clearance...........................5-6
Calculating vent system length.......................6
Venting methods & ductless conversion..........7
Charcoal lters & electrical requirements.......8
Preparation......................................................9
Installation................................................10-12
Range hood operations............................13-19
USE AND CARE
Troubleshooting...........................................20
Use and care information...............................21
Specications..............................................21
MAINTENANCE
Cleaning...............................................22
Replacing lter & light bulb....................22-23
WARRANTY
Coverage & exceptions.................................24
Disclaimer & contact information..................25

Page 4
Air diverter
(Optional re-circulating kit)
Charcoal Filter
(Optional re-circulating kit)
Description Quantity
Toggle Bolts 2 Pcs
Duct Set 1 Set
Body Hook (vary with model) 2 Pcs
Chimney Mounting Bracket 1 Set
This Guide and Warranty Card 1 Set
5mm x 16mm Screw with Washer 4 Set
4mm x 16mm Tapping Screw 6 Pcs
4mm x 10mm Tapping Screw 16 Pcs
Optional: Toggle Bolt with Tapping Screw for Air Diverter 2 Set
Optional: Screw for Charcoal Filter 3 Pcs
Stainless Steel Bafe or
Aluminum Filter(s)
Lower standard chimney Upper standard chimney
Flexible Duct Tube (Optional)
Flappers
Parts supplied: Range Hood
(vary with model)
Remote Control
(Optional w/ “R” Class
Control)
Mounting Bracket

Page 5
Max*: 110”
Standard
Upper
Chimney
Extension available*
Range hood
Mounting
Bracket
Standard
Lower
Chimney
Extension available*
36” base
Maximum* ceiling clearance
110” at 31” hood mounting
height above countertop/stove
(may vary with different
model). Chimney extensions
available for higher ceiling.
* Higher ceiling requires chim-
ney extension. Available at your
local resellers.
Min: 28”
Max: 31”
Venting Requirements Height & Clearance
Vent system must terminate to the outside •
(roof or side wall).
DO NOT terminate the vent system in an at-•
tic or other enclosed area.
DO NOT use 4” (10.2 cm) laundry-type wall •
caps.
Use metal/aluminum vent only. Rigid metal/•
aluminum vent is recommended.
DO NOT use plastic vent.•
Always keep the duct clean to ensure proper •
airow.
Calculate the following gures before instal-•
lation:
Distance from the oor to the ceiling.1.
Distance between the oor to the coun-2.
tertop/stove (recommend* 28” to 31”).
Distance between the countertop/stove3.
to the range hood.
Height of hood and duct cover.4.
For the most efcient & quiet operation:
A distance of 28” to 31” is recommended* •
between stove top and the bottom of range
hood.
It is recommended that the range hood be •
vented vertically through the roof through 6”
(15.2 cm) or bigger round metal/aluminum
vent work.
The size of the vent should be uniform.•
Use no more than three 90° elbows.•
Make sure there is a minimum of 24” (61 •
cm) of straight vent between the elbows if
more than one elbow is used.
DO NOT install two elbows together.•
The length of vent system and number of •
elbows should be kept to a minimum to pro-
vide efcient performance.
The vent system must have a damper. If •
roof or wall cap has a damper, DO NOT
use damper (if supplied) on top of the range
hood.
Use silver tape or duct tape to seal all joints •
in the vent system.
Use caulking to seal exterior wall or roof •
opening around the cap.
* Due to different ceiling height congurations, rec-
ommended height may not be applicable.
Countertop/Stove

IMPORTANT:
A minimum of 6” round (standard for this range hood) or 3-1/4 x 10” rectangular duct (purchased separately) •
must be used to maintain maximum airow efciency.
Flexible 6” round duct provided for convenience, always use rigid type metal/aluminum ducts if available to •
maximize airow when connecting to provided duct.
Please use • Duct Run Calculation below to compute the total available duct run when using elbows, transitions
and caps.
ALWAYS, when possible, reduce the number or transitions and turns. If long duct run is required, increase •
duct size from 6” to 7” or 8”. If a reducer is used, install a long reducer instead of a pancake reducer. Reduc-
ing duct size will restrict airow and decrease airow, thus reduce duct size as far away from opening as pos-
sible.
If turns or transitions are required: Install as far away from opening and as far apart, between 2, as possible.•
Minimum mount height between stove top to hood bottom should be no less than 28-inch*.•
Maximum mount height between stove top to hood bottom should be no higher than 31-inch*.•
It is important to install the hood at the proper mounting height. Hoods mounted too low could result in heat •
damage and re hazard; while hoods mounted too high will be hard to reach and will loose its performance
and efciency.
If available, also refer to stove top manufacturer’s height clearance requirements and recommended hood •
mounting height above range.
* Due to different ceiling height congurations, recommended height may not be applicable.
Minimum Duct Size:
Round - 6” minimum•
Rectangular - 3-1/4 x 10” minimum (requires a 6” to 3-1/4x10” adaptor, not supplied)•
Page 6
Duct Run Calculation:
Recommended maximum run
6” or 3-1/4 x 10” duct 50 ft
Vent piece deduction
Each 90º elbow used 9 ft
Each 45º elbow used 5 ft
Each 6” to 3/14 x 10” transition used 7 ft
Side wall cap with damper 0 ft
Roof cap 0 ft
Duct Run Calcuation example:
One roof cap, two 90º elbow, and one 45º elbow used:
0ft + 9ft + 9ft + 5ft = 23ft used.
Deduct 23ft from 50ft, 27ft maximum available for
straight duct run.
To calculate the length of the system you need, deduct the equivalent feet for each vent piece used in the system
from the recommended maximum duct run.
Calculating Vent System Length

Venting Methods
Page 7
This range hood is factory set for venting through the roof or wall. For non-vented (re-circulating) installa-•
tions, see Recirculating (Non-Vented) Kit on Page 11.
Vent work can terminate either through the roof or wall. To vent through a wall, a 90° elbow is needed.•
IMPORTANT:
NEVER exhaust air or terminate duct work into spaces between walls, crawl spaces, ceiling, attics or garages. •
All exhaust must be ducted to the outside.
Use metal/aluminum duct work only. •
Fasten all connections with sheet metal screws and tape all joints with certied Silver Tape or Duct Tape.•
Use caulking to seal exterior wall or roof opening around the cap.•
Ductless Conversion
Option 2:
Side wall cap
Vertical roof venting
Roof cap
Horizontal wall venting
Option 1:
Ductless conversion is intended for applications where an exhaust duct work is not possible to be installed. •
When converted, the hood functions as a purifying hood rather than an exhaust hood. Fumes and exhaust
from cooking is drawn and ltered by a set of charcoal lters. The air is then puried and re-circulated back
within the home.
We recommend to ALWAYS exhaust air outside of the home by employing existing or installing new duct •
work, if possible. Only when the exhaust option is not possible should you recourse to converting the hood
into a purifying unit.
When converted to be a “purifying” unit, a set of charcoal lters and an air-diverter are required in addition to •
its standard aluminum lter set. Available at your local resellers. The standard aluminum lters are intended
to capture residue from cooking, the optional charcoal lters help to purify fumes exhausted from cooking,
and the optional air-diverter redirects ltered clean air back to the house.

Page 8
Electrical Requirements
IMPORTANT: Observe all governing codes and ordinances.
(Please consult with a qualied electrician for 220-Volt 50 Hz voltage)
It is the customer’s responsibility:
To contact a qualied electrical installer.
To assure that the electrical installation is adequate and in conformance with National Electrical Code, ANSI/
NFPA 70 — latest edition*, or CSA Standards C22. 1-94, Canadian Electrical Code, Part 1 and C22. 2 No. 0-M91
- latest edition** and all local codes and ordinances.
If codes permit and a separate ground wire is used, it is recommended that a qualied electrician determine •
that the ground path is adequate.
A 120-volt, 60 Hz, AC-only, fused electrical supply is required on a separate 15-amp circuit, fused on both •
sides of the line.
Do not ground to a gas pipe.•
Do not have a fuse in the neutral or ground circuit.•
RISK OF ELECTRICAL SHOCK. This range hood must be properly grounded. Check with a qualied elec-•
trician if you are not sure whether the range hood is properly grounded.
The range hood should be connected directly to the fused disconnect (or circuit breaker) box through exible •
armored or non-metallic sheathed copper cable. A U.L. - or C.S.A. - listed strain relief must be provided at
each end of the power supply cable. Do not use extension cord or adapter plug with this appliance.
The range hood must be connected with copper wire/plug only.•
Always use plug provided. If not •
possible, connect three wires ac-
cording to its color (black to hot,
white to neutral, and green to
ground) to house wires and cap
with wire connectors:
Wire sizes (copper wire only) and connections must conform with the rating of the appliance as specied on
the model/serial rating label. Wire sizes must conform to the requirements of the National Electrical Code
ANSI/NFPA 70 — latest edition*, or CSA Standards C22. 1-94, Canadian Electrical Code Part 1 and C22.
2 No. 0-M91 - latest edition** and all local codes and ordinances. A U.L. - or C.S.A. - listed conduit con-
nector must be provided at each end of the power supply cable (at the range hood and at the junction box).
Copies of the standards listed may be obtained from:
* National Fire Protection Association ** CSA International
Batterymarch Park 8501 East Pleasant Valley Road
Quincy, Massachusetts 02269 Cleveland, Ohio 44131-5575
Charcoal Filter Installation
White
Green
Black
NOTE: The charcoal lters are preinstalled if you purchased the range hood with re-circulating kit from us.
Remove aluminum lters on hood.1.
Remove the safety lter under the aluminum lter by unscrewing two screws, then position the charcoal lter 2.
and align the screw holes, reinstall and fasten two screws.
Reinstall the aluminum lters back to the hood.3.
Charcoal lters must be replaced after 120 hours of use (or approximately every 2 to 3 months based on the 4.
average of 1 to 2 hours of daily cooking time). Available at your local reseller.

Page 9
Advanced Preparations:
Read the entire installation guide and users manual thoroughly, understand instructions and warnings.1.
Be familiar with the controls of the range hood by reading through 2. Range Hood Operations, Page 13.
Place the range hood on a at, stable surface. Connect the range hood to a designated standard outlet (please 3.
refer the product label for the suitable voltage of this unit) and verify no debris has entered the vent openings,
then turn on the range hood. Verify all operations of the range hood by referring to Range Hood Operations,
Page 13.
Place all supplied parts and required hardware on a at, stable surface and verify the existence of all supplied 4.
parts listed on Page 4.
Carefully remove the white plastic protective coat from the chimney covers and range hood.5.
Preparations:
NOTE: To avoid damage to your hood, prevent debris from entering the vent opening.
Determine and mark the center line on the ceiling where the range hood will be installed. Make sure there is 1.
proper clearance within the ceiling or wall for exhaust vent.
Due to the weight and size of this unit, please make sure that the support system or framework being used is 2.
stable and secure in the ceiling.
Put a thick, protective covering over counter top, cook top or range to protect from damage or dirt. Remove 3.
any hazardous objects around the area when installing.
Mark the locations of the support mounting bracket holes, vent cutout (if used) and power supply cable cutout 4.
on the ceiling. Use drill and saber saw or keyhole saw to cut openings for power supply cable and vent (see
Venting requirements and Electrical requirements, Pages 5-8).
If venting to the outside install vent system (see 5. Venting Methods, Page 7). Use caulking to seal exterior wall
or roof openings.
Disconnect main electrical supply, prepare and run electrical wiring through ceiling. Leave approximately 6.
12” of electrical cord hanging from the ceiling. Do not restore power until wiring is completed.
Disconnect power cord, remove the aluminum lter by pressing on the latch and gently pull the aluminum 7.
lter down.
If charcoal lter is present, unscrew the two screws and remove the lter.8.
Set aside the aluminum lters and charcoal lter until the range hood is properly installed.9.
If the range hood comes with a glass canopy and has not already been mounted to the hood, loosen the four 10.
canopy screws and washers from the hood top, carefully place the canopy on the hood top, and loosely tighten
the four canopy screws along with washers. DO NOT put excessive pressure against the glass.
WARNING
Severe Injury
Rotating fan can cause se-
vere injury. Stay clear of
fan when motor is running.
WARNING
Severe Injury
Hood may have very shape edges. Please wear
protective gloves if it is necessary to remove
any parts for installing, cleaning or servicing.
Preparation
WARNING
Excessive Weight
Require three or more person to move and
install this range hood. Spinal or other bodi-
ly injuries could occur if it is not followed.

Page 10
Install the Duct Set using six 4mm x 16mm Tapping 3.
Screws, then install Aluminum Duct Tube as shown in
Figure 3A and 3B. Proceed to step 6 on Page 12.
Figure 2
Installations (refer to Page 4 for parts):
Due to excessive weight, two or more person is recommended for this step.
Locate an optimal location to place the range hood. Mark the 1.
leveling points for two Body Hooks (Figure 1) on the wall and
drill two holes with diameter not exceeding 5/8”. Insert two
toggle bolts then fasten two 4mm x 16mm Tapping Screws,
reserve approximately 1/8” for the body hooks. Be sure to use appropriate anchors for your wall.
Find an optimal loca-2.
tion for the Chimney
Mounting Bracket.
The chimney mount-
ing bracket must be
placed directly above
and align with the
two body hooks, see
Figure 2. Drill two
more holes with di-
ameter not exceeding
5/8” and insert two
toggle bolts. Secure
the chimney mount-
ing bracket with two
4mm x 16mm Tapping Screws as shown
in Figure 2. Be sure to use appropriate an-
chors for your wall. Use four sets of 5mm
x 16mm Screw with Washer to install the
body hooks onto the hood. Then hang the
hood on the wall and tighten the screws.
CAUTION: MAKE SURE the range hood
is secure before releasing!
Figure 3A
Figure 1
Duct Set
Install the Duct Set
andAluminum duct
on the body of hood. Figure 3B
Installation
If Recirculating (Non-Vented) Kit is purchased, please skip this step and proceed to Page 11.
WARNING
Excessive Weight
Require three or more person to move and
install this range hood. Spinal or other bodi-
ly injuries could occur if it is not followed.

Duct Set
Page 11
Find an optimal location for the Air Diverter. The air diverter4. must be placed directly above and align
with the two body hooks, see Figure 4. Drill four more holes with diameter not exceeding 5/8” and in-
sert four toggle bolts. Secure the air diverter with four 4mm x 16mm Tapping Screws as shown in Fig-
ure 4. Be sure to use appropriate anchors for your wall. Use four sets of 5mm x 16mm Screw with
Washer to install the body hooks onto the hood. Then hang the hood on the wall and tighten the screws.
CAUTION: MAKE SURE the range hood is secure before releasing!
Figure 4
Install Aluminum Duct Tube as shown in Figure 5A. In-5.
stallation of charcoal lter during this step is also recom-
mended, please see Charcoal Filter Installation on Page
8.
Figure 5B
Figure 5A
Air Divertor
Safety Filter
Charcoal
Filter
Installation (Continued)
If Recirculating (Non-Vented) Kit is NOT purchased, please go back to step 2 on Page 10.
WARNING
Excessive Weight
Require three or more person to move and
install this range hood. Spinal or other bodi-
ly injuries could occur if it is not followed.

Page 12
Connect the duct tube to the exterior exhaust system or the optional air diverter. Make sure all joints are secure 6.
and air tight. Use of duct tape is recommended.
Place Upper Chimney and Lower Chimney over the body of the hood as shown in Figure 7A (or Figure 7B of 7.
air diverter is present). Slide up the upper duct cover towards the chimney mounting bracket or the optional
air diverter. Use four 4mm x 10mm Tapping Screws to secure the upper chimney onto the chimney mounting
bracket or the optional air diverter. Finally secure the lower chimney to the hood body by using two 4mm x
10mm Tapping Screws.
Page 12
Figure 7A
Figure 7B Air Divertor
Upper
Chimney
(has vent-
ing holes)
Lower
Chimney
Chimney Mounting Bracket
Upper
Chimney
(has vent-
ing holes)
Lower
Chimney
4 x 10 Screw
4 x 10 Screw
4 x 10 Screw
4 x 10 Screw
Installation (Continued)
WARNING
Excessive Weight
Require three or more person to move and
install this range hood. Spinal or other bodi-
ly injuries could occur if it is not followed.

Page 13
Power Switch
Low Speed
Medium Speed
High Speed
Light Switch
Range Hood Operations & Wiring Diagram
Turn On:
Press the speed control (Low Speed, Medium Speed, High Speed) switch to select the desired level of power. •
Once button is pressed, the previous speed mode will cancel.
Press the Light Switch to power on the lights.•
CAUTION: DO NOT touch the lights until switched OFF and cooled.
Turn Off:
Press the Power Switch to turn off the power.•
Press the Light Switch to power off the lights•
SV168/198 Series Standard Class (3 Speed Mechanical Control)
NOTE: Wiring Diagrams shown above with GU10 light conguration. A transformer is required for MR16 Lights.
SV168/198 Series Standard Class Wiring Diagram

Page 14
This range hood is equipped with a credit card size remote control (approximately 20ft range), three built-in elec-
tronic controls, a powerful centrifugal squirrel cage motor, grease lters and two bright 12V 20W halogen lights.
The three built-in electronic buttons control the power of the Lights, Power-Off Delay and Fan Speeds: Quiet (F1),
Low (F2), Medium (F3) and High (F4). The Power-Off Delay offers up to 99 minutes delay shutoff. The Light Con-
trol operates independently from the Power / Fan Speed Control but can be turned OFF the delay shutoff function.
Turning Fan ON using built-in electronic controls:
Always turn fan ON before cooking to establish air ow and allow fan to run for a few minutes after cooking for
cleaner air in the kitchen.
Press the Power / Fan Speed Control button once to activate the fan at Quite (F1) mode. The Speed / Timer •
Indicator will activate to indicate fan speed.
To change the fan speed, press the Power / Fan Speed Control button. Each press will cycle through Quiet •
(F1), Low (F2), Medium (F3), High (F4) Speed and OFF (00). The Speed / Timer Indicator will change ac-
cordingly.
Turning Fan OFF using built-in electronic controls:
The Power-Off Delay function will turn OFF both fan and lights.
1 to 99 Minute Delay
While the fan is operating, press Power-Off Delay Control button once, the Speed / Timer Indicator will •
display a 15-minute timer then ash for three seconds. While ashing, the timer can be adjusted by 1
minute increments, with the default set at 15 minutes, from as short as 1 minute to as long as 99 minutes.
After the desired setting has been achieved, the Speed / Timer Indicator will return to fan speed mode and
Power-Off Delay Control button will ash until power OFF after a few seconds. Changing speed does not
affect the delay shutoff function.
While the fan is OFF, press Power-Off Delay Control button once will turn ON the fan at Quiet (F1) mode •
with 15 minutes delay shut off activated.
Immediate Power-off
While the fan is operating, press the Power / Fan Speed • Control button one to four times until Speed /
Timer Indicator shows “00” to turn OFF the fan immediately. NOTE: Power / Fan Speed Control will
cycle through Quiet (F1), Low (F2), Medium (F3), High (F4) Speed and OFF (00).
Light Control using built-in electronic controls:
Light Control button operates independently from the Power / Fan Speed but can be turned OFF by the Power-Off
Delay function. Activating the delay function will turn halogen lights OFF.
CAUTION: DO NOT touch the lights until switched OFF and cooled.
While the halogen lights are OFF, press the Light Control button once to turn halogen lights ON. Light •
Control button will light up.
Press the Light Control button again to turn OFF the lights.•
Range Hood Operations & Wiring Diagram (Continued)
Remote Control Sensor
Power-Off Delay Control
Speed / Timer Indicator Light Control
Power / Fan Speed Control
SV168/198 Series “R” Class (4 Speed Electronic Control w/ Remote)

Page 15
The credit card size remote control controls the power of the Lights , Power-Off Delay , Power (ON/OFF)
and Fan Speeds: Quiet (F1), Low (F2), Medium (F3) and High (F4). The Power-Off Delay offers up to 99
minutes delay shutoff. The Light Control operates independently from the Power / Fan Speed Control but can be
turned OFF the delay shutoff function.
Turning Fan ON using remote control:
Always turn fan ON before cooking to establish air ow and allow fan to run for a few minutes after cooking for
cleaner air in the kitchen.
Press the • button once to activate the fan at Quite (F1) mode, once again to turn OFF the fan. The Speed /
Timer Indicator will activate to indicate fan speed.
While the fan is operating at Quite (F1) mode, press the • button to increase fan speed. Each press will go through
Low (F2), Medium (F3), High (F4) Speed, then OFF (00). The Speed / Timer Indicator will change accordingly.
Press the • button once to activate the fan at Medium (F3) Speed. Each press will cycle throught Medium
(F3), High (F4) Speed and OFF (00).
Press the • button once to activate the fan at High (F4) Speed, once again to turn OFF the fan.
Turning Fan OFF using remote control:
The Power-Off Delay function will turn OFF both fan and lights.
1 to 99 Minute Delay
While the fan is operating, press the • button once, the Speed / Timer Indicator will display a 15-minute
timer then ash for three seconds. While ashing, the timer can be adjusted by 1 minute increments by
pressing button and 1 minute decrements by pressing button, with the default set at 15 minutes,
from as short as 1 minute to as long as 99 minutes. After the desired setting has been achieved, the Speed
/ Timer Indicator will return to fan speed mode and Power-Off Delay Control button will ash until power
OFF after a few seconds. Changing speed does not affect the delay shutoff function.
While the fan is OFF, press • button once will turn ON the fan at Quiet (F1) mode with 15 minutes delay
shut off activated.
Immediate Power-off
While the fan is operating, press the • button once to turn OFF the fan immediately.
Light Control using remote control:
button operates independently from the , , buttons but can be turned OFF by the and func-
tion. Activating the delay function will turn halogen lights OFF.
CAUTION: DO NOT touch the lights until switched OFF and cooled.
While the halogen lights are OFF, press the • button once to turn halogen lights ON. Light Control but-
ton will light up.
Press the • button again to turn OFF the lights.
Remote Control Sensor
Power-Off Delay Control
Speed / Timer Indicator Light Control
Power / Fan Speed Control
Range Hood Operations & Wiring Diagram (Continued)
SV168/198 Series “R” Class (4 Speed Electronic Control w/ Remote)

Page 16
Range Hood Operations & Wiring Diagram (Continued)
SV168/198 Series “R” Class Wiring Diagram
NOTE: Wiring Diagrams shown above with GU10 light conguration. A transformer is required for MR16 Lights.

Page 17
This range hood is designed to remove smoke, cooking vapors and odors from the cook top area. For best results,
start the range hood before cooking and allow it to operate several minutes after the cooking is completed to clear
all smoke and odors from the kitchen.
Button functions:•
Power: Power ON/OFF the range hood and activate power-off delay timer.•
Decrease Value: Blower (motor) speed decrease, timer value decrease, and enter timer mode.•
Increase Value: Blower (motor) speed increase, timer value increase, and cleaning reminder reset.•
Blower Speed Indicator: Shows current blower (motor) speed (1-4 or 1-6).•
Light: Turns ON/OFF and dim halogen lights.•
Power-Off Delay Digital Timer: Indicates the length of time left for delay off function.•
Controls:•
Automatic cleaning reminder:•
This range hood is equipped with a cleaning reminder that will activate following 30 hours of use. •
When blower (motor) starts to rotate, cumulative running time reached 30 hours then the Cleaning
Reminder Indicator “C” ashes and reminds user to clean the aluminum lter.
After cleaning the lter and when the motor is not in use, press and hold • Increase Value button over 3
seconds to reset the timer. Please note that turning off the system will not reset the Power-On Elapsed
Timer.
Adjusting the blower (motor) speed:•
Press • Power button once to turn on the system. The Blower Speed Indicator shows the blower (mo-
tor) speed level. Decrease Value button will decrease the speed of the blower (motor) from 4 or 6 to 1
(strongest to quietest). Increase Value button will increase the speed of the blower (motor) from 1 to
4 or 6 (quietest to strongest).
Press • Power button once to turn off the system.
Note: The system saves user congurations, settings such as light, timer and blower (motor) speed will re-
main the same the next time it is turned on.
Range Hood Operations & Wiring Diagram (Continued)
SV168/198 Series “E” Class (4 or 6 Speed Electronic Touch Control)
Power
Power-Off Delay
Decrease Value
Light
Increase Value
Blower Speed Indicator
Power-Off Delay Digital Timer
Cleaning Reminder Indicator

Page 18
Controls:•
Adjusting the timer function:•
While the blower (motor) is not running, press and hold • Decrease Value button over 3 seconds to
enter timer mode. Adjust to desired period of delay off timer by pressing Increase Value or Decrease
Value button (minimum 1 minute to maximum 9 minutes). This setting will be saved immediately.
Activating the timer function:•
While the blower (motor) is running, press and hold • Power button for over 3 seconds to activate
delay off timer. Power-Off Delay Digital Timer begin to countdown, when it reaches zero, the blower
(motor) will shut down.
Adjusting the light:•
Press • Light button once to turn on the lights, and once again to turn off the lights.
While the lights are off, press and hold • Light button for over 3 seconds to dim the lights from high to
low. Level of brightness will be stored in system’s memory.
CAUTION: DO NOT touch the lights until switched OFF and cooled.
Note: Light settings are independent from other settings (including power-off delay) and lights has to be
manually turned on or off.
Note: The system saves user congurations, settings such as light, timer and blower (motor) speed will re-
main the same the next time it is turned on.
Range Hood Operations & Wiring Diagram (Continued)
SV168/198 Series “E” Class (4 or 6 Speed Electronic Touch Control)
Power
Power-Off Delay
Decrease Value
Light
Increase Value
Blower Speed Indicator
Power-Off Delay Digital Timer
Cleaning Reminder Indicator
